Scheme 1
Scheme 1: WIPER/WASHER SYSTEM LOCATION INDEX
Scheme 2
Scheme 2: WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
- Adjust the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE ADJUSTMENT» ).
Scheme 3
Scheme 3: Windshield Wiper Arm Installation Note
- Clean the windshield wiper arm connector shafts using a wire brush before installing the windshield wiper arms.
Scheme 4
Scheme 4: WINDSHIELD WIPER ARM AND BLADE ADJUSTMENT
- Operate the windshield wipers, and then turn off the windshield wiper motor to set the wipers in the park position.
- Slide the serrated connecting part and adjust the windshield wiper arm and blade so that its end is aligned with the hollowed mark in the ceramic coating. NOTE: If the hollowed mark in the ceramic coating cannot be located, measure the distance from the cowl grille end line, and adjust the windshield wiper arm and blade.
Scheme 5
Scheme 5: WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ).
- Remove the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/exteriorinterior-trim/#exterior-trim) ).
- Remove the cowl panel. (See «COWL PANEL REMOVAL/INSTALLATION» ).
- Remove the bolts.
- Move the windshield wiper motor in the direction of the arrow, remove the securing dowel from the bracket, then remove the windshield wiper motor.
- Disconnect the windshield wiper motor connector.
- Install in the reverse order of removal.
Scheme 6
Scheme 6: WINDSHIELD WIPER MOTOR DISASSEMBLY/ASSEMBLY
- Disassemble in the order indicated in the table.
- Assemble in the reverse order of disassembly.
Scheme 7
Scheme 7: Ball Joint Assembly Note
- Use a clean rag to protect the link, and squeeze using pliers.
Scheme 8
Scheme 8: Windshield Wiper Motor Assembly Note
- Connect the windshield wiper motor to the vehicle wiring harness connector, operate the windshield wipers, and then stop them at the auto-stop position.
- Adjust the motor crank, wiper link No.1, and wiper link No.2 so that they are parallel as shown in the figure.
- Assemble the windshield wiper motor.
Scheme 9
Scheme 9: WINDSHIELD WIPER MOTOR INSPECTION
- Disconnect the windshield wiper motor connector.
- Connect battery positive voltage to windshield wiper motor terminal A or B, and ground to terminal D, then verify that the windshield wipers operate as shown in the table. If the windshield wipers do not operate as indicated in the table, replace the windshield wiper motor. WINDSHIELD WIPER MOTOR TERMINALS AND OPERATION CONDITION REFERENCE Terminal connected to battery positive voltage Operation condition A LO B HI
- Disconnect battery positive voltage from the motor terminal A while the wipers are operating.
- Verify that the wipers do not stop in the park position.
- Short between the motor terminals A and C, and connect battery positive voltage to the motor terminal E
- Verify that the wipers operate at low speed again, then stop in the park position. If there is any malfunction, replace the windshield wiper motor.
Scheme 10
Scheme 10: WASHER TANK REMOVAL/INSTALLATION
Scheme 11
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION» ).
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Scheme 12
Scheme 12: WINDSHIELD WASHER MOTOR REMOVAL/INSTALLATION
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the washer tank. (See «WASHER TANK REMOVAL/INSTALLATION» ).
- Remove the windshield washer motor, then remove the grommet.
- Install in the reverse order of removal.
Scheme 13
Scheme 13: WINDSHIELD WASHER MOTOR INSPECTION
- Connect battery positive voltage to windshield washer motor terminal A and terminal B to ground.
- Verify that the windshield washer motor operates normally. If there is any malfunction, replace the windshield washer motor.
Scheme 14
Scheme 14: WINDSHIELD WASHER NOZZLE REMOVAL/INSTALLATION
- Remove the hood insulator.
- Remove the windshield washer hose from the windshield washer nozzle.
- Squeeze the tabs of the windshield washer nozzle.
- Pull the windshield washer nozzle out to remove it.
- Install in the reverse order of removal.
Scheme 15
Scheme 15: WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION
- Remove the hood insulator.
- Slightly bend back the mudguard (RH).
- Disconnect windshield washer hose A from the windshield washer motor.
- Remove front washer hose A from clips A.
- Detach clips B.
- Disconnect windshield washer hose B from the washer nozzle.
- Disconnect windshield washer hose C from the washer nozzle.
- Disconnect joint pipe A and remove windshield washer hose A, B and C.
- Install in the reverse order of removal.
Scheme 16
Scheme 16: WASHER FLUID-LEVEL SENSOR REMOVAL/INSTALLATION
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the washer tank. (See «WASHER TANK REMOVAL/INSTALLATION» ).
- Disconnect the connector.
- Remove the washer fluid-level sensor.
- Remove the grommet.
- Install in the reverse order of removal.
Scheme 17
Scheme 17: WASHER FLUID-LEVEL SENSOR INSPECTION
Scheme 18
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Inspect for continuity between the washer fluid-level sensor terminals using an ohmmeter. If not as specified, replace the washer fluid-level sensor.
Scheme 19
Scheme 19: WIPER AND WASHER SWITCH REMOVAL/INSTALLATION
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the meter hood. (See «METER HOOD REMOVAL/INSTALLATION» ).
- Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION» ).
- Disconnect the wiper and washer switch connector.
- Remove the screws, then remove the wiper and washer switch.
- Install in the reverse order of removal.
Scheme 20
Scheme 20: WINDSHIELD WIPER AND WASHER SWITCH INSPECTION
Scheme 21
- Verify that the continuity between the windshield wiper and washer switch is as indicated in the table. If not as indicated in the table, replace the wiper and washer switch.
Scheme 22
Scheme 22: VEHICLES WITHOUT THE AUTO WIPER SYSTEM
Scheme 23
Scheme 23: VEHICLES WITH THE AUTO WIPER SYSTEM
Scheme 24
Scheme 25
Scheme 25: REAR WIPER AND WASHER SWITCH INSPECTION
Scheme 26
- Verify that the continuity between the rear wiper and washer switch terminals is as indicated in the table. If not as indicated in the table, replace the wiper and washer switch.
Scheme 27
Scheme 27: REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION
- Remove in the order indicated in the table. '
- Install in the reverse order of removal.
- Adjust the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE ADJUSTMENT» ).
Scheme 28
Scheme 28: Rear Wiper Arm Installation Note
- Clean the rear wiper arm connector shaft using a wire brush before installing the rear wiper arm.
Scheme 29
Scheme 29: REAR WIPER ARM AND BLADE ADJUSTMENT
- Turn off the rear wiper switch while operating the rear wiper motor, and then stop the rear wiper at the auto-stop position.
- Set the rear wiper arm onto the ceramic end line.
Scheme 30
Scheme 30: REAR WIPER MOTOR REMOVAL/INSTALLATION
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION» ).
- Remove the liftgate trim. (See «LIFTGATE TRIM REMOVAL/INSTALLATION» ).
- Disconnect the rear wiper motor connector.
- Remove the bolts, then remove the rear wiper motor.
- Remove the outer bushing.
- Install in the reverse order of removal.
Scheme 31
Scheme 31: REAR WIPER MOTOR INSPECTION
- Connect battery positive voltage to the rear wiper motor terminal B, and ground the rear wiper motor terminal A.
- Verify that the rear wiper motor operates. If there is any malfunction, replace the rear wiper motor.
Scheme 32
Scheme 32: REAR WASHER MOTOR REMOVAL/INSTALLATION
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the washer tank. (See «WASHER TANK REMOVAL/INSTALLATION» ).
- Remove the rear washer motor, then remove the grommet.
- Install in the reverse order of removal.
Scheme 33
Scheme 33: REAR WASHER MOTOR INSPECTION
- Connect battery positive voltage to rear washer motor terminal A and terminal B to ground.
- Verify that the rear washer motor operates normally. If there is any malfunction, replace the rear washer motor.
Scheme 34
Scheme 34: REAR WASHER NOZZLE REMOVAL/INSTALLATION
- Remove the high-mount brake light cover.
- Press the tabs and remove the rear washer nozzle.
- Install in the reverse order of removal.
- Adjust the rear washer nozzle. (See «REAR WASHER NOZZLE ADJUSTMENT» ).
Scheme 35
Scheme 35: REAR WASHER NOZZLE ADJUSTMENT
- Insert a needle or an equivalent tool into the spray hole of the rear washer nozzle and adjust the nozzle direction as shown.
Scheme 36
Scheme 36: REAR WASHER HOSE REMOVAL/INSTALLATION
Scheme 37
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
- Disconnect the negative battery cable.
- Remove the mudguard (RH).
- Disconnect rear washer hose A from the washer tank.
- Remove rear washer hose A from clips A.
- Disconnect joint pipe A and remove rear washer hose A.
- Remove the following parts: Front door (See «FRONT DOOR REMOVAL/INSTALLATION» ). Sail garnish (See «SAIL GARNISH REMOVAL»(/mazda/5/i-2005-2007/remont/exteriorinterior-trim/#exterior-trim) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION» ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION» ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION» ). Selector lever component (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/automatic-trans/#automatic-transaxle-shift-mechanism) ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ). Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]» ). (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]» ). (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]» ). Rear heat duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION» ). Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ). Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/exteriorinterior-trim/#exterior-trim) ). Dashboard (See «DASHBOARD REMOVAL/INSTALLATION» ).
- Remove rear washer hose B from clips A.
- Disconnect joint pipe B and remove rear washer hose B.
- Detach clips B.
- Remove the following parts: Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION» ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION» ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION» ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION» ). Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION» ). Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION» ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION» ). Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION» ). Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION» ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION» ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION» ). Second-row seat belt upper anchor installation bolt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION» ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION» ). Map light (See «MAP LIGHT REMOVAL/INSTALLATION» ). Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION» ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION» ).
- Disconnect joint pipe C.
- Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION» ).
- Cut the urethane of the headliner and remove the tape and rear washer hose C. NOTE: After installing the rear washer hose, reinforce the urethane that was cut when removing.
- Remove rear washer hose D from the rear washer nozzle.
- Install in the reverse order of removal.
