Interior Trim: Removal & Installation Mazda 5 I

Exterior/interior Trim 50 illustrations ~3258 words

Dashboard Removal Note

WARNINGRemoving the dashboard without supporting it can be dangerous. The dashboard may fall and injure you. Always perform the following procedure with at least another person.
  1. Take the dashboard out through the opened front driver-side door.

Scheme 7

Scheme 7: DASHBOARD DISASSEMBLY/ASSEMBLY
Scheme 7: DASHBOARD DISASSEMBLY/ASSEMBLY
  1. Remove the following parts: LCD unit (vehicles with car-navigation system) (See «LCD UNIT REMOVAL/INSTALLATION»(ref-244348-S02908671002006092100000) ). Dashboard center panel (vehicles without car-navigation system) (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-244361-S23199388542006092100000) ). Car-navigation unit (vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-244348-S37944843702006092100000) ). Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244347-S08010337442006092100000) ). Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-244361-S41958864862006092100000) ).
  2. Disassemble in the order indicated in the table.
  3. Assemble in the reverse order of disassembly.

Scheme 8

Scheme 8: Dashboard Member Removal Note
Scheme 8: Dashboard Member Removal Note
  1. Remove the screw.
  2. Partially open the center duct in the direction shown by the arrow, and remove the dashboard member.

Scheme 9

Scheme 9: Dashboard Member Installation Note
Scheme 9: Dashboard Member Installation Note
  1. Install the dashboard member to the dashboard face while holding the dashboard member with the center duct.
  2. Install the screws.

Scheme 10

Scheme 10: COLUMN COVER REMOVAL/INSTALLATION
Scheme 10: COLUMN COVER REMOVAL/INSTALLATION
  1. Remove the screws.
  2. Pull the upper column cover upward and detach the upper column cover from the lower column cover.
  3. Remove the lower column cover.
  4. Remove the ignition key illumination.
  5. Install in the reverse order of removal. NOTE: The upper column cover is integrated with the meter hood.

Scheme 11

Scheme 11: METER HOOD REMOVAL/INSTALLATION
Scheme 11: METER HOOD REMOVAL/INSTALLATION
  1. Pull the upper column cover upward and detach the upper column cover from the lower column cover.
  2. Pull the meter hood and remove clips A and the pins.
  3. Remove the meter hood.
  4. Install in the reverse order of removal.

Scheme 12

Scheme 12: GLOVE COMPARTMENT REMOVAL/INSTALLATION
Scheme 12: GLOVE COMPARTMENT REMOVAL/INSTALLATION

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ).
  2. Partially peel back the seaming welt.
  3. Remove the side panel, (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-244361-S16170239572006092100000) ).
  4. Press the stay damper in the direction shown by the arrow and detach it from the glove compartment lid.
  5. While pressing the stopper in the direction shown by the arrow, detach the stopper from the glove compartment lid.
  6. Pull the glove compartment lid outward while lowering it to the position shown in the figure, and then detach the clip and remove the glove compartment lid.
  7. Remove the screws.
  8. Pull the glove compartment outward and detach clips A.
  9. Glove compartment light bulb, (vehicles with glove compartment light bulb) (See09-18-17 GLOVE COMPARTMENT LIGHT BULB REMOVAL/INSTALLATION).
  10. Remove the glove compartment.
  11. Install in the reverse order of removal.

Scheme 15

Scheme 15: LOWER PANEL REMOVAL/INSTALLATION
Scheme 15: LOWER PANEL REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Partially peel back the seaming welt.
  4. Remove the following parts: Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-244349-S20261737812006092100000) ).
  5. Remove the screw.
  6. Pull the lower panel outward and detach clips A.
  7. Remove the lower panel.
  8. Install in the reverse order of removal.

VENTILATOR GRILLE REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE CAUTIONS ). (See AIR BAG SYSTEM SERVICE CAUTIONS ).

Scheme 16

Scheme 16: Driver's Side
Scheme 16: Driver's Side

Scheme 17

Scheme 17
Scheme 17
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-244361-S09707910472006092100000) ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-244361-S34979483872006092100000) ). Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-244361-S33738517862006092100000) ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244347-S16479481112006092100000) ). Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-244338-S20307144292006092100000) ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-244393-S21979791272006092100000) ). Duct Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-244338-S20307144292006092100000) ).
  4. Remove the screws at A in the figure.
  5. Remove the screw.
  6. Pull the dashboard face outward to secure a space.
  7. Pull the ventilator grille out.
  8. Install in the reverse order of removal.

Scheme 18

Scheme 18: Passenger's Side
Scheme 18: Passenger's Side
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (passenger's side). (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-244361-S16170239572006092100000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-244361-S15926577782006092100000) ). Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ). LCD unit (vehicles with car-navigation system) (See «LCD UNIT REMOVAL/INSTALLATION»(ref-244348-S02908671002006092100000) ). Dashboard center panel (vehicles without car-navigation system) (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-244361-S23199388542006092100000) ). Duct Car-navigation unit (vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-244348-S37944843702006092100000) ). Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244347-S08010337442006092100000) ). Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-244361-S41958864862006092100000) ).
  4. Remove the screws at A in the figure.
  5. Remove the bolt at B in the figure.
  6. Remove the screw.
  7. Pull the dashboard face outward to secure a space.
  8. Pull the ventilator grille out.
  9. Install in the reverse order of removal.

Scheme 19

Scheme 19: Center
Scheme 19: Center

Scheme 20

Scheme 20
Scheme 20
  1. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ). LCD unit (vehicles with car-navigation system) (See «LCD UNIT REMOVAL/INSTALLATION»(ref-244348-S02908671002006092100000) ). Dashboard center panel (vehicles without car-navigation system) (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-244361-S23199388542006092100000) ).
  2. Remove the screw.
  3. Pull the center ventilator grille outward and detach clips A.
  4. Remove the center ventilator grille.
  5. Install in the reverse order of removal.

Scheme 21

Scheme 21: SIDE WALL REMOVAL/INSTALLATION
Scheme 21: SIDE WALL REMOVAL/INSTALLATION
  1. Detach clips A and tab B in the order of top to bottom.
  2. Remove the side wall by pulling it outward.
  3. Install in the reverse order of removal.

Scheme 22

Scheme 22: Driver's Side
Scheme 22: Driver's Side
  1. Remove the following parts: Front scuff plate inner (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-244349-S20261737812006092100000) ). Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-244361-S09707910472006092100000) ).
  2. Remove the screws.
  3. Remove the side panel from the lower panel.
  4. Install in the reverse order of removal.

Scheme 23

Scheme 23: Passenger's Side
Scheme 23: Passenger's Side
  1. Pull the side panel outward and detach clips A.
  2. Pull the side panel outward and detach tabs B from the dashboard.
  3. Remove the side panel.
  4. Install in the reverse order of removal.

Scheme 24

Scheme 24: INNER GARNISH REMOVAL/INSTALLATION
Scheme 24: INNER GARNISH REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable. (Vehicles with front tweeter)
  3. Pull the inner garnish outward and detach clips A.
  4. Disconnect the front tweeter connector. (Vehicles with front tweeter)
  5. Detach tab B and remove the inner garnish.
  6. Install in the reverse order of removal.

Scheme 25

Scheme 25: DASHBOARD CENTER PANEL REMOVAL/INSTALLATION
Scheme 25: DASHBOARD CENTER PANEL REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ).
  4. Remove the screws.
  5. Pull the dashboard center panel outward and detach clips A.
  6. Disconnect the hazard warning switch connector and information display connector.
  7. Remove the dashboard center panel.
  8. Install in the reverse order of removal.

DASHBOARD GARNISH REMOVAL/INSTALLATION

WARNINGHandling the air bag module improperly can accidentally operate (deploy) the air bag module, which may seriously injure you. Read the service warnings and cautions before handling the air bag module. (See AIR BAG SYSTEM SERVICE WARNINGS ). (See AIR BAG SYSTEM SERVICE CAUTIONS ).

Scheme 26

Scheme 26
Scheme 26
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable and wait 1 min or more.
  3. Remove the following parts: Front scuff plate inner (passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-244361-S16170239572006092100000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-244361-S15926577782006092100000) ). Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244348-S26058616022006092100000) ). LCD unit (vehicles with car-navigation system) (See «LCD UNIT REMOVAL/INSTALLATION»(ref-244348-S02908671002006092100000) ). Dashboard center panel (vehicles without car-navigation system) (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-244361-S23199388542006092100000) ). Car-navigation unit (vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-244348-S37944843702006092100000) ). Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-244347-S08010337442006092100000) ).
  4. Pull the dashboard garnish outward and detach clips A.
  5. Remove the PAD indicator, (vehicles with PAD switch) (See08-10-13 PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR REMOVAL/INSTALLATION).
  6. Remove the dashboard garnish.
  7. Install in the reverse order of removal.

Scheme 27

Scheme 27: FRONT CONSOLE REMOVAL/INSTALLATION
Scheme 27: FRONT CONSOLE REMOVAL/INSTALLATION

Scheme 28

Scheme 28
Scheme 28
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ).
  4. Remove the selector lever knob (ATX), shift lever knob (MTX).
  5. Pull the indicator panel (ATX), boot panel (MTX) upward and detach clips A.
  6. Disconnect the car-navigation control switch connector. (Vehicles with car-navigation system)
  7. Remove the indicator panel.
  8. Remove the screws.
  9. Pull the front console outward and detach clips A and tabs B.
  10. Disconnect the cigarette lighter connector.
  11. Remove the front console.
  12. Install in the reverse order of removal.

Scheme 29

Scheme 29: CENTER CONSOLE REMOVAL/INSTALLATION
Scheme 29: CENTER CONSOLE REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the front cup holder. (See «CENTER CONSOLE DISASSEMBLY/ASSEMBLY»(ref-244361-S25940292032006092100000) ).
  4. Remove the screws.
  5. Remove the center console.
  6. Install in the reverse order of removal.

Scheme 30

Scheme 30: CENTER CONSOLE DISASSEMBLY/ASSEMBLY
Scheme 30: CENTER CONSOLE DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 31

Scheme 31: FRONT SIDE TRIM REMOVAL/INSTALLATION
Scheme 31: FRONT SIDE TRIM REMOVAL/INSTALLATION
  1. Remove the front scuff plate inner. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ).
  2. Remove the fastener.
  3. Pull the front side trim in the direction shown by the arrow, then detach clip A and locator pin B.
  4. Install in the reverse order of removal.

Scheme 32

Scheme 32: A-PILLAR TRIM REMOVAL/INSTALLATION
Scheme 32: A-PILLAR TRIM REMOVAL/INSTALLATION

Scheme 33

Scheme 33
Scheme 33
  1. Partially peel back the seaming welt.
  2. Remove clips A using a fastener remover.
  3. Pull the A-pillar trim outward and remove clip B from the grommet (1).
  4. Slide the A-pillar trim upward and remove clip B from the A-pillar trim (2).
  5. Pull clip B out and rotate it 45° .
  6. Pull clip B and remove it from the grommet.
  7. Install clip B to the A-pillar trim.
  8. Install in the reverse order of removal.

Scheme 34

Scheme 34: B-PILLAR LOWER TRIM REMOVAL/INSTALLATION
Scheme 34: B-PILLAR LOWER TRIM REMOVAL/INSTALLATION
  1. Remove the front scuff plate inner. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ).
  2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ).
  3. Partially peel back the seaming welt.
  4. Remove one side of the B-pillar lower trim by pulling A part of the B-pillar lower trim.
  5. Pull the B-pillar lower trim outward and detach clip C and locator pin B.
  6. Remove the B-pillar lower trim.
  7. Install in the reverse order of removal.

Scheme 35

Scheme 35: B-PILLAR UPPER TRIM REMOVAL/INSTALLATION
Scheme 35: B-PILLAR UPPER TRIM REMOVAL/INSTALLATION
  1. Remove the following parts: Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S39759204652006092100000) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244361-S17191375542006092100000) ).
  2. Partially peel back the seaming welt.
  3. Pull the B-pillar upper trim outward and detach clips A and locator pin B.
  4. Detach the tab from the body and remove the B-pillar upper trim.
  5. Install in the reverse order of removal.

Scheme 36

Scheme 36: C-PILLAR TRIM REMOVAL/INSTALLATION
Scheme 36: C-PILLAR TRIM REMOVAL/INSTALLATION
  1. Remove the following parts: Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ). Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION»(ref-244361-S12459088702006092100000) ). Second-row seat belt upper anchor installation bolt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S12386615082006092100000) ).
  2. Partially peel back the seaming welt.
  3. Remove the fastener.
  4. Remove clips A, and pins B using a fastener remover.
  5. Remove the belt bezel, and remove the third-row seat belt from the C-pillar trim.
  6. Slide the C-pillar trim to the vehicle front and remove clips C from the C-pillar trim.
  7. Remove the C-pillar trim.
  8. Remove clips C from the body, then install it to the C-pillar trim.
  9. Install in the reverse order of removal.

Scheme 37

Scheme 37: SIDE DOOR GARNISH REMOVAL/INSTALLATION
Scheme 37: SIDE DOOR GARNISH REMOVAL/INSTALLATION
  1. Pull the side door garnish outward and detach clips A and pins B.
  2. Remove one side of the side door garnish by pulling C part of the side door garnish.
  3. Pull the side door garnish outward and remove it.
  4. Install in the reverse order of removal.

Scheme 38

Scheme 38: FRONT DOOR TRIM REMOVAL/INSTALLATION
Scheme 38: FRONT DOOR TRIM REMOVAL/INSTALLATION

Scheme 39

Scheme 39
Scheme 39
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Open the cap using a small flathead screwdriver and remove the screw.
  4. Remove the inner handle cover.
  5. Disconnect the door lock switch connector.
  6. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-244361-S41335276262006092100000) ).
  7. Remove the switch panel. (See «POWER WINDOW MAIN SWITCH REMOVAL/INSTALLATION»(ref-244409-S38490763792006092100000) ). (See «POWER WINDOW SUBSWITCH REMOVAL/INSTALLATION»(ref-244409-S40861683612006092100000) ).
  8. Detach clips A from the front door using a fastener remover.
  9. Pull the front door trim upward and detach tabs B from the front door.
  10. Remove the front door trim.
  11. Install in the reverse order of removal.

Scheme 40

Scheme 40: SLIDING DOOR TRIM REMOVAL/INSTALLATION
Scheme 40: SLIDING DOOR TRIM REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the rear side trim. (See «REAR SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S00748710892006092100000) ).
  4. Disconnect the power window subswitch connector.
  5. Remove the side door garnish. (See «SIDE DOOR GARNISH REMOVAL/INSTALLATION»(ref-244361-S21141517232006092100000) ).
  6. Remove the screws.
  7. Remove clips A from the sliding door using a fastener remover.
  8. Pull the sliding door trim upward and detach tabs B from the sliding door.
  9. Remove the sliding door trim.
  10. Install in the reverse order of removal.

Scheme 41

Scheme 41: REAR SIDE TRIM REMOVAL/INSTALLATION
Scheme 41: REAR SIDE TRIM REMOVAL/INSTALLATION
  1. Pull the rear side trim outward and detach clips A and B, pin C, and tabs D.
  2. Disconnect the power window subswitch connector.
  3. Remove the rear side trim.
  4. Install in the reverse order of removal.

Scheme 42

Scheme 42: Front Scuff Plate Inner
Scheme 42: Front Scuff Plate Inner
  1. Pull the front scuff plate inner upward while detaching tabs A, detach clips B, pins C and D from the body, and then remove the front scuff plate inner.
  2. Install in the reverse order of removal.

Scheme 43

Scheme 43: Front Scuff Plate Outer
Scheme 43: Front Scuff Plate Outer
  1. Pull the front scuff plate outer upward, detach clips A, pins B and C from the body, and then remove the front scuff plate outer.
  2. Install in the reverse order of removal.

Scheme 44

Scheme 44: REAR SCUFF PLATE REMOVAL/INSTALLATION
Scheme 44: REAR SCUFF PLATE REMOVAL/INSTALLATION
  1. Pull the rear scuff plate upward while detaching tabs A, detach clips B and C, and pin D and E from the body, and then remove the rear scuff plate.
  2. Install in the reverse order of removal.

Scheme 45

Scheme 45: TRUNK SIDE TRIM REMOVAL/INSTALLATION
Scheme 45: TRUNK SIDE TRIM REMOVAL/INSTALLATION
  1. Remove the following parts: Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ).
  2. Remove the screws and the fasteners.
  3. Remove the bolt, then remove the cargo net hook.
  4. Pull the trunk side trim outward and detach clips A and tabs B.
  5. Disconnect the accessory socket connector.
  6. Remove the trunk side trim.
  7. Install in the reverse order of removal.

Scheme 46

Scheme 46: TRUNK END TRIM REMOVAL/INSTALLATION
Scheme 46: TRUNK END TRIM REMOVAL/INSTALLATION
  1. Remove the sub-trunk.
  2. Remove the fastener.
  3. Pull the trunk end trim upward, then detach clips A, pins B, and tabs C.
  4. Remove the trunk end trim.
  5. Install in the reverse order of removal.

Scheme 47

Scheme 47: REAR HEADER TRIM REMOVAL/INSTALLATION
Scheme 47: REAR HEADER TRIM REMOVAL/INSTALLATION
  1. Pull the rear header trim and detach clips A and B, pin C, and tabs D.
  2. Remove the rear header trim.
  3. Install in the reverse order of removal.

Scheme 48

Scheme 48: REAR PACKAGE TRAY LID REMOVAL/INSTALLATION
Scheme 48: REAR PACKAGE TRAY LID REMOVAL/INSTALLATION
  1. Detach clips A.
  2. Remove the rear package tray lid.
  3. Install in the reverse order of removal.

Scheme 49

Scheme 49: LIFTGATE TRIM REMOVAL/INSTALLATION
Scheme 49: LIFTGATE TRIM REMOVAL/INSTALLATION
  1. Detach tabs A.
  2. Detach tabs B.
  3. Pull the liftgate trim in the direction shown by the arrow and detach tabs C.
  4. Remove the liftgate trim.
  5. Install in the reverse order of removal.

Scheme 50

Scheme 50: SUNVISOR REMOVAL/INSTALLATION
Scheme 50: SUNVISOR REMOVAL/INSTALLATION

Scheme 51

Scheme 51
Scheme 51
  1. Remove the screw.
  2. Unhook and remove the sunvisor.
  3. Press the center adaptor tabs as shown in the figure using two tape-wrapped flathead screwdrivers, and remove the center adaptor.
  4. Install in the reverse order of removal.

Scheme 52

Scheme 52: ASSIST HANDLE REMOVAL/INSTALLATION
Scheme 52: ASSIST HANDLE REMOVAL/INSTALLATION

Scheme 53

Scheme 53
Scheme 53
  1. Insert a flathead screwdriver into the assist handle notch and remove the assist handle covers.
  2. Pull the assist handle outward and remove it.
  3. Install in the reverse order of removal.

Scheme 54

Scheme 54: HEADLINER REMOVAL/INSTALLATION
Scheme 54: HEADLINER REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Partially peel back the seaming welt.
  4. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244361-S07896560402006092100000) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244361-S17191375542006092100000) ). Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S39759204652006092100000) ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-244361-S06495024552006092100000) ). Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION»(ref-244361-S12459088702006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ). Second-row seat belt upper anchor installation bolt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S12386615082006092100000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244361-S32342025012006092100000) ). Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-244399-S06289737222006092100000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-244361-S30917626052006092100000) ). Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-244361-S30518920232006092100000) ).
  5. Disconnect the roof wiring harness connector and detach the roof wiring harness connector clip from the body.
  6. Disconnect the rear washer hose.
  7. Disconnect the antenna feeder.
  8. Remove the sunroof seaming welt, (vehicles with sunroof)
  9. Remove the fasteners.
  10. Take the headliner out from the opened liftgate.
  11. Install in the reverse order of removal.

Scheme 55

Scheme 55: SHOCK ABSORBING PAD REMOVAL/INSTALLATION
Scheme 55: SHOCK ABSORBING PAD REMOVAL/INSTALLATION
  1. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244361-S07896560402006092100000) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244361-S17191375542006092100000) ). Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S39759204652006092100000) ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-244361-S06495024552006092100000) ). Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Rear header trim (See «REAR HEADER TRIM REMOVAL/INSTALLATION»(ref-244361-S12459088702006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ). Second-row seat belt upper anchor installation bolt (See «SECOND-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S12386615082006092100000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-244361-S32342025012006092100000) ). Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-244399-S06289737222006092100000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-244361-S30917626052006092100000) ). Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-244361-S30518920232006092100000) ). Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-244361-S18152412482006092100000) ).
  2. Pull the shock-absorbing pad outward and detach pins A and tabs B.
  3. Remove the shock-absorbing pad.
  4. Install in the reverse order of removal.

Scheme 56

Scheme 56: FLOOR COVERING REMOVAL/INSTALLATION
Scheme 56: FLOOR COVERING REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-244326-S41790335602006092100000) ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-244372-S00947186262006092100000) ). Second-row seat (See «SECOND-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S37010876322006092100000) ). Rear package tray lid (See «REAR PACKAGE TRAY LID REMOVAL/INSTALLATION»(ref-244361-S18906244912006092100000) ). Sub-trunk Third-row seat (See «THIRD-ROW SEAT REMOVAL/INSTALLATION»(ref-244372-S17463966512006092100000) ). Center console (See «CENTER CONSOLE REMOVAL/INSTALLATION»(ref-244361-S27977397232006092100000) ). Center console bracket Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S26008392432006092100000) ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S28323081802006092100000) ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-244361-S31703119622006092100000) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION»(ref-244361-S03102331672006092100000) ). Dust cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-244338-S20307144292006092100000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-244361-S08969594692006092100000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-244361-S17191375542006092100000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-244361-S41938693372006092100000) ). Third-row seat belt lower anchor installation bolt (See «THIRD-ROW SEAT BELT REMOVAL/INSTALLATION»(ref-244398-S28594203972006092100000) ). Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-244399-S02348388242006092100000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-244361-S40694322992006092100000) ).
  4. Remove fastener A, B, and C.
  5. Take the floor covering out from the opened liftgate.
  6. Install in the reverse order of removal.

More articles — Interior Trim
