Interior Trim: Overview Mazda 5 I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
2. Disconnect the negative battery cable.
3. Remove the following parts: Front door (See «FRONT DOOR REMOVAL/INSTALLATION» ). Sail garnish (See «SAIL GARNISH REMOVAL»(/mazda/5/i-2005-2007/remont/exteriorinterior-trim/#exterior-trim) ). Front scuff plate inner (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Side panel (passenger's side) (See «SIDE PANEL REMOVAL/INSTALLATION» ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION» ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). Undercover Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION» ). Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Knee bolster Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION» ). Selector lever component (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/automatic-trans/#automatic-transaxle-shift-mechanism) ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ). Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ). Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Lower column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ). Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION» ). A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]» ). (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]» ). (See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]» ). Rear heater duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION» ). Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ). Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/exteriorinterior-trim/#exterior-trim) ).
4. Disconnect the dashboard harness connectors.
5. Remove in the order indicated in the figure.
6. Install in the reverse order of removal.

Scheme 6

See also:
• SAIL GARNISH REMOVAL
• SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION
