Control System (HVAC): Overview Mazda 5 I

Automatic HVAC System 5 illustrations ~309 words

Scheme 47

Scheme 47: HVAC CONTROL SYSTEM LOCATION INDEX [FULL-AUTO AIR CONDITIONER]

Scheme 48

Scheme 48: HVAC CONTROL SYSTEM LOCATION INDEX [MANUAL AIR CONDITIONER]

Scheme 49

Scheme 49: AIR INTAKE ACTUATOR REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Front scuff plate inner (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ). Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/manual-trans/#manual-transaxle-shift-mechanism) ). Selector lever component (ATX) (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/automatic-trans/#automatic-transaxle-shift-mechanism) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION» ). Side panel (See «SIDE PANEL REMOVAL/INSTALLATION» ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). Car-navigation unit (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION» ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.

Scheme 50

Scheme 50: AIR INTAKE ACTUATOR INSPECTION
  1. Connect battery positive voltage to air intake actuator terminal C (or G), connect terminal G (or E) to ground, and then verify that the air intake actuator operates as shown in the table. If the operation condition is not normal, replace the air intake actuator. AIR INTAKE ACTUATOR OPERATION CONDITIONS Terminal Air Intake actuator operation C E G B+ - Ground FRESH --> RECIRCULATE - Ground B+ RECIRCULATE --> FRESH

Scheme 51

Scheme 51: AIR MIX ACTUATOR REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]» ).
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Front scuff plate inner (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ). Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/manual-trans/#manual-transaxle-shift-mechanism) ). Selector lever component (ATX) (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/5/i-2005-2007/remont/automatic-trans/#automatic-transaxle-shift-mechanism) ). Front console (See «FRONT CONSOLE REMOVAL/INSTALLATION» ). Side panel (See «SIDE PANEL REMOVAL/INSTALLATION» ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.
