Seat Belt System: Removal & Installation Mazda 3 BM

Restraints Control Systems 16 illustrations ~1212 words

FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the front seat belt (pre-tensioner seat belt) improperly can accidentally deploy the pre-tensioner seat belt, which may seriously injure you. Read the air bag system service warnings and cautions before handling the front seat belt. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)
WARNINGThe side air bag sensor is attached to the lower part of the B-pillar. When working around the B-pillar, disconnect the negative battery cable avoiding excessive impact to the lower part of the B-pillar.
CAUTIONThe ELR (emergency locking retractor) has a spring that will unwind if the retractor cover is removed. The spring cannot be rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the retractor.

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).)
  3. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).)
  4. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).)
  5. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).)
  6. Remove the cover. (Scheme 2): Pre-Tensioner Seat Belt, Bolts And Cover Tabs With Torque Specifications
  7. Remove the bolt A.
  8. Remove the bolt B.
  9. Remove the front seat belt.
  10. Using a flathead screwdriver, lift the locking device carefully, however do not remove it. (Scheme 3): Lifting Locking Device Using Flathead Screwdriver
  11. Disconnect the pre-tensioner seat belt connector.
  12. Install in the reverse order of removal.
  13. Switch the ignition to ON.
  14. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579333-S08531669002013100700000).)

FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]

WARNINGHandling the front seat belt (pre-tensioner seat belt) improperly can accidentally deploy the pre-tensioner seat belt, which may seriously injure you. Read the air bag system service warnings and cautions before handling the front seat belt. (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)
WARNINGThe side air bag sensor is attached to the lower part of the B-pillar. When working around the B-pillar, disconnect the negative battery cable avoiding excessive impact to the lower part of the B-pillar.
CAUTIONThe ELR (emergency locking retractor) has a spring that will unwind if the retractor cover is removed. The spring cannot be rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the retractor.

Scheme 4

Scheme 4: Driver-side
Scheme 4: Driver-side

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  3. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).)
  4. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).)
  5. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).)
  6. Remove the fastener. (Scheme 4): Identifying Lap Pre-Tensioner Seat Belt, Cover And Fastener
  7. Remove the cover.
  8. Remove the bolt A. (Scheme 5): Identifying Front Seat Belt, Cover Tabs, Bolt A And Bolt B With Torque Specifications
  9. Remove the bolt B.
  10. Remove the front seat belt.
  11. Using a flathead screwdriver, lift the locking device carefully, however do not remove it. (Scheme 6): Lifting Locking Device Using Flathead Screwdriver
  12. Disconnect the pre-tensioner seat belt connector.
  13. Disconnect the lap pre-tensioner seat belt connector.
  14. Install in the reverse order of removal.
  15. Switch the ignition to ON.
  16. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579334-S32994802122013100700000).)

Scheme 7

Scheme 7: Passenger-side
Scheme 7: Passenger-side

Scheme 8

Scheme 8
Scheme 8
  1. Switch the ignition to off.
  2. Disconnect the negative battery cable and wait for 1min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
  3. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).)
  4. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).)
  5. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).)
  6. Remove the cover. (Scheme 7): Identifying Front Seat Belt, Cover Tabs, Bolt A And Bolt B With Torque Specifications
  7. Remove the bolt A.
  8. Remove the bolt B.
  9. Remove the front seat belt.
  10. Using a flathead screwdriver, lift the locking device carefully, however do not remove it. (Scheme 8): Lifting Locking Device Using Flathead Screwdriver
  11. Disconnect the pre-tensioner seat belt connector.
  12. Install in the reverse order of removal.
  13. Switch the ignition to ON.
  14. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579334-S32994802122013100700000).)

ADJUSTER ANCHOR REMOVAL/INSTALLATION

WARNINGThe side air bag sensor is attached to the lower part of the B-pillar. When working around the B-pillar, disconnect the negative battery cable or work carefully, avoiding excessive impact to the lower part of the B-pillar.

Scheme 9

Scheme 9
Scheme 9
  1. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).)
  2. Remove the bolt. (Scheme 9): Adjuster Anchor With Torque Specifications
  3. Remove the adjuster anchor.
  4. Install in the reverse order of removal.

REAR SEAT BELT REMOVAL/INSTALLATION

CAUTIONThe ELR (emergency locking retractor) has a spring that will unwind if the retractor cover is removed. The spring cannot be rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the retractor.

Scheme 10

Scheme 10: 4SD
Scheme 10: 4SD
  1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim. (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear package trim. (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-579335-S35780317202013100700000).)
  2. Remove the bolts. (Scheme 10): Identifying Rear Seat Belt And Bolts - Sedan With Torque Specifications
  3. Remove the rear seat belt.
  4. Install in the reverse order of removal.

Scheme 11

Scheme 11: 5HB
Scheme 11: 5HB
  1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim. (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim. (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).)
  2. Remove the bolts. (Scheme 11): Identifying Rear Seat Belt And Bolts - Hatchback With Torque Specifications
  3. Remove the rear seat belt.
  4. Install in the reverse order of removal.

REAR CENTER SEAT BELT REMOVAL/INSTALLATION

CAUTIONThe ELR (emergency locking retractor) has a spring that will unwind if the retractor cover is removed. The spring cannot be rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the retractor.

Scheme 12

Scheme 12: 4SD
Scheme 12: 4SD

Scheme 13

Scheme 13
Scheme 13
  1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim. (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-579335-S35780317202013100700000).)
  2. Remove the bolt A. (Scheme 12): Identifying Rear Center Seat Belt And Bolt A - Sedan With Torque Specifications
  3. Remove the bolt B. (Scheme 13): Identifying Rear Center Seat Belt And Bolt B - Sedan With Torque Specifications
  4. Remove the rear center seat belt.
  5. Install in the reverse order of removal. (See «REAR CENTER SEAT BELT INSTALLATION NOTE»(ref-579339-S10518915212013100700000).)

Scheme 14

Scheme 14: 5HB
Scheme 14: 5HB
  1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).)
  2. Remove the bolt. (Scheme 14): Identifying Rear Center Seat Belt And Bolt - Hatchback With Torque Specifications
  3. Remove the rear center seat belt with the rear seat back. (See «REAR SEAT BACK FRAME REMOVAL/INSTALLATION»(ref-579337-S42094638172013100700000).)
  4. Install in the reverse order of removal. (See «REAR CENTER SEAT BELT INSTALLATION NOTE»(ref-579339-S10518915212013100700000).)

Scheme 15

Scheme 15: Rear Center Seat Belt Installation Note
Scheme 15: Rear Center Seat Belt Installation Note
  1. Rotate the rear center seat belt lower anchor clockwise 180° and install it. (Scheme 15): Rotating Rear Center Seat Belt Lower Anchor Clockwise 180°
  1. Verify that the belt is installed properly with no twists or kinks.
  2. Verify that there is no damage to the seat belt and no deformation of the metal fittings. If there is any malfunction, replace the seat belt.

Scheme 16

Scheme 16: Except 5HB (rear center seat belt)
Scheme 16: Except 5HB (rear center seat belt)

Scheme 17

Scheme 17
Scheme 17
  1. Verify that the belt can be pulled out smoothly, and that it retracts smoothly. (Scheme 16): Inspecting Seat Belt Can Be Pulled Out Smoothly And Retracts Smoothly If there is any malfunction, replace the seat belt.
  2. Verify that the retractor locks when the belt is pulled quickly. If there is any malfunction, replace the seat belt.
  3. Remove the retractor.
  4. While pulling the seat belt out, make sure that the seat belt does not lock when the retractor is tilted slowly up to 15° from the mounted position and locks when the retractor is tilted 40° or more. (Scheme 17): Identifying Retractor Tilted Angle If there is any malfunction, replace the seat belt.
