General Information: Other Mazda 3 BM

Range of Topics

1. This manual contains procedures for performing all required service operations. The procedures are divided into the following five basic operations: Removal/Installation Disassembly/Assembly Replacement Inspection Adjustment
2. Simple operations which can be performed easily just by looking at the vehicle (i.e., removal/installation of parts, jacking, vehicle lifting, cleaning of parts, and visual inspection) have been omitted.

Scheme 31

1. Inspection and adjustment procedures are divided into steps. Important points regarding the location and contents of the procedures are explained in detail and shown in the illustrations.

Scheme 32

1. Most repair operations begin with an overview illustration. It identifies the components, shows how the parts fit together, and describes visual part inspection. However, only removal/installation procedures that need to be performed methodically have written instructions.
2. Expendable parts, tightening torques, and symbols for oil, grease, and sealant are shown in the overview illustration. In addition, symbols indicating parts requiring the use of special service tools or equivalent are also shown.
3. Procedure steps are numbered and the part that is the main point of that procedure is shown in the illustration with the corresponding number. Occasionally, there are important points or additional information concerning a procedure. Refer to this information when servicing the related part.

Symbols

1. There are eight symbols indicating oil, grease, fluids, sealant, and the use of SST or equivalent. These symbols show application points or use of these materials during service.

Scheme 33

Advisory Messages

1. You will find several Warnings, Cautions, Notes, Specifications and Upper and Lower Limits in this manual.

Warning

1. A Warning indicates a situation in which serious injury or death could result if the warning is ignored.

Caution

1. A Caution indicates a situation in which damage to the vehicle or parts could result if the caution is ignored.

Note

1. A Note provides added information that will help you to complete a particular procedure.

Upper and lower limits

1. The values indicate the upper and lower limits that must not be exceeded when performing inspections or adjustments.

Scheme 34

UNITS

Conversion to SI Units (Systeme International d'Unites)

1. All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted from these values.

Rounding Off

1. Converted values are rounded off to the same number of places as the SI unit value. For example, if the SI unit value is 17.2 and the value after conversion is 37.84, the converted value will be rounded off to 37.8.

1. When the data indicates upper and lower limits, the converted values are rounded down if the SI unit value is an upper limit and rounded up if the SI unit value is a lower limit. Therefore, converted values for the same SI unit value may differ after conversion. For example, consider 2.7 kgf/cm 2 in the following specifications
2. 210-260 kPa {2.1-2.7 kgf/cm 2 , 30-38 psi}
3. 270-310 kPa {2.7-3.2 kgf/cm 2 , 39-45 psi}
4. The actual converted values for 2.7 kgf/cm 2 are 264 kPa and 38.4 psi. In the first specification, 2.7 is used as an upper limit, so the converted values are rounded down to 260 and 38. In the second specification, 2.7 is used as a lower limit, so the converted values are rounded up to 270 and 39.

Injury/damage Prevention Precautions

1. Depending on the vehicle, the cooling fan may operate suddenly even when the ignition is switched to off. Therefore, keep hands and tools away from the cooling fan even if the cooling fan is not operating to prevent injury to personnel or damage to the cooling fan. Always disconnect the negative battery cable when servicing the cooling fan or parts near the cooling fan.

Scheme 35

1. Always be sure to cover fenders, seats and floor areas before starting work.

Scheme 36

1. Be sure that all necessary tools and measuring equipment are available before starting any work.

Scheme 37

1. Use special service tools or equivalent when they are required.

1. Before removing the SRS air bag system-related parts, always disconnect the negative battery cable and wait for 1 min. or more to allow the back-up power supply to deplete its stored power.

Negative battery cable disconnection/required procedures after connecting

Using UV light (black light)

1. Remove any oil on the engine or transmission/transaxle. NOTE: Referring to the fluorescent dye instruction manual, mix the specified amount of dye into the engine oil or transmission/transaxle oil.
2. Pour the fluorescent dye into the engine oil or transmission/transaxle oil.
3. Allow the engine to run for 30 min.
4. Inspect for dye leakage by irradiating with UV light (black light), and identify the type of oil that is leaking.
5. If no dye leakage is found, allow the engine to run for another 30 min. or drive the vehicle then reinspect.
6. Find where the oil is leaking from, then make necessary repairs. NOTE: To determine whether it is necessary to replace the oil after adding the fluorescent dye, refer to the fluorescent dye instruction manual.

Scheme 38

1. Gather sample of the leaking oil using an absorbent white tissue.
2. Then, gather some samples of engine and transmission/transaxle oil onto a white cloth or piece of paper. MT vehicles: Transmission/transaxle oil AT vehicles: ATF
3. Compare the appearance and smell, and identify the type of oil that is leaking.
4. Remove any oil on the engine or transmission/transaxle.
5. Allow the engine to run for 30 min.
6. Check the area where the oil is leaking, then make necessary repairs.

Vehicles with keyless entry system

1. The power supply position can be switched in the order of LOCK, ACC, and ON by inserting the key into the ignition cylinder and turning the key. (Engine is off)
2. The engine can be started by inserting the key into the ignition cylinder and turning the key with the clutch pedal (MTX) or the brake pedal (ATX) depressed. (Engine is running)

Vehicles with advanced keyless entry system

1. The power supply position can be switched in the order of LOCK, ACC, and ON by bringing the advanced key into the vehicle and turning the ignition knob. (Engine is off)
2. The engine can be started by bringing the key into the vehicle and turning the ignition knob with the clutch pedal (MTX) or the brake pedal (ATX) depressed. (Engine is running)

Scheme 39

1. The power supply position can be switched as follows by operating the push button start with the advanced key in the vehicle. (Engine is off)
2. The engine can be started as follows by operating the push button start with the engine start conditions met. (Engine is running)

Scheme 40

Dynamometer

1. When inspecting and servicing the power train on the dynamometer or speed meter tester, pay attention to the following: Place a fan, preferably a vehicle-speed proportional type, in front of the vehicle. Make sure the vehicle is in a facility with an exhaust gas ventilation system. Since the rear bumper might deform from the heat, cool the rear with a fan. (Surface of the bumper must be below 70°C {158°F} .) Keep the area around the vehicle uncluttered so that heat does not build up. Watch the water temperature gauge and don't overheat the engine. Avoid added load to the engine and maintain normal driving conditions as much as possible.

Note. When only the front or rear wheels are rotated on a chassis dynamometer or equivalent, the ABS/DSC HU/CM determines that there is a malfunction in the ABS and illuminates the following lights: Vehicles with ABS ABS warning light Brake system warning light Vehicles with DSC ABS warning light Brake system warning light DSC indicator light If the above lights are illuminated, dismount the vehicle from the chassis dynamometer and switch the ignition to LOCK. Then, switch the ignition to ON position, run the vehicle at 10 km/h or more and verify that the warning lights go out. In this case, a DTC will be stored in the memory. Clear the DTC from the memory by following the memory clearing procedure [ABS]/[DSC] in the on-board diagnostic system. (See ON-BOARD DIAGNOSIS [ABS] .)(See ON-BOARD DIAGNOSIS [DYNAMIC STABILITY CONTROL (DSC)] .)

SST

1. Some global SST or equivalent are used as SSTs necessary for engine repair. Note that these SSTs are marked with global SST numbers.
2. Note that a global SST number is written together with a corresponding Mazda SST number as shown below.

Scheme 41

Scheme 42

Direction of View for Connector

1. The viewing direction of connectors is indicated with a symbol.
2. The figures showing the viewing direction are the same as those used in Wiring Diagrams.
3. The viewing directions are shown in the following three ways

Part-side connector

The viewing direction of part-side connectors is from the terminal side.

Scheme 43

Other

When it is necessary to show the terminal side of vehicle harness-side connectors, such as the following connectors, the viewing direction is from the terminal side.

Scheme 44

1. Main fuse block and the main fuse block relays
2. Data link connector
3. Check connector
4. Relay box

Jumper wire

Scheme 45

1. A jumper wire is used to create a temporary circuit. Connect the jumper wire between the terminals of a circuit to bypass a switch.

Scheme 46

1. The DC voltmeter is used to measure circuit voltage. A voltmeter with a range of 15 V or more is used by connecting the positive (+) probe (red lead wire) to the point where voltage will be measured and the negative (-) probe (black lead wire) to a body ground.

Ohmmeter

Scheme 47

1. The ohmmeter is used to measure the resistance between two points in a circuit and to inspect for continuity and short circuits.

Precautions Before Welding

A vehicle has various electrical parts. To protect the parts from excessive current generated when welding, be sure to perform the following procedure.

Scheme 48

Scheme 49

1. Switch the ignition to LOCK.
2. Disconnect the battery cables.
3. Securely connect the welding machine ground near the welding area.
4. Cover the peripheral parts of the welding area to protect them from weld spatter.

Jacking Positions

1. Use safety stands to support the vehicle after it has been lifted.

Front

Note. To prevent obstruction between the jack body and front bumper when the jack body is inserted, use a low-floor type jack.

1. Near the center of the front crossmember.

Rear

1. At the center of the rear crossmember.

Scheme 50

Front and rear

Scheme 51

1. Both sides of the vehicle, on side sills.

Scheme 52

1. Proper lifting and towing are necessary to prevent damage to the vehicle. Government and local laws must be followed.
2. A towed vehicle usually should have its drive wheel (front wheels) off the ground. If excessive damage or other conditions prevent this, use wheel dollies.
3. When towing with the rear wheels on the ground, release the parking brake.

Scheme 53

Scheme 54

Vehicle Securing Position

1. When transporting the vehicle by flat bed tow truck or trailer, secure the vehicle to the trailer using the holes and left tiedown loop shown in the figure.

Scheme 55

Scheme 56

Note. The tiedown eyelet (front) and the tiedown loops (rear) are used only when the vehicle is transported by ship.

Scheme 57

Scheme 58

SAE STANDARDS

1. In accordance with new regulations, SAE (Society of Automotive Engineers) standard names and abbreviations are now used in this manual. The table below lists the names and abbreviations that have been used in Mazda manuals up to now and their SAE equivalents.

1. #1: Diagnostic trouble codes depend on the diagnostic test mode.
2. #2: Controlled by the PCM
3. #3: Device that controls engine and powertrain
4. #4: Directly connected to exhaust manifold

Exterior

INSPECT and ADJUST , if necessary, the following items to specification

[] Glass, exterior bright metal and paint for damage

[] Wheel lug nuts

[] All weatherstrips for damage or detachment

[] Tire pressures

[] Headlight cleaner and fluid level (if equipped)

[] Operation of hood release and lock

[] Operation of trunk lid and fuel-filler lid opener

[] Door operation and alignment including side door and back door

[] Headlight aiming

INSTALL the following parts

[] Flap (if equipped)

Under hood-engine off

INSPECT and ADJUST , if necessary, the following items to specification

[] Fuel, engine coolant, and hydraulic lines, fittings, connections, and components for leaks

[] Engine oil level

[] Power steering fluid level

[] Brake and clutch fluid level

[] Windshield washer reservoir fluid level

[] Coolant level and specific gravity

[] Tightness of water hose clamps

[] Tightness of battery terminals, electrolyte level and specific gravity

[] Tension of drive belt

Interior

INSTALL the following items

[] Fuse for accessories

INSPECT the operations of the following items

[] Seat controls (slide and recline) and headrests

[] Folding rear seat

[] Door locks, including childproof door locks

[] Seat belts and warning system

[] Ignition switch and steering lock

[] Transaxle range switch

[] Warning buzzers

[] Ignition key reminder alarm

[] Air bag system using warning light

[] Cruise control system (if equipped)

[] Power door lock

[] Shift-lock system (if equipped)

[] Starter interlock

[] All lights including warning, and indicator lights

[] Horn, wipers, and washers

[] Wiper blades performance Clean wiper blades and windshield, if necessary

[] Audio system

[] Cigarette lighter and clock

[] Power windows (if equipped)

[] Heater, defroster, and air conditioner at various mode selections (if equipped)

INSPECT the following items

[] Presence of spare fuse

[] Upholstery and interior finish

INSPECT and ADJUST , if necessary, the following items

[] Operation and fit of windows

[] Pedal height and free play of clutch and brake pedal

[] Parking brake

Under hood-engine running at operating temperature

INSPECT the following items

[] Automatic transaxle fluid level

[] Operation of idle-up system for electrical load, air conditioner or power steering (if equipped)

[] Ignition timing

[] Idle speed

[] Operation of throttle position sensor

On hoist

INSPECT the following items

[] Manual transaxle oil level

[] Underside fuel, coolant and hydraulic lines, fittings, connections, and components for leaks

[] Tires for cuts or bruises

[] Steering linkage, suspension, exhaust system, and all underside hardware for looseness or damage

Schedule 1: (Normal Driving Conditions) for U.S.A.

1. The vehicle is mainly operated where none of the "unique driving conditions" apply.

Schedule 2: CANADA, Puerto Rico, and (Unique Driving Conditions) for U.S.A.

Schedule 1: (Normal Driving Conditions) for Mexico

1. The vehicle is mainly operated where none of the "unique driving conditions" apply.

Schedule 2: (Unique Driving Conditions) for Mexico

Cont.
