Control System - HVAC (Full Auto Air Conditioner): Overview Mazda 3 BM

Automatic HVAC System 3 illustrations ~215 words

Locating HVAC Control System Components (1 Of 2). Scheme 60

Scheme 60: Locating HVAC Control System Components (1 Of 2)

Locating HVAC Control System Components (2 Of 2). Scheme 61

Scheme 61: Locating HVAC Control System Components (2 Of 2)

Scheme 62

Scheme 62: AIR INTAKE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
  1. Set the air intake mode to FRESH.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).)
  3. Remove the following parts: Front scuff plate (Passenger-side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (Passenger-side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Lower panel (Passenger-side) (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) Shower duct (Passenger-side) (See «A/C UNIT REMOVAL/INSTALLATION»(ref-579378-S31323166662013100700000).)
  4. Disconnect the harness clip from the blower case.
  5. Disconnect the air intake actuator connector. (Scheme 62): Identifying Air Intake Actuator Connector, Harness Clip And Blower Case
  6. Remove the blower case. (See «BLOWER MOTOR REMOVAL [FULL-AUTO AIR CONDITIONER]»(ref-579409-S24338085262013100700000).) (See «BLOWER MOTOR INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-579409-S37450180742013100700000).)
  7. Remove the screw A.
  8. Remove the air intake actuator link.
  9. Remove the screw B.
  10. Remove the air intake actuator.
  11. Install in the reverse order of removal.
