Identifying HVAC Basic System Components Location - SKYACTIV-G 2.0. Scheme 1
Identifying HVAC Basic System Components Location - MZR 2.0 And MZR 2.5. Scheme 2
Identifying HVAC Basic System Components Location - MZR 2.3 DISI Turbo. Scheme 3
Scheme 4
- Disconnect the negative battery cable. (See BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5].) (See BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO].) (See BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0].)
- Remove the side wall. (See SIDE WALL REMOVAL/INSTALLATION.)
- Disconnect the evaporator temperature sensor connector.
- Disconnect the power MOS FET connector. (Full-auto air conditioner)
- Disconnect the resistor connector. (Manual air conditioner)
- Remove in the order indicated in the table. (Scheme 4): Identifying Air Filter Component Removal Sequence
- Install in the reverse order of removal.
Scheme 5
Scheme 6
- Insert the air filter projection between the ribs of the A/C unit and assemble the air filter (1) in the order shown in the figure. (Scheme 5): Inserting Air Filter Projection Between Ribs Of A/C Unit And Assemble Air Filter
- Assemble the air filter (2) in the order shown in the figure. (Scheme 6): Identifying Air Filter Component Assembly Sequence
