Scheme 2
- Fully open the glass panel.
- Press the spring in the direction shown by the arrow and remove it from the hook. (Scheme 2): Pressing Spring
- Remove the deflector.
- Install in the reverse order of removal.
Scheme 3
Scheme 4
- Fully close the glass panel.
- Fully open the sunshade.
- Remove the screws, and then remove the glass panel. (Scheme 3): Identifying Glass Panel And Screws
- Peel the weatherstrip off the glass panel. (Scheme 4): Peeling Weatherstrip Off Glass Panel
- Install in the reverse order of removal.
- Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT».)
Scheme 5
Scheme 6
- Fully close the glass panel.
- Measure the gap and height between the glass panel and body. (Scheme 5): Measuring Gap And Height Between Glass Panel And Body If not as specified, loosen the glass panel installation screws and reposition the glass panel. Clearance (4SD) a: -2.4-0.2 mm {-0.09-0.01 in} b: 0 mm {0 in} c: -2.2-0.4 mm {-0.08-0.01 in} d: 0 mm {0 in} Clearance (5HB) a: -2.3-0.3 mm {-0.09-0.01 in} b: 0 mm {0 in} c: -2.3-0.3 mm {-0.09-0.01 in} d: 0 mm {0 in}
- Tighten the installation screws.
- Insert a plastic card between the weatherstrip and the body of the vehicle. Verify that the sunroof is shut tightly (there is resistance when the plastic card is moved). (Scheme 6): Inserting Plastic Card Between Weatherstrip And Body Of Vehicle If the sunroof is not shut tightly, readjust by performing Steps 2 and 3.
