Seat System: Removal & Installation Mazda 3 BL рестайлинг

Seats 79 illustrations ~4359 words

FRONT SEAT REMOVAL/INSTALLATION

WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Note. When removing the front seat out of the vehicle or putting it back in, it can be performed smoothly by removing the headrest.

Scheme 6

Scheme 6: Vehicles without power seat system
Scheme 6: Vehicles without power seat system

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Detach hook A while pulling the adjuster cover No.1 and No.2 in the direction of the arrow (1), and remove it in the direction of arrow (2) shown in the figure. (Scheme 6): Pulling Adjuster Cover No.1 And No.2
  5. Detach hook B while pulling the adjuster cover No.3 in the direction of the arrow (3), (4) and remove it in the direction of arrow (5) shown in the figure. (Scheme 7): Pulling Adjuster Cover No.3
  6. Pull up the adjuster cover No.4 in the direction of arrow (6) shown in the figure, while remove the hook C. (Scheme 8): Pulling Up Adjuster Cover No.4
  7. Remove the front cover.(Vehicles with power seat system) (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITH POWER SEAT SYSTEM]»(ref-520455-S18957474592013010300000).)
  8. Disconnect the connector. (Scheme 9): Identifying Front Seat Connector
  9. Remove the bolts, then remove the front seat. (Scheme 10): Front Seat Bolts With Torque Specification
  10. Install in the reverse order of removal.

Scheme 11

Scheme 11: Vehicles with power seat system
Scheme 11: Vehicles with power seat system

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Detach hook A while pulling the adjuster cover No.1 and No.2 in the direction of the arrow (1), and remove it in the direction of arrow (2) shown in the figure. (Scheme 11): Pulling Adjuster Cover No.1 And No.2
  5. Detach hook B while pulling the adjuster cover No.3 in the direction of the arrow (3), (4) and remove it in the direction of arrow (5) shown in the figure. (Scheme 12): Pulling Adjuster Cover No.3
  6. Pull up the adjuster cover No.4 in the direction of arrow (6) shown in the figure, while remove the hook C. (Scheme 13): Pull Up Adjuster Cover No.4
  7. Remove the front cover.(Vehicles with power seat system) (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITH POWER SEAT SYSTEM]»(ref-520455-S18957474592013010300000).)
  8. Remove the bolts, then remove the front seat. (Scheme 14): Front Seat Bolts With Torque Specification
  9. Disconnect the connector. (Scheme 15): Identifying Front Seat Connector
  10. Install in the reverse order of removal.

Scheme 16

Scheme 16: Passenger-side
Scheme 16: Passenger-side

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the belt anchor cover. (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).)
  5. Remove the lower anchor of the front seat belt installation bolt. (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S38556519212013010300000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-520505-S00144206272013010300000).)
  6. Detach hook A and B while pulling the adjuster cover No.1 in the direction of the arrow (1), (2) and remove it in the direction of arrow (3) shown in the figure. (Scheme 16): Pulling Adjuster Cover No.1
  7. Detach hook C while pulling the adjuster cover No.3 in the direction of the arrow (4) and remove it in the direction of arrow (5) shown in the figure, while remove the tab D, F and hook E. (Scheme 17): Removing Tab D, F And Hook E
  8. Detach hook G and H while pulling the adjuster cover No.4 in the direction of the arrow (6), (7) and remove it in the direction of arrow (8) shown in the figure, while remove the tab I and J. (Scheme 18): Pulling Adjuster Cover No.4 CAUTION: When pulling the adjuster cover No.4, be careful not to damage the hooks and tabs.
  9. Disconnect the connector. (Scheme 19): Identifying Front Seat Connector
  10. Remove the bolts, then remove the front seat. (Scheme 20): Front Seat Bolts With Torque Specification
  11. Install in the reverse order of removal.
WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Remove the headrest.
  6. Remove the side cover. (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITHOUT POWER SEAT SYSTEM]»(ref-520455-S23553289132013010300000).)
  7. Cut the band securing the wiring harness. (Scheme 21): Identifying Side Air Bag Connector, Seat Warmer Connector, Side Air Bag Wiring Harness And Wiring Harness Band
  8. Disconnect the side air bag connector and seat warmer connector (Vehicles with power seat system).
  9. Remove the bolts and nut, then remove the front seat back component. (Scheme 22): Front Seat Back Component Bolts And Nut With Torque Specification
  10. Install in the reverse order of removal.

FRONT SEAT BACK TRIM REMOVAL/INSTALLATION

WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 23

Scheme 23: Removal
Scheme 23: Removal

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more.
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Remove the headrest.
  6. Cut the band securing the wiring harness. (Scheme 23): Identifying Side Air Bag Connector, Seat Warmer Connector And Side Air Bag Wiring Harness Band (Vehicle Without Power Seat System) (Scheme 24): Identifying Side Air Bag Connector, Seat Warmer Connector And Power Unit Connector (Vehicle With Power Seat System)
  7. Disconnect the side air bag connector and seat warmer connector (Vehicles with power seat system).
  8. Slide hook A in the order shown in the figure to detach it from hook B. (Scheme 25): Sliding Front Seat Hook A
  9. Open the fastener. (Scheme 26): Releasing Pole Guide Tabs
  10. Partially peal back the front seat back trim, release the pole guide tabs in the direction of arrow (4) shown in the figure, then pull the pole guide out in the direction of arrow (5).
  11. Remove the nut and remove the holder bracket A.
  12. Remove the holder hook B in the order of (6), (7) as shown in the figure. (Scheme 27): Holder Bracket A And Nut With Torque Specification (Scheme 28): Holder Hook B
  13. Pull out part A shown in the figure to the front. (Scheme 29): Pulling Out Front Seat Back Trim
  14. Remove the seat back trim and the seat back pad as a single unit from the seat frame by pulling them in the direction of the arrow. (Scheme 30): Removing Seat Back Trim And Seat Back Pad
  15. Partially peal back the seat back trim from the seat back pad, remove rings C in the order of (8), (9), (10) shown in the figure, then remove the seat back trim. (Scheme 31): Removing Seat Back Trim

Scheme 32

Scheme 32: Installation
Scheme 32: Installation

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Install the seat back trim to the front seat back pad, install the rings C in the order of (1), (2), (3) shown in the figure, then install the seat back trim. (Scheme 32): Installing Seat Back Trim
  2. Install the seat back trim and the seat back pad as a single unit from the seat frame by pushing them in the direction of the arrow (Scheme 33): Installing Seat Back Trim And Seat Back Pad
  3. Pass holder bracket A through slit A, holder hook B through slit B of the seat back pad. (Scheme 34): Passing Holder Bracket A CAUTION: Install it without twisting the sleeve. Get the holder bracket through between active frame and seat back frame.
  4. Push the part A shown in the figure to the rear. (Scheme 35): Pushing Front Seat Back Trim
  5. Assemble the holder bracket A to the seat back frame and install the nut shown in the figure. (Scheme 36): Assembling Holder Bracket A To Seat Back Frame With Torque Specification
  6. Install the pole guide in the direction of arrow shown in the figure. (Scheme 37): Installing Pole Guide
  7. Shut the fastener.
  8. Slide hook A in the order of (4), (5), (6) shown in the figure to install it to hook B (Scheme 38): Sliding Front Seat Hook A
  9. Install the band, while tighten the wiring harness. (Scheme 39): Identifying Side Air Bag Connector, Seat Warmer Connector, Side Air Bag Wiring Harness Band And Power Unit Connector
  10. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  11. Install the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)

FRONT SEAT CUSHION TRIM REMOVAL/INSTALLATION

WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Remove the side cover. (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITH POWER SEAT SYSTEM]»(ref-520455-S18957474592013010300000).) (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITHOUT POWER SEAT SYSTEM]»(ref-520455-S23553289132013010300000).)
  6. Detach hook A and B in the direction of the arrow shown in the figure.
  7. Detach hook C by sliding it in the order of (1), (2), and (3) as shown in the figure.
  8. Remove the seat cushion trim and the seat cushion pad from the seat frame as a single unit. (Scheme 40): Removing Seat Cushion Trim And Seat Cushion Pad From Seat Frame
  9. Remove rings C in the order of (4), (5), (6) and (7) as shown in the figure, then remove the seat cushion trim from the seat cushion pad in the direction of the arrow shown in the figure. (Scheme 41): Removing Seat Cushion Trim From Seat Cushion Pad
  10. Install in the reverse order of removal.

FRONT SEAT SLIDE ADJUSTER REMOVAL/INSTALLATION

WARNINGHandling the front seats improperly can accidentally deploy the side air bag, which may seriously injure you. Read air bag system service warnings and cautions before handling the front seats. (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)
  1. Disconnect the negative battery cable and wait 1 min or more . (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000) .) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000) .) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000) .)
  2. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000) .) Front seat side cover (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITH POWER SEAT SYSTEM]»(ref-520455-S18957474592013010300000) .) (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITHOUT POWER SEAT SYSTEM]»(ref-520455-S23553289132013010300000) .) Front seat rail guide cover (See «FRONT SEAT RAIL GUIDE COVER REMOVAL/INSTALLATION»(ref-520455-S10039450882013010300000) .) Front seat cushion pad and trim (See «FRONT SEAT CUSHION TRIM REMOVAL/INSTALLATION»(ref-520455-S01889478522013010300000) .) Front seat back component (See «FRONT SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-520455-S15960907792013010300000) .)
  3. Install in the reverse order of removal.
WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 42

Scheme 42: Side Cover
Scheme 42: Side Cover

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Pull the power seat switch knobs in the direction of arrow, while remove the hook. (Scheme 42): Pulling Power Seat Switch Knobs
  6. Pull the side cover (front door side) in the order of (1), (2), (3) shown in the figure to disengage the fastener, hook and tab. (Scheme 43): Pulling Side Cover (Front Door Side)
  7. Remove the front seat side cover (front door side).
  8. Pull the side cover (rear console side) in the order of (4), (5) shown in the figure to disengage the fastener and tab. (Scheme 44): Pulling Side Cover (Rear Console Side)
  9. Remove the front seat side cover (rear console side).
  10. Install in the reverse order of removal.

Scheme 45

Scheme 45: Front Cover
Scheme 45: Front Cover
  1. Remove the screws. (Scheme 45): Identifying Front Cover Screws
  2. Remove the front cover.
  3. Install in the reverse order of removal.
WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 46

Scheme 46: Driver-side
Scheme 46: Driver-side

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Operate the lift lever in the direction of arrow (1) shown in the figure. (Scheme 46): Removing Lift Lever Cover
  6. Insert a fastener remover from the position of arrow (2) shown in the figure, and remove the lift lever cover by disengaging the tab.
  7. Remove the screws, then remove the lift lever in the direction of the arrow. (Scheme 47): Removing Lift Lever With Screws
  8. After operating the recliner knob in the upward direction (3), cut the area indicated in the figure, then remove the recliner knob in the direction of arrow (4). (Scheme 48): Removing Recliner Knob CAUTION: The seat back folds forward when the recliner knob is operated. Be careful when operating the recliner knob.
  9. Remove the screw.
  10. Pull the side cover (front door side) in the order of (5), (6), (7) shown in the figure to disengage the fastener and tab. (Scheme 49): Pulling Side Cover (Front Door Side)
  11. Remove the front seat side cover (front door side).
  12. Remove the fastener left to the front seat frame and install it to the original position of the cover.
  13. Remove the screw.
  14. Remove the screws, and pull the side cover (rear console side) in the order of (8), (9), (10) shown in the figure to disengage the fastener and tab. (Scheme 50): Pulling Side Cover (Rear Console Side)
  15. Remove the front seat side cover (rear console side).
  16. Remove the fastener left to the front seat frame and install it to the original position of the cover.
  17. Install in the reverse order of removal.

Scheme 51

Scheme 51: Passenger-side
Scheme 51: Passenger-side

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53
  1. After operating the recliner knob in the upward direction (1), cut the area indicated in the figure, then remove the recliner knob in the direction of arrow (2). (Scheme 51): Removing Recliner Knob CAUTION: The seat back folds forward when the recliner knob is operated. Be careful when operating the recliner knob.
  2. Remove the screws, and pull the side cover (front door side) in the order of (3), (4), (5) shown in the figure to disengage the tab. (Scheme 52): Pulling Side Cover (Front Door Side)
  3. Remove the front seat side cover (front door side).
  4. Remove the screws, and pull the side cover (rear console side) in the order of (6), (7), (8) shown in the figure to disengage the tab. (Scheme 53): Pulling Side Cover (Rear Console Side)
  5. Remove the front seat side cover (rear console side).
  6. Install in the reverse order of removal.

FRONT SEAT RAIL GUIDE COVER REMOVAL/INSTALLATION

WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 54

Scheme 54: Vehicles Without Power Seat System
Scheme 54: Vehicles Without Power Seat System
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Remove the screw, clip and disengage the tab, remove the front seat rail guide cover. (Scheme 54): Removing Front Seat Rail Guide Cover (Vehicles Without Power Seat System)
  6. Install in the reverse order of removal.

Scheme 55

Scheme 55: Vehicles With Power Seat System
Scheme 55: Vehicles With Power Seat System
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  4. Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
  5. Remove the screws and disengage the tab, remove the front seat rail guide cover. (Scheme 55): Removing Front Seat Rail Guide Cover (Vehicles With Power Seat System)
  6. Install in the reverse order of removal.

Scheme 56

Scheme 56: ACTIVE HEADREST INSPECTION
Scheme 56: ACTIVE HEADREST INSPECTION
  1. Push the bottom of front seat back in the direction of arrow shown in the figure. (Scheme 56): Bottom Of Front Seat Back With Torque Specification
  2. While inspecting for move the front seat back.

Scheme 57

Scheme 57: REAR SEAT BACK REMOVAL/INSTALLATION
Scheme 57: REAR SEAT BACK REMOVAL/INSTALLATION

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59
  1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).)
  2. Remove the rear buckle installation bolt. (See «REAR BUCKLE REMOVAL/INSTALLATION»(ref-520505-S16576028252013010300000).)
  3. Fold the rear seat back.
  4. Remove the bolts. (Scheme 57): Rear Seat Back Bolts With Torque Specification (Scheme 58): Rear Seat Back From Rear Seat Back Bracket With Torque Specification
  5. Remove the rear seat back from the rear seat back bracket by pulling the rear seat back in the direction of the arrow shown in the figure.
  6. Remove the bolts, remove the hinge. (Scheme 59): Bushing, Hinge, Washer With Torque Specification
  7. Install in the reverse order of removal.

Scheme 60

Scheme 60: REAR SEAT BACK FRAME REMOVAL/INSTALLATION
Scheme 60: REAR SEAT BACK FRAME REMOVAL/INSTALLATION

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68
  1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).)
  2. Remove the rear buckle installation bolt. (See «REAR BUCKLE REMOVAL/INSTALLATION»(ref-520505-S16576028252013010300000).)
  3. Remove the rear seat back. (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-520455-S28972805732013010300000).)
  4. Remove the headrest.
  5. Open the fasteners.
  6. Detach the hooks. (Scheme 60): Detaching Rear Seat Back Frame Hooks
  7. Remove the child-restraint seat anchor covers in the order of (1), (2) as shown in the figure. (5HB only) (Scheme 61): Removing Child-Restraint Seat Anchor Covers
  8. Remove the push knob while remove the hooks in the direction of arrow shown in the figure. (Scheme 62): Removing Push Knob
  9. Open the fastener, remove the fastener and striker cover. (Scheme 63): Identifying Fasteners And Striker Cover
  10. Remove the bolt then remove the rear seat center armrest.(Vehicles with the rear seat center armrest) (Scheme 64): Rear Seat Center Armrest And Bolt With Torque Specification
  11. Peal back the rear seat pad, release the pole guide tabs in the direction of arrow (3) shown in the figure, then pull out the pole guides in the direction of arrow (4). (Scheme 65): Pulling Out Pole Guides
  12. Remove the screws, then remove the belt cover in the direction of arrow shown in the figure. (Scheme 66): Removing Belt Cover With Screws
  13. Open the fasteners.
  14. Remove the seat back frame from the seat back pad by pulling it in the direction of the arrow.(5HB) (Scheme 67): Removing Seat Back Frame From Seat Back Pad
  15. Remove the nut, then remove the rear seat belt. (Scheme 68): Rear Seat Belt And Nut With Torque Specification
  16. Install in the reverse order of removal.(5HB)

Scheme 69

Scheme 69: REAR SEAT BACK TRIM REMOVAL/INSTALLATION
Scheme 69: REAR SEAT BACK TRIM REMOVAL/INSTALLATION
  1. Remove the rear seat back frame. (See «REAR SEAT BACK FRAME REMOVAL/INSTALLATION»(ref-520455-S32926995662013010300000).)
  2. Remove rings C, then remove the seat back trim from the seat back pad. (Scheme 69): Identifying Rear Seat Back Rings C
  3. Install in the reverse order of removal.

Scheme 70

Scheme 70: REAR SEAT CUSHION REMOVAL/INSTALLATION
Scheme 70: REAR SEAT CUSHION REMOVAL/INSTALLATION
  1. Detach the hooks from the grommets by pulling the rear seat cushion in the order of (1), (2) in the direction of the arrow shown in the figure, while remove the wire. (Scheme 70): Detaching Hooks From Grommets
  2. Install in the reverse order of removal.

Scheme 71

Scheme 71: REAR SEAT CUSHION TRIM REMOVAL/INSTALLATION
Scheme 71: REAR SEAT CUSHION TRIM REMOVAL/INSTALLATION
  1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).)
  2. Remove rings C, then remove the seat cushion trim from the seat cushion pad. (Scheme 71): Identifying Rear Seat Cushion And Rings C
  3. Install in the reverse order of removal.

Scheme 72

Scheme 72: FRONT TILT MOTOR INSPECTION
Scheme 72: FRONT TILT MOTOR INSPECTION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the front tilt motor connector.
  4. Apply battery positive voltage to the front tilt motor terminals and inspect the front tilt motor operation (Scheme 72): Inspecting Front Tilt Motor Operation If not as specified, replace the front seat slide adjuster.
Motor operationConnection
B+GND
UpBD
DownDB

Scheme 73

Scheme 73: REAR TILT MOTOR INSPECTION
Scheme 73: REAR TILT MOTOR INSPECTION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the rear tilt motor connector.
  4. Apply battery positive voltage to the rear tilt motor terminals and inspect the rear tilt motor operation (Scheme 73): Inspecting Rear Tilt Motor Operation If not as specified, replace the front seat slide adjuster.
Motor operationConnection
B+GND
UpBD
DownDB

Scheme 74

Scheme 74: SLIDE MOTOR INSPECTION
Scheme 74: SLIDE MOTOR INSPECTION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the slide motor connector.
  4. Apply battery positive voltage to the slide motor terminals and inspect the slide motor operation (Scheme 74): Inspecting Slide Motor Operation If not as specified, replace the front seat slide adjuster.
Motor operationConnection
B+GND
ForwardDB
BackwardBD

Scheme 75

Scheme 75: RECLINER MOTOR INSPECTION
Scheme 75: RECLINER MOTOR INSPECTION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the recliner motor connector.
  4. Apply battery positive voltage to the recliner motor terminals and inspect the recliner motor operation. (Scheme 75): Inspecting Recliner Motor Operation If not as specified, replace the recliner motor.
Motor operationConnection
B+GND
ForwardAB
BackwardBA

Scheme 76

Scheme 76: POWER SEAT SWITCH INSPECTION
Scheme 76: POWER SEAT SWITCH INSPECTION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the power seat switch connector.
  4. Inspect for continuity between the power seat switch connector terminals using an ohmmeter. If not as specified, replace the power seat switch. (Scheme 76): Inspecting Continuity Between Power Seat Switch Connector Terminals

Scheme 77

Scheme 77: SEAT WARMER SWITCH REMOVAL/INSTALLATION
Scheme 77: SEAT WARMER SWITCH REMOVAL/INSTALLATION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the shift panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).)
  4. Squeeze the tabs of seat warmer switch and pull it outward to remove it. (Scheme 77): Squeezing Tabs Of Seat Warmer Switch
  5. Remove the seat warmer switch.
  6. Install in the reverse order of removal.

Scheme 78

Scheme 78: SEAT WARMER SWITCH INSPECTION
Scheme 78: SEAT WARMER SWITCH INSPECTION
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Inspect for resistance and continuity between the seat warmer switch terminals using a tester. (Scheme 78): Inspecting Resistance And Continuity Between Seat Warmer Switch Terminals If not as specified, replace the seat warmer switch.

Removal

WARNINGHandling a front seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a front seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a front seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the front seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a front seat. When performing the procedure with a front seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM] .)

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80
  1. Switch the ignition to off.
  2. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Disconnect the negative battery cable and wait 1 min or more.
  4. Remove the following parts: Front seat side cover (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITH POWER SEAT SYSTEM]»(ref-520455-S18957474592013010300000).) (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITHOUT POWER SEAT SYSTEM]»(ref-520455-S23553289132013010300000).) Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).) Front seat back trim (See «FRONT SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-520455-S15960907792013010300000).) Front seat cushion trim (See «FRONT SEAT CUSHION TRIM REMOVAL/INSTALLATION»(ref-520455-S01889478522013010300000).)
  5. Peel off the seat warmer unit from the position of the arrow shown in the figure. (Scheme 79): Locating Double-Sided Adhesive Tape Applying Area On Seat Warmer Unit
  6. Peel off the spacer pad from the position of the arrow shown in the figure. (Scheme 80): Locating Double-Sided Adhesive Tape Applying Area On Spacer Pad

Identifying Spacer Pad. Scheme 81

Scheme 81: Identifying Spacer Pad
Scheme 81: Identifying Spacer Pad

Installation

Note. If there are any peel-off marks from the seat back pad and seat cushion pad remaining after they have been peeled off, the seat pad cannot be reused and it must be replaced with a new one.

Identifying Double-Sided Adhesive Tape Peel-Off Marks Dimension. Scheme 82

Scheme 82: Identifying Double-Sided Adhesive Tape Peel-Off Marks Dimension
Scheme 82: Identifying Double-Sided Adhesive Tape Peel-Off Marks Dimension

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84
  1. Stick the spacer pad onto the seat pad shown in the figure. (Scheme 83): Identifying Spacer Pad And Seat Pad Gap Dimension
  2. Stick the seat warmer unit onto the seat pad. (Scheme 84): Identifying Double-Sided Adhesive Tape Applying Area On Seat Warmer Unit
  3. Install the following parts: Front seat cushion trim (See «FRONT SEAT CUSHION TRIM REMOVAL/INSTALLATION»(ref-520455-S01889478522013010300000).) Front seat back trim (See «FRONT SEAT BACK TRIM REMOVAL/INSTALLATION»(ref-520455-S15960907792013010300000).) Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).) Front seat side cover (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITH POWER SEAT SYSTEM]»(ref-520455-S18957474592013010300000).) (See «FRONT SEAT COVER REMOVAL/INSTALLATION [VEHICLES WITHOUT POWER SEAT SYSTEM]»(ref-520455-S23553289132013010300000).)
  4. Connect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  5. Install the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  6. Inspect the seat warmer unit. (See «SEAT WARMER UNIT INSPECTION»(ref-520455-S17884421672013010300000).)

More articles — Seat System
