5HB (rear center seat belt)
| CAUTION | The rear center seat belt ELR only becomes operable after a certain amount of belt webbing is pulled out. For the ELR inspection, fasten the rear center seat belt to the rear buckle (center) and perform the inspection after pulling out the rear center seat belt 130 mm {5.12 in} (ELR operable condition). If the inspection is performed while the ELR is not in an operable condition, the integrity of the system cannot be determined. |
Scheme 18
Scheme 19
- Fasten the rear center seat belt to the rear buckle (center) and pull out the rear center seat belt 130 mm {5.12 in}. (Scheme 18): Pulling Out Rear Center Seat Belt 130 mm (5.12 in)
- Verify that the belt can be pulled out smoothly, and that it retracts smoothly. If there is any malfunction, replace the seat belt.
- Verify that the retractor locks when the belt is pulled quickly. If there is any malfunction, replace the seat belt.
- Remove the rear center seat belt retractor.
- While pulling the seat belt out, make sure that the seat belt does not lock when the retractor is tilted slowly up to 15° from the mounted position and locks when the retractor is tilted 40° or more. (Scheme 19): Identifying Rear Center Seat Belt Retractor Tilted Angle If there is any malfunction, replace the seat belt.
ALR
- Pull the belt out fully to change the lock mode from ELR to ALR.
- Verify that retractor makes a clicking sound as the belt slowly retracts. If no sound is heard, the lock mode has not changed to ALR. If necessary, repeat Step 1. If there is any malfunction, replace the seat belt.
- Verify that the retractor locks when pulled. If there is any malfunction, replace the seat belt.
- Verify that the lock mode changes to ELR when the belt is fully pulled out. If there is any malfunction, replace the seat belt.
Load Limiter Retractor
| WARNING | When the load limiter operates, the belt and anchor rub against each other strongly leaving wear tracks. If the seat belt is used in this state, the seat belt will not function at its full capability and there is the possibility of serious injury to passengers. Be sure to replace the seat belt once the load limiter operates. |
Scheme 20
- If the vehicle has been subjected to a shock in an accident, pull the belt from the retractor and confirm that there are no wear tracks (the load limiter has not operated) by visually inspecting and feeling the belt. (Scheme 20): Inspecting Seat Belt For Wear Tracks (Load Limiter Retractor) If there is any malfunction, replace the seat belt.
Scheme 21
Scheme 21: FRONT BUCKLE REMOVAL/INSTALLATION
- Switch the ignition to off.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
- Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
- Remove the bolt. (Scheme 21): Front Buckle And Bolt With Torque Specifications
- Remove the front buckle.
- Install in the reverse order of removal.
Scheme 22
Scheme 22: Rear Buckle (RH) and Rear Buckle (Center)
- Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-520455-S42710378332013010300000).)
- Remove the bolt. (Scheme 22): Bolt, Rear Buckle (RH) And Rear Buckle (Center) With Torque Specifications
- Remove the rear buckle (RH) and rear buckle (center).
- Install in the reverse order of removal.
Rear Buckle (LH)
- When removing or installing the rear buckle (LH), refer to the rear center seat belt removal/installation procedure. (See «REAR CENTER SEAT BELT REMOVAL/INSTALLATION»(ref-520505-S17240149932013010300000) .)
Scheme 23
Scheme 23: Rear Buckle Installation Note
- After installing the rear seat cushion, position the rear buckle (RH) and rear buckle (center) with the rear buckle (RH) and rear buckle (center) buttons facing upward as shown in the figure. (Scheme 23): Identifying Rear Buckle (RH) And Rear Buckle (Center) Buttons
Scheme 24
Scheme 25
- Switch the ignition to off.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
- Remove the front seat. (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-520455-S27188652042013010300000).)
- Remove the front buckle. (See «FRONT BUCKLE REMOVAL/INSTALLATION»(ref-520505-S28045347672013010300000).)
- Inspect for continuity between the buckle switch terminals using a tester. (Scheme 24): Inspecting For Continuity Between Buckle Switch Terminals If not as indicated in the table, replace the driver side front buckle. (Scheme 25): Driver Side Front Buckle Switch Terminals Continuity Chart
Passenger Side
- Connect the M-MDS (IDS) to the DLC-2.
- After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "DataLogger". Select "Modules". Select "RCM".
- Verify that it is displayed according to the table using "BUCKLE_P". M-MDS display Operation Status Unbuckled Passenger-side front seat belt not fastened Buckled Passenger-side front seat belt fastened If not as indicated in the table, replace the passenger side front buckle.
Scheme 26
- Remove the cover. (Scheme 26): Cover, Bolt And Child-Restraint Seat Anchor With Torque Specifications
- Remove the bolt and child-restraint seat anchor.
- Install in the reverse order of removal.
Scheme 27
- Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-520454-S13459736022013010300000).) (Scheme 27): Bolt And Child-Restraint Seat Anchor With Torque Specifications
- Remove the bolt and child-restraint seat anchor.
- Install in the reverse order of removal.
