Glass/windows/mirrors: Overview Mazda 3 BL рестайлинг

Heated Glass/defoggers 29 illustrations ~1748 words
Fig. 1: Identifying Glass/Windows/Mirrors Components (1 Of 2)
Scheme 1: Identifying Glass/Windows/Mirrors Components (1 Of 2)
Fig. 2: Identifying Glass/Windows/Mirrors Components (2 Of 2)
Scheme 2: Identifying Glass/Windows/Mirrors Components (2 Of 2)

Scheme 1

Scheme 1: FRONT DOOR GLASS REMOVAL/INSTALLATION
Scheme 1: FRONT DOOR GLASS REMOVAL/INSTALLATION

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 1): Positioning Front Door Glass Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  4. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  5. Remove the front door speaker. (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S06651380612013010300000).)
  6. Remove the hole plug. (Scheme 2): Front Door And Hole Plug
  7. Remove the bolts. (Scheme 3): Front Door Bolts With Torque Specification CAUTION: If the bolts are removed without supporting the front door glass, the front door glass may fall off and be damaged. Remove the bolts while inserting your hand into the front door speaker installation hole to support the front door glass.
  8. Lift up the front door glass, tilt it in the direction of arrow (1) shown in the figure, then remove it in the direction of arrow (2). (Scheme 4): Lifting Up Front Door Glass (1 Of 2) (Scheme 5): Lifting Up Front Door Glass (2 Of 2)
  9. Install in the reverse order of removal. CAUTION: If the bolts are installed without supporting the front door glass, the front door glass may fall off and be damaged. When installing the front door glass, align the glass edge with the front door glass guide by hand through the speaker installation hole, and then install the bolts.

Scheme 6

Scheme 6: REAR DOOR GLASS REMOVAL/INSTALLATION
Scheme 6: REAR DOOR GLASS REMOVAL/INSTALLATION

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Fully lower the rear door glass.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  4. Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S15708751742013010300000).)
  5. Remove the rear power window motor. (See «POWER WINDOW MOTOR REMOVAL/INSTALLATION»(ref-520370-S06126990132013010300000).)
  6. Remove the service hole cover. (Scheme 6): Identifying Service Hole Cover
  7. Remove the rear door glass guide. (See «REAR DOOR QUARTER GLASS REMOVAL/INSTALLATION»(ref-520370-S40991658522013010300000).)
  8. Remove the rear door quarter glass. (See «REAR DOOR QUARTER GLASS REMOVAL/INSTALLATION»(ref-520370-S40991658522013010300000).)
  9. Remove the hole plug and bolt. (Scheme 7): Hole Plug And Bolt With Torque Specification CAUTION: If the bolts are removed without supporting the rear door glass, the rear door glass may fall off and be damaged. Remove the bolts while inserting your hand into the rear door speaker installation hole to support the rear door glass.
  10. Lift the rear door glass up and remove while tilting it. (Scheme 8): Lifting Rear Door Glass Up
  11. Install in the reverse order of removal. CAUTION: If the bolts are installed without supporting the rear door glass, the rear door glass may fall off and be damaged. When installing the rear door glass, align the glass edge with the rear door glass guide by hand through the speaker installation hole, and then install the bolts.

Scheme 9

Scheme 9: REAR DOOR QUARTER GLASS REMOVAL/INSTALLATION
Scheme 9: REAR DOOR QUARTER GLASS REMOVAL/INSTALLATION

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Fully lower the rear door glass.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  4. Remove the service hole cover. (Scheme 9): Identifying Service Hole Cover
  5. Remove the hole plug. (Scheme 10): Hole Plug, Bolts And Screws With Torque Specification
  6. Remove the screw.
  7. Remove the bolt A and B.
  8. Remove the rear door glass guide. (Scheme 11): Rear Door Glass Guide
  9. Remove the pin. (5HB) (Scheme 12): Identifying Pin
  10. Slide the rear door quarter glass in the direction of the arrow (1) shown in the figure. (Scheme 13): Sliding Rear Door Quarter Glass
  11. Remove the rear door quarter glass and rear door quarter glass guide as a single unit in the direction of the arrow (2) shown in the figure.
  12. Remove the rear door quarter glass from the rear door quarter glass guide. (Scheme 14): Rear Door Quarter Glass And Rear Door Quarter Glass Guide
  13. Install in the reverse order of removal.

Scheme 15

Scheme 15: FRONT POWER WINDOW REGULATOR REMOVAL/INSTALLATION
Scheme 15: FRONT POWER WINDOW REGULATOR REMOVAL/INSTALLATION

Scheme 16

Scheme 16
Scheme 16
  1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 15): Positioning Front Door Glass Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S06651380612013010300000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-520370-S29011543212013010300000).) Front power window motor (See «POWER WINDOW MOTOR REMOVAL/INSTALLATION»(ref-520370-S06126990132013010300000).)
  4. Remove the nuts. (Scheme 16): Front Door Module Panel And Nuts With Torque Specification
  5. Install in the reverse order of removal. CAUTION: When installing, do not allow the cable to come out from the drum housing.

Scheme 17

Scheme 17: REAR POWER WINDOW REGULATOR REMOVAL/INSTALLATION
Scheme 17: REAR POWER WINDOW REGULATOR REMOVAL/INSTALLATION

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Fully lower the rear door glass.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  4. Remove the service hole cover. (Scheme 17): Service Hole Cover
  5. Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S15708751742013010300000).)
  6. Remove the glass guide. (See «REAR DOOR QUARTER GLASS REMOVAL/INSTALLATION»(ref-520370-S40991658522013010300000).)
  7. Remove the rear power window motor. (See «POWER WINDOW MOTOR REMOVAL/INSTALLATION»(ref-520370-S06126990132013010300000).)
  8. Remove the rear door glass. (See «REAR DOOR GLASS REMOVAL/INSTALLATION»(ref-520370-S41193427072013010300000).)
  9. Remove the nuts. (Scheme 18): Rear Door And Nuts With Torque Specification
  10. Insert a hand through the speaker installation hole, rotate the drum housing in the direction shown in the figure to detach the tabs from the rear door module. (Scheme 19): Inserting Hand Through Speaker Installation Hole
  11. Remove the rear power window regulator through the speaker installation hole. (Scheme 20): Rear Power Window Regulator And Speaker Installation Hole
  12. Install in the reverse order of removal. CAUTION: Make sure the cable does not unspool from the drum housing when installing.

Scheme 21

Scheme 21: Front Power Window Motor
Scheme 21: Front Power Window Motor

Scheme 22

Scheme 22
Scheme 22
  1. Fully lower the front door glass.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  4. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  5. Remove the front door speaker. (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S06651380612013010300000).)
  6. Remove the bolts. (Scheme 21): Front Power Window Motor And Bolts With Torque Specification
  7. Disconnect the front power window motor connector. (Scheme 22): Front Power Window Motor Connector
  8. Install in the reverse order of removal. NOTE: When installing the front power window motor to the front power window regulator drum, the drum housing hooks may detach from the door module. If this happens, remove the front door speaker, insert your hand in the speaker installation hole, connect the drum housing hooks, and while supporting the drum housing, install the front power window motor to the drum.

Scheme 23

Scheme 23: Rear Power Window Motor
Scheme 23: Rear Power Window Motor

Scheme 24

Scheme 24
Scheme 24
  1. Fully lower the rear door glass.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  4. Remove the rear door speaker. (See «REAR DOOR SPEAKER REMOVAL/INSTALLATION»(ref-520392-S15708751742013010300000).)
  5. Remove the bolts. (Scheme 23): Front Power Window Motor And Bolts With Torque Specification
  6. Disconnect the front power window motor connector. (Scheme 24): Front Power Window Motor Connector
  7. Install in the reverse order of removal. NOTE: When installing the rear power window motor to the rear power window regulator drum, the drum housing hooks may detach from the door module. If this happens, remove the door speaker, insert your hand in the speaker installation hole, connect the drum housing hooks, and while supporting the drum housing, install the rear power window motor to the drum.

Scheme 25

Scheme 25: Front Driver Side
Scheme 25: Front Driver Side
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  4. Disconnect the power window motor connector.
  5. Apply battery positive voltage and connect the ground to power window motor terminals E and F, and then inspect the power window motor operation. (Scheme 25): Power Window Motor Connector Terminals (Front Driver Side) If the power window motor does not operate as indicated in the table, replace the power window motor. Operation Terminal E F Open Ground B+ Close B+ Ground
  6. Connect the battery positive voltage to power window motor terminal D and connect terminal C to ground.
  7. Operate the power window motor and measure the voltage at terminals A and B. If there is any malfunction, replace the power window motor. Voltage Pulse: max. 5 V/min. 0 V

Scheme 26

Scheme 26: Front Passenger Side
Scheme 26: Front Passenger Side
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-520454-S32815572972013010300000).)
  3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S34560758062013010300000).)
  4. Disconnect the power window motor connector.
  5. Apply battery positive voltage and connect the ground to power window motor terminals E and F, and then inspect the power window motor operation. (Scheme 26): Power Window Motor Connector Terminals (Front Passenger Side) If the power window motor does not operate as indicated in the table, replace the power window motor. Operation Terminal E F Open Ground B+ Close B+ Ground

Scheme 27

Scheme 27: Rear
Scheme 27: Rear
  1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
  2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-520454-S27602354862013010300000).)
  3. Disconnect the power window motor connector.
  4. Apply battery positive voltage and connect the ground to power window motor terminals E and F, and then inspect the power window motor operation. (Scheme 27): Power Window Motor Connector Terminals (Rear) If the power window motor does not operate as indicated in the table, replace the power window motor. Operation Terminal E F Open Ground B+ Close B+ Ground
