No.4 Programming Procedure Due to PCM Replacement
| CAUTION | The engine cannot be started if any step or procedure is skipped. Perform all procedures in the order of the steps. Conditions Have two or more valid keys. |
No.4 Programming Procedure Chart - Due To PCM Replacement. Scheme 154
Scheme 154: No.4 Programming Procedure Chart - Due To PCM Replacement
| Step | Procedure | Action after procedure |
|---|
| 1 | REPLACE PCM Refer to PCM removal/installation to perform PCM replacement and configuration. (See PCM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5] .) (See PCM REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO] .) (See PCM REMOVAL/INSTALLATION [SKYACTIV-G 2.0] .) | Go to the next step. |
| 2 | PERFORM PARAMETER RESET Connect the M-MDS (IDS) to the DLC-2. (See M-MDS CONNECTING PROCEDURE .) Turn the ignition switch to the ON position using a key (The key can be either the valid key) NOTE: Although the security light remains illuminated and DTC 23 is displayed after approx. 1 min , continue to perform the procedure as indicated. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Security". Select "PATS Functions". Then, select an item from the screen menu. item Parameter Reset Perform the security access according to the directions on the M-MDS (IDS) screen. Select the replaced parts "PCM" according to the directions on the M-MDS (IDS) screen. CAUTION: At this time, do not select the other parts from the M-MDS menu. After verifying that the PATS function menu is displayed again on the M-MDS (IDS) screen, select "Finish (this menu)". Switch the ignition to off. Switch the ignition to ON. Verify that the security light illuminates for approx. 3 s , and then turns off. Switch the ignition to off. | Go to the next step. |
| 3 | VERIFY THAT THE KEY IS PROGRAMMED TO THE PCM Verify that the engine can be started with all the keys. Can the engine be started? | Yes | Procedure is completed |
| No | Perform the corresponding DTC inspection to repair the malfunctioning part. |
| NOTE |
|---|
| Although the security light remains illuminated and DTC 23 is displayed after approx. 1 min , continue to perform the procedure as indicated. |
| CAUTION |
|---|
| At this time, do not select the other parts from the M-MDS menu. |
No.5 Programming Procedure Due to Instrument Cluster Replacement
| CAUTION | The engine cannot be started if any step or procedure is skipped. Perform all procedures in the order of the steps. |
Note. Since two or more keys need to be programmed to start the engine, program two or more keys after the replacement. Conditions Have two or more keys to be programmed after the replacement.
No.5 Programming Procedure Chart - Due To Instrument Cluster Replacement. Scheme 155
Scheme 155: No.5 Programming Procedure Chart - Due To Instrument Cluster Replacement
| Step | Procedure | Action after procedure |
|---|
| 1 | REPLACE INSTRUMENT CLUSTER. Refer to INSTRUMENT CLUSTER REMOVAL/INSTALLATION to perform instrument cluster replacement and configuration. (See INSTRUMENT CLUSTER REMOVAL/INSTALLATION .) | Go to the next step. |
| 2 | PERFORM PARAMETER RESET Connect the M-MDS (IDS) to the DLC-2. (See M-MDS CONNECTING PROCEDURE .) Turn the ignition switch to the ON position using a key (The key can be either the valid key) NOTE: Although the security light remains illuminated and DTC 15 is displayed after approx. 1 min , continue to perform the procedure as indicated. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Security". Select "PATS Functions". Then, select an item from the screen menu. item Parameter Reset Perform the security access according to the directions on the M-MDS (IDS) screen. Select the replaced parts "IC" according to the directions on the M-MDS (IDS) screen. CAUTION: At this time, do not select the other parts from the M-MDS menu. Verify that the PATS function menu is displayed again on the M-MDS (IDS) screen. | Go to the next step. |
| 3 | CLEAR IGNITION KEY ID NUMBERS Select "Ignition Key Code Erase and Program" from the M-MDS (IDS) screen menu. Clear the ignition key code according to the directions on the M-MDS (IDS). | Go to the next step. |
| 4 | PERFORM IGNITION KEY ID NUMBER PROGRAMMING Program two keys according to the directions on the M-MDS (IDS). After verifying that the PATS function menu is displayed again on the M-MDS (IDS) screen, select "Finish (this menu)". Switch the ignition to off. Switch the ignition to ON. Verify that the security light illuminates for approx. 3 s , and then turns off. Switch the ignition to off. Disconnect the M-MDS (IDS) from the DLC-2. | Go to the next step. |
| 5 | VERIFY THAT ANY KEY IS PROGRAMMED Verify that the engine can be started with all the keys. Can the engine be started? | Yes | Procedure is completed |
| No | Perform the corresponding DTC inspection to repair the malfunctioning part. |
| NOTE |
|---|
| Although the security light remains illuminated and DTC 15 is displayed after approx. 1 min , continue to perform the procedure as indicated. |
| CAUTION |
|---|
| At this time, do not select the other parts from the M-MDS menu. |
No.6 Programming Procedure Due to Simultaneous Replacement of Immobilizer System-related Parts (PCM and Instrument Cluster)
| CAUTION | The engine cannot be started if any step or procedure is skipped. Perform all procedures in the order of the steps. |
Note. Since two or more keys need to be programmed to start the engine, program two or more keys after the replacement. Conditions Have two or more keys to be programmed after the replacement.
No.6 Programming Procedure Chart - Due To Simultaneous Replacement Of Immobilizer System-Related Parts (PCM And Instrument Cluster). Scheme 156
Scheme 156: No.6 Programming Procedure Chart - Due To Simultaneous Replacement Of Immobilizer System-Related Parts (PCM And Instrument Cluster)
| Step | Procedure | Action after procedure |
|---|
| 1 | REPLACE INSTRUMENT CLUSTER. Refer to INSTRUMENT CLUSTER REMOVAL/INSTALLATION to perform instrument cluster replacement and configuration. (See INSTRUMENT CLUSTER REMOVAL/INSTALLATION .) | Go to the next step. |
| 2 | REPLACE PCM Refer to PCM removal/installation to perform PCM replacement and configuration. (See PCM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5] .) (See PCM REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO] .) (See PCM REMOVAL/INSTALLATION [SKYACTIV-G 2.0] .) | Go to the next step. |
| 3 | PERFORM PARAMETER RESET Connect the M-MDS (IDS) to the DLC-2. (See M-MDS CONNECTING PROCEDURE .) Switch the ignition to ON using a valid key. NOTE: Although the security light remains illuminated and DTC 15 is displayed after approx. 1 min , continue to perform the procedure as indicated. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Security". Select "PATS Functions". Then, select an item from the screen menu. item Parameter Reset Perform the security access according to the directions on the M-MDS (IDS) screen. Select the replaced parts according to the directions on the M-MDS (IDS) screen. If the instrument cluster is replaced: Select "IC". If the PCM is replaced: Select "PCM". CAUTION: At this time, do not select the other parts from the M-MDS menu. Verify that the PATS function menu is displayed again on the M-MDS (IDS) screen. | Go to the next step. |
| 4 | CLEAR IGNITION KEY ID NUMBERS Select "Ignition Key Code Erase and Program" from the M-MDS (IDS) screen menu. Clear the ignition key code according to the directions on the M-MDS (IDS). | Go to the next step. |
| 5 | PERFORM IGNITION KEY ID NUMBER PROGRAMMING Program two keys according to the directions on the M-MDS (IDS). After verifying that the PATS function menu is displayed again on the M-MDS (IDS) screen, select "Finish (this menu)". Switch the ignition to off. Switch the ignition to ON. Verify that the security light illuminates for approx. 3 s , and then turns off. Switch the ignition to off. Disconnect the M-MDS (IDS) from the DLC-2. | Go to the next step. |
| 6 | VERIFY THAT ANY KEY IS PROGRAMMED Verify that the engine can be started with all the keys. Can the engine be started? | Yes | Procedure is completed |
| No | Perform the corresponding DTC inspection to repair the malfunctioning part. |
| NOTE |
|---|
| Although the security light remains illuminated and DTC 15 is displayed after approx. 1 min , continue to perform the procedure as indicated. |
| CAUTION |
|---|
| At this time, do not select the other parts from the M-MDS menu. |
No.2 Programming Procedure After PCM Replacement
| CAUTION | The engine cannot be started if any step or procedure is skipped. Perform all procedures in the order of the steps. Conditions Prepare a valid key or an advanced key that can start the engine. |
No.2 Programming Procedure Chart - After PCM Replacement. Scheme 157
Scheme 157: No.2 Programming Procedure Chart - After PCM Replacement
| STEP | Procedure | Action after procedure |
|---|
| 1 | REPLACE PCM Refer to PCM removal/installation to perform PCM replacement and configuration. (See PCM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5] .) (See PCM REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO] .) | Go to the next step. |
| 2 | PERFORM PARAMETER RESET Connect the M-MDS to the DLC-2. (See M-MDS CONNECTING PROCEDURE .) Insert a valid key into the key slot and depress the clutch (MTX)/brake (ATX) pedal. NOTE: Although the security light remains illuminated and DTC 23 is displayed after approx. 1 min , continue to perform the procedure as indicated. The keyless indicator light (green) illuminates for approx. 5 s. NOTE: When a valid advanced key is used, the keyless indicator light (green) illuminates. Within 5 s after verifying that the keyless indicator light (green) illuminates, release the clutch (MTX)/brake (ATX) pedal and switch the ignition ON. CAUTION: When a valid advanced key is used, release the clutch (MTX)/brake (ATX) pedal and switch the ignition ON after verifying that the keyless indicator light (green) illuminates. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Security". Select "PATS Functions". Then, select the following from the screen menu. Item "Parameter Reset" Perform the security access according to the directions on the M-MDS (IDS) screen. Select "PCM" from the replaced parts according to the directions on the M-MDS (IDS) screen. CAUTION: At this time, do not select the other parts from the M-MDS menu. After verifying that the PATS function menu is displayed again on the M-MDS (IDS) screen, select "Finish (this menu)". Switch the ignition off (LOCK). Switch the ignition ON. Verify that the security light illuminates for approx. 3 s , and then turns off. Switch the ignition off (LOCK). Disconnect the M-MDS (IDS) from the DLC-2. | Go to the next step. |
| 3 | VERIFY THAT KEY IS PROGRAMMED TO PCM Verify that the engine can be started with all the keys. Can the engine be started? | Yes | Procedure is completed. |
| No | Perform the corresponding DTC inspection to repair the malfunctioning part. |
| NOTE |
|---|
| Although the security light remains illuminated and DTC 23 is displayed after approx. 1 min , continue to perform the procedure as indicated. |
| NOTE |
|---|
| When a valid advanced key is used, the keyless indicator light (green) illuminates. |
| CAUTION |
|---|
| When a valid advanced key is used, release the clutch (MTX)/brake (ATX) pedal and switch the ignition ON after verifying that the keyless indicator light (green) illuminates. |
| CAUTION |
|---|
| At this time, do not select the other parts from the M-MDS menu. |
No.3 Programming Procedure After Keyless Control Module Replacement
| CAUTION | The engine cannot be started if any step or procedure is skipped. Perform all procedures in the order of the steps. |
Note. Before beginning the procedure, verify that the customer has turned in all of the advanced keys and keys for the vehicle. The engine cannot be started unless an advanced key and two or more keys are programmed after the replacement. Conditions Have two or more keys to be programmed after the replacement. Have one or more advanced keys to be programmed after the replacement.
No.3 Programming Procedure Chart - After Keyless Control Module Replacement. Scheme 158
Scheme 158: No.3 Programming Procedure Chart - After Keyless Control Module Replacement
STEP Procedure Action after procedure 1 REPLACE KEYLESS CONTROL MODULE Refer to keyless control module removal/installation to perform keyless control module replacement and configuration. (See KEYLESS CONTROL MODULE REMOVAL/INSTALLATION .) Go to the next step. 2 PERFORM PARAMETER RESET Connect the M-MDS to the DLC-2. (See M-MDS CONNECTING PROCEDURE .) Remove the valid keys and the valid advanced keys from the vehicle (keep them 1 m or more from the vehicle) and switch the ignition ON according to the directions on the M-MDS screen. Select, "There is no programmed ignition key and programmed advanced key" from the M-MDS screen. CAUTION: If the ignition is switched ON by selecting "FORCED IGNITION ON", the engine cannot be started. Although the security light or the keyless warning light illuminates or flashes, this does not indicate an improper procedure. Continue to perform the procedure as indicated. NOTE: Although the security light flashes, this does not indicate an improper procedure. Continue to perform the procedure as indicated. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Security". Select "PATS Functions". Then, select the following from the screen menu. Item "Parameter Reset" Perform the security access according to the directions on the M-MDS (IDS) screen. Select "RKE" from the replaced parts according to the directions on the M-MDS (IDS) screen. CAUTION: At this time, do not select the other parts from the M-MDS menu. Go to the next step. 3 PERFORM IGNITION KEY ID NUMBER CLEARING Select "Ignition Key Code Erase and Program" from the M-MDS (IDS) screen menu. Clear the ignition key ID number according to the directions on the M-MDS (IDS). Go to the next step. 4 PERFORM IGNITION KEY ID NUMBER PROGRAMMING Program two keys according to the directions on the M-MDS (IDS). Verify that the PATS function menu is displayed again on the M-MDS (IDS) screen. Go to the next step. 5 PERFORM ADVANCED KEY PROGRAMMING Select "Program Additional Advanced Key" from the M-MDS (IDS) screen menu. Program the advanced key according to the directions on the M-MDS (IDS). Verify that the PATS function menu is displayed again on the M-MDS (IDS) screen. Go to the next step. 6 SET UP IMMOBILIZER SYSTEM WITH KEY 1 NOTE: By starting the engine, the immobilizer system is set up and key programming is finished. Start the engine using key 1. Verify that the security light and keyless warning light operate as shown in the following figure. Switch the ignition off (LOCK) and remove key 1. Go to the next step. 7 VERIFY THAT KEY IS PROGRAMMED Start the engine using key 2. Verify that the security light and keyless warning light operate as shown in the following figure. Switch the ignition off (LOCK) and remove key 2. Are there other keys to be programmed? Yes Repeat Step 7 using each programmed key. No Go to the next step. 8 VERIFY THAT ADVANCED KEY IS PROGRAMMED Bring the advanced key into the vehicle. Close all doors. Remove the key from the key slot and place it on the front passenger's seat. Start the engine using the advanced key. Verify that the security light and keyless warning light operate as shown in the following figure. After verifying that the keyless warning light turns off, switch the ignition off (LOCK). Procedure is completed
Scheme 159
No.4 Programming Procedure After Simultaneous Replacement of Immobilizer System-related Parts (PCM, Keyless Control Module)
| CAUTION | The engine cannot be started if any step or procedure is skipped. Perform all procedures in the order of the steps. |
Note. If the keyless control module is replaced, complete the configuration before performing the following menu. If the PCM is replaced, complete the configuration before performing the following menu. When replacing the keyless control module, remove the valid keys and the valid advanced keys from the vehicle (keep them 1 m or more from the vehicle) and switch the ignition ON according to the directions on the M-MDS (IDS) screen. Select, "There is no programmed ignition key and programmed advanced key" from the M-MDS (IDS) screen. CAUTION: If the ignition is switched ON by selecting "FORCED IGNITION ON", the engine cannot be started. Although the security light or the keyless warning light illuminates or flashes, this does not indicate an improper procedure. Continue to perform the procedure as indicated.
| CAUTION | M-MDS menu (1): Parameter Reset (2): Ignition Key Code Erase and Program (3): Program Additional Advanced Key |
| Replacement part | M-MDS execution menu/sequence | Conditions |
|---|
| Keyless control module and PCM | (1) --> (2) --> (3) | Have two or more keys to be programmed after the replacement. Have one or more advanced keys to be programmed after the replacement. |
No.4 Programming Procedure Chart - After Simultaneous Replacement Of Immobilizer System-Related Parts (PCM, Keyless Control Module). Scheme 160
Scheme 160: No.4 Programming Procedure Chart - After Simultaneous Replacement Of Immobilizer System-Related Parts (PCM, Keyless Control Module)
STEP Procedure Action after procedure 1 REPLACE UNIT OR PARTS Replace the unit or parts. Go to the next step. 2 PERFORM PARAMETER RESET Connect the M-MDS (IDS) to the DLC-2. (See M-MDS CONNECTING PROCEDURE .) Switch the ignition off (LOCK) using key 1. NOTE: Although the security light flashes or illuminates and DTC 15 or 23 is displayed after approx. 1 min , continue to perform the procedure. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Body". Select "Security". Select "PATS Functions". Then, select the following from the screen menu. Item "Parameter Reset" Perform the security access according to the directions on the M-MDS (IDS) screen. Select the replaced part according to the directions on the M-MDS (IDS) screen. If the PCM is replaced: Select "PCM". If the keyless control module is replaced: Select "RKE". CAUTION: At this time, do not select the other parts from the M-MDS menu. Go to the next step. 3 PERFORM IGNITION KEY ID NUMBER CLEARING Select "Ignition Key Code Erase and Program" from the M-MDS (IDS) screen menu. Clear the ignition key ID number according to the directions on the M-MDS (IDS). Go to the next step. 4 PERFORM IGNITION KEY ID NUMBER PROGRAMMING Program two keys according to the directions on the M-MDS (IDS). Verify that the PATS function menu is displayed again on the M-MDS (IDS) screen. Go to the next step. 5 PERFORM ADVANCED KEY PROGRAMMING Select "Program Additional Advanced Key" from the M-MDS (IDS) screen menu. Program the advanced key according to the directions on the M-MDS (IDS). Verify that the PATS function menu is displayed again on the M-MDS (IDS) screen. Go to the next step. 6 SET UP IMMOBILIZER SYSTEM WITH KEY 1 NOTE: By starting the engine, the immobilizer system is set up and key programming is finished. Start the engine using key 1. Verify that the security light and keyless warning light operate as shown in the following figure. Switch the ignition off (LOCK) and remove key 1. Go to the next step. 7 VERIFY THAT KEY IS PROGRAMMED Start the engine using key 2. Verify that the security light and keyless warning light operate as shown in the following figure. Switch the ignition off (LOCK) and remove key 2. Are there other keys to be programmed? Yes Repeat Step 7 using each programmed key. No Go to the next step. 8 VERIFY THAT ADVANCED KEY IS PROGRAMMED Bring the programmed key into the vehicle. Close all doors. Remove the key from the key slot and place it on the front passenger's seat. Start the engine using the advanced key. Verify that the security light and keyless warning light operate as shown in the following figure. After verifying that the keyless warning light turns off, switch the ignition off (LOCK). Procedure is completed
