Security System and Locks System: Overview Mazda 3 BL рестайлинг

Locating Locks And Openers Related Components (1 Of 2). Scheme 26

Locating Locks And Openers Related Components (2 Of 2). Scheme 27

Locating Advanced Keyless Entry And Push Button Start System/Immobilizer System Related Components. Scheme 28

Locating Keyless Entry System/Immobilizer System Related Components. Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 30): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION».) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION».) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION».) Front door key cylinder (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION».)
4. Disconnect the keyless antenna connector (With advanced keyless entry and push button start system). (Scheme 31): Locating Keyless Antenna Connector (With Advanced Keyless Entry And Push Button Start System)
5. Remove the front outer handle. (Scheme 32): Front Outer Handle
6. Remove the screw. NOTE: The screw cannot be removed because of the stopper. (Scheme 33): Identifying Front Outer Handle Screw
7. Press down the rod holder in the direction of arrow (1) and remove the front outer handle bracket in the direction of arrow (2). (Scheme 34): Pressing Down Rod Holder
8. Install in the reverse order of removal.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. Fully close the rear door glass.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION».)
4. Remove the service hole cover. (Scheme 35): Identifying Service Hole Cover
5. Remove the screw from the service hole. (Scheme 36): Identifying Service Hole Screw NOTE: The screw cannot be removed because of the stopper.
6. Press the tab on the rear outer handle bracket in the direction of the arrow. (Scheme 37): Pressing Tab On Rear Outer Handle Bracket
7. Maintaining the condition in procedure 6, remove the outer handle garnish. (Scheme 38): Outer Handle Garnish
8. Remove the rear outer handle. (Scheme 39): Rear Outer Handle
9. Loosen the screw. (Scheme 40): Identifying Rear Outer Handle Bracket And Screw
10. Press down the rod holder in the direction of arrow (1) and remove the rear outer handle bracket in the direction of arrow (2). (Scheme 41): Pressing Down Rod Holder
11. Install in the reverse order of removal.

Scheme 42

Scheme 43

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION».)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».)
4. Disconnect the door lock switch connector. (Scheme 42): Identifying Door Lock Switch Connector
5. Disconnect each cable and remove the front inner handle. (Scheme 43): Identifying Door Lock Knob Cable, Inner Handle Cable And Front Inner Handle
6. Install in the reverse order of removal.

Scheme 44

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION».)
3. Disconnect each cable and remove the rear inner handle. (Scheme 44): Identifying Door Lock Knob Cable, Inner Handle Cable And Rear Inner Handle
4. Install in the reverse order of removal.

Scheme 45

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION».)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».)
4. Remove the front inner handle. (See «INNER HANDLE REMOVAL/INSTALLATION».)
5. Remove the screws, then remove the door lock switch. (Scheme 45): Identifying Door Lock Switch, Screws And Front Inner Handle
6. Install in the reverse order of removal.

Scheme 46

Scheme 47

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION».)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».)
4. Remove the front inner handle. (See «INNER HANDLE REMOVAL/INSTALLATION».)
5. Inspect for continuity between the door lock switch terminals using an ohmmeter. (Scheme 46): Door Lock Switch Continuity And Resistance Chart If not as indicated in the table, replace the door lock switch. (Scheme 47): Identifying Door Lock Switch Terminals

Scheme 48

Scheme 49

1. Open the hood.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Disconnect the hood latch switch connector. (vehicles with theft-deterrent system) (Scheme 48): Locating Hood Latch Switch Connector
4. Remove the bolts. (Scheme 49): Identifying Hood Latch And Bolt With Torque Specification
5. Remove the hood latch.
6. Install in the reverse order of removal.
7. Adjust the hood. (See «HOOD ADJUSTMENT».)

Scheme 50

Scheme 51

Scheme 52

1. Pull the hood release lever. (Scheme 50): Pulling Hood Release Lever
2. While maintaining the condition in procedure 1, insert a tape-wrapped flathead screwdriver as shown in the figure, press the ends of the tabs with the screwdriver in the direction of the arrows (1), pull the hood release lever in the direction of arrow (2), and then disconnect the lower panel. (Scheme 51): Pressing Ends Of Tabs CAUTION: Remove the hood release lever while being careful not to damage the hood release cable with the flathead screwdriver.
3. Pull the latch release lever outward, remove it from the lower panel, and then disconnect the hood release cable. (Scheme 52): Identifying Hood Release Cable, Hood Release Lever And Lower Panel
4. Install in the reverse order of removal.

Scheme 53

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the battery tray. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Remove the Front mudguard (LH). (See «FRONT MUDGUARD REMOVAL/INSTALLATION».)
4. Remove the hood release cable from clips A. (Scheme 53): Hood Release Cable And Clips A And B
5. Remove the clips B.
6. Disconnect the hood latch from the hood release cable.
7. Remove the hood release cable from outside of the vehicle.
8. Install in the reverse order of removal.

Scheme 54

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the hood latch. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».)
3. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the hood latch. (Scheme 54): Hood Latch Switch Circuit And Continuity Table

Note. Press the latch lever in using a flathead screwdriver to inspect the closed condition of the hood latch switch. (Scheme 55): Pressing Latch Lever Using Flathead Screwdriver

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. Open the fuel-filler lid.
2. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION».) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION».)
3. Remove the nut. (Scheme 56): Lift Spring And Nut With Torque Specification
4. Remove the lift spring. (Scheme 57): Identifying Lift Spring
5. Pull out the fuel-filler lid opener in the direction of the arrow (1). (Scheme 58): Fuel-Filler Lid Opener
6. Disconnect the fuel-filler lid opener from the fuel-filler lid opener cable. (Scheme 59): Fuel-Filler Lid Opener Cable
7. Install in the reverse order of removal.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. Open the fuel-filler lid.
2. Remove the following parts: Rear scuff plate (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION».) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION».) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION».) Tire house trim (RH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION».) Trunk side upper trim (RH) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION».) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION».) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION».)
3. Remove the nut. (Scheme 60): Lift Spring And Nut With Torque Specification
4. Remove the lift spring. (Scheme 61): Identifying Lift Spring
5. Pull out the fuel-filler lid opener in the direction of the arrow (1). (Scheme 62): Fuel-Filler Lid Opener
6. Disconnect the fuel-filler lid opener from the fuel-filler lid opener cable. (Scheme 63): Fuel-Filler Lid Opener Cable
7. Install in the reverse order of removal.

Scheme 63

Scheme 64

1. Remove the front scuff plate (LH). (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».)
2. Remove the front side trim (LH). (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».)
3. Remove the fuel-filler lid opener bezel. (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION».)
4. Partially peel back the floor covering. (Scheme 64): Fuel-Filler Lid Opener Lever And Floor Covering
5. Remove the bolts. (Scheme 65): Fuel-Filler Lid Opener Lever And Bolts With Torque Specification
6. Disconnect the cable and fuel-filler lid opener lever.
7. Install in the reverse order of removal.

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the following parts: Front seat (LH) (See «FRONT SEAT REMOVAL/INSTALLATION».) Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION».) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION».) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION».) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION».) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION».) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION».) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION».) Fuel-filler lid opener (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION».) Fuel-filler lid opener lever (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION».)
3. Remove the bolts and nut. (Scheme 66): Filler Lid Opener Cable, Bracket, Nut And Bolt With Torque Specification
4. Remove the bracket.
5. Remove the fuel-filler lid opener cable from clips A and B. (Scheme 67): Fuel-Filler Lid Opener Cable And Clips A And B
6. Remove the fuel-filler lid opener cable from clips C.
7. Remove the fuel-filler lid opener cable from clips D and E. (Scheme 68): Fuel-Filler Lid Opener Cable And Clips D And E
8. Remove the fuel-filler lid opener cable from clips F. (Scheme 69): Fuel-Filler Lid Opener Cable And Clips F
9. Install in the reverse order of removal.

Scheme 69

Scheme 70

Scheme 71

Scheme 72

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the following parts: Front seat (LH) (See «FRONT SEAT REMOVAL/INSTALLATION».) Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION».) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION».) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION».) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION».) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION».) Trunk side upper trim (RH) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION».) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION».) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION».) Fuel-filler lid opener (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION».) Fuel-filler lid opener lever (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION».)
3. Remove the bolts and nut. (Scheme 70): Filler Lid Opener Cable, Bracket, Nut And Bolt With Torque Specification
4. Remove the bracket.
5. Remove the fuel-filler lid opener cable from clips A and B. (Scheme 71): Fuel-Filler Lid Opener Cable And Clips A And B
6. Remove the fuel-filler lid opener cable from clips C.
7. Remove the fuel-filler lid opener cable from clips D and E. (Scheme 72): Fuel-Filler Lid Opener Cable And Clips D And E
8. Remove the fuel-filler lid opener cable from clips F. (Scheme 73): Fuel-Filler Lid Opener Cable And Clips F
9. Install in the reverse order of removal.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 74): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION».) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION».) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION».)
4. Remove the service hole cover. (Scheme 75): Identifying Service Hole Cover
5. Remove the tab, then remove the door lock-link bracket. (Scheme 76): Door Lock-Link Bracket And Tab With Torque Specifications
6. Remove the service hole cover. (Scheme 77): Service Hole Cover
7. Remove the screw from the service hole. NOTE: The screw cannot be removed because of the stopper. (Scheme 78): Identifying Service Hole Screw
8. Lift the clip in the direction of the arrow (1), and pull out the key rod in the direction of the arrow (2). (Scheme 79): Pulling Out Key Rod
9. Press the tab on the front outer handle bracket in the direction of the arrow. (Scheme 80): Pressing Tab On Front Outer Handle Bracket
10. Maintaining the condition in Step 9, remove the front key cylinder. (Scheme 81): Front Key Cylinder
11. Using a tape-wrapped fastener remover, press up the collar cap in the direction of the arrow shown in the arrow, press aside the front door key cylinder tabs (1), and remove the collar cover from the front door key cylinder. (Scheme 82): Pressing Up Collar Cap
12. Install in the reverse order of removal.

Scheme 82

Scheme 83

Scheme 84

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 83): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION» ) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION».) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION».) Front door latch and lock actuator (See «FRONT DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION».)
4. Move the rod of the door key cylinder switch in the direction of the arrow shown in the figure, and verify that the continuity is as indicated in the table. (Scheme 84): Door Key Cylinder Switch Circuit And Terminal Identification If not as indicated in the table, replace the front door latch and lock actuator. (Scheme 85): Front Door Latch And Lock Actuator Terminal Continuity And Resistance Chart

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 86): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front inner handle (See «INNER HANDLE REMOVAL/INSTALLATION».) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION».) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION».) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION».)
4. Remove the service hole cover (with front door key cylinder). (Scheme 87): Service Hole Cover
5. Remove the tab, then remove the door lock-link bracket (with front door key cylinder). (Scheme 88): Door Lock-Link Bracket And Nut With Torque Specification
6. Disconnect the key rod from the front outer handle bracket. (Scheme 89): Key Rod And Front Outer Handle Bracket
7. Remove the screw. (Scheme 90): Front Outer Handle Bracket Screw And Clip With Torque Specification
8. Detach the clips.
9. Press down the rod holder of the front door latch and lock actuator in the direction of the arrow. (Scheme 91): Pressing Down Rod Holder Of Front Door Latch And Lock Actuator
10. Maintaining the condition in Step 9, remove the front door latch and lock actuator. see scheme 67: Front Door Latch And Lock Actuator
11. Install in the reverse order of removal.
