Locating HVAC Control System Components (1 Of 2). Scheme 1
Locating HVAC Control System Components (2 Of 2). Scheme 2
Scheme 3
- Set the air intake mode to FRESH.
- Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».)
- Remove the following parts: Front scuff plate (Passenger-side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION».) Front side trim (Passenger-side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION».) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION».) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION».) Lower panel (Passenger-side) (See «LOWER PANEL REMOVAL/INSTALLATION».) Shower duct (Passenger-side) (See «A/C UNIT REMOVAL/INSTALLATION».)
- Disconnect the harness clip from the blower case.
- Disconnect the air intake actuator connector. (Scheme 3): Identifying Air Intake Actuator Connector, Harness Clip And Blower Case
- Remove the blower case. (See «BLOWER MOTOR REMOVAL [FULL-AUTO AIR CONDITIONER]».) (See «BLOWER MOTOR INSTALLATION [FULL-AUTO AIR CONDITIONER]».)
- Remove the screw A.
- Remove the air intake actuator link.
- Remove the screw B.
- Remove the air intake actuator.
- Install in the reverse order of removal.
