Basic System (HVAC): Overview Mazda 3 BL рестайлинг

Identifying HVAC Basic System Components Location - SKYACTIV-G 2.0. Scheme 64

Identifying HVAC Basic System Components Location - MZR 2.0 And MZR 2.5. Scheme 65

Identifying HVAC Basic System Components Location - MZR 2.3 DISI Turbo. Scheme 66

Scheme 67

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]».) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]».) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]».)
2. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION».)
3. Disconnect the evaporator temperature sensor connector.
4. Disconnect the power MOS FET connector. (Full-auto air conditioner)
5. Disconnect the resistor connector. (Manual air conditioner)
6. Remove in the order indicated in the table. (Scheme 67): Identifying Air Filter Removal Sequence
7. Install in the reverse order of removal.

Scheme 68

Scheme 69

1. Insert the air filter projection between the ribs of the A/C unit and assemble the air filter (1) in the order shown in the figure. (Scheme 68): Inserting Air Filter Projection Between Ribs Of A/C Unit And Assemble Air Filter
2. Assemble the air filter (2) in the order shown in the figure. (Scheme 69): Identifying Air Filter Assemble Sequence
