Control System - HVAC (Full Auto Air Conditioner): Overview Mazda 3 BL facelift

Automatic HVAC System 3 illustrations ~215 words

Locating HVAC Control System Components (1 Of 2). Scheme 1

Scheme 1: Locating HVAC Control System Components (1 Of 2)

Locating HVAC Control System Components (2 Of 2). Scheme 2

Scheme 2: Locating HVAC Control System Components (2 Of 2)

Scheme 3

Scheme 3: AIR INTAKE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
  1. Set the air intake mode to FRESH.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-520412-S07601908282013010300000).)
  3. Remove the following parts: Front scuff plate (Passenger-side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-520454-S34787470772013010300000).) Front side trim (Passenger-side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-520454-S10636860092013010300000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-520454-S21271611252013010300000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-520454-S00904275812013010300000).) Lower panel (Passenger-side) (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-520454-S41081192382013010300000).) Shower duct (Passenger-side) (See «A/C UNIT REMOVAL/INSTALLATION»(ref-520443-S01420897172013010300000).)
  4. Disconnect the harness clip from the blower case.
  5. Disconnect the air intake actuator connector. (Scheme 3): Identifying Air Intake Actuator Connector, Harness Clip And Blower Case
  6. Remove the blower case. (See «BLOWER MOTOR REMOVAL [FULL-AUTO AIR CONDITIONER]»(ref-520438-S16615924982013010300000).) (See «BLOWER MOTOR INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-520438-S36906496002013010300000).)
  7. Remove the screw A.
  8. Remove the air intake actuator link.
  9. Remove the screw B.
  10. Remove the air intake actuator.
  11. Install in the reverse order of removal.
