STARTER REMOVAL/INSTALLATION [LF, L3]
| WARNING | When the battery cables are connected, touching the vehicle body with starter terminal B will generate sparks. This can cause personal injury, fire, and damage to the electrical components. Always disconnect the negative battery cable before performing the following operation. |
Scheme 40
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [LF, L3]»(ref-345206-S36173522052009102000000) .)
- Disconnect the negative battery cable.
- Remove the under cover.
- Remove the clutch release cylinder with the pipe still connected. (MTX) (See «MANUAL TRANSAXLE REMOVAL/INSTALLATION [G35M-R]»(ref-345216-S27572314912009102000000) .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Starter Installation Note
Note. If there is peeling on or damage to the insulator, attach a new insulator using the following procedure. Peel off the insulator from the starter completely using a scraper. Degrease the insulator attachment area. Attach a new insulator to the starter.
