Starting System (Lf, L3): Diagnosis Mazda 3 BL

On-vehicle Inspection

1. Verify that the battery is fully charged.
2. The starter is normal if it rotates smoothly and without any noise when the engine is cranked. If the starter does not operate, inspect the following: Remove the starter, and inspect the starter unit. Inspect the related wiring harnesses, the ignition switch, and the transaxle range switch (ATX).

Scheme 22

1. Verify that the battery is fully charged.
2. Connect the starter, battery, and a tester as shown in the figure.
3. Operate the starter and verify that it rotates smoothly. If the starter does not rotate smoothly, inspect the starter unit.
4. Measure the voltage and current while the starter is operating. If not within the specification, replace the starter.

Standard current

VOLTAGE AND CURRENT SPECIFICATION

Pull-out test

Note. Depending on the battery charge condition, the starter motor pinion may rotate while in an extended state. This is due to current flowing to the starter motor through the pull-in coil to turn the starter motor, and does not indicate an abnormality.

Scheme 23

1. Verify that the starter motor pinion is extended while battery positive voltage is connected to terminal S and the starter body is grounded. If the starter motor pinion is not extended, repair or replace the starter.

Scheme 24

1. Disconnect the motor wire from terminal M.
2. Connect battery positive voltage to terminal M and ground the starter body.
3. Pull out the drive pinion with a screwdriver. Verify that it returns to its original position when released. If does not return, repair or replace the starter.

Scheme 25

1. Pull out the drive pinion with battery positive voltage connected to terminal S and the starter body grounded. CAUTION: Applying power for more than 10 s can damage the starter. Do not apply power for more than 10 s.
2. Measure the pinion gap while the drive pinion is extended. If not as specified, adjust with an adjustment washer (between drive housing front cover and magnetic switch). Pinion gap 0.5-2.0 mm {0.02-0.07 in}

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Verify that there is no continuity between the commutator and the core at each segment using a tester. If there is continuity, replace the armature.
2. Verify that there is no continuity between the commutator and the shaft using a tester. If there is continuity, replace the armature.
3. Place the armature on V-blocks, and measure the runout using a dial indicator. Runout 0.05 mm {0.002 in} max.
4. Measure the commutator diameter. If not within the minimum specification, replace the armature. Standard commutator diameter 29.4 mm {1.16 in} Minimum commutator diameter 28.8 mm {1.13 in}
5. Measure the segment groove depth of commutator. If not within the minimum specification, undercut the grooves to the standard depth. Standard depth 0.4-0.6 mm {0.016-0.023 in} Minimum depth 0.2 mm {0.008 in}

Scheme 31

Scheme 32

Scheme 33

1. Inspect for continuity between terminals S and M using a tester. If there is no continuity, replace the magnetic switch.
2. Inspect for continuity between terminal S and the body using a tester. If there is no continuity, replace the magnetic switch.
3. Verify that there is no continuity between terminals M and B using a tester. If there is continuity, replace the magnetic switch.

Scheme 34

Scheme 35

Scheme 36

1. Verify that there is no continuity between each insulated brush and plate using a tester. If there is continuity, replace the brush holder.
2. Measure the brush length. If any brush is worn almost to or beyond the minimum specification, replace all of the brushes. Standard brush length 12.3 mm {0.48 in} Minimum brush length 7.0 mm {0.28 in}
3. Measure the brush spring force using a spring balance. If not within the minimum specification, replace the brush and brush holder component. Standard spring force 18.3-24.9 N {1.87-2.53 kgf, 4.12-5.59 lbf} Minimum spring force 5.9 N {0.6 kgf, 1.3 lbf}

Scheme 37

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

STARTER INTERLOCK SWITCH INSPECTION (MTX)[LF, L3]

Scheme 38

Scheme 39

1. Disconnect the negative battery cable.
2. Disconnect the starter interlock switch connector.
3. Verify that the continuity is as indicated in the table using a tester. If the continuity is not as indicated in the table, replace the starter interlock switch.
