Engine Mechanical -- Lubrication (Lf, L3): Overview Mazda 3 BL

Lubrication System 2 illustrations

Scheme 20

Scheme 20: LUBRICATION SYSTEM LOCATION INDEX [LF, L3]
Scheme 20: LUBRICATION SYSTEM LOCATION INDEX [LF, L3]
1Oil Pressure Switch
2Oil Filter
3Oil Pan
4Oil Strainer
5Oil Pump Component
6Oil Cooler

Scheme 21

Scheme 21: ENGINE OIL LEVEL INSPECTION [LF, L3]
Scheme 21: ENGINE OIL LEVEL INSPECTION [LF, L3]
  1. Position the vehicle on level ground.
  2. Warm up the engine.
  3. Stop the engine and allow approx. 5 min before continuing.
  4. Remove the dipstick and verify that the oil level is between the F and L marks on the dipstick. If the oil level is below the L mark, add engine oil.
