Charging System (Lf, L3): Overview Mazda 3 BL

Scheme 1

Scheme 2

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.

Scheme 3

Scheme 4

1. Install with PCM cover hooks B aligned with the PCM box holes at two points.
2. Install the PCM cover to the PCM box hook.

Scheme 5

1. Assemble the battery clamp so that the arrow on it is pointed toward the front of the vehicle.

Scheme 6

1. Assemble with battery box hooks E aligned with the battery tray holes at two points.

Scheme 7

1. Align the mark of the shroud panel with notch in the battery duct, and install the battery duct to the shroud panel.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Install the battery duct between the battery cover and the battery box.
2. Install with battery cover hooks A aligned with the battery tray holes at two points.
3. Install with battery cover hooks D aligned with the battery tray flange at four points.
4. Set the battery cover to battery tray hooks C at two points.
