Interior Trim: Removal & Installation Mazda 3 BK рестайлинг

Exterior/interior Trim 5 illustrations ~412 words

B-PILLAR LOWER TRIM REMOVAL/INSTALLATION

WARNINGHandling the side air bag sensor improperly can accidentally deploy the side air bag module, which may seriously injure you. Read AIR BAG SYSTEM SERVICE WARNINGS before working around the B-pillar areas. (See AIR BAG SYSTEM SERVICE WARNINGS .)

Note. The side air bag sensor is located in the B-pillar.

Scheme 24

Scheme 24
Scheme 24
  1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) ).
  2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) ).
  3. Pull the area marked A, then remove one side of the B-pillar lower trim.
  4. Pull the B-pillar lower trim outward and remove it.
  5. Install in the reverse order of removal.

Scheme 25

Scheme 25: B-PILLAR UPPER TRIM REMOVAL/INSTALLATION
Scheme 25: B-PILLAR UPPER TRIM REMOVAL/INSTALLATION
  1. Remove the following parts: Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-274503-S40694109052007121800000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-274485-S36482650312007121800000) ).
  2. Partially peel back the seaming welt.
  3. Pull the B-pillar upper trim outward and detach clips A and locator pin B from the body.
  4. Detach the tab from the body and remove the B-pillar trim.
  5. Install in the reverse order of removal.

Scheme 26

Scheme 26: 4 Door
Scheme 26: 4 Door
  1. Remove the rear seat. (See «REAR SEAT REMOVAL/INSTALLATION»(ref-274457-S14827575882007121800000) .)
  2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) ).
  3. Remove the tire house trim. (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-274485-S07747302772007121800000) ).
  4. Partially peel back the seaming welt.
  5. Detach clips A and locator pin B, using a fastener remover.
  6. Detach tabs C, D and E from the body and remove the C-pillar trim.
  7. Install in the reverse order of removal.

Scheme 27

Scheme 27: 5 Door
Scheme 27: 5 Door
  1. Remove the following parts: Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-274457-S14827575882007121800000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S13641334712007121800000) ). Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-274485-S07747302772007121800000) ). Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-274485-S19846250732007121800000) ).
  2. Partially peel back the seaming welt.
  3. Remove the fasteners.
  4. Detach clips A, B and locator pins C, using a fastener remover.
  5. Remove the C-pillar trim.
  6. Install in the reverse order of removal.

Scheme 28

Scheme 28: Driver's Side
Scheme 28: Driver's Side
  1. Disconnect the negative battery cable.
  2. Remove the following parts: A-pillartrim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-274485-S34078087152007121800000) ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-274485-S30785211232007121800000) ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-274485-S23405913072007121800000) ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-274461-S10727308952007121800000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-274485-S04523527642007121800000) ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-274485-S00945702122007121800000) ). Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-274485-S14066994972007121800000) ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-274485-S19981994312007121800000) ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-274417-S07022914612007121800000) .)
  3. Remove the screws.
  4. Pull the dashboard garnish outward, and detach clips A.
  5. Remove the dashboard garnish.
  6. Install in the reverse order of removal.
