Interior Trim: Overview Mazda 3 BK рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect the negative battery cable.
2. Remove the following parts: Front doors (See «FRONT DOOR REMOVAL/INSTALLATION» ) Side wall (See «SIDE WALL REMOVAL/INSTALLATION» ) Console (See «CONSOLE REMOVAL/INSTALLATION» ). Shift lever component (MTX) (See «SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(/mazda/3/bk-2006-2009/remont/manual-trans/#manual-transaxle-shift-mechanism) ) (See «SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(/mazda/3/bk-2006-2009/remont/manual-trans/#manual-transaxle-shift-mechanism).) Selector lever component (ATX) (See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION»(/mazda/3/bk-2006-2009/remont/automatic-trans/#automatic-transaxle-shift-mechanism) ) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). PJB (See «PASSENGER JUNCTION BOX (PJB) REMOVAL/INSTALLATION»(/mazda/3/bk-2006-2009/remont/communication-devices/#control-system-body-accessories) ) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION» ) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION».) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Center panel module (See «CENTER PANEL UNIT REMOVAL/INSTALLATION».) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]» ) (See «CLIMATE CONTROL UNIT REMOVAL [MANUAL AIR CONDITIONER]».)(See «CLIMATE CONTROL UNIT INSTALLATION [MANUAL AIR CONDITIONER]».) LCD unit (See «LCD UNIT REMOVAL/INSTALLATION».) Rear heat duct (1) (See «REAR HEAT DUCT REMOVAL/INSTALLATION» ) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION» ) Car-navigation unit (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION» ) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(/mazda/3/bk-2006-2009/remont/exteriorinterior-trim/#exterior-trim) ) Cowl panel (See «COWL PANEL REMOVAL/INSTALLATION» ) Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION» )
3. Disconnect the dashboard harness connectors.
4. Remove in the order indicated in the illustration. WARNING: Removing the dashboard without supporting it can be dangerous. The dashboard may fall and injure you. Always perform the following procedure with at least another person.
5. Remove the dashboard.
6. Take the dashboard off from the front driver-side door opening.
7. Install in the reverse order of removal.

Scheme 5

Scheme 6

1. Disconnect the connector by pulling it in direction (2) while pressing the tab in direction (1).

Scheme 7

1. Disconnect the connector by pulling it in direction (2) while pressing the tab in direction (1).

Scheme 8

1. Remove the following parts: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ).
2. Detach the fit of the upper column cover from the meter hood rubber.
3. Remove the upper column cover.
4. Remove the ignition key illumination.
5. Remove the screws.
6. Remove the lower column cover.
7. Install in the reverse order of removal.

Scheme 9

1. Remove the front scuff plate. (Passenger's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ).
2. Remove the front side trim. (Passenger's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ).
3. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION» ).
4. Remove the screws.
5. Pull the glove compartment outward and detach clips A and tab B.
6. Remove the glove compartment.
7. Install in the reverse order of removal.

Scheme 10

1. Disconnect the negative battery cable.
2. Detach the hood release lever from the lower panel. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».)
3. Remove the front scuff plate. (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ).
4. Remove the front side trim. (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ).
5. Remove the screw.
6. Pull the lower panel outward, and detach clips A and tab.
7. Disconnect the panel light control switch connector and the headlight leveling switch connector.
8. Remove the lower panel.
9. Install in the reverse order of removal.

Scheme 11

1. Remove the following parts: Front scuff plate (Driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (Driver's side) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ).
2. Detach the fit of the meter hood rubber from the upper column cover.
3. Pull the meter hood outward and detach the tabs A and locator pins B.
4. Remove the meter hood.
5. Install in the reverse order of removal.

Scheme 12

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION».) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION» ). Meter hood (See «METER HOOD REMOVAL/INSTALLATION» ). Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION».) Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION» ).
3. Pull the driver-side ventilator grille outward and remove it.
4. Remove the screw, then remove the driver-side demister grille.
5. Install in the reverse order of removal.

Scheme 13

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION» ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION» ). Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION» ). Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION» ). Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION» ). Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION» ). Dashboard garnish (See «DASHBOARD GARNISH REMOVAL/INSTALLATION» ).
3. Pull the passenger-side ventilator grille outward and remove it.
4. Remove the screw, then remove the passenger-side demister grille.
5. Install in the reverse order of removal.

Scheme 14

1. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION» ).
2. Remove the dashboard center panel. (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION» ).
3. Remove the screws, then remove the center ventilator grilles.
4. Install in the reverse order of removal.

Scheme 15

1. Pull the sail garnish outward and detach clips A.
2. Remove the sail garnish.
3. Install in the reverse order of removal.

Scheme 16

1. Remove the fastener.
2. Detach the tab and remove the side wall.
3. Install in the reverse order of removal.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Disconnect the negative battery cable.
2. Detach clips A, B and C and remove the upper panel.
3. Detach clips D, E and F and remove the boot panel.
4. Remove screws A.
5. Detach clips G.
6. Disconnect the cigarette lighter connector.
7. Remove the ashtray illumination, then remove the ashtray panel.
8. Remove the screws B.
9. Detach tabs H and remove the console.
10. Disconnect the auxiliary jack connector.
11. Disconnect the accessory socket connector.
12. Install in the reverse order of removal.

Scheme 21

1. Disassemble in the order indicated in the illustration.
2. Assemble in the reverse order of disassembly.

Scheme 22

Scheme 23

1. Partially peel back the seaming welt.
2. Detach clips A using a fastener remover.
3. Pull the A-pillar trim and detach clip B (1).
4. Pull the A-pillar trim upward and remove clip B from the A-pillar trim (2).
5. Pull clip B out and rotate it 45° .
6. Remove clip B from the grommet by pulling it upward.
7. Install in the reverse order of removal.
