Wiring diagram: Interior lights — Courtesy lamp circuit Mazda 3 BK
All systems — 28 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.0l 2
- Engine performance 2.3l 2
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Navigation
- Power distribution
- Power mirrors
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 21
Click a component to highlight it on every diagram it appears on.
