Engine Control System: Overview Mazda 3 BK

Testing & Diagnostics 8 illustrations

Scheme 530

Scheme 530: CONTROL SYSTEM LOCATION INDEX

Scheme 531

Scheme 531: California Emission Regulation Applicable Model

Scheme 532

Scheme 532: Except for California Emission Regulation Applicable Model

Scheme 533

Scheme 533: California Emission Regulation Applicable Model

Scheme 534

Scheme 534

Scheme 535

Scheme 535: Except for California Emission Regulation Applicable Model

Scheme 536

Scheme 536

Scheme 537

Scheme 537: PCM REMOVAL/INSTALLATION
  1. When replacing the PCM, perform the following: PCM configuration (See «PCM CONFIGURATION».)
  2. Remove the battery cover, battery duct, battery and battery tray with PCM. (See BATTERY REMOVAL/INSTALLATION .)
  3. Disconnect the PCM connector.
  4. Remove the PCM from the battery tray.
  5. When replacing the PCM on the vehicles, perform the following: PCM parameter reset (See IMMOBILIZER SYSTEM COMPONENT REPLACEMENT/KEY ADDITION AND CLEARING .)
  6. Install in the reverse order of removal.

See also:
RELAY INSPECTION
