Lubrication - Engine Mechanical: Removal & Installation Mazda 3 BK

Lubrication System 11 illustrations ~728 words

ENGINE OIL REPLACEMENT

WARNINGRemove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to used engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONIn case you spill engine oil on the exhaust system, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat.

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Position the vehicle on level ground.
  2. Remove the oil filler cap.
  3. Remove the oil pan drain plug.
  4. Drain the engine oil into a container.
  5. Install the oil pan drain plug with a new washer. Oil Pan Drain Plug Tightening Torque 30-41 N.m {3.0-4.2 kgf.m, 22-30 ft.lbf} NOTE: The amount of residual oil in the engine can vary according to the replacement method, oil temperature, etc. Verify the oil level after engine oil replacement.
  6. Refill the engine with the type and amount of engine oil specified in the figure. Recommended Engine Oil Oil Capacity (Approx. Quantity)
  7. Install the oil filler cap.
  8. Start the engine and confirm that there is no oil leakage. If there is oil leakage, find the cause and repair or replace the applicable part.
  9. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION»(ref-177561-S41250720812005060200000) .)

OIL FILTER REPLACEMENT

WARNINGRemove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to used engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.
CAUTIONIn case you spill engine oil on the exhaust system, wipe it off completely. If you fail to wipe the spilled engine oil, it will produce fumes because of the heat.

OIL PAN REMOVAL/INSTALLATION

WARNINGRemove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to used engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 6

Scheme 6
Scheme 6
  1. Remove the battery cover.
  2. Disconnect the negative battery cable.
  3. Remove the under cover and splash shield as a single unit.
  4. Remove the front tire (RH).
  5. Drain the engine oil. (See «ENGINE OIL REPLACEMENT»(ref-177561-S03762271062005060200000) .)
  6. Remove the plug hole plate. (See PLUG HOLE PLATE REMOVAL/INSTALLATION .)
  7. Remove the drive belt. (See DRIVE BELT REPLACEMENT .)
  8. Position the coolant reserve tank out of the way.
  9. Remove the A/C compressor with the pipes still connected. (See A/C COMPRESSOR REMOVAL/INSTALLATION .)
  10. Remove the ignition coil. (See IGNITION COIL REMOVAL/INSTALLATION .)
  11. Position the accelerator cable bracket out of the way.
  12. Remove the Crankshaft Position (CKP) sensor. (See CRANKSHAFT POSITION (CKP) SENSOR REMOVAL/INSTALLATION .)
  13. Remove the engine front cover. (See TIMING CHAIN REMOVAL/INSTALLATION .)
  14. Remove in the order indicated in the figure.
  15. Install in the reverse order of removal.
  16. Refill the engine with the specified type and amount of the engine oil. (See «ENGINE OIL REPLACEMENT»(ref-177561-S03762271062005060200000) .)
  17. Start the engine and inspect for oil leakage. If the oil leaks, specify the malfunctioning part and repair or replace it.
  18. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION»(ref-177561-S41250720812005060200000) .)
  19. Inspect for the ignition timing and idle speed. (See ENGINE TUNE-UP .)

Scheme 7

Scheme 7: OIL PAN REMOVAL NOTE
Scheme 7: OIL PAN REMOVAL NOTE
  1. Remove the oil pan using the separator tool.

OIL PAN INSTALLATION NOTE

CAUTIONApply the silicon sealant in a single, unbroken line around the whole perimeter. Install the oil pan within 5 min after applying the silicone sealant. Using bolts with the seal adhering could cause cracks in the housing.

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. Completely clean and remove any oil, dirt, sealant or other foreign material that may be adhering to the housing and oil pan.
  2. When reusing oil pan installation bolts, clean any old sealant from the bolts.
  3. Use a square ruler to align the oil pan and the cylinder block junction side on the engine front cover side.
  4. Apply silicone sealant to the oil pan along the inside of the bolt holes as shown. Thickness 2.2-3.2 mm {0.087-0.126 in}
  5. Tighten the bolts in the order shown. Tightening Torque 17-23 N.m {1.8-2.3 kgf.m, 12.6-16.9 ft.lbf}

OIL PUMP REMOVAL/INSTALLATION

WARNINGRemove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. A vehicle that is lifted but not securely supported on safety stands is dangerous. It can slip or fall, causing death or serious injury. Never work around or under a lifted vehicle if it is not securely supported on safety stands. Continuous exposure to used engine oil has caused skin cancer in laboratory mice. Protect your skin by washing with soap and water immediately after working with engine oil.

Scheme 12

Scheme 12
Scheme 12
  1. Remove the battery cover. (See BATTERY REMOVAL/INSTALLATION .)
  2. Disconnect the negative battery cable.
  3. Remove the under cover and splash shield as a single unit.
  4. Remove the front tire (RH).
  5. Drain the engine oil. (See «ENGINE OIL REPLACEMENT»(ref-177561-S03762271062005060200000) .)
  6. Remove the plug hole plate. (See PLUG HOLE PLATE REMOVAL/INSTALLATION .)
  7. Remove the drive belt. (See DRIVE BELT REPLACEMENT .)
  8. Position the coolant reserve tank out of the way.
  9. Remove the A/C compressor with the pipes still connected. (See A/C COMPRESSOR REMOVAL/INSTALLATION .)
  10. Remove the ignition coil. (See IGNITION COIL REMOVAL/INSTALLATION .)
  11. Position the accelerator cable bracket out of the way.
  12. Remove the Crankshaft Position (CKP) sensor. (See CRANKSHAFT POSITION (CKP) SENSOR REMOVAL/INSTALLATION .)
  13. Remove the engine front cover. (See TIMING CHAIN REMOVAL/INSTALLATION .)
  14. Remove the oil pan. (See «OIL PAN REMOVAL/INSTALLATION»(ref-177561-S24883718782005060200000) .)
  15. Remove in the order indicated in the figure.
  16. Install in the reverse order of removal.
  17. Refill the engine with the specified type and amount of the engine oil. (See «ENGINE OIL REPLACEMENT»(ref-177561-S03762271062005060200000) .)
  18. Start the engine and inspect for oil leakage. If the oil leaks, specify the faulty part and repair or replace it.
  19. Inspect the oil level. (See «ENGINE OIL LEVEL INSPECTION»(ref-177561-S41250720812005060200000) .)
  20. Inspect for the ignition timing and idle speed. (See ENGINE TUNE-UP .)

Scheme 13

Scheme 13: OIL PUMP SPROCKET REMOVAL/INSTALLATION NOTE
Scheme 13: OIL PUMP SPROCKET REMOVAL/INSTALLATION NOTE
  1. Install the SST to the oil pump sprocket to stop the oil pump from rotating.

Scheme 14

Scheme 14: OIL PUMP INSTALLATION NOTE
Scheme 14: OIL PUMP INSTALLATION NOTE
  1. Tighten the oil pump bolts in two steps in the order indicated in the figure. Tightening Torque: 1) 8-10 N.m {82-101 kgf.cm, 71-88 in.lbf} 2) 20-25 N.m {2.1-2.5 kgf.m, 15.2-18.4 ft.lbf}
