Interior Trim: Other Mazda 3 BK

Passenger's Side

Scheme 64

Scheme 65

1. Disconnect the negative battery cable and wait for 1 min or more.
2. Remove the following parts: A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-177786-S26159187132005060700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S35097446782005060700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-177786-S00759394172005060700000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-177786-S19547422042005060700000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-177786-S24941703152005060700000) .) Dashboard center panel (See «DASHBOARD CENTER PANEL REMOVAL/INSTALLATION»(ref-177786-S40983131332005060700000) .)
3. Using a flathead screwdriver, pry out the connector stopper plate.
4. Disconnect the passenger-side air bag module connector.
5. Remove the bolts and screws.
6. Pull the dashboard garnish outward, and detach clips A.
7. Remove the dashboard garnish.
8. Install in the reverse order of removal.

Scheme 66

1. Pull the decoration panel outward and detach the clips A and tab B in the order shown in the figure.
2. Remove the decoration panel.
3. Install in the reverse order of removal.

Scheme 67

1. Disconnect the negative battery cable.
2. Remove the decoration panel. (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-177786-S19547422042005060700000) .)
3. Remove the screws.
4. Pull the dashboard center panel outward and detach clips A and locator pins B.
5. Disconnect the hazard warning switch connector.
6. Remove the dashboard center panel.
7. Install in the reverse order of removal.

Scheme 68

1. Pull the sail garnish outward and detach clips A.
2. Remove the sail garnish.
3. Install in the reverse order of removal.

Scheme 69

Scheme 70

1. Disconnect the negative battery cable. (Vehicle with power window system or power outer mirror)
2. Using a small flathead screwdriver, open the cap and remove the screw, then remove the inner handle cover.
3. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-177786-S25101290202005060700000) .)
4. Remove the regulator handle. (Vehicle without power window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .)
5. Using a small flathead screwdriver, open the cap and remove the screw.
6. Detach clips A from the front door using a fastener remover.
7. Pull the front door trim upward and detach tabs B from the front door.
8. Disconnect the power window main switch connector and power outer mirror switch connector (LH). (Vehicle with power window system or power outer mirror)
9. Disconnect the power window subswitch connector (RH). (Vehicle with power window system)
10. Remove the front door trim.
11. Install in the reverse order of removal.

Scheme 71

Scheme 72

1. Disconnect the negative battery cable. (Vehicle with power window system)
2. Using a small flathead screwdriver, open the cap and remove the screw, then remove the inner handle cover.
3. Remove the sail garnish. (5 door) (See «SAIL GARNISH REMOVAL/INSTALLATION»(ref-177786-S22115692032005060700000) .)
4. Remove the regulator handle. (Vehicle without power window system) (See REGULATOR HANDLE REMOVAL .) (See REGULATOR HANDLE INSTALLATION .)
5. Using a small flathead screwdriver, open the cap and remove the screw.
6. Detach clips A from the front door using a fastener remover.
7. Pull the rear door trim upward and detach tabs B from the rear door.
8. Disconnect the power window subswitch connector. (Vehicle with power window system)
9. Remove the rear door trim.
10. Install in the reverse order of removal.

Scheme 73

1. Remove the fasteners, then remove the trunk lid trim.
2. Install in the reverse order of removal.

Scheme 74

Scheme 75

1. Remove the fasteners.
2. Pull the trunk end trim upward, then detach clips A, locator pins B and tabs.
3. Remove the trunk end trim.
4. Install in the reverse order of removal.

Scheme 76

1. Remove the following parts: Rear seat (See REAR SEAT REMOVAL/INSTALLATION .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S15571640632005060700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-177786-S13536083402005060700000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-177786-S31599506232005060700000) .) Service hole cover (LH)
2. Remove the fasteners, then remove the trunk side trim.
3. Install in the reverse order of removal.

Scheme 77

Scheme 78

1. Remove the following parts: Rear seat (See REAR SEAT REMOVAL/INSTALLATION .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S15571640632005060700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-177786-S13536083402005060700000) .) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-177786-S31599506232005060700000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-177786-S35215762612005060700000) .) Cargo compartment light (See CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION .)
2. Remove the screws, then remove the trunk board.
3. Remove the screws, then remove the cargo net hooks.
4. Remove the fasteners.
5. Detach the clip A and remove the trunk side trim.
6. Install in the reverse order of removal.

Scheme 79

Scheme 80

1. Disconnect the negative battery cable. (RH only)
2. Remove the rear seat belt lower bolt.
3. Detach the tabs and remove the cover from the trunk side upper trim.
4. Remove the cap and remove the screw.
5. Remove the fastener.
6. Pull the trunk side upper trim outward, then disengage tabs B and C from the C-pillar trim.
7. Pull the trunk side upper trim outward, then disengage clips A from the body.
8. Install in the reverse order of removal.

Scheme 81

1. Pull the liftgate upper trim outward, then detach the clips A, B and the locator pin C from the liftgate.
2. Remove the liftgate upper trim.
3. Install in the reverse order of removal.

Scheme 82

Scheme 83

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-177786-S12080296982005060700000) .)
2. Pull the point A of the strap hanger as shown in the figure.
3. Remove the strap hanger.
4. Pull the liftgate side trim outward and detach clip A, locator pin B.
5. Detach the tab C and remove the liftgate side trim.
6. Install in the reverse order of removal.

Scheme 84

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-177786-S12080296982005060700000) .)
2. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-177786-S15677368382005060700000) .)
3. While supporting at point A, pull the recess in the direction of the arrow and remove it.
4. Remove the fasteners.
5. Pull the liftgate lower trim outward, then detach clips B and locator pins C from the liftgate.
6. Remove the liftgate lower trim.
7. Install in the reverse order of removal.

Scheme 85

Scheme 86

1. Partially peel back the seaming welt.
2. Detach clips A using a fastener remover.
3. Pull the A-pillar trim and detach clip B (1).
4. Pull the A-pillar trim upward and remove clip B from the A-pillar trim (2).
5. Pull clip B out and rotate it 45°.
6. Remove clip B from the grommet by pulling it upward.
7. Install in the reverse order of removal.
