Service Specifications
| Application | Specification |
|---|
| Compressor Type | ATMOS GU10 |
| Compressor Magnetic Clutch Air Gap | 0.014-0.029" (0.35-0.75 mm) |
| Compressor Oil Capacity | 5.24 Ozs. |
| Magnetic Clutch Gap | 0.012-0.019" (0.30-0.50 mm) |
| Pressure Relief Valve | (1) |
| Refrigerant (R-134a) Capacity | 16.8-18.5 ozs. |
| Refrigerant Pressure Switch |
| On |
| Low Side | 25.53-36.31 psi (176-250 kPa) |
| High Side | 57-114 psi (393-786 kPa) |
| Off |
| Low Side | 25.53-31.31 psi (176-216 kPa) |
| High Side | 427-463 psi (2944-3192 kPa) |
| System Oil Capacity | (1) |
| System Operating Pressures (2) |
| High Side | 180-264 psi (1241-1820 kPa) |
| Low Side | 12-23 psi (83-159 kPa) |
| (1) Information not available from manufacturer. (2) Specification is with ambient temperature at 86°F (30°C) and engine speed at 1500 RPM. Specifications are approximate. |
| (1) | Information not available from manufacturer. |
| (2) | Specification is with ambient temperature at 86°F (30°C) and engine speed at 1500 RPM. Specifications are approximate. |
A/C SYSTEM SPECIFICATIONS
Torque Specifications
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Mounting Bolts | 13-20 (18-27) |
| INCH Lbs. (N.m) |
| A/C Line-To-Condenser Core | 61-87 (7-10) |
| A/C Manifold & Tube-To-Evaporator Bolt | 61-88 (7-10) |
| Clutch Hub Bolt | 108 (12) |
| Condenser Core Mounting Bolt | 71-106 (7-12) |
| Expansion Valve Bolt | 31-48 (4-5) |
| High/Low Hose-To-Compressor Bolt | 61-88 (7-10) |
| Receiver Drier Bolt | 61-88 (7-10) |
A/C SYSTEM TORQUE SPECIFICATIONS
Scheme 1
Scheme 1: HEATER, VENTILATION & AIR CONDITIONING (HVAC) SST
