Wheel Alignment System: Adjustments Mazda 2 II рестайлинг

Front wheel alignment (unloaded)

Scheme 2

1. Loosen the locknut of the tie-rod end.
2. Remove the rack boot clamp.
3. Rotate the tie rod and adjust the steering angle. NOTE: The travel distance of the right and left tie rods should be the same.
4. Rotate the tie rod and adjust so that the length L shown in the figure is within the specification. (Scheme 2): Identifying Tie Rod Adjusting Length Standard 29.6-45.6 mm {1.17-1.79 in}
5. Tighten the locknut of the tie-rod end. Tightening torque 69-98 N m {7.1-9.9 kgf m, 51-72 ft lbf}
6. Correct the rack boot twists.
7. Install and fix the rack boot clamp.
8. After adjusting the steering angle, always inspect and adjust the toe angle.

Total Toe-in Adjustment

1. Loosen the locknut of the tie-rod end.
2. Remove the rack boot clamp.
3. Adjust the total toe-in by rotating each tie rod (left and right) in the opposite directions by the same amount respectively. NOTE: Toe angle changes by approx. 6 mm {0.2 in} per one rotation of the tie rod for one wheel. Each tie rod has a right-hand thread. When increasing the toe-in angle, rotate the right tie rod toward the front of the vehicle and rotate the left tie rod toward the rear of the vehicle by the same amount.
4. Tighten the locknut of the tie-rod end. Tightening torque 69-98 N m {7.1-9.9 kgf m, 51-72 ft lbf}
5. Verify that the rack boot does not have any twisting and install the rack boot clamp.

Rear wheel alignment (unloaded)*
