Front Suspension System: Removal & Installation Mazda 2 II рестайлинг

Suspension Front 3 illustrations ~272 words

Bolt (ABS Wheel-Speed Sensor) Removal Note

  1. Remove the ABS wheel-speed sensor installation bolt, then remove the ABS wheel-speed sensor from the steering knuckle.

Scheme 23

Scheme 23: ABS Wheel-Speed Sensor Removal Note
  1. Disconnect the steering knuckle from the shock absorber.
  2. While pressing the tabs (2 locations) of the ABS wheel-speed wiring harness sensor clip, remove the ABS wheel-speed sensor wiring harness from the shock absorber. (Scheme 23): Abs Wheel-Speed Sensor Wiring Harness At Shock Absorber
  3. Remove the ABS wheel-speed sensor wiring harness grommet from the shock absorber.
  4. Move the ABS wheel-speed sensor to a place out of the way.

Scheme 24

Scheme 24: ABS Wheel-Speed Sensor, Bolt (Lower End Of Shock Absorber), Bolt (ABS Wheel-Speed Sensor) Installati
  1. Install the steering knuckle to the shock absorber, insert the bolts from the direction shown as follows, then tighten them to the specified torque. Vehicle left side: Insert the bolts from the vehicle rear. Vehicle right side: Insert the bolts from the vehicle front.
  2. Install the ABS wheel-speed sensor wiring harness grommet to the shock absorber as shown in the figure. (Scheme 24): ABS Wheel-Speed Sensor Wiring Harness Grommet At Shock Absorber
  3. Install the ABS wheel-speed sensor wiring harness clip to the shock absorber.
  4. Install the ABS wheel-speed sensor to the steering knuckle, then tighten the bolt (ABS wheel-speed sensor) to the specified torque.
  5. Verify that the ABS wheel-speed sensor wiring harness is not twisted.

Scheme 25

Scheme 25: FRONT SHOCK ABSORBER AND COIL SPRING DISASSEMBLY/ASSEMBLY
  1. Remove the front shock absorber and coil spring. (See «FRONT SHOCK ABSORBER AND COIL SPRING REMOVAL/INSTALLATION»(ref-517468-S14779769462012121200000).)
  2. Disassemble in the order indicated in the table.
  3. Assemble in the reverse order of removal.
  4. Inspect the wheel alignment and adjust it if necessary. (See «FRONT WHEEL ALIGNMENT»(ref-517479-S08987345662012121200000).) (Scheme 25): Exploded View Of Front Shock Absorber And Coil Spring
