Security System and Locks System: Overview Mazda 2 II рестайлинг

Door Locks & Anti-Theft Systems 10 illustrations ~341 words
Scheme 6: Identifying Locks And Openers Related Components (1 Of 2)
Scheme 7: Identifying Locks And Openers Related Components (2 Of 2)

Keyless Entry System and Immobilizer System [Keyless Entry System]

Identifying Keyless Entry System And Immobilizer System Related Components. Scheme 8

Scheme 8: Identifying Keyless Entry System And Immobilizer System Related Components

Scheme 9

Scheme 9: FRONT OUTER HANDLE REMOVAL/INSTALLATION

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15
  1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 110 mm {4.33 in}. (Scheme 9): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
  2. Disconnect the negative battery cable.
  3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION».) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION».) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(/mazda/2/ii-2010-2014/remont/entertainment-systems/#entertainment-system).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION».) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION».) Rod protector (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION».) Front door key cylinder (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION».)
  4. Press the hook on the front outer handle bracket in the direction of the arrow. (Scheme 10): Pressing Hook On Front Outer Handle Bracket
  5. Maintaining the condition in procedure 4, remove the front outer handle. (Scheme 11): Removing Front Outer Handle
  6. Remove the handle protector and handle seat. (Scheme 12): Identifying Handle Protector And Handle Seat
  7. Remove the double-sided adhesive tape from the handle protector and body. (See «Outer handle bracket Installation Note».)
  8. Remove the service hole cover. (Scheme 13): Identifying Service Hole Cover
  9. Remove the screw from the service hole. NOTE: The screw cannot be removed because of the stopper. (Scheme 14): Identifying Screw Of Service Hole
  10. Press down the rod holder in the direction of arrow (1) and remove the front outer handle bracket in the direction of arrow (2).(See «Outer handle bracket Installation Note».) (Scheme 15): Pressing Down Rod Holder
  11. Install in the reverse order of removal.
