Scheme 236

The transaxle shift control linkage consists of

1. A shift cable that connects the transaxle range selector lever to the floor shifter assembly.
2. A brake shift interlock actuator that is integral to the floor shifter assembly.

The floor shifter assembly

1. Locks the transaxle range selector lever in the PARK position when the ignition switch is in the LOCK position.
2. Requires the transaxle range selector lever to be in the PARK position to turn the ignition switch to the LOCK position.

SPECIAL TOOL(S) DESCRIPTION 73 III Digital Multimeter 105-R0057 or equivalent Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Inspection and Verification

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom. GO to «SYMPTOM CHART»(/lincoln/zephyr/us-2006-2006/remont/automatic-trans/#automatic-transaxletransmission-external-controls__symptom-chart) . VISUAL INSPECTION CHART Mechanical Electrical Transmission shift cable Manual control lever Transmission control module out of adjustment (6-speed transaxle) Fuse Connections Wiring harness Brake pedal position (BPP) switch Shift lock actuator

DIAGNOSTIC TROUBLE CODE (DTC) CHART

Symptom Chart

SYMPTOM CHART

Scheme 237

CIRCUIT FUNCTION REFERENCE CHART

Scheme 238

Scheme 239

1. A1 TEST THE BRAKE LIGHTS Apply the brake pedal and view the brake lights. Do the brake lights illuminate? Yes : GO to A2. No : REFER to «EXTERIOR LIGHTING»(/lincoln/zephyr/us-2006-2006/remont/exterior-lights/#exterior-lighting) .
2. A2 TEST SHIFT INTERLOCK ACTUATOR POWER CIRCUIT Disconnect: Floor Shifter Harness Connector C3245. Key in ON position. Measure the voltage between floor shifter harness connector C3245-1, vehicle harness side and ground, while applying the brake pedal. Is the voltage greater than 10 volts? Yes : GO to A3. No : REPAIR the circuit. TEST the system for normal operation.
3. A3 TEST SHIFT INTERLOCK ACTUATOR GROUND CIRCUIT Key in OFF position. Measure the resistance between floor shifter harness connector C3245-4, vehicle harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new selector lever. Refer to «SELECTOR LEVER»(/lincoln/zephyr/us-2006-2006/remont/automatic-trans/#automatic-transaxletransmission-external-controls) No : REPAIR the circuit. TEST the system for normal operation.

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

1. Disconnect the selector lever cable end from the manual lever.
2. Place the manual control lever in DRIVE. Place the manual control lever in PARK. Move the manual control lever counterclockwise 3 detents to the DRIVE position.
3. Disconnect the selector lever cable end from the manual lever.
4. Place the manual control lever in NEUTRAL. Place the manual control lever in PARK. Move the manual control lever clockwise 3 detents to the DRIVE position.
5. Place the gear selector lever in DRIVE.
6. Unlock the adjuster by sliding the locking tab over.
7. Slide the cable end forward or backward to align it with the manual lever.
8. With the adjuster locking tab released connect the selector lever cable end to the manual lever.
9. Slide the release tab back to lock the adjuster.
10. Verify that the vehicle starts in PARK and NEUTRAL only and that the reverse lamps illuminate in REVERSE.

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

1. Remove the heater core and evaporator core housing. For additional information, refer to «CLIMATE CONTROL»(/lincoln/zephyr/us-2006-2006/remont/automatic-hvac-system/#climate-control) .
2. Remove the restraint control module (RCM). For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/lincoln/zephyr/us-2006-2006/remont/airbag/#supplemental-restraint-system) .
3. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/lincoln/zephyr/us-2006-2006/remont/body-electrical/#battery-mounting-and-cables) .
4. Disconnect the selector lever cable end from the manual lever.
5. Release the 2 tabs and remove the selector lever cable from the selector lever cable bracket.
6. Disconnect the selector lever cable end from the manual lever.
7. Release the 2 tabs and remove the selector lever cable from the selector lever cable bracket.
8. Disconnect the 2 wiring harness fasteners and position the RCM wiring harness aside.
9. Position the insulation away from the bulkhead to gain access to the 2 selector lever cable bracket nuts.
10. Remove the 2 selector lever cable grommet nuts and remove the selector lever cable through the interior of the vehicle.

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

1. Position the selector lever cable in place and install the 2 nuts. Tighten to 8 Nm (71 lb-in).
2. Position the insulation in place over the selector lever cable grommet.
3. Position back the RCM wiring harness and install the fasteners on the studs.
4. Position the selector lever cable in the bracket.
5. Install the selector lever cable end on the manual lever.
6. Install the selector lever cable in the bracket. Be sure the tabs are locked in place.
7. Connect the selector lever cable end on the manual lever.
8. Install the battery and battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/lincoln/zephyr/us-2006-2006/remont/body-electrical/#battery-mounting-and-cables) .
9. Install the RCM. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(/lincoln/zephyr/us-2006-2006/remont/airbag/#supplemental-restraint-system) .
10. Install the heater core and evaporator core housing. For additional information, refer to «CLIMATE CONTROL»(/lincoln/zephyr/us-2006-2006/remont/automatic-hvac-system/#climate-control) .
11. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(/lincoln/zephyr/us-2006-2006/remont/automatic-trans/#automatic-transaxletransmission-external-controls) .

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

1. Remove the center console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/lincoln/zephyr/us-2006-2006/remont/gauges-instrument-panels/#instrument-panel-and-console) .
2. Disconnect the selector lever cable end from the selector lever.
3. Release the tab on the selector lever cable and remove it from the selector lever housing.
4. Disconnect the electrical connector.
5. Remove the 4 nuts and remove the selector lever.

Scheme 266

Scheme 267

Scheme 268

1. Install the selector lever and the 4 nuts. Tighten to 12 Nm (9 lb-ft).
2. Connect the electrical connector.
3. Install the selector lever cable in the selector lever housing.
4. Connect the selector lever cable end to the selector lever.
5. Install the center console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/lincoln/zephyr/us-2006-2006/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Adjust the selector lever cable, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(/lincoln/zephyr/us-2006-2006/remont/automatic-trans/#automatic-transaxletransmission-external-controls) .

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

1. Remove the PRNDL trim ring.
2. Remove the upper console panel.
3. Remove the power outlet trim panel from the center console.
4. Disconnect the electrical connector and remove the power outlet trim panel.
5. Slide the lower shift knob bezel downward.
6. Remove the 2 bolts and remove the selector lever knob.
7. Remove the lower shift knob bezel.
8. Disconnect the light from the PRNDL bezel.
9. Disconnect the LED electrical connector.
10. Release the 3 tabs and remove the PRNDL bezel.

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

1. Install the PRNDL bezel. Make sure that the 3 locking tabs are locked in place.
2. Connect the LED electrical connector.
3. Connect the light to the PRNDL bezel.
4. Install the lower shift knob bezel.
5. Install the shift knob and the bolts.
6. Slide the lower shift knob bezel up and snap it into place.
7. Connect the power outlet electrical connector.
8. Install the power outlet trim panel in the center console.
9. Install the upper console panel.
10. Install the PRNDL trim ring.

Scheme 289

Scheme 290

Scheme 291

1. Slide the lower shift knob bezel downward.
2. Remove the 2 bolts and lift up on the shift knob to remove.

Scheme 292

Scheme 293

1. Install the shift knob and the 2 bolts.
2. Slide the lower shift knob bezel up and snap it into place.
