Identification Codes Lincoln Town Car III рестайлинг

Scheme 1

The vehicle identification number (VIN) is a 17-digit combination of letters and numbers. The VIN is stamped on a metal tab riveted to the instrument panel, top upper left of the dash. The VIN number is also found on the vehicle certification (VC) label.

Scheme 2

Scheme 3

The first 3 vehicle identification number (VIN) positions are the world manufacturer identifier (WMI).

1. 1LN - Lincoln, USA, passenger car
2. 1LJ - Lincoln, USA, incomplete vehicle, Hearse
3. 1L1 - Lincoln, USA, Limousine

Scheme 4

The fourth VIN position is the vehicle restraint system type code.

1. F - Active safety belts - all positions, driver and front passenger air bags (limousine/hearse)
2. H - Active safety belts - all positions, driver and front passenger air bags with driver and front passenger side impact air bags

Scheme 5

Positions 5 through 7 indicate vehicle line and series code.

1. M81 - Signature Series
2. M82 - Signature Limited Series
3. M83 - Signature Designer Series
4. M84 - Executive Series (long wheelbase)
5. M85 - Signature Series (long wheelbase)
6. M88 - Executive Series (fleet)

Scheme 6

The eighth VIN position is the engine displacement and number of cylinders code.

1. W - 4.6L EFI (SOHC), EFI, 8-cylinder
2. V - 4.6L EFI (SOHC), EFI, 8-cylinder (flex-fuel)

Scheme 7

The ninth VIN position is a computer-generated check digit code (0-9).

Scheme 8

The tenth VIN position is the model year code.

1. 7 - 2007

Scheme 9

The eleventh VIN position is the assembly plant code.

1. Y - Wixom, Michigan (USA)

Scheme 10

The last 6 VIN positions are the production sequence number. These numbers determine the vehicle build order and provide warranty information.

1. 600001-999999

Scheme 11

The upper portion of the vehicle certification (VC) label contains the manufacturer name, the month and year of manufacture, the certification statement and the VIN. It also includes gross vehicle weight ratings (GVWR). The VC label is located on the front left-hand door jamb.

Scheme 12

Scheme 13

Paint codes are listed as a 2-part code. The first set of characters listed indicate the vehicle primary body color. The second set of characters listed (if applicable) indicate a 2-tone or accent body color. All colors are base coat/clear coat.

Primary Body Color Codes

1. DX - Dark Blue Pearl
2. G3 - Pueblo Gold
3. G4 - Cashmere (tri-coat)
4. HH - Dark Cherry
5. JP - Silver Birch
6. LS - Light Ice Blue Metallic
7. PV - White Chocolate (tri-coat)
8. T3 - Satellite Silver Pearl
9. T7 - Charcoal Beige Metallic
10. UA - Ebony
11. WT - Performance White

2-Tone Color Codes

1. G3 - Pueblo Gold
2. JP - Silver Birch Metallic

Scheme 14

The interior trim codes are listed below. The first digit indicates the interior fabric. The second digit indicates the interior color.

1. D - Provence leather with logo
2. Q - Nudo leather

The interior trim colors are

1. G - Greystone/Medium-Light Stone
2. K - Medium Camel/Light Camel
3. N - Charcoal Black
4. S - Shale/Dove

Scheme 15

Tape and paint stripe codes do not apply.

Scheme 16

The radio type codes are

1. B - AM/FM stereo with in-dash 6-disc compact disc (CD) changer
2. K - Premium electronic AM/FM stereo with cassette, CD player and clock
3. Z - Electronic AM/FM stereo with CD player and clock

Scheme 17

The axle ratios are

1. 27 - 3.27 conventional
2. 55 - 3.55 locker

Scheme 18

The transmission code is

1. H - 4-speed automatic overdrive, 4R75E (Sharonville)
2. U - 4-speed automatic overdrive, 4R75E (Livonia)

Scheme 19

Lincoln Town Car uses a rear air suspension. Only front spring codes are listed.

1. Base part number - 18B036

Scheme 20

Note. Powertrain calibration information is limited to a maximum of 5 characters per line on the Vehicle Certification Label. Because of this, calibration identification consisting of more than 5 characters will wrap to the second line on the VC label.

Powertrain calibration information is printed in the lower right corner of the Vehicle Certification Label. Only the base calibration information is printed. Revision levels will not appear, however, they can be found in On Line Automotive Service Information System (OASIS). For the current model year, Ford Motor Company is using 3 different protocols which describe powertrain base calibration. These protocols are designed to provide worldwide standardization for vehicle calibration. If the electronic calibration strategy has been used since 1998 and carried into the current model year, Protocol 1 will be used. Refer to Protocol 1 below. (Scheme 21) If the electronic calibration strategy has been used since 1999 and is carried into the current model year, Protocol 2 will be used. Refer to Protocol 2 below. (Scheme 22) For electronic calibration strategies introduced since the 2000 model year, use Protocol 3. Refer to Protocol 3 below. (Scheme 23)

Scheme 21

Scheme 22

Scheme 23

The following offers a more detailed explanation of the coding strategy used for Protocol 3.

Model Year

1. 0 - 2000
2. 1 - 2001
3. 2 - 2002
4. 3 - 2003
5. 4 - 2004
6. 5 - 2005
7. 6 - 2006
8. 7 - 2007

Vehicle Line

1. VC - Lincoln Town Car

Transmission

1. 1 - Automatic transmission

Unique Calibration

The Emission/CAFE/CO2 Compliance Department is responsible for assigning these calibration numbers. Unique calibration identifications are assigned to cover similar vehicles to differentiate between tires, drive configurations, final drive ratios and other certification-significant factors.

These 2 characters are chosen by the analyst to provide easily identifiable information unique to each calibration. For example, using the number 2 to denote a 2-valve engine versus using the number 4 to denote a 4-valve engine provides an easily identifiable difference.

Fleet Code

1. 0 - Certification (U.S. 4K, final sale in an export market)
2. 1 - HDGE/Dyno
3. 2 - Fast AMA U.S.
4. 3 - ADP U.S.
5. 4 - Not assigned
6. 5 - Not assigned
7. 6 - Evaporative emissions
8. 7 - MACAA
9. 8 - On-board diagnostics
10. 9 - Not assigned

Certification Region

1. 5 - U.S. 50 states
2. A - U.S. federal, including altitude, may include Canada, may include Mexico
3. B - U.S. California standard, includes U.S. green states
4. C - Canada
5. D - China
6. G - Gulf Cooperative Council (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia and UAE)
7. H - Hong Kong
8. J - Japan
9. K - Korea
10. L - Malaysia
11. M - Mexico
12. N - New Zealand
13. P - Australia
14. Q - South America (Brazil)
15. S - Singapore
16. T - Taiwan
17. U - South America (unleaded fuel regions)
18. V - Vietnam
19. X - Rest of world (ROW)
20. Y - Military
21. Z - Israel

Revision Level (not printed on label)

1. 91-99 - Hardware and certification levels
2. 01-04 - Preliminary levels
3. 00 - Job 1 production (initial certification)
4. 05-09 - Pre-job 1 revisions to calibrations
5. 10-89 - Post-job 1 revisions to calibrations
6. 0B - Durability test level
7. BD - On-board diagnostics (OBD) intermediate level (pre-05)
