BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| Accessory Delay Relay | In battery junction box. (Scheme 27) |
| A/C Clutch Relay | In battery junction box. (Scheme 27) |
| Air Suspension Compressor Relay | In battery junction box. (Scheme 27) |
| Blower Motor Relay | In battery junction box. (Scheme 27) |
| Fuel Pump Relay | In battery junction box. (Scheme 27) |
| Horn Relay | In battery junction box. (Scheme 27) |
| Ignition Coils Relay | In battery junction box. (Scheme 27) |
| PCM Power Relay | In battery junction box. (Scheme 27) |
| Rear Window Defrost Relay | In central junction box. (Scheme 26) |
| Starter Relay | In battery junction box. (Scheme 27) |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location |
|---|---|
| A/C Compressor Clutch Diode | In battery junction box (BJB). (Scheme 27) |
| Battery Junction Box (BJB) | At right of engine compartment. (Scheme 1) |
| Central Junction Box | Behind left side of dash, to left of steering column. (Scheme 9) |
| Fusible Link A | Right front of engine. (Scheme 2) |
| Ground Diode | In battery junction box (BJB). (Scheme 27) |
| Ignition Transformer Capacitor | Left front of engine. (Scheme 3) |
| PCM Power Diode | In battery junction Box (BJB). (Scheme 27) |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| ABS Control Module | Left side of engine compartment. (Scheme 2) |
| Air Suspension Module | Under lower center of dash. (Scheme 1) |
| Audio/Navigation Control Unit | Behind center of dashboard. (Scheme 9) |
| Door Lock Unit, Driver Side Front | Bottom rear of driver's door. (Scheme 20) |
| Door Lock Unit, Left Rear | Left rear door. (Scheme 22) |
| Door Lock Unit, Passenger Side Front | Bottom rear of right front door. (Scheme 21) |
| Door Lock Unit, Right Rear | Rear of right rear door. (Scheme 23) |
| Driver Door Module | In top front of left front door. (Scheme 20) |
| Driver Seat Module | Under driver's seat. (Scheme 13) |
| EGR System Module (ESM) | Top of engine. (Scheme 5) |
| Electronic Automatic Temperature Control (EATC) Module | Behind center of dash. (Scheme 10) |
| Electronic Throttle Control (ECT) Module | Top left rear of engine. (Scheme 3) |
| Engine Cooling Fan Module | Front of engine compartment. (Scheme 2) |
| Front Blower Motor Speed Controller | In right rear of engine compartment, on evaporator housing. (Scheme 7) |
| Fuel Pump Driver Module | At left side of trunk. (Scheme 14) |
| Heated Seat Module, Left Rear | In left rear seat. (Scheme 19) |
| Heated Seat Module, Passenger Side Front | Under passenger's seat. (Scheme 21) |
| Heated Seat Module, Right Rear | In right rear seat. (Scheme 19) |
| Isolator/Radio Antenna Module | Center of trunk. (Scheme 15) |
| Lighting Control Module | Under lower left side of dash. (Scheme 10) |
| Navigation Module | Center of trunk. (Scheme 14) |
| Occupant Classification Sensor Module | In passenger's seat. (Scheme 18) |
| Parking Aid Module (PAM) | At right side of trunk. (Scheme 15) |
| Passive Anti-Theft Transceiver Module | At top of steering column. (Scheme 9) |
| Powertrain Control Module | Left rear side of engine compartment. (Scheme 1) |
| Rear Audio/Climate Control Module | Under right rear seat. (Scheme 19) |
| Restraints Control Module | At center floor pan. (Scheme 13) |
| Roof Opening Panel Unit | At center front of roof. (Scheme 25) |
| Side Air Bag Module, Left | Driver's seat back. (Scheme 17) |
| Side Air Bag Module, Right | Right side of passenger's seat back. (Scheme 18) |
| Trunk Pull-Down Module | Center rear of trunk. (Scheme 14) |
CONTROL UNITS LOCATION
MOTORS
| Component | Location |
|---|---|
| Adjustable Pedal Motor | On brake pedal support. (Scheme 13) |
| Air Suspension Compressor | Left front of engine compartment. (Scheme 2) |
| Backrest Motor, Driver Seat | Under driver's seat. (Scheme 17) |
| Backrest Motor, Passenger Seat | In passenger's seat. (Scheme 18) |
| Driver Seat Backrest Motor | Bottom left of driver's seat. (Scheme 17) |
| Driver Seat Lumbar Compressor Motor | Right side of driver's seat. (Scheme 17) |
| Electronic Throttle Control (ECT) Motor | Top of engine. (Scheme 3) |
| Floor Mode Actuator | Behind right side of dash. (Scheme 8) |
| Fresh/Recirculation Door Actuator | Behind center of dash. (Scheme 8) |
| Front Blower Motor | Right rear of engine compartment. (Scheme 7) |
| Fuel Tank Unit | In fuel tank assembly. (Scheme 14) |
| Panel/Defrost Mode Actuator | Behind left side of dash. (Scheme 8) |
| Passenger Seat Lumbar Compressor Motor | Left rear of front passenger's seat. (Scheme 18) |
| Power Seat Motor Assembly, Left | Below left front seat. (Scheme 17) |
| Power Seat Motor Assembly, Right | Below right front seat. (Scheme 18) |
| Power Trunk Motor Assembly | Left rear of trunk. (Scheme 14) |
| Power Window Motor, Driver Side Front | In driver's door. (Scheme 20) |
| Power Window Motor, Left Rear | In left rear door. (Scheme 22) |
| Power Window Motor, Passenger Side Front | In right front door. (Scheme 21) |
| Power Window Motor, Right Rear | In right rear door. (Scheme 23) |
| Starter Motor | Right side of engine. (Scheme 1) |
| Temperature Blend Door Actuator, Driver | Behind center left side of dash. (Scheme 8) |
| Temperature Blend Door Actuator, Passenger | Behind center right side of dash. (Scheme 8) |
| Windshield Washer Pump Motor | At right rear of engine compartment. (Scheme 1) |
| Windshield Wiper Motor | At left rear of engine compartment. (Scheme 1) |
MOTORS LOCATION
SENDING UNITS & SENSORS
| Component | Location |
|---|---|
| A/C Pressure Transducer Sensor | Right front of engine. (Scheme 5) |
| Adjustable Pedal Position Sensor | On accelerator pedal. (Scheme 13) |
| Adjustable Pedal Potentiometer | On brake pedal support. (Scheme 13) |
| Air Suspension Height Sensor | At center rear of vehicle. (Scheme 15) |
| Ambient Air Temperature Sensor | Left front of engine compartment. (Scheme 2) |
| Autolamp Sensor | On top left side of dash, above instrument cluster. (Scheme 9) |
| Camshaft Position Sensor | Left front of engine. (Scheme 3) |
| Crankshaft Position Sensor | On right front of engine. (Scheme 3) |
| Cylinder-Head Temperature Sensor | Left front of engine. (Scheme 3) |
| Digital Transmission Range (DTR) Sensor | On lower left side of transmission. (Scheme 6) |
| Engine Coolant Temperature (ECT) Sensor | Right front of engine. (Scheme 5) |
| Front Impact Severity Sensor, Left | Left front center of engine compartment. (Scheme 2) |
| Front Impact Severity Sensor, Right | Right front center of engine compartment. (Scheme 2) |
| Fuel Rail Pressure & Temperature Sensor | At right front side of engine. (Scheme 5) |
| Heated Oxygen Sensor (HO2S) #11 | Lower right rear of engine compartment, in exhaust manifold. (Scheme 6) |
| Heated Oxygen Sensor (HO2S) #12 | Near right rear of transmission. (Scheme 6) |
| Heated Oxygen Sensor (HO2S) #21 | Lower left rear of engine compartment, in exhaust manifold. (Scheme 6) |
| Heated Oxygen Sensor (HO2S) #22 | Near left rear of transmission. (Scheme 6) |
| In-Vehicle Temperature Sensor | Behind lower center of dash. (Scheme 10) |
| Knock Sensor | Left front of engine. (Scheme 3) |
| Mass Air Flow (MAF) Sensor | Left front of engine compartment, near air cleaner assembly. (Scheme 2) |
| Occupant Classification Sensor (OCS) | Under right front seat. (Scheme 18) |
| Output Shaft Speed (OSS) Sensor | On top left side of transmission. (Scheme 6) |
| Safety Belt Sensor, Driver Side | Right side of driver seat. (Scheme 17) |
| Safety Belt Sensor, Passenger Side | Lower left side of front passenger's seat. (Scheme 18) |
| Seat Position Sensor, Driver | Under drivers seat. (Scheme 17) |
| Side Air Bag Sensor (Left) | At bottom of left "B" pillar. (Scheme 13) |
| Side Air Bag Sensor (Right) | At bottom of right "B" pillar. (Scheme 16) |
| Turbine Shaft Speed (TSS) Sensor | Left side of transmission. (Scheme 6) |
| Wheel Speed Sensor, Left Front | In left front brake assembly. (Scheme 2) |
| Wheel Speed Sensor, Left Rear | In left rear brake assembly. (Scheme 14) |
| Wheel Speed Sensor, Right Front | In right front brake assembly. (Scheme 1) |
| Wheel Speed Sensor, Right Rear | In right rear brake assembly. (Scheme 15) |
SENDING UNITS & SENSORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| A/C Clutch Field Coil | Front of A/C compressor. (Scheme 4) |
| Air Spring Solenoid Valve, Left Rear | Above left rear air spring. (Scheme 15) |
| Air Spring Solenoid Valve, Right Rear | Above right rear air spring. (Scheme 15) |
| Brake Shift Interlock Solenoid | On top of steering column. (Scheme 10) |
| EVAP Canister Purge Valve | Top right of intake manifold. (Scheme 5) |
| EVAP Canister Vent Control Solenoid | Center of trunk. (Scheme 15) |
| Fuel Door Release Solenoid | Left side of trunk. (Scheme 14) |
| Fuel Injector 1 | Top right of engine. (Scheme 5) |
| Fuel Injector 2 | Top right of engine. (Scheme 5) |
| Fuel Injector 3 | Top right of engine. (Scheme 5) |
| Fuel Injector 4 | Top right of engine. (Scheme 5) |
| Fuel Injector 5 | Top left of engine. (Scheme 3) |
| Fuel Injector 6 | Top left of engine. (Scheme 3) |
| Fuel Injector 7 | Top left of engine. (Scheme 3) |
| Fuel Injector 8 | Top left of engine. (Scheme 3) |
| Luggage Compartment Lid Release Solenoid | On center rear of trunk lid. (Scheme 24) |
| Power Steering Valve Solenoid | Left front of engine compartment. (Scheme 3) |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| A/C Cycling Switch | Right front of engine. (Scheme 4) |
| Air Suspension Disable Switch | Left side of trunk. (Scheme 14) |
| Anti-Theft Alarm Inhibit Switch | In left front door. (Scheme 20) |
| Anti-Theft Hood Switch | At center front of engine compartment. (Scheme 2) |
| Brake Fluid Level Switch | On brake fluid reservoir. (Scheme 1) |
| Brake Pedal Position Switch | On brake pedal support. (Scheme 13) |
| Deactivator Switch | Behind left side of dash, on brake pedal support. (Scheme 13) |
| Door Ajar Switch, Driver Side Front | In driver's door. (Scheme 20) |
| Door Ajar Switch, Driver Side Rear | In left rear door. (Scheme 22) |
| Door Ajar Switch, Passenger Side Front | In right front door. (Scheme 21) |
| Door Ajar Switch, Passenger Side Rear | In right rear door. (Scheme 23) |
| Ignition Switch | On steering column. (Scheme 10) |
| Inertia Fuel Shutoff (IFS) Switch | At left side of trunk. (Scheme 14) |
| Oil Pressure Switch | Lower left of engine, above oil filter. (Scheme 3) |
| Parking Brake Switch | On top of park brake assembly. (Scheme 13) |
| Power Steering Pressure Switch | Right front of engine compartment. (Scheme 4) |
| Trunk Striker Motor And Switch | Front center of trunk. (Scheme 15) |
| Washer Fluid Level Switch | On washer reservoir. (Scheme 1) |
SWITCHES LOCATION
MISCELLANEOUS
| Component | Location |
|---|---|
| Air Bag Sliding Contact | On steering column. (Scheme 10) |
| Antenna | Right side of trunk. (Scheme 15) |
| Battery | Right front of engine compartment. (Scheme 2) |
| Circuit Filter | Rear center of roof. (Scheme 25) |
| Coil On Plug (COP) 1 | Top right of engine. (Scheme 4) |
| Coil On Plug (COP) 2 | Top right of engine. (Scheme 4) |
| Coil On Plug (COP) 3 | Top right of engine. (Scheme 4) |
| Coil On Plug (COP) 4 | Top right of engine. (Scheme 4) |
| Coil On Plug (COP) 5 | Top left of engine. (Scheme 3) |
| Coil On Plug (COP) 6 | Top left of engine. (Scheme 3) |
| Coil On Plug (COP) 7 | Top left of engine. (Scheme 3) |
| Coil On Plug (COP) 8 | Top left of engine. (Scheme 3) |
| Data Link Connector (DLC) | At lower left side of dash. (Scheme 10) |
| Deployable Steering Column | In steering column. (Scheme 11) |
| Driver Safety Belt Retractor Pretensioner | Base of left "B" pillar. (Scheme 13) |
| Generator | Right front of engine. (Scheme 2) |
| Horn | Behind radiator grill. (Scheme 1) |
| Navigation System Amplifier | Center of trunk. (Scheme 14) |
| Passenger Safety Belt Retractor Pretensioner | Base of right "B" pillar. (Scheme 16) |
| Positive Crankshaft Ventilation (PCV) | Top right front of engine. (Scheme 4) |
| Seat Back Heater, Left Rear | In left rear seat. (Scheme 19) |
| Seat Back Heater, Right Rear | In right rear seat. (Scheme 19) |
| Seat Cushion Heater, Left Front | In driver's seat. (Scheme 17) |
| Seat Cushion Heater, Left Rear | In left rear seat. (Scheme 19) |
| Seat Cushion Heater, Right Front | In passenger's seat. (Scheme 18) |
| Seat Cushion Heater, Right Rear | In right rear seat. (Scheme 19) |
| Subwoofer Amplifier - W/ Navigation | Left side of trunk. (Scheme 14) |
| Subwoofer Amplifier - W/O Navigation | At left side of trunk. (Scheme 14) |
MISCELLANEOUS LOCATION
CONNECTORS
| Component | Location |
|---|---|
| C110 (Black, 2 Pin) | At left front side of engine. (Scheme 3) |
| C133 (Black, 7 Pin) | At left front side of engine compartment. (Scheme 2) |
| C134 (Black, 7 Pin) | At right front side of engine compartment. (Scheme 2) |
| C139 (Black, 34 Pin) | At left rear side of engine compartment. (Scheme 1) |
| C140 (Black, 1 Pin) | Right side of engine compartment. (Scheme 1) |
| C145 (Black, 13 Pin) | Left rear of engine compartment. (Scheme 2) |
| C192 (Black, 2 Pin) | Right side of engine compartment. (Scheme 4) |
| C210 (Black, 8 Pin) | Right rear of engine compartment. (Scheme 1) |
| C211 (57 Pin) | Right kick panel. (Scheme 8) |
| C213 (Black, 40 Pin) | Right kick panel. (Scheme 13) |
| C214 (57 Pin) | Right kick panel. (Scheme 13) |
| C219 (Black, 14 Pin) | Right rear of engine compartment. (Scheme 1) |
| C248 (Black, 40 Pin) | Left rear of engine compartment. (Scheme 13) |
| C260 (Black, 76 Pin) | Left rear of engine compartment. (Scheme 1) |
| C263 (Gray, 2 Pin) | In steering column assembly. (Scheme 11) |
| C265 (Black, 16 Pin) | Under lower center of dash. (Scheme 8) |
| C299 (Gray, 4 Pin) | Front of left "A" pillar. (Scheme 9) |
| C300 (Black, 7 Pin) | Base of right "B" pillar. (Scheme 16) |
| C311 (Gray, 8 Pin) | Under right rear seats. (Scheme 19) |
| C312 (Gray, 8 Pin) | Under driver's seat. (Scheme 19) |
| C313 (Black, 16 Pin) | Base of right "B" pillar. (Scheme 16) |
| C314 (Black, 12 Pin) | Under right rear seats. (Scheme 19) |
| C315 (Yellow, 2 Pin) | Under passenger's seat. (Scheme 17) |
| C316 (Yellow, 2 Pin) | Bottom rear of front passenger's seat. (Scheme 18) |
| C327 (Gray, 16 Pin) | Under passenger's seat. (Scheme 16) |
| C327 (Gray, 16 Pin) | Under passenger's seat. (Scheme 18) |
| C328 (Gray, 8 Pin) | Base of left "B" pillar. (Scheme 13) |
| C339 (Black, 16 Pin) | Base of left "B" pillar. (Scheme 13) |
| C340 (Black, 10 Pin) | Base of left "B" pillar. (Scheme 13) |
| C405 (Gray, 6 Pin) | At rear center bottom of trunk. (Scheme 15) |
| C406 (Gray, 8 Pin) | At left rear of vehicle. (Scheme 24) |
| C408 (Gray, 3 Pin) | In deck lid. (Scheme 24) |
| C431 (Gray, 3 Pin) | At right rear of vehicle. (Scheme 15) |
| C432 (Gray, 3 Pin) | At left rear of vehicle. (Scheme 14) |
| C510 (Gray, 6 Pin) | In left front door. (Scheme 20) |
| C511 (Black, 8 Pin) | In left front door. (Scheme 20) |
| C610 (Gray, 2 Pin) | In right front door. (Scheme 21) |
| C611 (Black, 8 Pin) | In right front door. (Scheme 21) |
| C700 (Gray, 4 Pin) | In left rear door. (Scheme 22) |
| C710 (Black, 8 Pin) | In left rear door. (Scheme 22) |
| C716 (Black, 8 Pin) | In left rear door. (Scheme 22) |
| C800 (Gray, 4 Pin) | In right rear door. (Scheme 23) |
| C810 (Black, 8 Pin) | In right rear door. (Scheme 23) |
| C818 (Black, 8 Pin) | In right rear door. (Scheme 23) |
| C913 (Black, 16 Pin) | Left front of roof. (Scheme 15) |
| C1026 (Black, 12 Pin) | Right Rear of engine compartment. (Scheme 1) |
| C3007 (Gray, 8 Pin) | Base of right "B" pillar. (Scheme 16) |
| C3049 (Gray, 16 Pin) | Under driver's seat. (Scheme 17) |
| C3133 (Black, 8 Pin) | Near right front footwell. (Scheme 13) |
| C3134 (Gray, 12 Pin) | Under right rear seats. (Scheme 19) |
| C3135 (Black, 12 Pin) | Under right rear seat. (Scheme 19) |
| C3205 (Gray, 4 Pin) | Under driver's seat. (Scheme 17) |
| C3206 (Gray, 4 Pin) | Under passenger's seat. (Scheme 18) |
CONNECTORS LOCATION
GROUNDS
| Component | Location |
|---|---|
| G100 | Right front of engine compartment. (Scheme 2) |
| G101 | Top front of engine. (Scheme 1) |
| G102 | At right front fender. (Scheme 1) |
| G103 | At right front fender. (Scheme 1) |
| G104 | Left front of engine compartment. (Scheme 1) |
| G105 | Left front of engine. (Scheme 1) |
| G106 | Left front of engine. (Scheme 1) |
| G107 | Left rear of engine compartment. (Scheme 1) |
| G108 | Left rear of engine compartment. (Scheme 1) |
| G202 | Right side of dash. (Scheme 8) |
| G203 | Right side of dash. (Scheme 8) |
| G205 | Bottom of right "A" pillar. (Scheme 8) |
| G206 | Bottom of right "A" pillar. (Scheme 8) |
| G207 | Bottom of left "A" pillar. (Scheme 8) |
| G208 | Bottom of left "A" pillar. (Scheme 13) |
| G209 | Left kick panel. (Scheme 13) |
| G210 | Left kick panel. (Scheme 13) |
| G300 | Right kick panel. (Scheme 16) |
| G301 | Right kick panel. (Scheme 16) |
| G401 | Right rear of trunk. (Scheme 15) |
| G402 | Rear center of trunk. (Scheme 15) |
| G403 | Right rear of trunk. (Scheme 15) |
| G404 | Center of trunk. (Scheme 15) |
| G406 | At right side of trunk. (Scheme 15) |
| G407 | At right side of trunk. (Scheme 15) |
GROUNDS LOCATION
SPLICES
| Component | Location |
|---|---|
| S107 | In headlamp lead harness, near breakout to right front park/turn lamp. (Scheme 1) |
| S119 | In headlamp lead harness, in breakout to left front park/turn lamp. (Scheme 1) |
| S120 | Headlamp lead, in breakout to right front park/turn lamp. (Scheme 1) |
| S123 | Engine control sensor and fuel charge harness, in breakout to powertrain control module. (Scheme 3) |
| S126 | In engine harness, at rear of engine. (Scheme 4) |
| S130 | In headlamp lead harness, near breakout to left low beam. (Scheme 1) |
| S135 | Engine control sensor & fuel charge harness, near breakout to heated oxygen sensor (HO2S) #11. (Scheme 4) |
| S136 | In starter motor relay and battery ground harness, near breakout to fusible link A. (Scheme 4) |
| S146 | Dash panel to headlamp junction, near central junction box (CJB). (Scheme 6) |
| S147 | In engine control sensor and fuel charge wiring harness, near breakout to powertrain control module. (Scheme 3) |
| S158 | In engine control sensor and fuel charge harness, near breakout to C192. (Scheme 4) |
| S162 | Starter motor relay and battery ground, near breakout to fusible link A. (Scheme 2) |
| S165 | In dash panel to headlamp junction harness, near breakout to G102. (Scheme 1) |
| S167 | In dash panel to headlamp junction harness, near breakout to battery junction box (BJB). (Scheme 2) |
| S169 | In dash panel to headlamp junction harness, near breakout to battery junction box (BJB). (Scheme 1) |
| S171 | In dash panel to headlamp junction harness, near breakout to battery junction box (BJB). (Scheme 2) |
| S174 | In dash panel to headlamp junction harness, near breakout to G104. (Scheme 2) |
| S176 | In dash panel to headlamp junction harness, near breakout to G104. (Scheme 1) |
| S179 | In dash panel to headlamp junction harness, near breakout to powertrain control module. (Scheme 2) |
| S182 | Left rear of engine compartment. (Scheme 1) |
| S183 | In dash panel to headlamp junction, near breakout to G104. (Scheme 1) |
| S184 | In dash panel to headlamp junction harness, near breakout to battery junction box. (Scheme 1) |
| S185 | In dash panel to headlamp junction harness, near breakout to battery junction box. (Scheme 1) |
| S186 | In dash panel to headlamp junction harness, near breakout to G104. (Scheme 1) |
| S187 | In body main harness, near breakout to C248. (Scheme 2) |
| S200 | In body main, near breakout to C211. (Scheme 16) |
| S201 | In main harness, near breakout to instrument cluster. (Scheme 8) |
| S202 | In main harness near breakout to C251. (Scheme 10) |
| S203 | In main harness near breakout to C251. (Scheme 10) |
| S209 | In main harness, near breakout to C220a. (Scheme 8) |
| S210 | In main harness, near breakout to G202. (Scheme 8) |
| S212 | In body main harness, near breakout to G202. (Scheme 13) |
| S215 | Body main, near breakout to C214. (Scheme 13) |
| S217 | At right footwell, forward of "A" pillar. (Scheme 9) |
| S218 | Left side of dash. (Scheme 8) |
| S219 | Main harness, near breakout to ignition switch. (Scheme 8) |
| S221 | Main harness in breakout to panel/defrost mode actuator. (Scheme 9) |
| S223 | Body main, near breakout to C913. (Scheme 16) |
| S232 | Main harness, near breakout to message center switch. (Scheme 10) |
| S233 | Main harness, near steering column. (Scheme 8) |
| S237 | Body main, in breakout to adjustable pedal motor. (Scheme 10) |
| S242 | Main harness in breakout to panel/defrost mode actuator. (Scheme 13) |
| S245 | In main body harness, breakout to C214. (Scheme 13) |
| S248 | Main harness in breakout to panel/defrost mode actuator. (Scheme 10) |
| S254 | Main harness, near breakout to lighting control module. (Scheme 8) |
| S255 | Main harness, near breakout to ignition switch. (Scheme 13) |
| S260 | Body main, near left front door grommet. (Scheme 13) |
| S262 | In body main harness, near breakout to C248. (Scheme 8) |
| S265 | In body main harness, near breakout to C248. (Scheme 13) |
| S266 | In body main harness, near breakout to C248. (Scheme 13) |
| S267 | In body main harness, near breakout to C2003. (Scheme 13) |
| S268 | In body main harness, near breakout to adjustable pedal motor & potentiometer. (Scheme 13) |
| S269 | In body main harness, near breakout to front cigar lighter. (Scheme 10) |
| S270 | In body main harness, near breakout to C211. (Scheme 16) |
| S271 | In body main harness, near breakout to C248. (Scheme 13) |
| S277 | In body main harness, near breakout to C214. (Scheme 13) |
| S279 | In body main harness, near breakout to C2131a. (Scheme 10) |
| S280 | In body main harness, near breakout to C214. (Scheme 13) |
| S281 | Air conditioning harness, in breakout to C265. (Scheme 8) |
| S282 | In body main harness, near breakout to C265. (Scheme 8) |
| S286 | In main harness, near breakout to C213. (Scheme 8) |
| S287 | In main harness, near breakout to C260. (Scheme 8) |
| S288 | In main wiring harness, near breakout to C260. (Scheme 8) |
| S289 | In main body harness, near breakout to C214. (Scheme 13) |
| S290 | In dash panel to headlamp junction, near breakout to air suspension module. (Scheme 1) |
| S291 | In dash panel to headlamp junction, near breakout to air suspension module. (Scheme 1) |
| S293 | In turn signal main harness, near breakout to C203. (Scheme 12) |
| S294 | In body main harness, near breakout to brake shift interlock. (Scheme 12) |
| S295 | In turn signal main harness, near breakout to C214. (Scheme 13) |
| S297 | In body main harness, near breakout to C214. (Scheme 13) |
| S298 | In body main harness, near breakout to C299. (Scheme 9) |
| S299 | In body main harness, near breakout to C248. (Scheme 13) |
| S300 | In body main harness, near breakout to C3133. (Scheme 13) |
| S301 | In power seats wiring harness, near breakout to C3049. (Scheme 17) |
| S302 | In power seats wiring harness, near breakout to C3049. (Scheme 17) |
| S303 | In body main harness, near breakout to C810. (Scheme 23) |
| S304 | In body main harness, near breakout to C219. (Scheme 16) |
| S305 | In body main harness, near breakout to C300. (Scheme 16) |
| S307 | In body main harness, near breakout to C327. (Scheme 18) |
| S308 | In power seats harness, near breakout to C3049. (Scheme 17) |
| S328 | Power seats, near breakout to C3049. (Scheme 13) |
| S330 | In radio harness near breakout to rear audio/climate control switch. (Scheme 19) |
| S335 | In seat heated pad harness, near breakout to C311. (Scheme 19) |
| S337 | Radio feed, near breakout to left rear power point. (Scheme 19) |
| S338 | Radio feed, near breakout to left rear power point. (Scheme 19) |
| S340 | Radio feed, near breakout to left rear power point. (Scheme 19) |
| S341 | Power seats, near breakout to C3049. (Scheme 17) |
| S400 | In body main harness, near breakout to fuel pump driver module. (Scheme 14) |
| S401 | In body main harness, near breakout to fuel pump driver module. (Scheme 14) |
| S422 | Rear license plate lamp, in breakout to C408. (Scheme 24) |
| S453 | In body main harness, near breakout to navigation system amplifier. (Scheme 14) |
| S454 | In body main harness, near breakout to fuel pump driver module. (Scheme 14) |
| S455 | In body main harness, near breakout to fuel pump driver module. (Scheme 14) |
| S456 | In body main harness, near breakout to C428. (Scheme 14) |
| S457 | In body main harness, near breakout to C4033. (Scheme 14) |
| S458 | In body main harness, near breakout to C4033. (Scheme 14) |
| S460 | In body main harness, near breakout to C4197. (Scheme 15) |
| S461 | In body main harness, near breakout to G402. (Scheme 15) |
| S499 | In body main harness, near breakout to G404. (Scheme 15) |
| S500 | In body main harness, near breakout to driver side door lock unit. (Scheme 20) |
| S501 | In body main harness, near breakout to C501b. (Scheme 20) |
| S502 | In body main harness, near breakout to C523. (Scheme 20) |
| S510 | In driver's door. (Scheme 20) |
| S511 | In driver's door. (Scheme 20) |
| S515 | In driver's door. (Scheme 20) |
| S524 | In body main harness, near breakout to C516. (Scheme 20) |
| S601 | In body main harness, near breakout to C211. (Scheme 16) |
| S602 | In body main harness, near breakout to C681. (Scheme 21) |
| S603 | In body main harness, near breakout to front passenger's side door lock switch. (Scheme 21) |
| S700 | In switch and wiring harness, near breakout to left rear courtesy door lamp. (Scheme 22) |
| S703 | In body main harness, near breakout to C710. (Scheme 22) |
| S800 | In window regulator right rear door switch and wiring assembly, in breakout to right rear door courtesy lamp. (Scheme 23) |
| S801 | In body main harness, near breakout to C810. (Scheme 23) |
| S903 | Interior lamps, near breakout to overhead console. (Scheme 25) |
| S904 | Interior lamps, near breakout to left vanity mirror lamp. (Scheme 25) |
| S905 | Interior lamps, near breakout to right vanity mirror lamp. (Scheme 25) |
| S907 | At front of roof. (Scheme 25) |
| S910 | Interior lamps, near breakout to high mounted stop lamp. (Scheme 25) |
SPLICES LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
