Material
| Item | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A |
MATERIAL SPECIFICATIONS TABLE
Scheme 10
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | RH Camshaft Position (CMP) sensor electrical connector |
| 2 | W503279 | RH CMP sensor bolt |
| 3 | 6B288 | RH CMP sensor |
| 4 | 14A464 | LH CMP sensor electrical connector |
| 5 | W503279 | LH CMP sensor bolt |
| 6 | 6B288 | LH CMP sensor |
PART NUMBER DESCRIPTION TABLE
| Item | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A |
| Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada) |
MATERIAL SPECIFICATIONS TABLE
| Item | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A |
| Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada) |
MATERIAL SPECIFICATIONS TABLE
Scheme 11
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-355922) .
- Disconnect the Catalyst Monitor Sensor (CMS) electrical connector.
- Using the Exhaust Gas Oxygen Sensor Socket, remove the CMS . Calculate the correct torque wrench setting for the following torque. Refer to Torque Wrench Adapter Formulas in illustration. To install, tighten to 48 Nm (35 lb-ft). NOTE: If necessary, lubricate the sensor threads with penetrating and lock lubricant to assist in removal.
- To install, reverse the removal procedure. NOTE: Apply a light coat of anti-seize lubricant to the threads of the CMS .
Scheme 12
| Item | Part Number | Description |
|---|---|---|
| 1 | W500215 | Variable Camshaft Timing (VCT) oil control solenoid bolt |
| 2 | 6B297 | VCT oil control solenoid |
PART NUMBER DESCRIPTION TABLE
| Item | Specification |
|---|---|
| Motorcraft® Premium Gold Engine Coolant with Bittering Agent (US); Motorcraft® Premium Gold Engine Coolant (Canada) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
| Motorcraft® Specialty Green Engine Coolant with Bittering Agent (US); Motorcraft® Specialty Green Engine Coolant (Canada) VC-10-A (US); CVC-10-A (Canada) | WSS-M97B55-A |
MATERIAL SPECIFICATIONS TABLE
Scheme 13
| Item | Part Number | Description |
|---|---|---|
| 1 | 9N271 | Coolant tube |
| 2 | 8565 | O-ring seal |
| 3 | 14A464 | Knock Sensor (KS) electrical connector |
| 4 | W704749 | KS bolts (2 required) |
| 5 | 12A699 | KS |
PART NUMBER DESCRIPTION TABLE
