Warning System - Side & Rear Vision: Diagnosis Lincoln MKZ I рестайлинг

Inspection and Verification

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical and electrical damage. VISUAL INSPECTION TABLE Mechanical Electrical Rear bumper cover Lower rear bumper quarter panel splash shield Smart Junction Box (SJB) fuse 35 (10A) Left and right exterior mirrors
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC). NOTE: Make sure to use the latest scan tool software release.
5. If the scan tool does not communicate with the VCM : Check the VCM connection to the vehicle. Check the scan tool connection to the VCM . Refer to «PINPOINT TEST AF: NO POWER TO THE SCAN TOOL»(ref-355946-S03084164432010013000000) to diagnose no power to the scan tool. NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM .
6. If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «PINPOINT TEST A: THE PCM DOES NOT RESPOND TO THE SCAN TOOL»(ref-355946-S02817008552010013000000) to diagnose no response from the PCM.
7. Carry out the network test. If the scan tool responds with no communication with the Side Obstacle Detection Control Module - Right (SOD-R), GO to «SYMPTOM TABLE»(ref-356018-S29284672152010013000000) . If the scan tool responds with no communication for one or more modules, refer to «INSPECTION AND VERIFICATION»(ref-355946-S34749853742010013000000) . If the network test passes, retrieve and record the continuous memory DTCs.
8. Clear the continuous DTCs and carry out the self-test diagnostics for the SOD-R and Side Obstacle Detection Control Module - Left (SOD-L).
9. If the DTCs retrieved are related to the concern, go to «DTC TABLES»(ref-356018-S15260782662010013000000) . For all other DTCs, refer to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) .
10. If no DTCs related to the concern are retrieved, GO to «SYMPTOM TABLE»(ref-356018-S29284672152010013000000) .

Side Obstacle Detection Control Module - Left (SOD-L) and Side Obstacle Detection Control Module - Right (SOD-R) DTC Table

Note. This module utilizes a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2- character DTC status code suffix to assist in determining DTC history.

SIDE OBSTACLE DETECTION CONTROL MODULE - LEFT (SOD-L) AND SIDE OBSTACLE DETECTION CONTROL MODULE - RIGHT (SOD-R) DTC TABLE

Instrument Panel Cluster (IPC) DTC Table

Note. This module utilizes a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2- character DTC status code suffix to assist in determining DTC history.

INSTRUMENT PANEL CLUSTER (IPC) DTC TABLE

Symptom Table

SYMPTOM TABLE

PINPOINT TEST A: BLIS™ IS INOPERATIVE/DOES NOT OPERATE CORRECTLY OR POOR PERFORMANCE AND NO MESSAGE CENTER WARNING MESSAGE OR WARNING LED INDICATORS PRESENT

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. A1 CARRY OUT THE SOD-L AND SOD-R DIAGNOSTIC SYSTEM CHECK Start the engine. Observe the left and right exterior mirror BLIS™ / CTA LEDs. Do the left and right BLIS™/CTA LEDs illuminate and turn off after 3 seconds? Yes: GO to A2 . No: Go To «PINPOINT TEST D»(ref-356018-S30368604882010013000000) .
2. A2 VERIFY BLIS™ OPERATION Drive the vehicle and test BLIS™ to verify the customer's concern. Does BLIS™ operate correctly? Yes: The fault may have been caused by an intermittent condition such as poor weather conditions or customer's perception of how BLIS™ operates. REFER to Owner's Literature. TEST the system for normal operation. No: GO to A3 .
3. A3 CHECK FOR SOD-L AND SOD-R OBSTRUCTIONS Check the lower rear side bumper cover fascia and lower rear bumper cover splash shield for a build up of mud, bumper stickers or any obstruction. Are any obstructions present? Yes: CLEAN and REMOVE all obstructions from the lower rear side bumper cover fascia and lower rear bumper cover splash shield. TEST the system for normal operation. No: GO to A4 .
4. A4 CHECK FOR DAMAGE TO THE LOWER REAR SIDE BUMPER COVER OR THE SOD-L AND SOD-R Check the lower rear side bumper cover fascia, lower rear bumper cover splash shield and the SOD-L and SOD-R mounting bracket for damage. Is any damage present? Yes: REPAIR or INSTALL any damaged parts. TEST the system for normal operation. No: GO to A5 .
5. A5 VERIFY THE SOD-L AND SOD-R PASS THE NETWORK TEST Enter the following diagnostic mode on the scan tool: Network Test. Verify that the SOD-L and SOD-R pass the network test. Do the SOD-L and SOD-R pass the network test? Yes: GO to A6 . No: For SOD-L , REFER to «PINPOINT TEST R: THE SIDE OBSTACLE DETECTION CONTROL MODULE -- LEFT (SOD-L) DOES NOT RESPOND TO THE SCAN TOOL»(ref-355946-S26778314392010013000000) . For SOD-R , Go To «PINPOINT TEST E»(ref-356018-S22227370332010013000000) .
6. A6 VERIFY BLIS™ CONFIGURATION NOTE: BLIS™ must be enabled in both the SOD-L and the SOD-R . Enter the following diagnostic mode on the scan tool: Programmable Parameters. Verify that BLIS™ is enabled in the SOD-L and SOD-R . Is BLIS™ enabled? Yes: GO to A7 . No: ENABLE BLIS™ in the SOD-L and SOD-R using the scan tool programmable parameters menu. TEST the system for normal operation.
7. A7 CHECK THE DTCs FROM BOTH THE CONTINUOUS AND ON-DEMAND SOD-L AND SOD-R SELF-TESTS Check the SOD-L and SOD-R DTCs from the continuous and on-demand self-tests. Are any SOD-L and SOD-R DTCs recorded? Yes: REFER to «DTC TABLES»(ref-356018-S15260782662010013000000) . No: GO to A8 .
8. A8 CHECK FOR VEHICLE SPEED SIGNAL DTCs Enter the following diagnostic mode on the scan tool: IPC CMDTCs. Check for correct operation of the speedometer in the IPC . Are vehicle speed display faults and DTCs related to vehicle speed present? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) for a list of all DTCs. No: For an inoperative SOD-L , GO to A9 . For an inoperative SOD-R , GO to A10 .
9. A9 CHECK FOR CORRECT SOD-L OPERATION Disconnect the SOD-L connector. Check for: corrosion damaged pins pushed-out pins Connect the SOD-L connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SOD-L . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
10. A10 CHECK FOR CORRECT SOD-R OPERATION

1. Disconnect the SOD-R connector.
2. Check for: corrosion damaged pins pushed-out pins
3. Connect the SOD-R connector and make sure it seats correctly.
4. Operate the system and verify the concern is still present.
5. Is the concern still present?

1. Yes: INSTALL a new SOD-R . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation.
2. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test B: The Cross Traffic Alert (CTA) System Is Inoperative/Does Not Operate Correctly Or Poor Performance And No Warning Led Indicators Present

Note. The Cross Traffic Alert (CTA) system customer ON/OFF feature in the Instrument Panel Cluster (IPC) is not available on early build hybrid vehicles.

PINPOINT TEST B: THE CTA SYSTEM IS INOPERATIVE/DOES NOT OPERATE CORRECTLY OR POOR PERFORMANCE AND NO WARNING LED INDICATORS PRESENT

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. B1 CARRY OUT THE SOD-L AND SOD-R DIAGNOSTIC SYSTEM CHECK Start the engine. Observe the left and right exterior mirror BLIS™ / CTA LEDs. Do the left and right BLIS™/CTA LEDs illuminate and turn off after 3 seconds? Yes: GO to B2 . No: Go To «PINPOINT TEST D»(ref-356018-S30368604882010013000000) .
2. B2 VERIFY THE CTA SYSTEM OPERATION Test the CTA system to verify the customer's concern. NOTE: The CTA system only operates in reverse (R) while backing out of a front-in parking space. Does the CTA system operate correctly? Yes: The fault may have been caused by an intermittent condition such as poor weather conditions or customer's perception of how the CTA system operates. REFER to Owner's Literature. TEST the system for normal operation. No: GO to B3 .
3. B3 CHECK FOR SOD-L AND SOD-R OBSTRUCTIONS Check the lower rear side bumper cover fascia and lower rear bumper cover splash shield for a build up of mud, bumper stickers or any obstruction. Are any obstructions present? Yes: CLEAN and REMOVE all obstructions from the lower rear side bumper cover fascia and lower rear bumper cover splash shield. TEST the system for normal operation. No: GO to B4 .
4. B4 CHECK FOR DAMAGE TO THE LOWER REAR SIDE BUMPER COVER OR THE SOD-L AND SOD-R Check the lower rear side bumper cover fascia, lower rear bumper cover splash shield and the SOD-L and SOD-R mounting bracket for damage. Is any damage present? Yes: REPAIR or INSTALL any damaged parts. TEST the system for normal operation. No: GO to B5 .
5. B5 VERIFY THE SOD-L AND SOD-R PASS THE NETWORK TEST Enter the following diagnostic mode on the scan tool: Network Test. Verify that the SOD-L and SOD-R pass the network test. Do the SOD-L and SOD-R pass the network test? Yes: GO to B6 . No: For SOD-L , REFER to «PINPOINT TEST R: THE SIDE OBSTACLE DETECTION CONTROL MODULE -- LEFT (SOD-L) DOES NOT RESPOND TO THE SCAN TOOL»(ref-355946-S26778314392010013000000) . For SOD-R , Go To «PINPOINT TEST E»(ref-356018-S22227370332010013000000) .
6. B6 VERIFY THE CTA SYSTEM CONFIGURATION NOTE: The CTA must be enabled in both the SOD-L and the SOD-R . Enter the following diagnostic mode on the scan tool: Programmable Parameters. Verify that the CTA system is enabled in the SOD-L and SOD-R . Is the CTA system enabled? Yes: GO to B7 . No: ENABLE the CTA system in the SOD-L and SOD-R using the scan tool programmable parameters menu. TEST the system for normal operation.
7. B7 CHECK THE DTCs FROM BOTH THE CONTINUOUS AND ON-DEMAND SOD-L AND SOD-R SELF-TESTS Check the SOD-L and SOD-R DTCs from the continuous and on-demand self-tests. Are any SOD-L and SOD-R DTCs recorded? Yes: REFER to «DTC CHARTS»(ref-356018-S15260782662010013000000) . No: GO to B8 .
8. B8 CHECK THE DTCs FROM BOTH THE CONTINUOUS AND ON-DEMAND PAM SELF-TESTS Check the PAM DTCs from the continuous and on-demand self-tests. Are any PAM DTCs recorded? Yes: REFER to «PARKING AID MODULE (PAM) DTC TABLE»(ref-356021-S00084819952010013000000) . REPAIR all PAM DTCs and TEST the CTA system for normal operation. No: GO to B9 .
9. B9 CHECK FOR VEHICLE SPEED SIGNAL DTCs Enter the following diagnostic mode on the scan tool: IPC CMDTCs. Check for correct operation of the speedometer in the IPC . Are vehicle speed display faults and DTCs related to vehicle speed present? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) for a list of all DTCs. No: GO to B10 .
10. B10 CHECK FOR CORRECT PRNDL DISPLAY OPERATION Enter the following diagnostic mode on the scan tool: IPC CMDTCs. Check for correct operation of the PRNDL in the IPC . Are PRNDL display faults and DTCs related to the PRNDL present? Yes: REFER to «INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES»(ref-355951-S17097178632010013000000) . No: For an inoperative SOD-L , GO to B11 . For an inoperative SOD-R , GO to B12 .
11. B11 CHECK FOR CORRECT SOD-L OPERATION Disconnect the SOD-L connector. Check for: corrosion damaged pins pushed-out pins Connect the SOD-L connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SOD-L . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
12. B12 CHECK FOR CORRECT SOD-R OPERATION

1. Disconnect the SOD-R connector.
2. Check for: corrosion damaged pins pushed-out pins
3. Connect the SOD-R connector and make sure it seats correctly.
4. Operate the system and verify the concern is still present.
5. Is the concern still present?

1. Yes: INSTALL a new SOD-R . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation.
2. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test C: The Left Or Right Exterior Mirror Blind Spot Information System (BLIS™)/Cross Traffic Alert (CTA) LED Is Constantly On And A Message In The Instrument Panel Cluster (IPC) Message Center Is Present, But No DTCs Are Recorded

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. The Cross Traffic Alert (CTA) system customer ON/OFF feature in the Instrument Panel Cluster (IPC) is not available on early build hybrid vehicles.

PINPOINT TEST C: THE LEFT OR RIGHT EXTERIOR MIRROR BLIS™/CTA LED IS CONSTANTLY ON AND A MESSAGE IN THE IPC MESSAGE CENTER IS PRESENT, BUT NO DTCs ARE RECORDED

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. C1 VERIFY THE SOD-L AND SOD-R PASS THE NETWORK TEST Enter the following diagnostic mode on the scan tool: Network Test. Verify that the SOD-L and SOD-R pass the network test. Do the SOD-L and SOD-R pass the network test? Yes: GO to C2 . No: For SOD-L , REFER to «PINPOINT TEST R: THE SIDE OBSTACLE DETECTION CONTROL MODULE -- LEFT (SOD-L) DOES NOT RESPOND TO THE SCAN TOOL»(ref-355946-S26778314392010013000000) . For SOD-R , Go To «PINPOINT TEST E»(ref-356018-S22227370332010013000000) .
2. C2 CHECK FOR VEHICLE SPEED SIGNAL DTCs Enter the following diagnostic mode on the scan tool: IPC CMDTCs. Check for correct operation of the speedometer in the IPC . Are vehicle speed display faults and DTCs related to vehicle speed present? Yes: REFER to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(ref-355947-S19553737032010013000000) for a list of all DTCs. No: GO to C3 .
3. C3 CHECK FOR PRNDL DTCs Enter the following diagnostic mode on the scan tool: IPC CMDTCs. Check for correct operation of the PRNDL in the IPC . Are PRNDL display faults and DTCs related to the PRNDL present? Yes: REFER to «INSTRUMENTATION, MESSAGE CENTER AND WARNING CHIMES»(ref-355951-S17097178632010013000000) . No: For a BLIS™ fault, Go To «PINPOINT TEST A»(ref-356018-S07858947972010013000000) . For a CTA system fault, GO to C4 .
4. C4 CHECK FOR PAM DTCs

1. Enter the following diagnostic mode on the scan tool: PAM CMDTCs.
2. Check DTCs in the PAM .
3. Are DTCs present?

1. Yes: REFER to «PARKING AID»(ref-356021-S39045175972010013000000) .
2. No: Go To «PINPOINT TEST B»(ref-356018-S33808709472010013000000) .

Pinpoint Test D: DTC B11D6:11 Or DTC B11D6:15

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY DISCONNECT .

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. D1 CHECK THE DTCs FROM BOTH THE CONTINUOUS AND ON-DEMAND SOD-L AND SOD-R SELF-TESTS Check the SOD-L and SOD-R DTCs from the continuous and on-demand self-tests. Are any SOD-L or SOD-R DTCs recorded? Yes: For DTC B11D6:11, GO to D2 . For DTC B11D6:15, GO to D4 . For all other DTCs, REFER to «DTC TABLES»(ref-356018-S15260782662010013000000) . No: For the LEDs constantly on with no DTCs, GO to D4 . Otherwise, Go To «PINPOINT TEST I»(ref-356018-S38983662042010013000000) .
2. D2 CHECK THE EXTERIOR MIRROR BLIS™/CTA LED SUPPLY CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: SOD-L C4230 or SOD-R C4229. For the SOD-L , measure the resistance between the SOD-L C4230-6, circuit CRB04 (YE/GN), harness side and ground. For the SOD-R , measure the resistance between the SOD-R C4229-6, circuit CRB02 (BU./BAN), harness side and ground. Is the resistance greater than 10,000 ohms? Yes: GO to D3 . No: REPAIR the circuit. CLEAR the DTCs. TEST the system for normal operation.
3. D3 CHECK THE EXTERIOR MIRROR BLIS™/CTA LED SUPPLY CIRCUIT FOR A SHORT TO GROUND WITH THE LED DISCONNECTED Disconnect: Left Exterior Mirror BLIS™ / CTA LED Connector Or Right Exterior Mirror BLIS™ / CTA LED Connector. For the SOD-L , measure the resistance between the SOD-L C4230-6, circuit CRB04 (YE/GN), harness side and ground. For the SOD-R , measure the resistance between the SOD-R C4229-6, circuit CRB02 (BU./BAN), harness side and ground. Is the resistance greater than 10,000 ohms? Yes: INSTALL a new exterior mirror for the indicator in question. REFER to «REMOVAL AND INSTALLATION»(ref-356023-S16116166512010013000000) . No: REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation.
4. D4 CHECK THE EXTERIOR MIRROR BLIS™/CTA LED SUPPLY CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: SOD-L C4230 or SOD-R C4229. Ignition ON. For the SOD-L , measure the voltage between the SOD-L C4230-6, circuit CRB04 (YE/GN), harness side and ground. For the SOD-R , measure the voltage between the SOD-R C4229-6, circuit CRB02 (BU./BAN), harness side and ground. Is any voltage present? Yes: REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation. No: GO to D5 .
5. D5 CHECK THE EXTERIOR MIRROR BLIS™/CTA LED SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Exterior Mirror Indicator Left Or Exterior Mirror Indicator Right. For the SOD-L , measure the resistance between the SOD-L C4230-6, circuit CRB04 (YE/GN), harness side and the left exterior mirror BLIS™ / CTA LED pin 1, harness side. For the SOD-R , measure the resistance between the SOD-R C4229-6, circuit CRB02 (BU./BAN), harness side and the right exterior mirror BLIS™ / CTA LED pin 1, harness side. Is the resistance less than 5 ohms? Yes: GO to D6 . No: REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation.
6. D6 CHECK THE EXTERIOR MIRROR BLIS™/CTA LED GROUND CIRCUIT FOR AN OPEN Disconnect: Negative Battery Cable. For the SOD-L , measure the resistance between the left exterior mirror BLIS™ / CTA LED pin 2, harness side and ground. For the SOD-R , measure the resistance between the right exterior mirror BLIS™ / CTA LED pin 2, harness side and ground. Is the resistance less than 5 ohms? Yes: For the SOD-L DTC B11D6:15, GO to D7 . For the SOD-R DTC B11D6:15, GO to D8 . No: REPAIR the circuit in question. CLEAR the DTCs. TEST the system for normal operation.
7. D7 CHECK FOR CORRECT SOD-L OPERATION Disconnect the SOD-L connector. Check for: corrosion damaged pins pushed-out pins Connect the SOD-L connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SOD-L . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
8. D8 CHECK FOR CORRECT SOD-R OPERATION

1. Disconnect the SOD-R connector.
2. Check for: corrosion damaged pins pushed-out pins
3. Connect the SOD-R connector and make sure it seats correctly.
4. Operate the system and verify the concern is still present.
5. Is the concern still present?

1. Yes: INSTALL a new SOD-R . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation.
2. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test E: The Side Obstacle Detection Control Module - Right (SOD-R) Does Not Respond To The Scan Tool Or Cannot Be Configured

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

PINPOINT TEST E: THE SOD-R DOES NOT RESPOND TO THE SCAN TOOL OR CANNOT BE CONFIGURED

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY DISCONNECT .

Scheme 5

1. E1 VERIFY THE SOD-R PASSES THE NETWORK TEST Enter the following diagnostic mode on the scan tool: Network Test. Verify that the SOD-R passes the network test. Does SOD-R pass the network test? Yes: The system is operating correctly at this time. The concern may have been caused by high network traffic or an intermittent problem. TEST the system for normal operation. No: GO to E2 .
2. E2 CHECK THE SOD-R ADDRESS GROUND CIRCUIT FOR AN OPEN Disconnect: Negative Battery Cable. Disconnect: SOD-R C4229. Measure the resistance between the SOD-R C4229-1, circuit GD171 (BK/GY), harness side and ground.
3. Is the resistance less than 5 ohms?

1. Yes: CONFIGURE the SOD-R . REFER to «MODULE CONFIGURATION»(ref-355948-S19142020732010013000000) .
2. No: REPAIR the circuit in question. TEST the system for normal operation.

PINPOINT TEST F: THE IPC MESSAGE CENTER DISPLAYS A BLOCKED SENSOR MESSAGE

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

1. F1 INSPECT REAR BUMPER FASCIA COVER FOR DAMAGE Inspect for damage on the rear bumper fascia cover and proper bracket connection to sheet metal . Is the rear bumper fascia cover damaged or incorrect bracket connection? Yes: For the rear bumper cover, REPAIR or REPLACE the rear bumper cover as necessary. REFER to «REMOVAL AND INSTALLATION»(ref-356008-S10030840742010013000000) . For the SOD-L or the SOD-R bracket, REPAIR or REPLACE the SOD-L or the SOD-R bracket. REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation. No: GO to F2 .
2. F2 INSPECT THE SOD-R AND SOD-L FOR DEBRIS, MUD, SNOW OR ICE Inspect for debris, mud, snow or ice on the rear bumper fascia cover and SOD-R and SOD-L module housing. Is the rear bumper fascia cover and radar unit obstructed or blocked due to the concerns above? Yes: REMOVE and CLEAN the rear bumper fascia cover and module as necessary. Once the vehicle is cleaned, complete one key cycle and test drive the vehicle. The blocked module needs to detect an unblocked situation or 2 good detected vehicles or targets before clearing. TEST the system for normal operation. No: For an inoperative SOD-L , GO to F3 . For an inoperative SOD-R , GO to F4 .
3. F3 CHECK FOR CORRECT SOD-L OPERATION Disconnect the SOD-L connector. Check for: corrosion damaged pins pushed-out pins Connect the SOD-L connector and make sure it seats correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SOD-L . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
4. F4 CHECK FOR CORRECT SOD-R OPERATION

1. Disconnect the SOD-R connector.
2. Check for: corrosion damaged pins pushed-out pins
3. Connect the SOD-R connector and make sure it seats correctly.
4. Operate the system and verify the concern is still present.
5. Is the concern still present?

1. Yes: INSTALL a new SOD-R . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation.
2. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test G: The Blind Spot Information System (BLIS™) and Cross Traffic Alert (CTA) System Cannot Be Turned Off In The Instrument Panel Cluster (IPC) Message Center

Note. The CTA system customer ON/OFF feature in the Instrument Panel Cluster (IPC) is not available on early build hybrid vehicles.

PINPOINT TEST G: THE BLIS™ AND CTA SYSTEM CANNOT BE TURNED OFF IN THE IPC MESSAGE CENTER

1. G1 CHECK THE DTCs FROM BOTH THE CONTINUOUS AND ON-DEMAND IPC, SOD-R AND SOD-L SELF-TESTS Check the IPC , SOD-R and SOD-L DTCs from the continuous and on-demand self-tests. Are any IPC, SOD-R or SOD-L DTCs recorded? Yes: For IPC , REFER to «PINPOINT TEST A: THE INSTRUMENT PANEL CLUSTER (IPC) IS INOPERATIVE»(ref-355951-S20873817512010013000000) . REPAIR all IPC DTCs and RETEST the BLIS™ and CTA system for normal operation. For SOD-R or SOD-L DTCs, REFER to «DTC TABLES»(ref-356018-S15260782662010013000000) . No: GO to G2 .
2. G2 CHECK THE MESSAGE CENTER FOR CORRECT OPERATION

1. Check the IPC message center for correct operation, while turning the BLIS™ and CTA system off and on.
2. Does the message center operate correctly?

1. Yes: The system is operating correctly at this time.
2. No: REFER to «PINPOINT TEST A: THE INSTRUMENT PANEL CLUSTER (IPC) IS INOPERATIVE»(ref-355951-S20873817512010013000000) to diagnose the IPC message center not operating correctly.

PINPOINT TEST H: DTC U3000:44 OR DTC U3000:49

1. H1 CHECK THE SOD-R and SOD-L FOR DTCs

1. Ignition ON.
2. Enter the following diagnostic mode on the scan tool: SOD-R and SOD-L Module Self-Test.
3. Clear the DTCs.
4. Ignition OFF.
5. Wait 5 seconds
6. Ignition ON.
7. Repeat the SOD-R and SOD-L module self-test.
8. Is DTC U3000:44 or DTC U3000:49 still present?

1. Yes: INSTALL a new SOD-R or SOD-L . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation.
2. No: The system is operating correctly at this time. The concern may have been caused by an intermittent problem.

Pinpoint Test I: The Left Or Right Exterior Mirror Blind Spot Information System (BLIS™)/Cross Traffic Alert (CTA) LED Appears Dim Or Does Not Illuminate With No DTC Or Message In The Instrument Panel Cluster (IPC) Message Center Present

Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

PINPOINT TEST I: THE LEFT OR RIGHT EXTERIOR MIRROR BLIS™/CTA LED APPEARS DIM OR DOES NOT ILLUMINATE WITH NO DTC OR MESSAGE IN THE IPC MESSAGE CENTER PRESENT

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY DISCONNECT .

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. I1 VERIFY THE CUSTOMER'S CONCERN Carry out the diagnostic system check. Start the engine. Observe the left and right exterior mirror BLIS™ / CTA LEDs and compare the illumination in each mirror. Is one LED noticeably dimmer than the other? Yes: GO to I2 . No: The concern may be due to customer perception or ambient lighting conditions. TEST the system for normal operation.
2. I2 VERIFY THE EXTERIOR MIRROR BLIS™/CTA LED OPERATION Ignition OFF. Apply the park brake. Ignition ON. Select REVERSE. Enter the following diagnostic mode on the scan tool: SOD-R and/or SOD-L DataLogger. NOTE: The SOD-R and SOD-L are separate modules and the active command PID needs to be commanded on in each individual module. Select the SOD-R or SOD-L PID (CTALERT) and active command the LED ON. Observe the left and/or right exterior mirror BLIS™ / CTA LED and message center. Does the LED blink brightly, audible tone and a message in the message center display "CTA ALERT"? Yes: The concern may be due to customer perception, ambient lighting conditions or system functionality. TEST the system for normal operation. No: GO to I3 .
3. I3 CHECK THE SOD-R OR SOD-L VOLTAGE SUPPLY CIRCUIT Ignition OFF. Disconnect: SOD-L C4230 or SOD-R C4229. Ignition ON. For a dim left LED, measure the voltage between the SOD-L C4230-5, circuit CBP35 (YE/GY), harness side and ground. For a dim right LED, measure the voltage between the SOD-R C4229-5, circuit CBP35 (YE/GY), harness side and ground. Is the voltage greater than 10 volts? Yes: GO to I4 . No: REPAIR the circuit in question. TEST the system for normal operation.
4. I4 CHECK THE SOD-R OR SOD-L GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Negative battery cable. For a dim left LED, measure the resistance between the SOD-L C4230-2, circuit GD171 (BK/GY), harness side and ground. For a dim right LED, measure the resistance between the SOD-R C4229-2, circuit GD171 (BK/GY), harness side and ground. Is the resistance less that 5 ohms? Yes: GO to I5 . No: REPAIR the circuit in question. TEST the system for normal operation.
5. I5 CHECK THE SUSPECTED EXTERIOR MIRROR BLIS™/CTA LED FOR ILLUMINATION Connect: Negative Battery Cable. Ignition OFF. For a dim left LED, connect a fused jumper wire between the SOD-L C4230-5, circuit CBP35 (YE/GY), harness side and the SOD-L C4230-6, circuit CRB04 (YE/GN), harness side. For a dim right LED, connect a fused jumper wire between the SOD-R C4229-5, circuit CBP35 (YE/GY), harness side and the SOD-R C4229-6, circuit CRB02 (BU./BAN), harness side. Ignition ON. Does the LED appear dim? Yes: GO to I6 . No: INSTALL a new SOD-R or SOD-L . REFER to «Removal and Installation»(ref-356018-S14146651352010013000000) . TEST the system for normal operation.
6. I6 CHECK THE SUSPECTED EXTERIOR MIRROR BLIS™/CTA LED CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: Left Exterior Mirror BLIS™ / CTA LED Connector Or Right Exterior Mirror BLIS™ / CTA LED Connector. Ignition ON. For a dim left LED, measure the voltage between the left exterior mirror BLIS™ / CTA LED connector pin 1, harness side and the left exterior mirror BLIS™ / CTA LED connector pin 2, harness side. For a dim right LED, measure the voltage between the right exterior mirror BLIS™ / CTA LED connector pin 1, harness side and the right exterior mirror BLIS™ / CTA LED connector pin 2, harness side. Is the voltage greater than 10 volts? Yes: INSTALL a new exterior mirror for the LED in question. REFER to «REMOVAL AND INSTALLATION»(ref-356023-S16116166512010013000000) . No: GO to I7 .
7. I7 CHECK THE SUSPECTED EXTERIOR MIRROR BLIS™/CTA LED VOLTAGE SUPPLY CIRCUIT FOR AN OPEN

1. Ignition OFF.
2. For the left LED, measure the resistance between the SOD-L C4230-6, circuit CRB04 (YE/GN), harness side and left exterior mirror BLIS™ / CTA LED connector pin 1, harness side.
3. For the right LED, measure the resistance between the SOD-R C4229-6, circuit CRB02 (BU./BAN), harness side and the right exterior mirror BLIS™ / CTA LED connector pin 1, harness side.
4. Is the resistance less than 5 ohms?

1. Yes: For the left exterior mirror, REPAIR circuit GD126 (BK/WH) for an open. TEST the system for normal operation. For the right exterior mirror, REPAIR circuit GD139 (BK/YE) for an open. TEST the system for normal operation.
2. No: For the left exterior mirror, REPAIR circuit CRB04 (YE/GN) for an open. TEST the system for normal operation. For the right exterior mirror, REPAIR circuit CRB02 (BU./BAN) for an open. TEST the system for normal operation.
