REMOVAL AND INSTALLATION
- Position the steering wheel in the straight-ahead position and turn the ignition switch to the OFF position. Remove the key.
- Remove the driver air bag module. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-292554) article.
- Remove the steering wheel nut. To install, tighten to 35 Nm (26 lb-ft).
- Disconnect the steering wheel switches electrical connector.
- Using a suitable puller, remove the steering wheel.
- To install, reverse the removal procedure. Align the steering wheel using the reference mark.
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 1 | In-vehicle temperature sensor hose (part of 19C734) | |
| 2 | In-vehicle temperature sensor electrical connector (part of 14401) | |
| 3 | W505002 | Steering column opening cover bolts (2 required) |
| 4 | 04459 | Steering column opening cover |
| 5 | 3530 | Upper steering column shroud |
| 6 | 3K512 | Lower steering column shroud |
| 7 | W707658 | Lower steering column shroud screws (3 required) |
| 8 | Multi-function switch electrical connector (part of 14401) | |
| 9 | Ignition switch electrical connector (part of 14401) | |
| 10 | Clockspring electrical connector (part of 14401) | |
| 11 | Steering angle sensor electrical connector (part of 14401) | |
| 12 | Wiring harness retainer (part of 14401) | |
| 13 | Passive anti-theft system (PATS) electrical connector (part of 14401) |
Scheme 3
| Item | Part Number | Description |
|---|---|---|
| 14 | 3524 | Steering column |
| 15 | W712961 | Steering column shaft bolt |
| 16 | N806423 | Steering column support bracket nuts (4 required) |
| 17 | 3C611B | Steering column dust seal |
| 18 | W704904 | Lower steering column shaft joint cover nut (2 required) |
| 19 | 3C611A | Lower steering column shaft joint cover |
- Turn the steering wheel to the straight-ahead position and turn the ignition switch to the OFF position. Remove the key.
- Depower the supplemental restraint system (SRS). For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-292554) article.
- Remove the upper steering column shroud.
- Release the tilt lever, remove the 3 lower steering column shroud screws and the shroud.
- Remove the 2 steering column opening cover screws. Detach the steering column opening cover.
- If equipped, disconnect the electrical connector and hose from the in-vehicle temperature sensor. Remove the steering column opening cover.
- Disconnect the multi-function switch, ignition switch and clockspring electrical connectors.
- Disconnect the steering angle sensor electrical connector.
- Disconnect the passive anti-theft system (PATS) electrical connector.
- Detach the wiring harness retainer and position the wiring harness aside.
- Remove the lower steering column shaft joint cover nuts and the cover.
- Index-mark the steering column shaft position to the steering gear for reference during installation.
- Remove the steering column shaft bolt and disconnect the shaft from the steering gear. To install, tighten to 23 Nm (17 lb-ft).
- Remove the 4 steering column support bracket nuts and the steering column. To install, tighten to 28 Nm (21 lb-ft).
- To install, reverse the removal procedure.
- Repower the SRS. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-292554) article.
