GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Cooling System Pressure Test Specifications | |
| Cooling System | 124 kPa (18 psi) |
| Radiator Cap Pressure Test Specification | |
| Pressure release cap | 89-124 kPa (13-18 psi) |
| Thermostat Opening Temperatures | |
| Thermostat starts to open | 86°C (187°F) |
| Thermostat fully open | 96°C (205°F) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | N.m | Lb-ft | Lb-in |
|---|---|---|---|
| A/C condenser-to-radiator bolts | 10 | 89 | |
| Block heater | 40 | 30 | |
| Compressor-to-condenser bracket bolt | 7 | 62 | |
| Coolant pump bolts a | |||
| Cooling fan motor and shroud bolts | 6 | 53 | |
| Degas bottle-to-fender bolt | 9 | 80 | |
| Engine oil filter (1) | |||
| Exhaust clamp | 40 | 30 | |
| Oil cooler bracket bolt | 6 | 53 | |
| Oil pan drain plug | 27 | 20 | |
| Primary timing chain guide bolts | 10 | 89 | |
| Primary timing chain tensioner bolts | 10 | 89 | |
| Thermostat housing bolts | 10 | 89 | |
| Thermostat housing cover bolts | 10 | 89 | |
| Variable camshaft timing (VCT) oil control solenoid housing bolts (1) | |||
| Y-pipe nuts | 40 | 30 | |
| (1) Refer to the procedure in this service information. | |||
| (1) | Refer to the procedure in this service information. |
TORQUE SPECIFICATIONS
| CAUTION | The engine cooling system is filled with Motorcraft Premium Gold Engine Coolant. Mixing coolant types degrades the corrosion protection of Motorcraft Premium Gold Engine coolant. |
Note. Stop-leak style pellets/products must not be used as an additive in this engine cooling system. The addition of stop-leak style pellets/products can clog or damage the cooling system, resulting in degraded cooling system performance and/or failure.
The cooling system components are the
- radiator.
- bypass tube.
- pressure relief cap.
- degas bottle.
- radiator draincock.
- coolant pump.
- engine coolant temperature indicator unit.
- thermostat (cold side).
- variable speed fan motor assembly.
- fan control module.
- engine block coolant weep hole.
Scheme 1
The engine is equipped with an engine block coolant weep hole. If the inner coolant pump shaft seal fails, coolant will be diverted out the weep hole in the LH side of the engine block. This prevents any coolant from entering the crankcase.
Engine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level in the degas bottle.
When adding engine coolant, use a 50/50 mixture of engine coolant and distilled water.
To maintain the integrity of the coolant and the cooling system
- add Motorcraft Premium Gold Engine Coolant. Do not mix coolant types.
- do not add/mix orange-colored Motorcraft Specialty Orange Engine Coolant or equivalent meeting Ford specification WSS-M97B44-D or green colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44-A or equivalent. Mixing coolants may degrade the coolant's corrosion protection.
- do not add alcohol, methanol or brine, or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing.
- Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Note. In the following illustration, Black arrows indicate hot, white arrows indicate cold.
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 1 | 8C633 | Lower degas bottle hose |
| 2 | 8005 | Radiator |
| 3 | 8B273 | Lower radiator hose |
| 4 | 8B274 | Upper radiator hose |
| 5 | 6050 | Cylinder head |
| 6 | 6083 | Cylinder head gasket |
| 7 | 8A586 | Thermostat housing |
| 8 | 9N271 | Heater inlet tube |
| 9 | 9K461 | Lower intake manifold |
| 10 | 8501 | Coolant pump |
| 11 | 6010 | Engine block |
| 12 | 8W005 | Upper degas bottle hose |
| 13 | 18C553 | Heater hose assembly |
| 14 | 18B539 | Heater core |
| 15 | 8A080 | Degas bottle |
SPECIAL TOOLS Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Battery/Antifreeze Tester 014-R1060 or equivalent Pressure Test Kit 014-R1072 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware or equivalent scan tool
Scheme 3
Scheme 4
| Item | Specification |
|---|---|
| Motorcraft Premium Gold Engine Coolant with Bittering Agent (US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
MATERIAL
