TORQUE SPECIFICATIONS
| Description | N.m |
|---|---|
| Air cleaner assembly bolt | 11 |
| Air cleaner assembly outlet hose clamp | 5 |
| Manual control lever nut | 18 |
| Selector lever bolts | 12 |
| Selector lever cable bracket bolts | 12 |
| Selector lever cable grommet nuts | 10 |
| Selector lever knob screws | 2 |
TORQUE SPECIFICATIONS
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 7A257 | Manual control lever |
| 2 | Adjuster locking tab (part of 7E395) | |
| 3 | 7E395 | Selector lever cable |
| 4 | 7B229 | Selector lever cable bracket |
| 5 | Selector lever cable grommet (part of 7E395) | |
| 6 | 7K004 | Selector lever assembly |
| 7 | 7L010 | Selector lever knob |
| 8 | Transmission control (TC)/overdrive (O/D) cancel switch (part of 7L010) |
The transaxle selector lever linkage consists of
- a selector lever cable that connects the transaxle manual control lever to the selector lever assembly.
- a brake shift interlock actuator (BSIA) that is integral to the selector lever assembly.
- a transmission control (TC) switch that turns off the operation of 6th gear.
The selector lever assembly
- locks the transaxle selector lever in the PARK position when the ignition switch is in the LOCK position.
- requires the transaxle selector lever to be in the PARK position to turn the ignition switch to the LOCK position.
See also:
• AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50
