Body System - Uni-Body, Subframe & Mounting System: Component Locations Lincoln MKT I

Frames, Subframes & Crossmembers 17 illustrations ~633 words

Special Tool(s)

SPECIAL TOOL DESCRIPTION TABLE Powertrain Lift Table 014-00765

Scheme 26

Scheme 26: 3.7L
Scheme 26: 3.7L
ItemPart NumberDescription
1W505274Stabilizer bar brackets-to-front subframe bolts (4 required)
2W713000Power steering gear-to-front subframe bolts (2 required)
3W714890Lower ball joint nuts (2 required)
4W713156Lower roll restrictor bolt
55R364 RH/ 5362 LHFront subframe bracket
6W710999Front subframe bracket bolts (4 required)
7W714039Front subframe rear bolts (2 required)
8W710714Front subframe front bolts (2 required)
9W520515Power steering gear-to-front subframe nut (2 required)
10W709474Power steering line routing bolt (2 required)
115N356Front subframe assembly
125L022Front subframe front bolt washers (2 required)

ITEM DESCRIPTION TABLE

Scheme 27

Scheme 27: 3.5L Gasoline Turbocharged Direct Injection (GTDI)
Scheme 27: 3.5L Gasoline Turbocharged Direct Injection (GTDI)
ItemPart NumberDescription
1Underbody shield retainer (part of 10494A) (4 required)
210494Underbody shield
3W714039Front subframe rearward bolt (2 required)
4W710999Subframe support bracket bolt (4 required)
55362 LH/ 5R364 RHSubframe support bracket
6W710714Front subframe forward bolt (2 required)
7W712850Front engine roll restrictor bolt
8W712856Rear engine roll restrictor bolt
95L022Front subframe forward bolt washer (2 required)
105N356Front subframe
11W714890Lower ball joint nut (2 required)
12W505274Stabilizer bar bracket bolt (4 required)

ITEM DESCRIPTION TABLE

SPECIAL TOOL DESCRIPTION TABLE Front Subframe Bushing Remover/Installer 204-362

Scheme 28

Scheme 28: Special Tool(s)
Scheme 28: Special Tool(s)

Scheme 29

Scheme 29: Removal
Scheme 29: Removal
  1. Remove the front subframe. For additional information, refer to «SUBFRAME - FRONT»(ref-356645-S27336481732010022500000) .
  2. Assemble the Front Subframe Bushing Remover/Installer to the front subframe.
  3. Press out the subframe bushing.

Scheme 30

Scheme 30: Installation
Scheme 30: Installation

Scheme 31

Scheme 31
Scheme 31
  1. Assemble the Front Subframe Bushing Remover/Installer to the front subframe with the new subframe bushing.
  2. Align the subframe bushing to the front subframe. Align the subframe bushing so that the voids are oriented in the fore-aft position.
  3. Press the new subframe bushing into the front subframe.
  4. Install the front subframe. For additional information, refer to «SUBFRAME - FRONT»(ref-356645-S27336481732010022500000) .

Subframe - Rear

Note. All-Wheel Drive (AWD) shown, Front Wheel Drive (FWD) similar.

Scheme 32

Scheme 32: Subframe - Rear
Scheme 32: Subframe - Rear
ItemPart NumberDescription
15N354Rear subframe assembly
2W711270Rear subframe mounting bracket bolts (4 required)
3W713714Rear subframe front mounting bolts (2 required)
4W713714Rear subframe rear mounting bolts (2 required)
55084 RH/ 5A111 LHRear subframe mounting bracket (2 required)
6W710681Brake caliper bolt (4 required)
7W505251Wheel opening parking brake cable bracket bolt
8W505251Intermediate parking brake cable bracket bolt
9W714033Rear shock lower bolt (2 required)
10W500748Rear shock lower nut (2 required)
112A635 RH/2A808 LHParking brake rear cable assembly
12W790063Driveshaft bolt (6 required)

ITEM DESCRIPTION TABLE

Scheme 33

Scheme 33: Removal and Installation
Scheme 33: Removal and Installation

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. Measure and record the vehicle ride height. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-356590) .
  2. Remove the rear wheels. For additional information, refer to «WHEELS & TIRES»(ref-356589) .
  3. With a wax pencil, mark the relational alignment of the rear subframe to the underbody at the mounting locations.
  4. Remove the muffler and tail pipe. For additional information, refer to «EXHAUST SYSTEM»(ref-356593) .
  5. If equipped, remove and discard the 6 driveshaft bolts and position the driveshaft aside. To install, tighten the new bolts to 25 Nm (18 lb-ft). NOTE: If equipped, index-mark the driveshaft before disconnecting from the rear drive axle.
  6. Remove and discard the sway bar link upper nuts and reposition the sway bar.
  7. Using a suitable jackstand, support the lower arm.
  8. Remove the rear shock lower bolts. To install, tighten the rear shock lower bolts to 175 Nm (129 lb-ft). NOTE: Before tightening the lower shock bolts, make sure that the vehicle is at the recorded vehicle ride height. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-356590) .
  9. Remove the jackstand from the lower arm.
  10. Disconnect the main subframe electrical connector.
  11. Release the parking brake cable tension. For additional information, refer to «PARKING BRAKE AND ACTUATION»(ref-356617) .
  12. Disconnect the RH parking brake cable from the front parking brake cable and the frame cable bracket.
  13. Remove the rear parking brake cable bracket and reposition. To install, tighten to 15 Nm (133 lb-in).
  14. Remove the wheel opening parking brake cable bracket bolts and reposition the brackets. To install, tighten to 15 Nm (133 lb-in).
  15. Remove the parking brake cables from the calipers.
  16. Remove the rear brake caliper bolts. To install, tighten to 103 Nm (76 lb-ft).
  17. Remove the rear calipers and position aside. Attach to the body using mechanic's wire. NOTE: It is not necessary to disconnect the hydraulic brake lines.
  18. Remove and discard the 4 rear subframe bracket bolts. To install, tighten to 55 Nm (41 lb-ft).
  19. Position a lifting table under the subframe. NOTE: When positioning the lifting table, be sure to support the rear subframe on the subframe rails. Do not lift on the rear differential or rear control arms, damage may occur.
  20. Remove and discard the 2 front bolts of the rear subframe. To install, tighten to 200 Nm (148 lb-ft).
  21. Remove and discard the 2 rear bolts of the rear subframe. To install, tighten to 200 Nm (148 lb-ft).
  22. To install, reverse the removal procedure. Align the rear subframes to the alignment marks.

SPECIAL TOOL DESCRIPTION TABLE Remover/Installer, Rear Drive Unit (RDU) Bushing (65 mm) 204-618 Remover/Installer, Rear Drive Unit (RDU) Bushing (70 mm) 204-616

Scheme 41

Scheme 41: Special Tool(s)
Scheme 41: Special Tool(s)
ItemPart NumberDescription
14B425AARear Drive Unit (RDU) bushing - rear bushings (2 required)
25N354Rear subframe

ITEM DESCRIPTION TABLE

SPECIAL TOOL DESCRIPTION TABLE Remover/Installer, Rear Drive Unit (RDU) Bushing (65 mm) 204-618 Remover/Installer, Rear Drive Unit (RDU) Bushing (70 mm) 204-616

Scheme 42

Scheme 42: Special Tool(s)
Scheme 42: Special Tool(s)
ItemPart NumberDescription
14B424ARear Drive Unit (RDU) bushing - front bushings (2 required)
25N354Rear subframe

ITEM DESCRIPTION TABLE
