Engine Mechanical - 3.7L: Other Lincoln MKS I

Engine Code Information Label

The engine code information label, located on the front side of the valve cover, contains the following

Scheme 472

ITEM DESCRIPTION

Scheme 473

Exhaust Emission Control System

Operation and required maintenance of the exhaust emission control devices used on this engine is covered in the INTRODUCTION - GASOLINE MODELS .

Induction System

The SFI provides the fuel/air mixture needed for combustion in the cylinders. The 6 solenoid-operated fuel injectors

1. are mounted between the fuel rail and the intake manifold.
2. meter fuel into the air intake stream in accordance with engine demand.
3. are positioned so that their tips direct fuel just ahead of the engine intake valves.

Valve Train

The valve train uses Direct Acting Mechanical Buckets (DAMB). The camshaft lobes are positioned directly above mechanical buckets which are positioned on top of the valves.

Variable Camshaft Timing (VCT) System

The VCT system changes intake camshaft timing dependent on engine speed, load and oil temperature. Oil pressure advances and retards camshaft timing to improve low-speed and high-speed engine performance, engine idle quality and exhaust emissions.

PCV System

All engines are equipped with a closed-type PCV system recycling the crankcase vapors to the upper intake manifold.

Oil Pump

The lubrication system is designed to provide optimum oil flow to critical components of the engine through its entire operating range.

The heart of the system is a positive displacement internal gear oil pump.

Generically, this design is known as a gerotor pump, which operates as follows

1. The oil pump is mounted on the front face of the cylinder block.
2. The inner rotor is piloted on the crankshaft post and is driven through flats on the crankshaft.
3. System pressure is limited by an integral, internally-vented relief valve which directs the bypassed oil back to the inlet side of the oil pump.
4. Oil pump displacement has been selected to provide adequate volume to make sure of correct oil pressure both at hot idle and maximum speed.
5. The relief valve calibration protects the system from excessive pressure during high-viscosity conditions.
6. The relief valve is designed to provide adequate connecting rod bearing lubrication under high-temperature and high-speed conditions.

Cooling System

The engine cooling system includes the following

1. Radiator
2. Timing chain driven coolant pump
3. Electric fan assembly(ies)
4. Degas bottle (aids in maintaining the correct volume of engine coolant)
5. Coolant thermostat
6. Coolant hoses

For basic engine mechanical concerns, refer to ENGINE SYSTEM - GENERAL INFORMATION . For driveability concerns, refer to the INTRODUCTION - GASOLINE MODELS .

Scheme 474

1. Remove the valve covers. For additional information, refer to «VALVE COVER - LH»(ref-375983-S17384705352010103100000) and «VALVE COVER - RH»(ref-375983-S17064822752010103100000) .
2. Use a feeler gauge to measure the clearance of each valve and record its location. A midrange clearance is the most desirable: Intake: 0.15-0.25 mm (0.006-0.01 in) Exhaust: 0.360-0.460 mm (0.0142-0.0181 in)
3. If any of the valve clearances are out of specification, select new tappets using this formula: tappet thickness = measured clearance + the base tappet thickness - most desirable thickness. Select the tappets and mark the installation location.
4. If required, install the new selected valve tappets in the marked locations. For additional information, refer to «VALVE TAPPETS»(ref-375983-S36933607902010103100000) .

Scheme 475

ITEM DESCRIPTION CHART

Scheme 476

ITEM DESCRIPTION CHART

Material

MATERIAL SPECIFICATIONS

Scheme 477

ITEM DESCRIPTION CHART

Valve Cover - LH (View 2 of 2)

Note. Early build shown in illustration, late build similar.

Scheme 478

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 479

ITEM DESCRIPTION CHART

Valve Cover - RH (View 2 of 2)

Note. Early build shown in illustration, late build similar.

Scheme 480

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 481

Scheme 482

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-375987) .
2. Remove the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-375999) .
3. Using the Strap Wrench, remove the crankshaft pulley bolt and washer. Discard the bolt.
4. Using the 3 Jaw Puller, remove the crankshaft pulley.

Scheme 483

1. Lubricate the crankshaft front seal inner lip with clean engine oil.
2. Using the Front Cover Oil Seal Installer and Crankshaft Vibration Damper Replacer, install the crankshaft pulley.
3. Using the Strap Wrench, install the crankshaft pulley washer and new bolt and tighten in 4 stages. Stage 1: Tighten to 120 Nm (89 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
4. Install the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-375999) .

MATERIAL SPECIFICATIONS

Scheme 484

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-375987) .
2. Remove the crankshaft pulley. For additional information, refer to «CRANKSHAFT PULLEY»(ref-375983-S35111463032010103100000) .
3. Using the Oil Seal Remover, remove and discard the crankshaft front seal. Clean all sealing surfaces with metal surface prep.

MATERIAL SPECIFICATIONS

Scheme 485

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-375987) .
2. Remove the flexplate. For additional information, refer to «FLEXPLATE»(ref-375983-S11962785882010103100000) .
3. Remove the crankshaft sensor ring.
4. Using the Crankshaft Rear Oil Seal Remover and Slide Hammer, remove and discard the crankshaft rear seal. Clean all sealing surfaces with metal surface prep.

Scheme 486

1. Position the Rear Main Seal Installer onto the end of the crankshaft and slide a new crankshaft rear seal onto the tool.
2. Using the Rear Main Seal Installer and Handle, install the new crankshaft rear seal.
3. Install the crankshaft sensor ring.
4. Install the flexplate. For additional information, refer to «FLEXPLATE»(ref-375983-S11962785882010103100000) .

MATERIAL SPECIFICATIONS

MATERIAL SPECIFICATIONS

Scheme 487

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 488

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 489

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 490

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 491

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Valve Tappets

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

1. Depending on the valve tappets being serviced, remove the LH and/or the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-375983-S26138060862010103100000) .
2. Remove the valve tappets from the cylinder head.

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. On early build engines, the timing chain rides on the inner side of the RH timing chain guide. Late build engines are equipped with a different design RH timing chain guide that requires the timing chain to ride on the outer side of the RH timing chain guide. For service, all replacement RH timing chain guides will be the late build design.

All vehicles

Scheme 492

Scheme 493

Scheme 494

Scheme 495

Scheme 496

Scheme 497

Scheme 498

Scheme 499

Scheme 500

Scheme 501

Scheme 502

Scheme 503

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

1. Remove the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-375983-S26138060862010103100000) .
2. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
3. Disconnect the RH Camshaft Position (CMP) sensor electrical connector.
4. Remove the bolt and the RH CMP sensor.
5. Remove the bolt and the Power Steering Pressure (PSP) tube bracket from the RH cylinder head.
6. Remove the bolt and the ground wire.
7. Disconnect the 6 fuel injector electrical connectors (3 shown in illustration).
8. Disconnect the Cylinder Head Temperature (CHT) sensor electrical connector.
9. Disconnect the LH Catalyst Monitor Sensor (CMS) electrical connector.
10. Remove the 2 LH catalytic converter bracket bolts.
11. Remove the 4 nuts (3 shown in illustration) and the LH catalytic converter. Discard the nuts and the gasket.
12. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
13. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and gasket.
14. If equipped, remove the heat shield and disconnect the block heater electrical connector. Remove the block heater wiring harness from the engine.
15. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
16. Remove the 3 bolts and the RH exhaust manifold heat shield.
17. Remove the 6 nuts and the RH exhaust manifold. Discard the nuts and exhaust manifold gaskets.
18. Clean and inspect the RH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
19. Remove and discard the 6 RH exhaust manifold studs. Engines equipped with early build RH timing chain guides
20. Remove the 2 bolts and the RH primary timing chain guide. Engines equipped with late build/replacement RH timing chain guides
21. Remove the 2 bolts and the RH primary timing chain guide. All vehicles
22. Remove the bolts and the RH secondary timing chain tensioner.
23. Remove the 2 bolts and the engine lifting eye.
24. Remove the bolt and the upper intake manifold support bracket.
25. Remove the coolant bypass hose from the thermostat housing.
26. Remove the 4 bolts and the fuel rail and injectors as an assembly.
27. Remove the 3 thermostat housing-to-lower intake manifold bolts. Remove the thermostat housing and discard the gasket and O-ring seal.
28. Remove the 10 bolts and the lower intake manifold. Discard the gaskets.
29. Disconnect and remove the CHT sensor jumper harness.
30. Remove the valve tappets from the cylinder head.
31. Inspect the valve tappets. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
32. Remove and discard the M6 bolt.
33. Remove and discard the 8 bolts from the cylinder head. Remove the cylinder head. Discard the cylinder head gasket.
34. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder heads and the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
35. Support the cylinder head on a bench with the head gasket side up. Check the cylinder head distortion and the cylinder block distortion. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Scheme 519

Scheme 520

Scheme 521

Scheme 522

Scheme 523

Scheme 524

Scheme 525

Scheme 526

Scheme 527

Scheme 528

Scheme 529

Scheme 530

Scheme 531

Scheme 532

Scheme 533

1. Remove the LH camshafts. For additional information, refer to «CAMSHAFT»(ref-375983-S26138060862010103100000) .
2. Disconnect the 6 fuel injector electrical connectors (3 shown in illustration).
3. Disconnect the Cylinder Head Temperature (CHT) sensor electrical connector.
4. Disconnect the LH Camshaft Position (CMP) sensor electrical connector.
5. Remove the bolt and the LH CMP sensor.
6. Disconnect the LH Heated Oxygen Sensor (HO2S) electrical connector.
7. Disconnect the LH Catalyst Monitor Sensor (CMS) electrical connector.
8. Detach the wiring harness retainer from the rear of the LH cylinder head.
9. Remove the nut and disconnect the generator B+ cable.
10. Disconnect the generator electrical connector.
11. Remove the nut, bolt and the generator. Remove the generator stud.
12. Disconnect the Engine Oil Pressure (EOP) switch electrical connector and the wiring harness pin-type retainer. Remove the wiring harness from the engine.
13. Remove the 2 LH catalytic converter bracket bolts.
14. Remove the 4 nuts (3 shown in illustration) and the LH catalytic converter. Discard the nuts and the gasket.
15. Remove the 3 bolts and the LH exhaust manifold heat shield.
16. Remove the 6 nuts and the LH exhaust manifold. Discard the nuts and the exhaust manifold gasket.
17. Clean and inspect the LH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
18. Remove and discard the 6 LH exhaust manifold studs.
19. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
20. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and gasket.
21. If equipped, remove the heat shield and disconnect the block heater electrical connector. Remove the block heater wiring harness from the engine.
22. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
23. Remove the coolant bypass hose from the thermostat housing.
24. Remove the 4 bolts and the fuel rail and injectors as an assembly.
25. Remove the 3 thermostat housing-to-lower intake manifold bolts. Remove the thermostat housing and discard the gasket and O-ring seal.
26. Remove the 10 bolts and the lower intake manifold. Discard the gaskets.
27. Remove the 2 bolts and the upper LH primary timing chain guide.
28. Remove the 2 bolts and the LH secondary timing chain tensioner.
29. Remove the valve tappets from the cylinder head.
30. Inspect the valve tappets. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
31. Remove and discard the M6 bolt.
32. Remove and discard the 8 bolts from the cylinder head. Remove the cylinder head. Discard the cylinder head gasket.
33. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder heads and the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
34. Support the cylinder head on a bench with the head gasket side up. Check the cylinder head distortion and the cylinder block distortion. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. Early build engines have 11 fastener valve covers, late build engines have 9 fastener valve covers. Do not attempt to install bolts in the 2 empty late build valve cover holes or damage to the valve cover will occur.

All vehicles

Scheme 534

Scheme 535

Scheme 536

Scheme 537

Scheme 538

Scheme 539

1. Remove the engine from the vehicle. For additional information, refer to «ENGINE»(ref-375983-S36486420762010103100000) .
2. Remove the 8 bolts and the flywheel.
3. Remove the crankshaft sensor ring.
4. Mount the engine on a suitable engine stand.
5. If equipped, remove the heat shield and disconnect the block heater electrical connector. Detach all of the engine block heater harness retainers and remove the harness.
6. Disconnect the PCV hose from the PCV valve.
7. Disconnect the Throttle Body (TB) electrical connector.
8. Detach the wiring harness retainers from the upper intake manifold.
9. Remove the upper intake manifold support bracket bolt.
10. Remove the fuel tube bracket bolt from the upper intake manifold.
11. Remove the 6 bolts and the upper intake manifold. Discard the gaskets.
12. Disconnect the Power Steering Pressure (PSP) switch electrical connector. Front Wheel Drive (FWD) vehicles
13. Disconnect the RH Catalyst Monitor Sensor (CMS) electrical connector. All vehicles
14. Disconnect the RH Variable Camshaft Timing (VCT) solenoid electrical connector.
15. Disconnect the 3 RH coil-on-plug electrical connectors.
16. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
17. Detach all of the wiring harness retainers from the RH valve cover and stud bolts.
18. Disconnect the LH CMS electrical connector.
19. Disconnect the LH VCT solenoid electrical connector.
20. Disconnect the 3 LH coil-on-plug electrical connectors.
21. Detach all of the wiring harness retainers from the LH valve cover and stud bolts.
22. Remove the 6 bolts and the 6 coil-on-plugs.
23. Remove the A/C compressor nut and stud.
24. Remove the PSP tube bracket-to-power steering pump bolt.
25. Remove the nut and the PSP tube bracket from the RH valve cover stud bolt.
26. Remove the 3 bolts and position aside the power steering pump.
27. Remove the 3 bolts and the accessory drive belt tensioner.
28. Remove the 4 nuts (3 shown in illustration) and the LH catalytic converter. Discard the nuts and the gasket. FWD vehicles
29. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and the gasket. All vehicles
30. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
31. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
32. Remove the engine cover stud from the LH valve cover stud bolt. Early build vehicles
33. Loosen the 11 stud bolts and remove the LH valve cover. Discard the gasket.
34. Loosen the bolt, the 10 stud bolts and remove the RH valve cover. Discard the gasket. Late build vehicles
35. Loosen the 9 stud bolts and remove the LH valve cover. Discard the gasket.
36. Loosen the 9 stud bolts and remove the RH valve cover. Discard the gasket. All vehicles
37. Inspect the VCT solenoid seals and the spark plug tube seals. Remove any damaged seals. Using the VCT Spark Plug Tube Seal Remover and Handle, remove the seal(s).
38. Using the Strap Wrench, remove the crankshaft pulley bolt and washer. Discard the bolt.
39. Using the 3 Jaw Puller, remove the crankshaft pulley.
40. Using the Oil Seal Remover, remove and discard the crankshaft front seal.
41. Remove the 2 bolts and the engine mount bracket.
42. Remove the 2 engine mount studs.
43. Remove the 3 bolts and the engine mount bracket.
44. Remove the 22 engine front cover bolts.
45. Install 6 of the engine front cover bolts (finger-tight) into the 6 threaded holes in the engine front cover. Tighten the bolts one turn at a time in a crisscross pattern until the engine front cover-to-cylinder block seal is released. Remove the engine front cover.
46. Remove the 16 oil pan bolts.
47. Install 2 of the oil pan bolts (finger-tight) into the 2 threaded holes in the oil pan. Alternately tighten the 2 bolts one turn at a time until the oil pan-to-cylinder block seal is released. Remove the oil pan.
48. Clean the engine front cover and oil pan using a 3M™ Roloc® Bristle Disk (2-in white, part number 07528) in a suitable tool turning at the recommended speed of 15,000 rpm. Thoroughly wash the engine front cover and oil pan to remove any foreign material, including any abrasive particles created during the cleaning process.
49. Clean the sealing surfaces of the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil or coolant and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal. Make sure the 2 locating dowel pins are seated correctly in the cylinder block.

Oil Pump Screen and Pickup Tube

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Scheme 540

1. Remove the oil pan. For additional information, refer to «OIL PAN»(ref-375983-S33856609152010103100000) .
2. Remove the 2 bolts and the oil pump screen and pickup tube. Discard the O-ring seal.

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. This procedure is for removal of the crankshaft rear seal and retainer plate and requires removal of the oil pan. If only removing the crankshaft rear seal, refer to CRANKSHAFT REAR SEAL .

Scheme 541

Scheme 542

Scheme 543

Scheme 544

Scheme 545

1. Remove the oil pan. For additional information, refer to «OIL PAN»(ref-375983-S33856609152010103100000) .
2. Using the Heavy Duty Floor Crane and Spreader Bar, remove the engine from the stand.
3. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
4. Remove the bolt and the CKP sensor.
5. Using the Crankshaft Rear Oil Seal Remover and Slide Hammer, remove and discard the rear crankshaft seal.
6. Remove the 8 crankshaft rear seal retainer bolts.
7. Install the 2 M6 oil pan bolts (finger-tight) into the 2 threaded holes in the crankshaft rear seal retainer. Alternately tighten the 2 bolts one turn at a time until the crankshaft rear seal retainer-to-cylinder block seal is released. Remove the crankshaft rear seal retainer.
8. Clean the crankshaft rear seal retainer plate using a 3M™ Roloc® Bristle Disk (2-in white, part number 07528) in a suitable tool turning at the recommended speed of 15,000 rpm. Thoroughly wash the crankshaft rear seal retainer plate to remove any foreign material, including any abrasive particles created during the cleaning process.
9. Clean the sealing surfaces of the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil or coolant and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. Early build engines have 11 fastener valve covers, late build engines have 9 fastener valve covers. Do not attempt to install bolts in the 2 empty late build valve cover holes or damage to the valve cover will occur.

Note. On early build engines, the timing chain rides on the inner side of the RH timing chain guide. Late build engines are equipped with a different design RH timing chain guide that requires the timing chain to ride on the outer side of the RH timing chain guide. For service, all replacement RH timing chain guides will be the late build design.

Note. For additional information, refer to the exploded view under the ASSEMBLY procedure.

All vehicles

Scheme 546

Scheme 547

Scheme 548

Scheme 549

Scheme 550

Scheme 551

Scheme 552

Scheme 553

Scheme 554

Scheme 555

Scheme 556

Scheme 557

Scheme 558

Scheme 559

Scheme 560

Scheme 561

Scheme 562

Scheme 563

Scheme 564

Scheme 565

Scheme 566

Scheme 567

Scheme 568

1. Remove the 8 bolts and the flexplate.
2. Remove the crankshaft sensor ring.
3. Using the Crankshaft Rear Oil Seal Remover and Slide Hammer, remove and discard the rear crankshaft seal.
4. Mount the engine on a suitable engine stand.
5. If equipped, remove the heat shield and disconnect the block heater electrical connector. Detach all of the engine block heater harness retainers and remove the harness.
6. Disconnect the PCV hose from the PCV valve.
7. Disconnect the Throttle Body (TB) electrical connector.
8. Detach the wiring harness retainers from the upper intake manifold.
9. Remove the upper intake manifold support bracket bolt.
10. Remove the wire harness pin-type retainer and the fuel tube bracket bolt from the upper intake manifold.
11. Remove the 6 bolts and the upper intake manifold. Discard the gaskets.
12. Disconnect the Power Steering Pressure (PSP) switch electrical connector. Front Wheel Drive (FWD) vehicles
13. Disconnect the RH Catalyst Monitor Sensor (CMS) electrical connector. All vehicles
14. Disconnect the RH Heated Oxygen Sensor (HO2S) electrical connector.
15. Disconnect the RH Variable Camshaft Timing (VCT) solenoid electrical connector.
16. Disconnect the 3 RH coil-on-plug electrical connectors.
17. Detach all of the wiring harness retainers from the RH valve cover and stud bolts.
18. Disconnect the RH Camshaft Position (CMP) sensor electrical connector.
19. Disconnect the Knock Sensor (KS) electrical connector.
20. Remove the bolt and the ground cable from the RH cylinder.
21. Disconnect the 6 fuel injector electrical connectors (3 shown in illustration).
22. Disconnect the Cylinder Head Temperature (CHT) sensor electrical connector.
23. Disconnect the LH CMP sensor electrical connector.
24. Disconnect the LH CMS electrical connector.
25. Disconnect the LH HO2S electrical connector.
26. Disconnect the 3 LH coil-on-plug electrical connectors.
27. Disconnect the LH VCT solenoid electrical connector.
28. Detach all of the wiring harness retainers from the LH valve cover and stud bolts.
29. Remove the nut, the bolt and the heat shield.
30. Remove the wiring harness retainer stud bolt.
31. Remove the wiring harness grommet.
32. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
33. Disconnect the A/C compressor electrical connector. Detach the A/C compressor wiring harness retainer.
34. Remove the nut and disconnect the generator B+ cable.
35. Disconnect the generator electrical connector.
36. Disconnect the Engine Oil Pressure (EOP) switch electrical connector and the wiring harness pin-type retainer. Remove the wiring harness from the engine.
37. Remove the nut, 2 bolts and the A/C compressor.
38. Remove the A/C compressor mounting stud from the oil pan.
39. Remove the nut, bolt and the generator. Remove the generator stud.
40. Remove the PSP tube bracket-to-power steering pump bolt.
41. Remove the nut and the PSP tube bracket from the RH valve cover stud bolt.
42. Remove the bolt and the PSP tube bracket from the RH cylinder head.
43. Remove the 3 bolts and position aside the power steering pump.
44. Remove the 3 bolts and the accessory drive belt tensioner.
45. Remove the 4 nuts (3 shown in illustration) and the LH catalytic converter. Discard the nuts and the gasket.
46. Remove the 3 bolts and the LH exhaust manifold heat shield.
47. Remove the 6 nuts and the LH exhaust manifold. Discard the nuts and exhaust manifold gaskets.
48. Clean and inspect the LH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
49. Remove and discard the 6 LH exhaust manifold studs. FWD vehicles
50. Remove the 4 nuts and the RH catalytic converter. Discard the nuts and the gasket. All vehicles
51. Remove the 3 bolts and the RH exhaust manifold heat shield.
52. Remove the 6 nuts and the RH exhaust manifold. Discard the nuts and exhaust manifold gaskets.
53. Clean and inspect the RH exhaust manifold. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
54. Remove and discard the 6 RH exhaust manifold studs.
55. Remove the RH cylinder block drain plug or, if equipped, the block heater. Allow coolant to drain from the cylinder block.
56. Remove the LH cylinder block drain plug. Allow coolant to drain from the cylinder block.
57. Remove the pin-type retainer and the cover.
58. Remove the 2 bolts and the engine lifting eye.
59. Remove the bolt and the upper intake manifold support bracket.
60. Remove the bolt and the RH CMP sensor.
61. Remove the coolant bypass hose from the thermostat housing.
62. Remove the 4 bolts and the fuel rail and injectors as an assembly.
63. Remove the 3 thermostat housing-to-lower intake manifold bolts. Remove the thermostat housing and discard the gasket.
64. Remove the 10 bolts and the lower intake manifold. Discard the gaskets.
65. Disconnect and remove the CHT sensor jumper harness.
66. Remove the bolt and the LH CMP sensor.
67. Remove the bolt and the CKP sensor.
68. Remove the 3 bolts and the oil filter adapter. Discard the gasket.
69. Remove the EOP switch.
70. Remove the 6 bolts and the 6 coil-on-plugs.
71. Remove the engine cover stud from the LH valve cover stud bolt. Early build vehicles
72. Loosen the 11 stud bolts and remove the LH valve cover. Discard the gasket.
73. Loosen the bolt, the 10 stud bolts and remove the RH valve cover. Discard the gasket. Late build vehicles
74. Loosen the 9 stud bolts and remove the LH valve cover. Discard the gasket.
75. Loosen the 9 stud bolts and remove the RH valve cover. Discard the gasket. All vehicles
76. Inspect the VCT solenoid seals and the spark plug tube seals. Remove any damaged seals. Using the VCT Spark Plug Tube Seal Remover and Handle, remove the seal(s).
77. Using the Strap Wrench, remove the crankshaft pulley bolt and washer. Discard the bolt.
78. Using the 3 Jaw Puller, remove the crankshaft pulley.
79. Using the Oil Seal Remover, remove and discard the crankshaft front seal.
80. Remove the 2 bolts and the engine mount bracket.
81. Remove the 2 engine mount studs.
82. Remove the 3 bolts and the engine mount bracket.
83. Remove the 22 engine front cover bolts.
84. Install 6 of the engine front cover bolts (finger tight) into the 6 threaded holes in the engine front cover. Tighten the bolts one turn at a time in a crisscross pattern until the engine front cover-to-cylinder block seal is released. Remove the engine front cover. Engines equipped with early build RH timing chain guides
85. Rotate the crankshaft clockwise and align the timing marks on the VCT assemblies as shown in illustration. Engines equipped with late build/replacement RH timing chain guides
86. Rotate the crankshaft clockwise and align the timing marks on the VCT assemblies as shown in illustration. All vehicles
87. Install the Camshaft Holding Tool onto the flats of the LH camshafts.
88. Install the Camshaft Holding Tool onto the flats of the RH camshafts.
89. Remove the 3 bolts and the RH VCT housing.
90. Remove the 3 bolts and the LH VCT housing.
91. Remove the 2 bolts and the primary timing chain tensioner.
92. Remove the primary timing chain tensioner arm.
93. Remove the 2 bolts and the lower LH primary timing chain guide.
94. Remove the primary timing chain.
95. Remove the crankshaft timing chain sprocket.
96. Remove the 2 bolts and the upper LH primary timing chain guide.
97. Compress the LH secondary timing chain tensioner and install a suitable lockpin to retain the tensioner in the collapsed position.
98. Remove and discard the LH VCT assembly bolt and the LH exhaust camshaft sprocket bolt. Remove the VCT assembly, secondary timing chain and the LH exhaust camshaft sprocket as an assembly.
99. Remove the Camshaft Holding Tool from the LH camshafts.
100. Verify the LH camshafts are in the neutral position.
101. Remove the 2 bolts and the LH secondary timing chain tensioner.
102. Remove the bolts and the LH camshaft bearing caps. Remove the LH camshafts.
103. Compress the RH secondary timing chain tensioner and install a suitable lockpin to retain the tensioner in the collapsed position.
104. Remove and discard the RH VCT assembly bolt and the RH exhaust camshaft sprocket bolt. Remove the RH VCT assembly, secondary timing chain and the RH exhaust camshaft sprocket as an assembly.
105. Remove the Camshaft Holding Tool from the RH camshafts.
106. Rotate the RH camshafts counterclockwise to the neutral position.
107. Remove the 2 bolts and the RH secondary timing chain tensioner. Engines equipped with early build RH timing chain guides
108. Remove the 2 bolts and the RH primary timing chain guide. Engines equipped with late build/replacement RH timing chain guides
109. Loosen the RH primary timing chain guide upper bolt. Position the RH primary timing chain guide and install the lower bolt. Tighten the 2 bolts to 10 Nm (89 lb-in). All vehicles
110. Remove the bolts and the RH camshaft bearing caps. Remove the RH camshafts.
111. Remove the valve tappets from the cylinder heads.
112. Remove and discard the M6 bolt from each cylinder head.
113. Remove and discard the 8 bolts from each cylinder head. Remove the cylinder heads. Discard the cylinder head gaskets.
114. Clean the cylinder head-to-cylinder block mating surfaces of both the cylinder heads and the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material with a plastic scraper. Apply silicone gasket remover, following package directions, and allow to set for several minutes. Remove the silicone gasket remover with a plastic scraper. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep, following package directions, to remove any remaining traces of oil or coolant and to prepare the surfaces to bond with the new gasket. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal.
115. Support the cylinder head on a bench with the head gasket side up. Check the cylinder head distortion and the cylinder block distortion. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
116. Remove the coolant inlet tube. Remove and discard the O-ring seals.
117. Remove the 2 bolts and the KS .
118. Remove the 8 bolts and the coolant pump.
119. Remove the 16 oil pan bolts.
120. Install 2 of the oil pan bolts (finger-tight) into the 2 threaded holes in the oil pan. Alternately tighten the 2 bolts one turn at a time until the oil pan-to-cylinder block seal is released. Remove the oil pan.
121. Remove the 2 bolts and the oil pump screen and the pickup tube. Discard the O-ring seal.
122. Remove the 3 bolts and the oil pump.
123. Remove the 8 crankshaft rear seal retainer bolts.
124. Install the 2 M6 oil pan bolts (finger-tight) into the 2 threaded holes in the crankshaft rear seal retainer. Alternately tighten the 2 bolts one turn at a time until the crankshaft rear seal retainer-to-cylinder block seal is released. Remove the crankshaft rear seal retainer.
125. Clean the engine front cover, oil pan and crankshaft rear seal retainer plate using a 3M™ Roloc® Bristle Disk (2-in white, part number 07528) in a suitable tool turning at the recommended speed of 15,000 rpm. Thoroughly wash the engine front cover, oil pan and crankshaft rear seal retainer plate to remove any foreign material, including any abrasive particles created during the cleaning process.
126. Before removing the pistons, inspect the top of the cylinder bores. If necessary, remove the ridge or carbon deposits from each cylinder using an abrasive pad or equivalent, following manufacturer's instructions.
127. Remove the bolts in the sequence shown in illustration. Remove the main bearing cap support brace. Discard the bolts.
128. Remove the connecting rod cap bolts and cap.
129. Remove the piston/rod assembly from the engine block.
130. Repeat the previous 2 steps until all the piston/rod assemblies are removed from the engine block.
131. Remove the 8 main bearing cap side bolts and the 8 main bearing cap bolts in the sequence shown in illustration. Discard the bolts.
132. Remove the 4 main bearing caps.
133. Remove the crankshaft.
134. Remove the 2 crankshaft thrust bearings from the rear main bearing bulkhead.
135. Remove the 4 crankshaft main bearings from the cylinder block.
136. Remove the 4 crankshaft main bearings from the main bearing caps.
137. Inspect the cylinder block, bearing cap support brace, pistons and connecting rods. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-375993) .
138. Clean the sealing surfaces of the cylinder block in the following sequence. Remove any large deposits of silicone or gasket material. Apply silicone gasket remover and allow to set for several minutes. Remove the silicone gasket remover. A second application of silicone gasket remover may be required if residual traces of silicone or gasket material remain. Apply metal surface prep to remove any remaining traces of oil or coolant and to prepare the surfaces to bond. Do not attempt to make the metal shiny. Some staining of the metal surfaces is normal. Make sure the 2 engine front cover locating dowel pins are seated correctly in the cylinder block.

MATERIAL SPECIFICATIONS

Scheme 569

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 570

ITEM DESCRIPTION CHART

MATERIAL SPECIFICATIONS

Scheme 571

ITEM DESCRIPTION CHART

Scheme 572

ITEM DESCRIPTION CHART

Scheme 573

ITEM DESCRIPTION CHART

Engine Front

Note. Early build shown in illustration, late build similar.

Scheme 574

ITEM DESCRIPTION CHART

Scheme 575

ITEM DESCRIPTION CHART

Scheme 576

ITEM DESCRIPTION CHART

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. Early build engines have 11 fastener valve covers, late build engines have 9 fastener valve covers. Do not attempt to install bolts in the 2 empty late build valve cover holes or damage to the valve cover will occur.

Note. Assembly of the engine requires various inspections/measurements of the engine components (engine block, crankshaft, connecting rods, pistons and piston rings). These inspections/measurements will aid in determining if the engine components will require replacement. For additional information, refer to ENGINE SYSTEM - GENERAL INFORMATION .

Note. On early build engines, the timing chain rides on the inner side of the RH timing chain guide. Late build engines are equipped with a different design RH timing chain guide that requires the timing chain to ride on the outer side of the RH timing chain guide. For service, all replacement RH timing chain guides will be the late build design.

All vehicles

Scheme 577

Scheme 578

Scheme 579

Scheme 580

Scheme 581

Scheme 582

Scheme 583

Scheme 584

Scheme 585

Scheme 586

Scheme 587

Scheme 588

Scheme 589

Scheme 590

Scheme 591

Scheme 592

Scheme 593

Scheme 594

Scheme 595

Scheme 596

Scheme 597

Scheme 598

Scheme 599

Scheme 600

Scheme 601

Scheme 602

Scheme 603

Scheme 604

Scheme 605

Scheme 606

Scheme 607

Scheme 608

Scheme 609

Scheme 610

Scheme 611

Scheme 612

Scheme 613

Scheme 614

Scheme 615

Scheme 616

Scheme 617

Scheme 618

Scheme 619

Scheme 620

Scheme 621

Scheme 622

Scheme 623

Scheme 624

Scheme 625

Scheme 626

Scheme 627

Scheme 628

Scheme 629

Scheme 630

Scheme 631

Scheme 632

Scheme 633

Scheme 634

Scheme 635

Scheme 636

Scheme 637

Scheme 638

Scheme 639

Scheme 640

Scheme 641

Scheme 642

Scheme 643

Scheme 644

Scheme 645

Scheme 646

Scheme 647

Scheme 648

Scheme 649

Scheme 650

Scheme 651

Scheme 652

Scheme 653

Scheme 654

Scheme 655

Scheme 656

Scheme 657

Scheme 658

Scheme 659

Scheme 660

Scheme 661

Scheme 662

Scheme 663

Scheme 664

Scheme 665

Scheme 666

Scheme 667

Scheme 668

Scheme 669

Scheme 670

Scheme 671

Scheme 672

Scheme 673

Scheme 674

Scheme 675

Scheme 676

Scheme 677

Scheme 678

Scheme 679

Scheme 680

Scheme 681

Scheme 682

Scheme 683

Scheme 684

Scheme 685

Scheme 686

Scheme 687

Scheme 688

Scheme 689

Scheme 690

Scheme 691

Scheme 692

Scheme 693

Scheme 694

Scheme 695

Scheme 696

Scheme 697

Scheme 698

Scheme 699

Scheme 700

Scheme 701

Scheme 702

Scheme 703

Scheme 704

1. Select the crankshaft main bearings for each crankshaft journal. Read the code on the crankshaft flange. Read the code on the cylinder block face. The first letter after the first asterisk makes up the code for main No. 1 and the next letter for main No. 2. The first letter after the second asterisk makes up the code for main No. 3 and the last letter for main No. 4.
2. Using the chart, choose a bearing for each main. Match the block and crankshaft code with its corresponding column or row, by reading across the "crankshaft" row and down the "block" column. If the block code is *BM*QS* and the crankshaft code is *OL*PO*, Main No. 1 should be built with grade 1 bearings, as determined by the intersection of the B block column and the O crankshaft row on the chart. Mains No. 2, No. 3 and No. 4 should all be grade 2.
3. Using the original connecting rod cap bolts, install the connecting rod caps and bolts. Tighten the bolts in 3 stages. Stage 1: Tighten to 23 Nm (17 lb-ft). Stage 2: Tighten to 43 Nm (32 lb-ft). Stage 3: Tighten an additional 90 degrees.
4. Measure the connecting rod large end bore in 2 directions. Remove the bolts and the rod cap. Discard the connecting rod cap bolts.
5. Measure each of the crankshaft connecting rod bearing journal diameters in at least 2 directions.
6. Using the chart, select the correct connecting rod bearings for each crankshaft connecting rod journal.
7. Lubricate the upper crankshaft main bearings with clean engine oil and install the 4 crankshaft main bearings in the cylinder block.
8. Install the crankshaft onto the upper main bearings.
9. Push the crankshaft rearward and install the rear crankshaft upper thrust washer at the back of the No. 4 rear bulkhead.
10. Push the crankshaft forward and install the front crankshaft upper thrust washer at the front of the No. 4 rear bulkhead.
11. Lubricate the crankshaft lower main bearings with clean engine oil and install them into the main bearing caps. Visually check seating and squareness of the bearings to make sure of proper seating in caps.
12. Position the No. 1, No. 2 and No. 3 main bearing caps on the cylinder block and, keeping the caps as square as possible, alternately draw the caps down evenly using the new bolts until the main bearing caps are seated.
13. Install the lower crankshaft thrust washer to the back side of the No. 4 rear main bearing cap, with the tab aligned with the cutout in the main bearing cap.
14. Position main bearing cap No. 4 on the cylinder block and keeping the cap as square as possible, alternately draw the cap down evenly using the new bolts until the main bearing cap is seated.
15. Loosen the No. 4 main bearing cap bolts.
16. Tighten the main bearing bolts in the sequence shown in illustration in 2 stages. Stage 1: Tighten fasteners 1 through 8 to 60 Nm (44 lb-ft). Stage 2: Tighten fasteners 1 through 8 an additional 90 degrees.
17. Install the new 8 main bearing cap side bolts. Tighten in the sequence shown in illustration in 2 stages. Stage 1: Tighten fasteners 1 through 8 to 45 Nm (33 lb-ft). Stage 2: Tighten fasteners 1 through 8 an additional 90 degrees.
18. Using the Dial Indicator Gauge with Holding Fixture, measure crankshaft end play. Position the crankshaft to the rear of the cylinder block. Zero the Dial Indicator Gauge. Move the crankshaft to the front of the cylinder block. Note and record the crankshaft end play.
19. Prepare the connecting rod and cap. Insert the new bolts in the rod cap. Insert the upper and lower rod bearings into the rod and cap.
20. Before installing the pistons into the cylinder block, verify proper ring gap location. Center line of the piston parallel to the wrist pin bore Upper compression ring gap location Upper oil control segment ring gap location Lower oil control segment ring gap location Expander ring and lower compression ring gap location
21. Using the Piston Ring Compressor, install the piston and connecting rod assemblies.
22. Seat the connecting rod on the crankshaft journal.
23. Install the connecting rod cap and bolts. Tighten the bolts in 3 stages. Stage 1: Tighten to 23 Nm (17 lb-ft). Stage 2: Tighten to 43 Nm (32 lb-ft). Stage 3: Tighten an additional 90 degrees.
24. Repeat the previous 3 steps until all 6 piston, connecting rod and connecting rod cap assemblies are installed.
25. Install the main bearing cap support brace and the new bolts. Tighten in the sequence shown in illustration in 2 steps. Stage 1: Tighten fasteners to 20 Nm (177 lb-in). Stage 2: Tighten fasteners an additional 180 degrees.
26. Apply a 3 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the sealing surface of the crankshaft rear seal retainer.
27. Install the crankshaft rear seal retainer and the 8 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
28. Install the oil pump and the 3 bolts. Tighten to 10 Nm (89 lb-in).
29. Using a new O-ring seal, install the oil pump screen and pickup tube and the 2 bolts. Tighten to 10 Nm (89 lb-in).
30. Install the A/C compressor and the 2 bolts. Tighten to 25 Nm (18 lb-ft).
31. Apply a 3 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the sealing surface of the oil pan. Apply a 5.5 mm (0.21 in) bead of Motorcraft® High Performance Engine RTV Silicone to the 2 crankshaft seal retainer plate-to-cylinder block joint areas on the sealing surface of the oil pan.
32. Install the oil pan and bolts 10, 11, 13 and 14. Tighten the bolts in the sequence shown in illustration to 3 Nm (27 lb-in). Loosen the bolts 180 degrees.
33. Align the oil pan to the cylinder block and A/C compressor. Position the oil pan so the mounting boss is against the A/C compressor and using a straightedge, align the oil pan flush with the rear of the cylinder block at the 2 areas shown in illustration.
34. Tighten bolts 10, 11, 13 and 14 in the sequence shown in illustration to 3 Nm (27 lb-in).
35. Install the remaining oil pan bolts. Tighten all the oil pan bolts in the sequence shown in illustration. Tighten the large bolts (1-14) to 20 Nm (177 lb-in). Tighten the small bolts (15 and 16) to 10 Nm (89 lb-in).
36. Install the A/C compressor mounting stud and nut. Tighten the stud to 9 Nm (80 lb-in) and the nut to 25 Nm (18 lb-ft).
37. Install the coolant pump and the 8 bolts. Tighten in the sequence shown in illustration in 2 stages: Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten an additional 45 degrees.
38. Install the Knock Sensor (KS) and the 2 bolts. Tighten to 20 Nm (177 lb-in).
39. Using new O-ring seals, install the coolant inlet tube.
40. Install a new gasket, the RH cylinder head and 8 new bolts. Tighten in the sequence shown in illustration in 5 stages: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 35 Nm (26 lb-ft). Stage 3: Tighten 90 degrees. Stage 4: Tighten 90 degrees. Stage 5: Tighten 90 degrees.
41. Install the M6 bolt. Tighten to 10 Nm (89 lb-in).
42. Install a new gasket, the LH cylinder head and 8 new bolts. Tighten in the sequence shown in illustration in 5 stages: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 35 Nm (26 lb-ft). Stage 3: Tighten 90 degrees. Stage 4: Tighten 90 degrees. Stage 5: Tighten 90 degrees.
43. Install the M6 bolt. Tighten to 10 Nm (89 lb-in).
44. Position the crankshaft dowel pin in the 9 o'clock position.
45. Install the valve tappets.
46. Position the camshafts onto the RH cylinder head in the neutral position as shown in illustration.
47. Install the 8 camshaft caps and the 16 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
48. Position the camshafts onto the LH cylinder head in the neutral position as shown in illustration.
49. Install the 8 camshaft caps and the 16 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
50. Using a feeler gauge, confirm that the valve tappet clearances are within specification. For additional information, refer to «VALVE CLEARANCE CHECK»(ref-375983-S29344586002010103100000) . Engines equipped with early build RH timing chain guides
51. Install the RH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in). Engines equipped with late build/replacement RH timing chain guides
52. Install the RH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in). All vehicles
53. Install the RH secondary timing chain tensioner and the 2 bolts. Tighten to 10 Nm (89 lb-in).
54. Rotate the RH camshafts to the Top Dead Center (TDC) position and install the Camshaft Holding Tool on the flats of the camshafts.
55. Assemble the RH Variable Camshaft Timing (VCT) assembly, the RH exhaust camshaft sprocket and the RH secondary timing chain. Align the colored links with the timing marks.
56. Position the RH secondary timing assembly onto the camshafts.
57. Install the new VCT bolt and the exhaust camshaft bolt and the original washers. Tighten in 4 stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 10 Nm (89 lb-in). Stage 4: Tighten 90 degrees.
58. Remove the lockpin from the RH secondary timing chain tensioner.
59. Install the LH secondary timing chain tensioner and the 2 bolts. Tighten to 10 Nm (89 lb-in).
60. Rotate the LH camshafts to the TDC position and install the Camshaft Holding Tool on the flats of the camshafts.
61. Assemble the LH VCT assembly, the LH exhaust camshaft sprocket and the LH secondary timing chain. Align the colored links with the timing marks.
62. Position the LH secondary timing assembly onto the camshafts.
63. Install the new VCT bolt and the exhaust camshaft bolt and the original washers. Tighten in 4 stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 10 Nm (89 lb-in). Stage 4: Tighten 90 degrees.
64. Remove the lockpin from the LH secondary timing chain tensioner.
65. Rotate the crankshaft clockwise 60 degrees to the TDC position (crankshaft dowel pin at 11 o'clock).
66. Install the crankshaft timing chain sprocket.
67. Install the primary timing chain with the colored links aligned with the timing marks on the VCT assemblies and the crankshaft sprocket.
68. Install the upper LH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in).
69. Install the lower LH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in).
70. Install the primary timing chain tensioner arm.
71. Reset the primary timing chain tensioner. Rotate the lever counterclockwise. Using a soft-jawed vise, compress the plunger. Align the hole in the lever with the hole in the tensioner housing. Install a suitable lockpin.
72. Install the primary tensioner and the 2 bolts. Tighten to 10 Nm (89 lb-in). Remove the lockpin.
73. As a post-check, verify correct alignment of all timing marks.
74. Inspect the VCT housing seals for damage and replace as necessary.
75. Install the LH VCT housing and the 3 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
76. Install the RH VCT housing and the 3 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
77. Install the Alignment Pins.
78. Apply a 3.0 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover sealing surfaces including the 3 engine mount bracket bosses. Apply a 5.5 mm (0.21 in) bead of Motorcraft® High Performance Engine RTV Silicone to the oil pan-to-cylinder block joint and the cylinder head-to-cylinder block joint areas of the engine front cover in 5 places as indicated.
79. Install the engine front cover and bolts 17, 18, 19 and 20. Tighten in sequence to 3 Nm (27 lb-in).
80. Remove the Alignment Pins.
81. Install the engine mount bracket and the 3 bolts.
82. Install the remaining engine front cover bolts. Tighten all of the engine front cover bolts and engine mount bracket bolts in the sequence shown in illustration in 2 stages: Stage 1: Tighten bolts 1 thru 22 to 10 Nm (89 lb-in) and bolts 23, 24 and 25 to 15 Nm (133 lb-in). Stage 2: Tighten bolts 1 thru 22 to 24 Nm (18 lb-ft) and bolts 23, 24 and 25 to 75 Nm (55 lb-ft).
83. Install the engine mount studs in the following sequence. Clean the front cover engine mount stud holes with pressurized air to remove any foreign material. Clean all the thread sealer from the engine mount studs (old and new studs). Apply new Threadlock and Sealer to the engine mount stud threads. Install the 2 engine mount studs. Tighten to 20 Nm (177 lb-in).
84. Install the engine mount bracket and the 2 bolts. Tighten to 24 Nm (18 lb-ft).
85. Using the Crankshaft Vibration Damper Installer and Front Crankshaft Seal Installer, install a new crankshaft front seal.
86. Using the Crankshaft Vibration Damper Installer and Front Cover Oil Seal Installer, install the crankshaft pulley.
87. Using the Strap Wrench, install the crankshaft pulley washer and new bolt and tighten in 4 stages. Stage 1: Tighten to 120 Nm (89 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
88. Using the VCT Spark Plug Tube Seal Installer and Handle, install new VCT solenoid and/or spark plug tube seals.
89. Apply an 8 mm (0.31 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover-to-RH cylinder head joints. Early build vehicles
90. Using a new gasket, install the RH valve cover, bolt and the 10 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). Late build vehicles
91. Using a new gasket, install the RH valve cover and tighten the 9 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). All vehicles
92. Apply an 8 mm (0.31 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover-to-LH cylinder head joints. Early build vehicles
93. Using a new gasket, install the LH valve cover and 11 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). Late build vehicles
94. Using a new gasket, install the LH valve cover and tighten the 9 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). All vehicles
95. Install the engine cover stud to the LH valve cover stud bolt. Tighten to 6 Nm (53 lb-in).
96. Install the 6 coil-on-plug assemblies and the 6 bolts. Tighten to 7 Nm (62 lb-in).
97. Install the EOP switch. Tighten to 18 Nm (159 lb-in).
98. Using a new gasket, install the oil filter adapter and 3 bolts. Tighten to 10 Nm (89 lb-in).
99. Install the Crankshaft Position (CKP) sensor and install the bolt. Tighten to 10 Nm (89 lb-in).
100. Install LH Camshaft Position (CMP) sensor and the bolt. Tighten to 10 Nm (89 lb-in).
101. Install and connect the Cylinder Head Temperature (CHT) sensor jumper harness.
102. Using new gaskets, install the lower intake manifold and the 10 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
103. Using a new gasket, install the thermostat housing and the 3 bolts. Tighten to 10 Nm (89 lb-in).
104. Install new fuel injector O-ring seals. Remove the retaining clips and separate the fuel injectors from the fuel rail. Remove and discard the O-ring seals. Install new O-ring seals and lubricate with clean engine oil. Install the fuel injectors and the retaining clips onto the fuel rail.
105. Install the fuel rail and injectors as an assembly and install the 4 bolts. Tighten to 10 Nm (89 lb-in).
106. Install the coolant bypass hose to the thermostat housing.
107. Install the RH CMP sensor and the bolt. Tighten to 10 Nm (89 lb-in).
108. Install the upper intake manifold support bracket and the bolt. Tighten to 10 Nm (89 lb-in).
109. Install the engine lifting eye and the 2 bolts. Tighten to 24 Nm (18 lb-ft).
110. Install the cover and the pin-type retainer.
111. Install the LH cylinder block drain plug. Tighten to 20 Nm (177 lb-in) plus an additional 180 degrees.
112. Install the RH cylinder block drain plug or, if equipped, the block heater. Tighten to 40 Nm (30 lb-ft).
113. Install 6 new RH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
114. Using a new gasket, install the RH exhaust manifold and 6 new nuts. Tighten in 2 stages in the sequence shown in illustration: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
115. Install the RH exhaust manifold heat shield and the 3 bolts. Tighten to 10 Nm (89 lb-in). Front Wheel Drive (FWD) vehicles
116. Using a new gasket, install the RH catalytic converter and the 4 new nuts. Tighten to 40 Nm (30 lb-ft). All vehicles
117. Install 6 new LH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
118. Using a new gasket, install the LH exhaust manifold and 6 new nuts. Tighten in 2 stages in the sequence shown in illustration: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
119. Install the LH exhaust manifold heat shield and the 3 bolts. Tighten to 10 Nm (89 lb-in).
120. Using a new gasket, install the LH catalytic converter and 4 new nuts (3 shown in illustration). Tighten to 40 Nm (30 lb-ft).
121. Install the accessory drive belt tensioner and the 3 bolts. Tighten to 11 Nm (97 lb-in).
122. Install the power steering pump and the 3 bolts. Tighten to 25 Nm (18 lb-ft).
123. Install the Power Steering Pressure (PSP) tube bracket and the bolt to the RH cylinder head. Tighten to 10 Nm (89 lb-in).
124. Install the PSP tube bracket and nut to the RH valve cover stud bolt. Tighten to 7 Nm (62 lb-in).
125. Install the PSP tube bracket bolt. Tighten to 10 Nm (89 lb-in).
126. Install the stud, generator and the nut and the bolt. Tighten the generator stud to 12 Nm (106 lb-in). Tighten nut and bolt to 48 Nm (35 lb-ft).
127. Position the wiring harness onto the engine.
128. Connect the EOP switch electrical connector and the wiring harness pin-type retainer.
129. Connect the generator electrical connector.
130. Connect the generator B+ cable and install the nut. Tighten to 17 Nm (150 lb-in).
131. Connect the A/C compressor electrical connector. Attach the A/C compressor wiring harness retainer.
132. Connect the CKP sensor electrical connector.
133. Install the wiring harness grommet.
134. Install the wiring harness retainer stud bolt. Tighten to 10 Nm (89 lb-in).
135. Install the heat shield, the nut and the bolt. Tighten to 10 Nm (89 lb-in).
136. Attach all of the wiring harness retainers to the LH valve cover and stud bolts.
137. Connect the LH camshaft VCT solenoid electrical connector.
138. Connect the 3 LH coil-on-plug electrical connectors.
139. Connect the LH Heated Oxygen Sensor (HO2S) electrical connector.
140. Connect the LH CMS electrical connector.
141. Connect the LH CMP sensor electrical connector.
142. Connect the CHT sensor electrical connector.
143. Connect the 6 fuel injector electrical connectors (3 shown in illustration).
144. Install the RH cylinder head ground cable and the bolt. Tighten to 10 Nm (89 lb-in).
145. Connect the KS electrical connector.
146. Connect the RH CMP sensor electrical connector.
147. Attach all of the wiring harness retainers to the RH valve cover and stud bolts.
148. Connect the 3 RH coil-on-plug electrical connectors.
149. Connect the RH VCT solenoid electrical connector.
150. Connect the RH HO2S electrical connector. FWD vehicles
151. Connect the RH CMS electrical connector. All vehicles
152. Connect the PSP switch electrical connector.
153. Using a new gasket, install the upper intake manifold and the 6 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
154. Install the fuel tube bracket bolt to the upper intake manifold and install the wiring harness pin-type retainer. Tighten to 6 Nm (53 lb-in).
155. Install the upper intake manifold support bracket bolt. Tighten to 10 Nm (89 lb-in).
156. Attach the wiring harness retainers to the upper intake manifold.
157. Connect the Throttle Body (TB) electrical connector.
158. Connect the PCV hose to the PCV valve.
159. If equipped, position the block heater wiring harness onto the engine and attach all of the harness retainers.
160. If equipped, connect the block heater electrical connector and install the heat shield.
161. Install the Engine Lift Eye on the LH cylinder head.
162. Using the Heavy Duty Floor Crane and Spreader Bar, remove the engine from the stand.
163. Position the Rear Main Seal Installer onto the end of the crankshaft and slide a new crankshaft rear seal onto the tool.
164. Using the Rear Main Seal Installer and Handle, install the new crankshaft rear seal.
165. Install the crankshaft sensor ring.
166. Install the flexplate and the 8 bolts. Tighten to 80 Nm (59 lb-ft).

MATERIAL SPECIFICATIONS

All vehicles

Scheme 705

Scheme 706

Scheme 707

Scheme 708

Scheme 709

Scheme 710

Scheme 711

Scheme 712

Scheme 713

Scheme 714

Scheme 715

Scheme 716

Scheme 717

Scheme 718

Scheme 719

Scheme 720

Scheme 721

Scheme 722

Scheme 723

Scheme 724

Scheme 725

Scheme 726

Scheme 727

Scheme 728

Scheme 729

Scheme 730

Scheme 731

Scheme 732

Scheme 733

Scheme 734

Scheme 735

Scheme 736

Scheme 737

Scheme 738

Scheme 739

Scheme 740

Scheme 741

Scheme 742

Scheme 743

Scheme 744

Scheme 745

Scheme 746

Scheme 747

Scheme 748

Scheme 749

Scheme 750

Scheme 751

Scheme 752

Scheme 753

Scheme 754

Scheme 755

Scheme 756

Scheme 757

Scheme 758

Scheme 759

Scheme 760

Scheme 761

Scheme 762

Scheme 763

Scheme 764

Scheme 765

Scheme 766

Scheme 767

Scheme 768

Scheme 769

Scheme 770

Scheme 771

Scheme 772

Scheme 773

1. Using the Heavy Duty Floor Crane and Spreader Bar, align the transaxle to the engine.
2. Install the 5 transaxle-to-engine bolts. Tighten to 48 Nm (35 lb-ft).
3. Install the 2 engine-to-transaxle bolts. Tighten to 48 Nm (35 lb-ft).
4. Using the Heavy Duty Floor Crane and Spreader Bar, position the engine and transaxle onto the Powertrain Lift table.
5. Install the Powertrain Lift and Universal Adapter Brackets.
6. Attach the transaxle control wire harness retainer to the transaxle stud bolt.
7. Connect the transaxle control electrical connector.
8. Install the starter, the stud bolt and bolt. Tighten to 27 Nm (20 lb-ft).
9. Connect the wiring harness retainer to the starter motor stud bolt.
10. Attach the starter wire terminals and install the 2 nuts. Tighten the B+ terminal nut to 12 Nm (106 lb-in). Tighten the S-terminal nut to 5 Nm (44 lb-in).
11. Install the starter motor solenoid cover.
12. Raise the engine and transaxle assembly into the vehicle.
13. Install the engine mount and the 3 bolts. Tighten to 90 Nm (66 lb-ft).
14. Install the 4 engine mount nuts. Tighten to 63 Nm (46 lb-ft).
15. Install the engine mount brace, nut and bolt. Tighten to 20 Nm (177 lb-in).
16. Install the transaxle support insulator bracket, 3 nuts and the bolt. Tighten the transaxle support insulator bracket nuts to 63 Nm (46 lb-ft). Tighten the transaxle support insulator bolt to 55 Nm (41 lb-ft).
17. Install the transaxle support insulator through bolt and nut. Tighten to 175 Nm (129 lb-ft). All-Wheel Drive (AWD) vehicles
18. Using a small screwdriver, remove the compression seal and discard.
19. Using a soft face hammer, install the new compression seal.
20. Position the Power Transfer Unit (PTU) in place and install the 5 bolts. Tighten to 90 Nm (66 lb-ft).
21. Position the PTU support bracket in place and install the 5 bolts. Tighten to 70 Nm (52 lb-ft).
22. Using a new gasket, install the RH catalytic converter and 4 new nuts. Tighten to 40 Nm (30 lb-ft).
23. Connect the RH Catalyst Monitor Sensor (CMS) electrical connector.
24. Install a new intermediate shaft seal and deflector. For additional information, refer to «TRANSFER CASE - POWER TRANSFER UNIT (PTU)»(ref-376013) . All vehicles
25. Install the 4 oil pan-to-transaxle bolts. Tighten to 48 Nm (35 lb-ft).
26. Install 3 new torque converter bolts. Tighten to 55 Nm (41 lb-ft).
27. Install the inspection cover and the 2 fasteners.
28. Connect the transaxle cooler tubes and install the 2 secondary latches.
29. Install the RH halfshaft support bracket and the 4 bolts. Tighten the halfshaft support-to-cylinder block bolts to 40 Nm (30 lb-ft). Tighten the catalytic converter-to-halfshaft support bolts to 20 Nm (177 lb-in).
30. Install the 2 halfshaft support bracket studs. Tighten to 10 Nm (89 lb-in).
31. Install the correct new circlip on the inboard stub shaft.
32. Push the stub shaft into the transmission so the circlip locks into the differential side gear.
33. Rotate the LH wheel knuckle into position and insert the LH halfshaft into the wheel hub.
34. Install the intermediate and halfshaft assembly and the 2 bolts. Tighten to 25 Nm (18 lb-ft).
35. Rotate the RH wheel knuckle into position and insert the RH halfshaft into the wheel hub.
36. Using the Powertrain Lift, raise the subframe into the installed position.
37. Install the 2 front subframe bolts. Tighten to 200 Nm (148 lb-ft).
38. Position the subframe brackets and install the 4 bolts finger-tight.
39. Install the 2 rear subframe bolts. Tighten to 150 Nm (111 lb-ft).
40. Tighten the 4 subframe bracket-to-body bolts to 55 Nm (41 lb-ft).
41. Position the ball joints into the wheel knuckles. Install the new ball joint nuts. Tighten to 200 Nm (148 lb-ft).
42. Install new tie-rod end nuts. Tighten to 150 Nm (111 lb-ft).
43. Install new upper stabilizer bar link nuts. Tighten to 150 Nm (111 lb-ft).
44. Install the 2 front engine roll restrictor-to-transaxle bolts. Tighten to 90 Nm (66 lb-ft).
45. Install the 2 rear engine roll restrictor-to-transaxle bolts. Tighten to 90 Nm (66 lb-ft).
46. Using a new O-ring seal, install the Power Steering Pressure (PSP) tube onto the steering gear, rotate the clamp plate and install the bolt. Tighten to 25 Nm (18 lb-ft).
47. Install the PSP tube bracket-to-steering gear bolt. Tighten to 10 Nm (89 lb-in).
48. Install a new engine oil filter. Tighten to 5 Nm (44 lb-in) and then rotate an additional 180 degrees. AWD vehicles
49. Line up the index marks on the rear driveshaft to the index marks on the PTU flange made during removal and install the 4 new bolts. Tighten to 70 Nm (52 lb-ft). All vehicles
50. Using a new gasket, install the Y-pipe and install the 2 new nuts. Tighten to 40 Nm (30 lb-ft). Attach the exhaust hanger.
51. Install the Y-pipe assembly and 4 new nuts. Tighten to 40 Nm (30 lb-ft).
52. Install the steering intermediate shaft onto the steering gear and install a new bolt. Tighten to 23 Nm (17 lb-ft).
53. Position the RH brake hose bracket and install the bolt. Tighten to 30 Nm (22 lb-ft).
54. Position the rubber shield and install the 2 lower scrivets.
55. Using the previously removed RH and LH wheel hub nuts, seat the halfshaft. Tighten to 350 Nm (258 lb-ft). Remove and discard the wheel hub nuts.
56. Install a new RH and LH wheel hub nut. Tighten to 350 Nm (258 lb-ft).
57. Connect the hose to the power steering reservoir.
58. Install the ground cable and bolt. Tighten to 12 Nm (106 lb-in).
59. Attach the wire to the RH valve cover stud bolt.
60. Attach the engine wiring harness retainer.
61. Connect the fuel supply tube to the fuel rail. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-376044) .
62. Using a new O-ring seal, connect the upper A/C tube to the condenser, install the nut and connect the A/C pressure switch electrical connector. Tighten to 15 Nm (133 lb-in).
63. If equipped, attach the engine block heater harness to the radiator support.
64. Attach the wiring harness pin-type retainer and connect the transaxle control cable to the shift cable bracket.
65. Connect the transaxle control cable to the control lever.
66. Connect the upper radiator hose, lower radiator hose and 2 heater hoses to the thermostat housing.
67. Install the engine wiring harness retainer to the bulkhead. Slide the wiring harness in the bulkhead. Make sure the wiring harness retainer tab is below the bulkhead lip.
68. Connect the 2 PCM electrical connectors.
69. Connect the PCM and engine harness electrical connectors. Attach the wiring harness retainer.
70. Install the Evaporative Emission (EVAP) canister purge valve. For additional information, refer to «EVAPORATIVE EMISSIONS»(ref-376045) .
71. Attach the EVAP tube pin-type retainer to the upper intake manifold.
72. Connect the vacuum hose and the EVAP tube from the upper intake manifold.
73. Install the degas bottle. For additional information, refer to «ENGINE COOLING»(ref-376040) .
74. Using a new O-ring seal and gasket seal, install the A/C tube and the nut. Tighten to 15 Nm (133 lb-in).
75. Using a new O-ring seal and gasket seal, connect the A/C tube and install the nut. Tighten to 15 Nm (133 lb-in).
76. Connect the power steering cooler tube.
77. Install the front valance, 7 pushpins and 5 screws.
78. Install the accessory drive belt and the power steering belt. For additional information, refer to «ACCESSORY DRIVE»(ref-375999) .
79. Install the LF wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-375990) .
80. Connect the ground cable to the negative battery terminal and install the nut. Tighten to 6 Nm (53 lb-in).
81. Connect the 2 power feed wires to the positive battery terminal and install the nut. Tighten to 6 Nm (53 lb-in).
82. Connect the engine wiring harness electrical connector.
83. Install the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-376024) .
84. Install the engine Air Cleaner (ACL) and ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-376025) .
85. Install the strut tower brace and the 4 nuts. Tighten to 35 Nm (26 lb-ft).
86. Attach the brake booster vacuum hose retainers to the strut tower brace.
87. Install the cowl panel grille. For additional information, refer to «FRONT END BODY PANELS»(ref-376031) .
88. Fill the engine with clean engine oil.
89. Fill and bleed the cooling system. For additional information, refer to «ENGINE COOLING»(ref-376040) .
90. Fill the power steering system. For additional information, refer to «STEERING SYSTEM - HYDRAULIC POWER ASSIST STEERING (HPAS)»(ref-375997) .
91. Recharge the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS»(ref-375996) .

MATERIAL SPECIFICATIONS

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

1. Install the valve tappets.
2. Depending on the valve tappets being serviced, install the LH and/or the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-375983-S29082050962010103100000) .

MATERIAL SPECIFICATIONS

Scheme 774

1. Using the Valve Stem Oil Seal Installer, install a new valve stem seal.
2. Using the Valve Spring Compressors, install the valve spring, retainer and key.
3. Install the valve tappets. For additional information, refer to «VALVE TAPPETS»(ref-375983-S12606183572010103100000) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. On early build engines, the timing chain rides on the inner side of the RH timing chain guide. Late build engines are equipped with a different design RH timing chain guide that requires the timing chain to ride on the outer side of the RH timing chain guide. For service, all replacement RH timing chain guides will be the late build design.

All vehicles

Scheme 775

Scheme 776

Scheme 777

Scheme 778

Scheme 779

Scheme 780

Scheme 781

Scheme 782

Scheme 783

Scheme 784

Scheme 785

Scheme 786

Scheme 787

Scheme 788

Scheme 789

Scheme 790

Scheme 791

Scheme 792

Scheme 793

Scheme 794

Scheme 795

Scheme 796

Scheme 797

Scheme 798

Scheme 799

Scheme 800

Scheme 801

Scheme 802

Scheme 803

Scheme 804

1. Install a new gasket, the RH cylinder head and 8 new bolts. Tighten in the sequence shown in illustration in 5 stages: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 35 Nm (26 lb-ft). Stage 3: Tighten 90 degrees. Stage 4: Tighten 90 degrees. Stage 5: Tighten 90 degrees.
2. Install the M6 bolt. Tighten to 10 Nm (89 lb-in).
3. Install the valve tappets.
4. Install and connect the Cylinder Head Temperature (CHT) sensor jumper harness.
5. Using new gaskets, install the lower intake manifold and the 10 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
6. Using a new gasket and O-ring seal, install the thermostat housing and the 3 bolts. Tighten to 10 Nm (89 lb-in).
7. Install new fuel injector O-ring seals. Remove the retaining clips and separate the fuel injectors from the fuel rail. Remove and discard the O-ring seals. Install new O-ring seals and lubricate with clean engine oil. Install the fuel injectors and the retaining clips onto the fuel rail.
8. Install the fuel rail and injectors as an assembly and install the 4 bolts. Tighten to 10 Nm (89 lb-in).
9. Install the coolant bypass hose to the thermostat housing.
10. Install the upper intake manifold support bracket and the bolt. Tighten to 10 Nm (89 lb-in).
11. Install the engine lifting eye and the 2 bolts. Tighten to 24 Nm (18 lb-ft).
12. Install the RH secondary timing chain tensioner and the 2 bolts. Tighten to 10 Nm (89 lb-in). Engines equipped with late build/replacement RH timing chain guides
13. Install the RH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in). Engines equipped with early build RH timing chain guides
14. Install the RH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in). All vehicles
15. Install 6 new RH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
16. Using a new gasket, install the RH exhaust manifold and 6 new nuts. Tighten in 2 stages in the sequence shown in illustration: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
17. Install the RH exhaust manifold heat shield and the 3 bolts. Tighten to 10 Nm (89 lb-in).
18. Install the RH cylinder block drain plug or, if equipped, the block heater. Tighten to 40 Nm (30 lb-ft).
19. If equipped, install the block heater wiring harness onto the engine. Connect the block heater electrical connector and install the heat shield.
20. Using a new gasket, install the RH catalytic converter and 4 new nuts. Tighten to 40 Nm (30 lb-ft).
21. Install the LH cylinder block drain plug. Tighten to 20 Nm (177 lb-in) plus an additional 180 degrees.
22. Using a new gasket, install the LH catalytic converter and 4 new nuts (3 shown in illustration). Tighten to 40 Nm (30 lb-ft).
23. Install the 2 LH catalytic converter bracket bolts. Tighten to 20 Nm (177 lb-in).
24. Connect the LH Catalyst Monitor Sensor (CMS) electrical connector.
25. Connect the CHT sensor electrical connector.
26. Connect the 6 fuel injector electrical connectors (3 shown in illustration).
27. Install the ground wire and the bolt. Tighten to 10 Nm (89 lb-in).
28. Install the Power Steering Pressure (PSP) tube bracket and the bolt to the RH cylinder head. Tighten to 10 Nm (89 lb-in).
29. Install the RH Camshaft Position (CMP) sensor and the bolt. Tighten to 10 Nm (89 lb-in).
30. Connect the RH CMP sensor electrical connector.
31. Connect the RH Heated Oxygen Sensor (HO2S) electrical connector.
32. Install the RH camshafts. For additional information, refer to «CAMSHAFT»(ref-375983-S29082050962010103100000) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Scheme 805

Scheme 806

Scheme 807

Scheme 808

Scheme 809

Scheme 810

Scheme 811

Scheme 812

Scheme 813

Scheme 814

Scheme 815

Scheme 816

Scheme 817

Scheme 818

Scheme 819

Scheme 820

Scheme 821

Scheme 822

Scheme 823

Scheme 824

Scheme 825

Scheme 826

Scheme 827

Scheme 828

Scheme 829

Scheme 830

Scheme 831

Scheme 832

Scheme 833

1. Install a new gasket, the LH cylinder head and 8 new bolts. Tighten in the sequence shown in illustration in 5 stages: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 35 Nm (26 lb-ft). Stage 3: Tighten 90 degrees. Stage 4: Tighten 90 degrees. Stage 5: Tighten 90 degrees.
2. Install the M6 bolt. Tighten to 10 Nm (89 lb-in).
3. Install the valve tappets.
4. Install the LH secondary timing chain tensioner and the 2 bolts. Tighten to 10 Nm (89 lb-in).
5. Install the upper LH primary timing chain guide and the 2 bolts. Tighten to 10 Nm (89 lb-in).
6. Using new gaskets, install the lower intake manifold and the 10 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
7. Using a new gasket and O-ring seal, install the thermostat housing and the 3 bolts. Tighten to 10 Nm (89 lb-in).
8. Install new fuel injector O-ring seals. Remove the retaining clips and separate the fuel injectors from the fuel rail. Remove and discard the O-ring seals. Install new O-ring seals and lubricate with clean engine oil. Install the fuel injectors and the retaining clips onto the fuel rail.
9. Install the fuel rail and injectors as an assembly and install the 4 bolts. Tighten to 10 Nm (89 lb-in).
10. Install the coolant bypass hose to the thermostat housing.
11. Install the RH cylinder block drain plug or, if equipped, the block heater. Tighten to 40 Nm (30 lb-ft).
12. If equipped, install the block heater wiring harness onto the engine. Connect the block heater electrical connector and install the heat shield.
13. Using a new gasket, install the RH catalytic converter and 4 new nuts. Tighten to 40 Nm (30 lb-ft).
14. Install the LH cylinder block drain plug. Tighten to 20 Nm (177 lb-in) plus an additional 180 degrees.
15. Install 6 new LH exhaust manifold studs. Tighten to 12 Nm (106 lb-in).
16. Using a new gasket, install the LH exhaust manifold and 6 new nuts. Tighten in 2 stages in the sequence shown in illustration: Stage 1: Tighten to 20 Nm (177 lb-in). Stage 2: Tighten to 25 Nm (18 lb-ft).
17. Install the LH exhaust manifold heat shield and the 3 bolts. Tighten to 10 Nm (89 lb-in).
18. Using a new gasket, install the LH catalytic converter and 4 new nuts (3 shown in illustration). Tighten to 40 Nm (30 lb-ft).
19. Install the LH catalytic converter bracket bolts. Tighten to 20 Nm (177 lb-in).
20. Attach the Engine Oil Pressure (EOP) switch wiring harness pin-type retainer.
21. Install the stud, generator and the nut and bolt. Tighten the stud to 12 Nm (106 lb-in). Tighten the nut and bolt to 48 Nm (35 lb-ft).
22. Connect the generator electrical connector.
23. Connect the generator B+ cable and install the nut. Tighten to 17 Nm (150 lb-in).
24. Attach the pin-type wire harness retainer to the rear of LH cylinder head.
25. Connect the LH Catalyst Monitor Sensor (CMS) electrical connector.
26. Connect the LH Heated Oxygen Sensor (HO2S) electrical connector.
27. Install the LH Camshaft Position (CMP) sensor and the bolt. Tighten to 10 Nm (89 lb-in).
28. Connect the LH CMP sensor electrical connector.
29. Connect the Cylinder Head Temperature (CHT) sensor electrical connector.
30. Connect the 6 fuel injector electrical connectors (3 shown in illustration).
31. Install the LH camshafts. For additional information, refer to «CAMSHAFT»(ref-375983-S29082050962010103100000) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, may cause engine failure.

Note. Early build engines have 11 fastener valve covers, late build engines have 9 fastener valve covers. Do not attempt to install bolts in the 2 empty late build valve cover holes or damage to the valve cover will occur.

All vehicles

Scheme 834

Scheme 835

Scheme 836

Scheme 837

Scheme 838

Scheme 839

Scheme 840

Scheme 841

Scheme 842

Scheme 843

Scheme 844

Scheme 845

Scheme 846

Scheme 847

Scheme 848

Scheme 849

Scheme 850

Scheme 851

Scheme 852

Scheme 853

Scheme 854

Scheme 855

Scheme 856

Scheme 857

Scheme 858

Scheme 859

Scheme 860

Scheme 861

Scheme 862

Scheme 863

Scheme 864

Scheme 865

Scheme 866

Scheme 867

Scheme 868

Scheme 869

Scheme 870

Scheme 871

Scheme 872

Scheme 873

Scheme 874

Scheme 875

Scheme 876

Scheme 877

Scheme 878

Scheme 879

1. Apply a 3 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the sealing surface of the oil pan. Apply a 5.5 mm (0.21 in) bead of Motorcraft® High Performance Engine RTV Silicone to the 2 crankshaft seal retainer plate-to-cylinder block joint areas on the sealing surface of the oil pan.
2. Install the oil pan and bolts 10, 11, 13 and 14. Tighten in the sequence shown in illustration to 3 Nm (27 lb-in). Loosen the bolts 180 degrees.
3. Align the oil pan to the cylinder block and A/C compressor. Position the oil pan so the mounting boss is against the A/C compressor and using a straightedge, align the oil pan flush with the rear of the cylinder block at the 2 areas shown in illustration.
4. Tighten bolts 10, 11, 13 and 14 in the sequence shown in illustration, to 3 Nm (27 lb-in).
5. Install the remaining oil pan bolts. Tighten all the oil pan bolts in the sequence shown in illustration. Tighten the large bolts (1-14) to 20 Nm (177 lb-in). Tighten the small bolts (15 and 16) to 10 Nm (89 lb-in).
6. Install the A/C compressor mounting stud and nut. Tighten the stud to 9 Nm (80 lb-in) and the nut to 25 Nm (18 lb-ft).
7. Install the Alignment Pins.
8. Apply a 3.0 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover sealing surfaces including the 3 engine mount bracket bosses. Apply a 5.5 mm (0.21 in) bead of Motorcraft® High Performance Engine RTV Silicone to the oil pan-to-cylinder block joint and the cylinder head-to-cylinder block joint areas of the engine front cover in 5 places as indicated.
9. Install the engine front cover and bolts 17, 18, 19 and 20. Tighten in sequence shown in illustration to 3 Nm (27 lb-in).
10. Remove the Alignment Pins.
11. Install the engine mount bracket and the 3 bolts.
12. Install the remaining engine front cover bolts. Tighten all of the engine front cover bolts and engine mount bracket bolts in the sequence shown in illustration in 2 stages: Stage 1: Tighten bolts 1 thru 22 to 10 Nm (89 lb-in) and bolts 23, 24 and 25 to 15 Nm (133 lb-in). Stage 2: Tighten bolts 1 thru 22 to 24 Nm (18 lb-ft) and bolts 23, 24 and 25 to 75 Nm (55 lb-ft).
13. Install the engine mount studs in the following sequence. Clean the front cover engine mount stud holes with pressurized air to remove any foreign material. Clean all the thread sealer from the engine mount studs (old and new studs). Apply new Threadlock and Sealer to the engine mount stud threads. Install the 2 engine mount studs. Tighten to 20 Nm (177 lb-in).
14. Install the engine mount bracket and the 2 bolts. Tighten to 24 Nm (18 lb-ft).
15. Using the Crankshaft Vibration Damper Installer and Front Crankshaft Seal Installer, install a new crankshaft front seal.
16. Using the Crankshaft Vibration Damper Installer and Front Cover Oil Seal Installer, install the crankshaft pulley.
17. Using the Strap Wrench, install the crankshaft pulley washer and new bolt and tighten in 4 stages. Stage 1: Tighten to 120 Nm (89 lb-ft). Stage 2: Loosen one full turn. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten an additional 90 degrees.
18. Using the VCT Spark Plug Tube Seal Installer and Handle, install new VCT solenoid and/or spark plug tube seals.
19. Apply an 8 mm (0.31 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover-to-RH cylinder head joints. Early build vehicles
20. Using a new gasket, install the RH valve cover, bolt and the 10 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). Late build vehicles
21. Using a new gasket, install the RH valve cover and tighten the 9 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). All vehicles
22. Apply an 8 mm (0.31 in) bead of Motorcraft® High Performance Engine RTV Silicone to the engine front cover-to-LH cylinder head joints. Early build vehicles
23. Using a new gasket, install the LH valve cover and 11 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). Late build vehicles
24. Using a new gasket, install the LH valve cover and tighten the 9 stud bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in). All vehicles
25. Install the engine cover stud to the LH valve cover stud bolt. Tighten to 6 Nm (53 lb-in).
26. Install the 6 coil-on-plug assemblies and the 6 bolts. Tighten to 7 Nm (62 lb-in).
27. Install the LH cylinder block drain plug. Tighten to 20 Nm (177 lb-in) plus an additional 180 degrees.
28. Install the RH cylinder block drain plug or, if equipped, the block heater. Tighten to 40 Nm (30 lb-ft). Front Wheel Drive (FWD) vehicles
29. Using a new gasket, install the RH catalytic converter and 4 new nuts. Tighten to 40 Nm (30 lb-ft). All vehicles
30. Using a new gasket, install the LH catalytic converter and 4 new nuts (3 shown in illustration). Tighten to 40 Nm (30 lb-ft).
31. Install the accessory drive belt tensioner and the 3 bolts. Tighten to 11 Nm (97 lb-in).
32. Install the power steering pump and the 3 bolts. Tighten to 25 Nm (18 lb-ft).
33. Install the Power Steering Pressure (PSP) tube bracket bolt. Tighten to 10 Nm (89 lb-in).
34. Install the PSP bracket and nut to the RH valve cover stud bolt. Tighten to 7 Nm (62 lb-in).
35. Attach all of the wiring harness retainers to the LH valve cover and stud bolts.
36. Connect the 3 LH coil-on-plug electrical connectors.
37. Connect the LH camshaft VCT solenoid electrical connector.
38. Connect the LH Catalyst Monitor Sensor (CMS) electrical connector.
39. Attach all of the wiring harness retainers to the RH valve cover and stud bolts.
40. Connect the RH Heated Oxygen Sensor (HO2S) electrical connector.
41. Connect the 3 RH coil-on-plug electrical connectors.
42. Connect the RH VCT solenoid electrical connector. FWD vehicles
43. Connect the RH CMS electrical connector. All vehicles
44. Connect the PSP switch electrical connector.
45. Using new gaskets, install the upper intake manifold and the 6 bolts. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
46. Install the fuel tube bracket bolt to the upper intake manifold. Tighten to 6 Nm (53 lb-in).
47. Install the upper intake manifold support bracket bolt. Tighten to 10 Nm (89 lb-in).
48. Attach the wiring harness retainers to the upper intake manifold.
49. Connect the Throttle Body (TB) electrical connector.
50. Connect the PCV hose to the PCV valve.
51. If equipped, connect the block heater electrical connector and install the heat shield. Attach all the engine block heater wiring harness retainer.
52. Using the Heavy Duty Floor Crane and Spreader Bar, remove the engine from the stand.
53. Install the crankshaft sensor ring.
54. Install the flexplate and the 8 bolts. Tighten to 80 Nm (59 lb-ft).
55. Install the engine in the vehicle. For additional information, refer to «ENGINE»(ref-375983-S41746817652010103100000) .

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Scheme 880

1. Using a new O-ring seal, install the oil pump screen and pickup tube and the 2 bolts. Tighten to 10 Nm (89 lb-in).
2. Install the oil pan. For additional information, refer to «OIL PAN»(ref-375983-S31231260922010103100000) .

MATERIAL SPECIFICATIONS

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces that enters the oil passages, coolant passages or the oil pan, can cause engine failure.

Scheme 881

Scheme 882

Scheme 883

Scheme 884

Scheme 885

1. Apply a 3 mm (0.11 in) bead of Motorcraft® High Performance Engine RTV Silicone to the sealing surface of the crankshaft rear seal retainer.
2. Install the rear seal retainer and the 8 bolts in the sequence shown in illustration. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
3. Position the Rear Main Seal Installer onto the end of the crankshaft and slide a new crankshaft rear seal onto the tool.
4. Using the Rear Main Seal Installer and Handle, install the new crankshaft rear seal.
5. Install the Crankshaft Position (CKP) sensor and install the bolt. Tighten to 10 Nm (89 lb-in).
6. Connect the CKP sensor electrical connector.
7. Using the Heavy Duty Floor Crane and Spreader Bar, install the engine onto the stand.
8. Install the oil pan. For additional information, refer to «OIL PAN»(ref-375983-S31231260922010103100000) .
