Multifunction Electronic Modules: Diagnosis

Diagnostic Trouble Code (DTC) Chart

Note. Most powertrain (P-code) DTCs are diagnosed in the INTRODUCTION - GASOLINE MODELS . If the P-code retrieved is not listed below, refer to the INTRODUCTION - GASOLINE MODELS to continue diagnostics.

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

Note. Some of these modules utilize a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

DTC	Description	Source	Action
B0001:11	Driver Frontal Stage 1 Deployment Control: Circuit Short To Ground	Restraints Control Module (RCM)	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:12	Driver Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:13	Driver Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:1A	Driver Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:2B	Driver Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:4A	Driver Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:11	Driver Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:12	Driver Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:13	Driver Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:1A	Driver Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:2B	Driver Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:4A	Driver Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0004:11	Driver Knee Bolster Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0004:12	Driver Knee Bolster Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0004:13	Driver Knee Bolster Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0004:1A	Driver Knee Bolster Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0004:2B	Driver Knee Bolster Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0004:4A	Driver Knee Bolster Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:11	Collapsible Steering Column Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:12	Collapsible Steering Column Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:13	Collapsible Steering Column Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:1A	Collapsible Steering Column Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:2B	Collapsible Steering Column Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0005:4A	Collapsible Steering Column Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:11	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:12	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:13	Passenger Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:1A	Passenger Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:2B	Passenger Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:4A	Passenger Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:11	Passenger Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:12	Passenger Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:13	Passenger Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:1A	Passenger Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:2B	Passenger Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:4A	Passenger Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:11	Left Side Airbag Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:12	Left Side Airbag Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:13	Left Side Airbag Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:1A	Left Side Airbag Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:2B	Left Side Airbag Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:4A	Left Side Airbag Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:11	Left Curtain Deployment Control 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:12	Left Curtain Deployment Control 1: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:13	Left Curtain Deployment Control 1: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:1A	Left Curtain Deployment Control 1: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:2B	Left Curtain Deployment Control 1: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0021:4A	Left Curtain Deployment Control 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:11	Right Side Airbag Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:12	Right Side Airbag Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:13	Right Side Airbag Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:1A	Right Side Airbag Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:2B	Right Side Airbag Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:4A	Right Side Airbag Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0029:11	Right Curtain Deployment Control 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0029:12	Right Curtain Deployment Control 1: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0029:13	Right Curtain Deployment Control 1: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0029:1A	Right Curtain Deployment Control 1: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0029:2B	Right Curtain Deployment Control 1: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0029:4A	Right Curtain Deployment Control 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:11	Driver Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:12	Driver Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:13	Driver Seatbelt Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:1D	Driver Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:2B	Driver Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:4A	Driver Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:11	Passenger Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:12	Passenger Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:13	Passenger Seatbelt Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:1D	Passenger Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:2B	Passenger Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:4A	Passenger Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0061:11	Passenger Seatbelt Tension Sensor: Circuit Short To Ground	Occupant Classification System Module (OCSM)	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0061:12	Passenger Seatbelt Tension Sensor: Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0061:13	Passenger Seatbelt Tension Sensor: Circuit Open	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0061:1A	Passenger Seatbelt Tension Sensor: Circuit Resistance Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0061:1C	Passenger Seatbelt Tension Sensor: Circuit Voltage Out Of Range	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:11	Driver Seatbelt Load Limiter Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:12	Driver Seatbelt Load Limiter Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:13	Driver Seatbelt Load Limiter Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:1A	Driver Seatbelt Load Limiter Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:2B	Driver Seatbelt Load Limiter Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0080:4A	Driver Seatbelt Load Limiter Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:11	Passenger Seatbelt Load Limiter Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:12	Passenger Seatbelt Load Limiter Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:13	Passenger Seatbelt Load Limiter Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:1A	Passenger Seatbelt Load Limiter Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:2B	Passenger Seatbelt Load Limiter Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0082:4A	Passenger Seatbelt Load Limiter Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:11	Left Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:4A	Left Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:81	Left Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:93	Left Frontal Restraints Sensor: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:96	Left Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:11	Left Side Restraints Sensor 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:4A	Left Side Restraints Sensor 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:81	Left Side Restraints Sensor 1: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:93	Left Side Restraints Sensor 1: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:96	Left Side Restraints Sensor 1: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:11	Left Side Restraints Sensor 2: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:4A	Left Side Restraints Sensor 2: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:81	Left Side Restraints Sensor 2: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:93	Left Side Restraints Sensor 2: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0092:96	Left Side Restraints Sensor 2: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:11	Right Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:4A	Right Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:81	Right Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:93	Right Frontal Restraints Sensor: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:96	Right Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:11	Right Side Restraints Sensor 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:4A	Right Side Restraints Sensor 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:81	Right Side Restraints Sensor 1: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:93	Right Side Restraints Sensor 1: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:96	Right Side Restraints Sensor 1: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:11	Right Side Restraints Sensor 2: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:4A	Right Side Restraints Sensor 2: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:81	Right Side Restraints Sensor 2: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:93	Right Side Restraints Sensor 2: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0097:96	Right Side Restraints Sensor 2: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:09	Occupant Classification System: Component Failures	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:4A	Occupant Classification System: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:54	Occupant Classification System: Missing Calibration	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:63	Occupant Classification System: Circuit/Component Protection Time-Out	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:64	Occupant Classification System: Signal Plausibility Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:67	Occupant Classification System: Signal Incorrect After Event	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:68	Occupant Classification System: Event Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:76	Occupant Classification System: Wrong Mounting Position	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:97	Occupant Classification System: Component Or System Operation Obstructed Or Blocked	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:11	Driver Seat Track Position Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:12	Driver Seat Track Position Restraints Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:13	Driver Seat Track Position Restraints Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:1D	Driver Seat Track Position Restraints Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:2B	Driver Seat Track Position Restraints Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:4A	Driver Seat Track Position Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C0:12	Passenger Seat Occupant Classification Sensor "A": Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C0:13	Passenger Seat Occupant Classification Sensor "A": Circuit Open	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C0:1A	Passenger Seat Occupant Classification Sensor "A": Circuit Resistance Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C0:49	Passenger Seat Occupant Classification Sensor "A": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C0:81	Passenger Seat Occupant Classification Sensor "A": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:12	Passenger Seat Occupant Classification Sensor "B": Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:13	Passenger Seat Occupant Classification Sensor "B": Circuit Open	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:1A	Passenger Seat Occupant Classification Sensor "B": Circuit Resistance Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:49	Passenger Seat Occupant Classification Sensor "B": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C1:81	Passenger Seat Occupant Classification Sensor "B": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:12	Passenger Seat Occupant Classification Sensor "C": Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:13	Passenger Seat Occupant Classification Sensor "C": Circuit Open	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:1A	Passenger Seat Occupant Classification Sensor "C": Circuit Resistance Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:49	Passenger Seat Occupant Classification Sensor "C": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C2:81	Passenger Seat Occupant Classification Sensor "C": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:12	Passenger Seat Occupant Classification Sensor "D": Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:13	Passenger Seat Occupant Classification Sensor "D": Circuit Open	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:1A	Passenger Seat Occupant Classification Sensor "D": Circuit Resistance Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:49	Passenger Seat Occupant Classification Sensor "D": Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00C3:81	Passenger Seat Occupant Classification Sensor "D": Invalid Serial Data Received	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:11	Restraint System Passenger Disable Indicator: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:12	Restraint System Passenger Disable Indicator: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:13	Restraint System Passenger Disable Indicator: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:4A	Restraint System Passenger Disable Indicator: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B103B	Thermoelectric Driver Overcurrent Low	Dual Climate Controlled Seat Module (DCSM)	REFER to SEATING .
B103C	Thermoelectric Driver Open Load	DCSM	REFER to SEATING .
B103C:11	Left Headlamp Control: Circuit Short To Ground Module (HCM)	Headlamp Control	REFER to EXTERIOR LIGHTING .
B103C:15	Left Headlamp Control: Circuit Short To Battery Or Open	HCM	REFER to EXTERIOR LIGHTING .
B103C:49	Left Headlamp Control: Internal Electronic Failure	HCM	REFER to EXTERIOR LIGHTING .
B103C:98	Left Headlamp Control: Component Or System Over Temperature	HCM	REFER to EXTERIOR LIGHTING .
B103D	Blower Driver Overtemperature	DCSM	REFER to SEATING .
B103D:11	Right Headlamp Control: Circuit Short To Ground	HCM	REFER to EXTERIOR LIGHTING .
B103D:15	Right Headlamp Control: Circuit Short To Battery Or Open	HCM	REFER to EXTERIOR LIGHTING .
B103D:49	Right Headlamp Control: Internal Electronic Failure	HCM	REFER to EXTERIOR LIGHTING .
B103D:98	Right Headlamp Control: Component Or System Over Temperature	HCM	REFER to EXTERIOR LIGHTING .
B106A	TPMS Sensor Pressure Range Bit Incorrect State	Smart Junction Box (SJB)	REFER to WHEELS AND TIRES .
B106B	Tire Pressure Sensor Low Battery	SJB	REFER to WHEELS AND TIRES .
B106D	Tire Pressure Monitor System (TPMS) Initiators Not Configured	SJB	REFER to WHEELS AND TIRES .
B106E	Solid State Driver Disabled Due to Short Circuit	Driver Door Module (DDM)	REFER to DRIVER DOOR MODULE (DDM) .
B106E	Solid State Driver Disabled Due to Short Circuit	Driver Seat Module (DSM)	REFER to DRIVER SEAT MODULE (DSM) .
B106E	Solid State Driver Disabled Due to Short Circuit	Interior Lighting Control Module (ILCM)	REFER to INTERIOR LIGHTING .
B106E	Solid State Driver Disabled Due to Short Circuit	SJB	REFER to SMART JUNCTION BOX (SJB) .
B106F	Module Disabled Due to External Fault	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B106F	Module Disabled Due to External Fault	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B106F	Module Disabled Due to External Fault	ILCM	REFER to INTERIOR LIGHTING .
B106F	Module Disabled Due to External Fault	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1081:07	Left Temperature Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1081:11	Left Temperature Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1081:12	Left Temperature Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1081:13	Left Temperature Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:07	Right Temperature Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:11	Right Temperature Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:12	Right Temperature Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1082:13	Right Temperature Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:07	Recirculation Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:11	Recirculation Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:12	Recirculation Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1083:13	Recirculation Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:07	Air Distribution Damper Motor: Mechanical Failures	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:11	Air Distribution Damper Motor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:12	Air Distribution Damper Motor: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1086:13	Air Distribution Damper Motor: Circuit Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B108A:11	Start Button: Circuit Short To Ground	Remote Function Actuator (RFA) module	REFER to STEERING COLUMN SWITCHES .
B108A:15	Start Button: Circuit Short To Battery Or Open	RFA module	REFER to STEERING COLUMN SWITCHES .
B109E:42	Remote Keyless Entry: General Memory Failure	Instrument Panel Cluster (IPC)	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B109E:51	Remote Keyless Entry: Not Programmed	IPC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B109E:86	Remote Keyless Entry: Signal Invalid	IPC	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B10AB:06	Remote Keyless Entry Synchronization: Algorithm Based Failures	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B10AF:12	Blower Fan Relay: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10AF:14	Blower Fan Relay: Circuit Short To Ground Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10B9:12	Blower Control: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10B9:14	Blower Control: Circuit Short To Ground Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B10C6:13	Exterior Trunk Antenna: Circuit Open	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B10C7:13	Interior Trunk Antenna: Circuit Open	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10C8:13	Interior Center Antenna: Circuit Open	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10C9:13	Interior Front Antenna: Circuit Open	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D5:13	PATS Antenna: Circuit Open	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:05	PATS Key: System Programming Failures	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:05	PATS Key: System Programming Failures	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:31	PATS Key: No Signal	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:51	PATS Key: Not Programmed	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:87	PATS Key: Missing Message	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D7:8F	PATS Key: Erratic	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D8:00	PATS Key Less Than Minimum Programmed: No Sub Type Information	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D8:51	PATS Key Less Than Minimum Programmed: Not Programmed	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:11	PATS Transponder: Circuit Short To Ground	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:12	PATS Transponder: Circuit Short To Battery	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:31	PATS Transponder: No Signal	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:87	PATS Transponder: Missing Message	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10D9:87	PATS Transponder: Missing Message	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:51	PATS PCM Identifier: Not Programmed	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:51	PATS PCM Identifier: Not Programmed	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:61	PATS PCM Identifier: Signal Calculation Failure	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:61	PATS PCM Identifier: Signal Calculation Failure	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:86	PATS PCM Identifier: Signal Invalid	IPC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10DA:86	PATS PCM Identifier: Signal Invalid	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B10E7:11	Ignition On Relay: Circuit Short To Ground	RFA module	REFER to STEERING COLUMN SWITCHES .
B10E7:12	Ignition On Relay: Circuit Short To Battery	RFA module	REFER to STEERING COLUMN SWITCHES .
B10E7:13	Ignition On Relay: Circuit Open	RFA module	REFER to STEERING COLUMN SWITCHES .
B1111	Driver Thermal Electric Device Control Overtemperature Fault	DCSM	REFER to SEATING .
B1113	Passenger Thermal Electric Device Control Overtemperature Fault	DCSM	REFER to SEATING .
B111B	Passenger Thermoelectric Driver Overcurrent Low	DCSM	REFER to SEATING .
B111C	Passenger Thermoelectric Driver Open Load	DCSM	REFER to SEATING .
B111D	Passenger Blower Driver Overtemperature	DCSM	REFER to SEATING .
B1134:11	Phone Input: Circuit Short To Ground	Audio Control Module (ACM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1138	Memory Full	SJB	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1139	Invalid Transmitter Identification Code	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B113E:11	External Boot/Trunk Release Switch: Circuit Short To Ground	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1175:13	Drivers Door Ajar Switch: Circuit Open	RFA module	REFER to INTERIOR LIGHTING .
B1176:13	Passenger Door Ajar Switch: Circuit Open	RFA module	REFER to INTERIOR LIGHTING .
B1178:13	Boot/Trunk Ajar Switch: Circuit Open	RFA module	REFER to INTERIOR LIGHTING .
B1193:00	Crash Event Storage Full and Locked: No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1193:00	Crash Event Storage Full and Locked: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B119F:01	GPS Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B119F:13	GPS Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:1C	Steering Wheel Audio Switch Pack: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BA:63	Steering Wheel Audio Switch Pack: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11BB:12	Rear Park Aid Audio Input: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B11C0:13	Driver Side Rear Door Ajar Switch: Circuit Open	RFA module	REFER to INTERIOR LIGHTING .
B11C1:13	Passenger Side Rear Door Ajar Switch: Circuit Open	RFA module	REFER to INTERIOR LIGHTING .
B11C7:15	High Beam Sensor: Circuit Short To Battery Or Open	Headlamp Control Module 2 (HCM-2)	REFER to EXTERIOR LIGHTING .
B11C7:46	High Beam Sensor: Calibration/Parameter Memory Failure	HCM-2	REFER to EXTERIOR LIGHTING .
B11C7:97	High Beam Sensor: Component Or System Operation Obstructed Or Blocked	HCM-2	REFER to EXTERIOR LIGHTING .
B11C8:11	Auto High Beam Controller Output: Circuit Short To Ground	HCM-2	REFER to EXTERIOR LIGHTING .
B11CA:13	Driver Door External Antenna: Circuit Open	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B11E5:11	Left HVAC Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E5:15	Left HVAC Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E6:11	Right HVAC Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E6:15	Right HVAC Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E7:11	Air Distribution Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11E7:15	Air Distribution Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11F0:11	Air Intake Damper Position Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B11F0:15	Air Intake Damper Position Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:1C	Steering Wheel Audio Switch Pack 2: Circuit Voltage Out Of Range	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1201:63	Steering Wheel Audio Switch Pack 2: Circuit/Component Protection Time-Out	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1211:11	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:12	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:13	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:1A	Driver Seatbelt Retractor Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:2B	Driver Seatbelt Retractor Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1211:4A	Driver Seatbelt Retractor Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:11	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:12	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:13	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:1A	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:2B	Driver Seatbelt Buckle Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:4A	Driver Seatbelt Buckle Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:11	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:12	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:13	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:1A	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:2B	Passenger Seatbelt Buckle Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:4A	Passenger Seatbelt Buckle Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1217:11	Passive Key-In Ignition Output: Circuit Short To Ground	RFA module	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1217:15	Passive Key-In Ignition Output: Circuit Short To Battery Or Open	RFA module	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1219:11	Interior Boot/Trunk Release Switch: Circuit Short To Ground	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B121A:11	Keypad Illumination Output: Circuit Short To Ground	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B121A:15	Keypad Illumination Output: Circuit Short To Battery Or Open	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B121B:11	Keypad Input Switch: Circuit Short To Ground	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B121C:01	Hard Drive: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:04	USB Port: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1252:11	USB Port: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B125C:11	Radio Mute: Circuit Short To Ground	RFA module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B125C:15	Radio Mute: Circuit Short To Battery Or Open	RFA module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B125D:11	Ignition Run LED: Circuit Short To Ground	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B125D:15	Ignition Run LED: Circuit Short To Battery Or Open	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B129C:12	Left Front Side Sensor: Circuit Short To Battery	PAM	REFER to ACTIVE PARK ASSIST .
B129C:14	Left Front Side Sensor: Circuit Short To Ground Or Open	PAM	REFER to ACTIVE PARK ASSIST .
B129C:96	Left Front Side Sensor: Component Internal Failure	PAM	REFER to ACTIVE PARK ASSIST .
B129D:12	Right Front Side Sensor: Circuit Short To Battery	PAM	REFER to ACTIVE PARK ASSIST .
B129D:14	Right Front Side Sensor: Circuit Short To Ground Or Open	PAM	REFER to ACTIVE PARK ASSIST .
B129D:96	Right Front Side Sensor: Component Internal Failure	PAM	REFER to ACTIVE PARK ASSIST .
B12B8:04	USB Port #2: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B12B8:11	USB Port #2: Circuit Short To Ground	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1302	Accessory Delay Relay Coil Circuit Failure	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1303:11	Park Assist Switch: Circuit Short To Ground	PAM	REFER to ACTIVE PARK ASSIST .
B1304	Accessory Delay Relay Coil Circuit Short to Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1304:68	Electronic Power Assisted Steering System: Event Information	PAM	REFER to ACTIVE PARK ASSIST .
B1317	Battery Voltage High	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1317	Battery Voltage High	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B1317	Battery Voltage High	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1317	Battery Voltage High	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1317	Battery Voltage High	Steering Angle Sensor Module (SASM)	REFER to VEHICLE DYNAMIC SYSTEMS .
B1318	Battery Voltage Low	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1318	Battery Voltage Low	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B1318	Battery Voltage Low	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1318	Battery Voltage Low	Front Display Interface Module (FDIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SASM	REFER to VEHICLE DYNAMIC SYSTEMS .
B1318	Battery Voltage Low	SECM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
B1318	Battery Voltage Low	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1320	Driver Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1328	Passenger Door Ajar Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1331	Decklid Ajar Rear Door Circuit Failure	SJB	REFER to INTERIOR LIGHTING .
B1336	Door Ajar RR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1342	ECU is Faulted	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1342	ECU is Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1342	ECU is Faulted	DCSM	REFER to SEATING .
B1342	ECU is Faulted	DDM	REFER to DRIVER DOOR MODULE (DDM) .
B1342	ECU is Faulted	DSM	REFER to DRIVER SEAT MODULE (DSM) .
B1342	ECU is Faulted	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU is Faulted	ILCM	REFER to INTERIOR LIGHTING .
B1342	ECU is Faulted	PCM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PCM. REFER to ELECTRONIC ENGINE CONTROLS . TEST the system for normal operation.
B1342	ECU is Faulted	SASM	REFER to VEHICLE DYNAMIC SYSTEMS .
B1342	ECU is Faulted	SJB	DIAGNOSE all other DTCs first. If no other DTCs are present, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
B1352	Ignition Key-In Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1472	Lamp Headlamp Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1485	Brake Pedal Input Short to Battery	SJB	REFER to EXTERIOR LIGHTING .
B1510	Flash to Pass Switch Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1520	Hood Switch Circuit Open	SJB	REFER to ANTI-THEFT - PERIMETER .
B1534	Memory 1 Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1538	Memory 2 Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1572	Door Ajar LR Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B1578	Lamp Park Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1596	Service Continuous Codes	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1624	Lamp Keypad Output Open Circuit	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1626	Lamp Keypad Output Short Circuit to Ground	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1663	Seat Driver Front Up/Down Motor Stalled	DSM	REFER to SEATING .
B1664	Seat Driver Rear Up/Down Motor Stalled	DSM	REFER to SEATING .
B1665	Seat Driver Forward/Backward Motor Stalled	DSM	REFER to SEATING .
B1666	Seat Driver Recline Motor Stalled	DSM	REFER to SEATING .
B1667	Mirror Driver Up/Down Motor Stalled	DDM	REFER to REAR VIEW MIRRORS .
B1668	Mirror Driver Right/Left Motor Stalled	DDM	REFER to REAR VIEW MIRRORS .
B1669	Mirror Passenger Up/Down Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1670	Mirror Passenger Right/Left Motor Stalled	DSM	REFER to REAR VIEW MIRRORS .
B1676	Battery Pack Voltage Out of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1696	Autolamp On Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1703	Seat Driver Recline Forward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1707	Seat Driver Recline Rearward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1711	Seat Driver Front Up Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1715	Seat Driver Front Down Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1719	Seat Driver Forward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1723	Seat Driver Rearward Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1727	Seat Driver Rear Up Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1731	Seat Driver Rear Down Switch Circuit Short To Battery	DSM	REFER to SEATING .
B1733	Mirror Driver Vertical Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1737	Mirror Driver Horizontal Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1737	Mirror Driver Horizontal Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1741	Mirror Passenger Vertical Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1741	Mirror Passenger Vertical Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1745	Mirror Passenger Horizontal Switch Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B1745	Mirror Passenger Horizontal Switch Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B1791	Autolamp Sensor Input Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B1793	Autolamp Sensor Input Circuit Short to Ground	SJB	REFER to EXTERIOR LIGHTING .
B1952	Seat Rear Up/Down Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1953	Seat Rear Up/Down Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1956	Seat Front Up/Down Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1957	Seat Front Up/Down Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1960	Seat Recline Forward/Backward Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1961	Seat Recline Forward/Backward Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B1964	Seat Horizontal Forward/Rearward Position Feedback Circuit Short To Battery	DSM	REFER to SEATING .
B1965	Seat Horizontal Forward/Rearward Position Feedback Circuit Short To Ground	DSM	REFER to SEATING .
B19A1	Passenger Seat Cushion Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A2	Passenger Seat Back Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A3	Driver Seat Cushion Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A4	Driver Seat Back Blower Speed Short To Battery	DCSM	REFER to SEATING .
B19A5	Passenger Seat Cushion Blower Speed Short To Ground	DCSM	REFER to SEATING .
B19A6	Passenger Seat Back Blower Speed Short To Ground	DCSM	REFER to SEATING .
B19A7	Driver Seat Cushion Blower Speed Short To Ground	DCSM	REFER to SEATING .
B19A8	Driver Seat Back Blower Speed Short To Ground	DCSM	REFER to SEATING .
B1A01:01	Speaker #1: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:01	Speaker #1: General Electrical Failure	Audio Digital Signal Processing (DSP) module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:11	Speaker #1: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:11	Speaker #1: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:12	Speaker #1: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:12	Speaker #1: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:13	Speaker #1: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A01:13	Speaker #1: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:01	Speaker #2: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:01	Speaker #2: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:11	Speaker #2: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:11	Speaker #2: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:12	Speaker #2: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:12	Speaker #2: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:13	Speaker #2: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A02:13	Speaker #2: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:01	Speaker #3: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:01	Speaker #3: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:11	Speaker #3: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:11	Speaker #3: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:12	Speaker #3: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:12	Speaker #3: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:13	Speaker #3: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A03:13	Speaker #3: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:01	Speaker #4: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:01	Speaker #4: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:11	Speaker #4: Circuit Short To Ground	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:11	Speaker #4: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:12	Speaker #4: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:12	Speaker #4: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:13	Speaker #4: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A04:13	Speaker #4: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:01	Speaker #5: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:01	Speaker #5: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:02	Speaker #5: General Signal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:11	Speaker #5: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:12	Speaker #5: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A05:13	Speaker #5: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:01	Speaker #6: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:01	Speaker #6: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:02	Speaker #6: General Signal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:11	Speaker #6: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:12	Speaker #6: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A06:13	Speaker #6: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:01	Speaker #7: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:01	Speaker #7: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:11	Speaker #7: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:12	Speaker #7: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A07:13	Speaker #7: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:01	Speaker #8: General Electrical Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:11	Speaker #8: Circuit Short To Ground	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:12	Speaker #8: Circuit Short To Battery	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A08:13	Speaker #8: Circuit Open	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A09:02	Speaker #9: General Signal Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A56:21	Antenna: Signal Amplitude	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A59:01	Sensor 5 Volt Supply: General Electrical Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1A59:11	Sensor 5 Volt Supply: Circuit Short To Ground	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1A61:11	Cabin Temperature Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A61:15	Cabin Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A63:11	Right Solar Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A63:15	Right Solar Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A64:11	Left Solar Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A64:15	Left Solar Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A68:11	Ambient Temperature Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A68:15	Ambient Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1A82:09	External Trip Switch: Component Failures	IPC	REFER to CLIMATE CONTROL (without navigation) or INFORMATION AND ENTERTAINMENT SYSTEMS (with navigation).
B1A82:11	External Trip Switch: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1A82:13	External Trip Switch: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B1A89:01	Satellite Antenna: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1A89:13	Satellite Antenna: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1B36:12	Right Front Outer Sensor: Circuit Short To Battery	Parking Aid Module (PAM)	REFER to PARKING AID .
B1B36:14	Right Front Outer Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B36:96	Right Front Outer Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B38:12	Right Front Inner Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B38:14	Right Front Inner Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B38:96	Right Front Inner Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B40:12	Left Front Outer Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B40:14	Left Front Outer Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B40:96	Left Front Outer Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B42:12	Left Front Inner Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B42:14	Left Front Inner Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B42:96	Left Front Inner Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B44:12	Right Rear Outer Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B44:14	Right Rear Outer Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B44:96	Right Rear Outer Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B46:12	Right Rear Inner Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B46:14	Right Rear Inner Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B46:96	Right Rear Inner Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B48:12	Left Rear Outer Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B48:14	Left Rear Outer Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B48:96	Left Rear Outer Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B50:12	Left Rear Inner Sensor: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B50:14	Left Rear Inner Sensor: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B50:96	Left Rear Inner Sensor: Component Internal Failure	PAM	REFER to PARKING AID .
B1B52:12	Rear Sounder - Park Aid: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B52:14	Rear Sounder - Park Aid: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B53:12	Front Sounder - Park Aid: Circuit Short To Battery	PAM	REFER to PARKING AID .
B1B53:14	Front Sounder - Park Aid: Circuit Short To Ground Or Open	PAM	REFER to PARKING AID .
B1B58:11	Rear Sensors Power Circuit: Circuit Short To Ground	PAM	REFER to PARKING AID .
B1B71:11	Evaporator Temperature Sensor: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1B71:15	Evaporator Temperature Sensor: Circuit Short To Battery Or Open	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
B1C37:11	Master Lock Switch: Circuit Short To Ground	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1C38:11	Master Unlock Switch: Circuit Short To Ground	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1C83:12	Rear Defog Relay: Circuit Short To Battery	HVAC module	REFER to GLASS, FRAMES AND MECHANISMS .
B1C83:14	Rear Defog Relay: Circuit Short To Ground Or Open	HVAC module	REFER to GLASS, FRAMES AND MECHANISMS .
B1D19:49	Compact Disc Unit: Internal Electronic Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D19:4B	Compact Disc Unit: Over Temperature	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D23:68	Overheat Sensor: Event Information	Power Steering Control Module (PSCM)	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
B1D78:13	Auxiliary Input: Circuit Open	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1D79:01	Microphone Input: General Electrical Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2008	Wipers On Signal Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2044	Left Rear Stop Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2045	Left Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2046	Right Rear Stop Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2047	Right Rear Stop Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2048	Left Rear Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2049	Left Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2050	Right Rear Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2051	Right Rear Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2071	Hazard Switch Signal Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2100	Door Driver Key Cylinder Switch Failure	SJB	REFER to ANTI-THEFT - PERIMETER .
B2112	Door Driver Set Switch Stuck Failure	DDM	REFER to ANTI-THEFT - PERIMETER .
B2116	Door Driver Reset Switch Stuck Failure	DDM	REFER to ANTI-THEFT - PERIMETER .
B213A	Digital Dimmer Switch Input Circuit Failure	SJB	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B2223	Mirror Driver Drive Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B2224	Mirror Passenger Drive Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2254	Front Fog Lamp Switch Failure	SJB	REFER to EXTERIOR LIGHTING .
B2276	Less Than 2 Transmitters Programmed	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2281	Right Turn Switch Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2282	Left Turn Switch Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2290	Occupant Classification System Fault	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2312	Mirror Passenger Horizontal Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2314	Mirror Passenger Horizontal Feedback Potentiometer Circuit Short To Battery	DSM	REFER to REAR VIEW MIRRORS .
B2316	Mirror Passenger Vertical Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2318	Mirror Passenger Vertical Feedback Potentiometer Circuit Short To Battery	DSM	REFER to REAR VIEW MIRRORS .
B2320	Mirror Driver Horizontal Feedback Potentiometer Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B2322	Mirror Driver Horizontal Feedback Potentiometer Circuit Short To Battery	DDM	REFER to REAR VIEW MIRRORS .
B2324	Mirror Driver Vertical Feedback Potentiometer Circuit Failure	DDM	REFER to REAR VIEW MIRRORS .
B2324	Mirror Driver Vertical Feedback Potentiometer Circuit Failure	DSM	REFER to REAR VIEW MIRRORS .
B2326	Mirror Driver Vertical Feedback Potentiometer Circuit Short To Battery	DDM	REFER to REAR VIEW MIRRORS .
B2330	Column Reach Feedback Potentiometer Circuit Short To Battery	DSM	REFER to STEERING COLUMN .
B2331	Column Reach Feedback Potentiometer Circuit Short To Ground	DSM	REFER to STEERING COLUMN .
B2334	Column Tilt Feedback Potentiometer Circuit Short To Battery	DSM	REFER to STEERING COLUMN .
B2335	Column Tilt Feedback Potentiometer Circuit Short To Ground	DSM	REFER to STEERING COLUMN .
B2340	Column Reach Motor Stalled	DSM	REFER to STEERING COLUMN .
B2341	Column Tilt Motor Stalled	DSM	REFER to STEERING COLUMN .
B2425	Remote Keyless Entry Out Of Synchronization	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2477	Module Configuration Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2477	Module Configuration Failure	DCSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DDM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DSM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	FDIM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	ILCM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SECM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SJB	REFER to MODULE CONFIGURATION .
B2479	Park Brake Switch Circuit Short to Ground	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
B2486	Climate Control Seat Module Voltage Out Of Range	DCSM	REFER to SEATING .
B2498	Headlamp Switch Multiple Signals Input Active	SJB	REFER to EXTERIOR LIGHTING .
B2572	Brake Shift Interlock Output Circuit Failure	SJB	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
B2574	Drivers Door LOCK Switch Short To Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2575	Drivers Door UNLOCK Switch Short To Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2667	Liftglass Release Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2729	Cushion Over-Temp Detected	DCSM	REFER to SEATING .
B272A	Passenger Cushion Over-Temp Detected	DCSM	REFER to SEATING .
B272B	Passenger Back Over-Temp Detected	DCSM	REFER to SEATING .
B272C	Driver Differential Temperature Fault	DCSM	REFER to SEATING .
B272D	Passenger Differential Temperature Fault	DCSM	REFER to SEATING .
B272E	Driver Ignition Run/Blower Circuit Short to Ground	DCSM	REFER to SEATING .
B272F	Passenger Ignition Run/Blower Circuit Short to Ground	DCSM	REFER to SEATING .
B2730	Back-Over Temp Detected	DCSM	REFER to SEATING .
B2844	Ignition Fault	SJB	REFER to STEERING COLUMN SWITCHES .
B2868	Left Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS AND TIRES .
B2869	Right Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS AND TIRES .
B2870	Right Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS AND TIRES .
B2871	Left Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS AND TIRES .
B2872	Tire Pressure Sensor Fault	SJB	REFER to WHEELS AND TIRES .
B287A	Tire Pressure System Fault	SJB	REFER to WHEELS AND TIRES .
B2900	VIN Mismatch	4X4 control module	REFER to MODULE CONFIGURATION .
B2900	VIN Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2924	Audio Button Stuck	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B2947	Global Opening/Closing Circuit Open	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2949	Global Opening/Closing Circuit Short To Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B2A20	Ignition Stuck In START	SJB	REFER to STEERING COLUMN SWITCHES .
B2A21	One or More Configuration Files Missing or Corrupt	ILCM	REFER to INTERIOR LIGHTING .
B2A21	One or More Configuration Files Missing or Corrupt	SJB	REFER to SMART JUNCTION BOX (SJB) .
B2A22	Headlamp OFF Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A23	High Beam Input Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A24	Turn Signal Input Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B2A25	Trim Panel Lock Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A26	Keypad Switch Circuit Failure	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2A27	Right Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A28	Right Front Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A29	Left Front Turn Lamp Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2A	Left Front Turn Lamp Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A2E	Right Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A2F	Right Front Lamp Low Beam Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A30	Left Front Lamp Low Beam Circuit Open	SJB	REFER to EXTERIOR LIGHTING .
B2A31	Left Front Lamp Low Beam Circuit Short To Ground	SJB	REFER to EXTERIOR LIGHTING .
B2A35	Interior Lighting Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A36	Interior Lighting Output Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
B2A39	Puddle Lamp Output Circuit Open	SJB	REFER to INTERIOR LIGHTING .
B2A3A	Puddle Lamp Output Circuit Short To Ground	SJB	REFER to INTERIOR LIGHTING .
B2A41	Steering Column Telescopic Rear Switch Short To Battery	DSM	REFER to STEERING COLUMN .
B2A42	Steering Column Tilt Up Switch Short To Battery	DSM	REFER to STEERING COLUMN .
B2A44	Steering Column Telescopic Forward Switch Short To Battery	DSM	REFER to STEERING COLUMN .
B2B00	Ambient Light Zone 1 Red Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B01	Ambient Light Zone 1 Red Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B02	Ambient Light Zone 1 Green Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B03	Ambient Light Zone 1 Green Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B04	Ambient Light Zone 1 Blue Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B05	Ambient Light Zone 1 Blue Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B06	Ambient Light Zone 1 Signature Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B07	Ambient Light Zone 1 Signature Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B08	Ambient Light Zone 2 Red Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B09	Ambient Light Zone 2 Red Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B0A	Ambient Light Zone 2 Green Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B0B	Ambient Light Zone 2 Green Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B0C	Ambient Light Zone 2 Blue Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B0D	Ambient Light Zone 2 Blue Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B0E	Ambient Light Zone 2 Signature Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B0F	Ambient Light Zone 2 Signature Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B10	Ambient Light Zone 3 Red Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B11	Ambient Light Zone 3 Red Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B12	Ambient Light Zone 3 Green Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B13	Ambient Light Zone 3 Green Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B14	Ambient Light Zone 3 Blue Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B16	Ambient Light Zone 3 Signature Circuit Open	ILCM	REFER to INTERIOR LIGHTING .
B2B17	Ambient Light Zone 3 Signature Circuit Short to Ground	ILCM	REFER to INTERIOR LIGHTING .
B2B18	Ambient Light Switch Input Fault	ILCM	REFER to INTERIOR LIGHTING .
C0072:00	Brake Temperature Too High: No Sub Type Information	Cruise-Control Module (C-CM)	REFER to CRUISE CONTROL .
C1001:01	Vision System Camera: General Electrical Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
C1105	Traction Control Disable Lamp Circuit Short to Battery	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1125	Brake Fluid Level Sensor Input Circuit Failure	SJB	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
C1132:4B	Head Up Display: Over Temperature	C-CM	REFER to CRUISE CONTROL .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1222	Speed Wheel Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1266	ABS Valve Power Relay Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1278	Steering Wheel Angle 1 And 2 Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1279	Yaw Rate Sensor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1280	Yaw Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1281	Lateral Accelerometer Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1282	Lateral Accelerometer Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1296	Wheel Speed LF Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1297	Wheel Speed RF Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1298	Wheel Speed RR Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1299	Wheel Speed LR Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1300	ABS Pump Motor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1440	Pressure Transducer Main/Primary Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1446	Brake Switch Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1805	Mismatched PCM And/Or ABS-TC Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1956	Steering Angle Sensor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1963	Stability Control Inhibit Warning	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1975	IVD Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1A67:54	Forward Looking Sensor: Missing Calibration	C-CM	REFER to CRUISE CONTROL .
C1A67:76	Forward Looking Sensor: Wrong Mounting Position	C-CM	REFER to CRUISE CONTROL .
C1A67:96	Forward Looking Sensor: Component Internal Failure	C-CM	REFER to CRUISE CONTROL .
C1A67:97	Forward Looking Sensor: Component Or System Operation Obstructed Or Blocked	C-CM	REFER to CRUISE CONTROL .
C1A67:98	Forward Looking Sensor: Component Or System Over Temperature	C-CM	REFER to CRUISE CONTROL .
C1B00:2F	Steering Angle Sensor: Signal Erratic	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C1B00:62	Steering Angle Sensor: Signal Compare Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C1B14:11	Sensor Supply Voltage A: Circuit Short To Ground	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
C1B14:12	Sensor Supply Voltage A: Circuit Short To Battery	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
C200B:2F	Steering Shaft Torque Sensor 1: Signal Erratic	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200B:61	Steering Shaft Torque Sensor 1: Signal Calculation Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200B:62	Steering Shaft Torque Sensor 1: Signal Compare Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200C:2F	Steering Shaft Torque Sensor 2: Signal Erratic	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C200D:49	Motor Rotation Angle Sensor: Internal Electronic Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
C2769	Longitudinal Acceleration Sensor Electrical Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2770	Longitudinal Acceleration Sensor Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2780	ECU In Manufacturer Sub-State	SJB	REFER to WHEELS AND TIRES .
P0460:11	Fuel Level Sensor A Circuit: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0460:13	Fuel Level Sensor A Circuit: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0512	Starter Request Circuit	PCM	REFER to STARTING SYSTEM .
P0532	A/C Refrigerant Pressure Sensor A Circuit Low	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0533	A/C Refrigerant Pressure Sensor A Circuit High	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0562	System Voltage Low	PCM	REFER to CHARGING SYSTEM .
P0563	System Voltage High	PCM	REFER to CHARGING SYSTEM .
P0579	Cruise Control Multifunction Input A Circuit Range/Performance	PCM	REFER to CRUISE CONTROL .
P0581	Cruise Control Multifunction Input A Circuit High	PCM	REFER to CRUISE CONTROL .
P0602	Powertrain Control Module Programming Error	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P0602	Powertrain Control Module Programming Error	PCM	REFER to MODULE CONFIGURATION .
P0605	Internal Control Module Read Only Memory (ROM) Error	PCM	REFER to MODULE CONFIGURATION .
P0615:11	Starter Relay Circuit: Circuit Short To Ground	RFA module	REFER to STARTING SYSTEM .
P0615:12	Starter Relay Circuit: Circuit Short To Battery	RFA module	REFER to STARTING SYSTEM .
P0615:13	Starter Relay Circuit: Circuit Open	RFA module	REFER to STARTING SYSTEM .
P0620	Generator Control Circuit	PCM	REFER to CHARGING SYSTEM .
P0625	Generator Field Terminal Circuit Low	PCM	REFER to CHARGING SYSTEM .
P0626	Generator Field Terminal Circuit High	PCM	REFER to CHARGING SYSTEM .
P062F	Internal Control Module EEPROM Error	SJB	REFER to SMART JUNCTION BOX (SJB) .
P0645	A/C Clutch Relay Control Circuit	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0657	Actuator Supply Voltage A Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P065B	Generator Control Circuit Range/Performance	PCM	REFER to CHARGING SYSTEM .
P0705	Transmission Range Sensor A Circuit (PRNDL Input)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0706	Transmission Range Sensor A Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0708	Transmission Range Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0709	Transmission Range Sensor A Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0710	Transmission Fluid Temperature Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0711	Transmission Fluid Temperature Sensor A Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0712	Transmission Fluid Temperature Sensor A Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0713	Transmission Fluid Temperature Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0715	Turbine/Input Shaft Speed Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0717	Turbine/Input Shaft Speed Sensor A Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0718	Turbine/Input Shaft Speed Sensor A Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0720	Output Shaft Speed Sensor Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0721	Output Shaft Speed Sensor Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0722	Output Shaft Speed Sensor Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0729	Gear 6 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P072C	Stuck in Gear 1	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P072E	Stuck in Gear 3	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P072F	Stuck in Gear 4	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0733	Gear 3 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0734	Gear 4 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0735	Gear 5 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P073A	Stuck in Gear 5	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P073B	Stuck in Gear 6	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0740	Torque Converter Clutch Solenoid Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0741	Torque Converter Clutch Solenoid Circuit Performance Or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0742	Torque Converter Clutch Solenoid Circuit Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0743	Torque Converter Clutch Solenoid Circuit Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0744	Torque Converter Clutch Solenoid Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0748	Pressure Control Solenoid A Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0750	Shift Solenoid A	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0751	Shift Solenoid A Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0752	Shift Solenoid A Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0753	Shift Solenoid A Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0755	Shift Solenoid B	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0756	Shift Solenoid B Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0757	Shift Solenoid B Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0758	Shift Solenoid B Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0760	Shift Solenoid C	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0761	Shift Solenoid C Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0762	Shift Solenoid C Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0763	Shift Solenoid C Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0765	Shift Solenoid D	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0766	Shift Solenoid D Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0767	Shift Solenoid D Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0768	Shift Solenoid D Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0770	Shift Solenoid E	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0771	Shift Solenoid E Performance or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0772	Shift Solenoid E Stuck On	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0773	Shift Solenoid E Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0774	Shift Solenoid E Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P07AE:09	Transmission Friction Element "G" Performance/Stuck Off: Component Failures	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
P0812:12	Reverse Input Circuit: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
P0815	Upshift Switch Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
P0816	Downshift Switch Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
P081C:11	Park Input Circuit: Circuit Short To Ground	RFA module	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P0960	Pressure Control Solenoid A Control Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0962	Pressure Control Solenoid A Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0963	Pressure Control Solenoid A Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0973	Shift Solenoid A Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0974	Shift Solenoid A Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0976	Shift Solenoid B Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0977	Shift Solenoid B Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0979	Shift Solenoid C Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0980	Shift Solenoid C Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0982	Shift Solenoid D Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P0983	Shift Solenoid D Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1243:06	Second Fuel Pump Fault or Ground Fault: Algorithm Based Failures	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1260	Theft Detected, Vehicle Immobilized	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1346:11	Fuel Level Sensor B Circuit: Circuit Short To Ground	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1346:13	Fuel Level Sensor B Circuit: Circuit Open	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1464	A/C Demand Out Of Self Test Range	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P1534:01	Restraint Deployment Indicator Circuit: General Electrical Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1571:12	Brake Switch: Circuit Short To Battery	RFA module	REFER to EXTERIOR LIGHTING .
P1603:55	EEPROM Malfunction: Not Configured	PAM	REFER to PARKING AID .
P1635	Tire/Axle Out of Acceptable Range	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1636	Inductive Signature Chip Communication Error	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1639	Vehicle ID Block Corrupted, Not Programmed	PCM	REFER to MODULE CONFIGURATION .
P163E	Transmission Control Module Programming Error	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P163F	Transmission ID Block Corrupted, Not Programmed	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1700	Transmission Indeterminate Failure (Failed to Neutral)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1702	Transmission Range Sensor Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1703	Brake Switch Out of Self-Test Range	PCM	REFER to CRUISE CONTROL .
P1705	Transmission Range Circuit Not Indicating Park/Neutral During Self Test	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1706:00	High Vehicle Speed Observed in Park: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
P1711	Transmission Fluid Temperature Sensor Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1744	Torque Converter Clutch Solenoid Circuit Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1780	Transmission Control Switch (O/D Cancel) Circuit Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1783	Transmission Overtemperature Condition	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P1824	4-Wheel Drive Clutch Relay Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1825	4-Wheel Drive Clutch Relay Open Circuit	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1910	Reverse Lamp Control Circuit/Open	PCM	REFER to EXTERIOR LIGHTING .
P254F:13	Engine Hood Switch Circuit/Open: Circuit Open	RFA module	REFER to ANTI-THEFT - PERIMETER .
P2700	Transmission Friction Element A Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P2701	Transmission Friction Element B Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P2702	Transmission Friction Element C Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P2703	Transmission Friction Element D Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P2704	Transmission Friction Element E Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P2705	Transmission Friction Element F Apply Time Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
P2783	Torque Converter Temperature Too High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F50/6F55 .
PXXXX	All Other DTCs	PCM	REFER to INTRODUCTION - GASOLINE MODELS .
U0001:88	High Speed CAN Communication Bus: Bus Off	C-CM	REFER to MODULE COMMUNICATIONS NETWORK .
U0001:88	High Speed CAN Communication Bus: Bus Off	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0002:88	High Speed CAN Communication Bus Performance: Bus Off	IPC	REFER to MODULE COMMUNICATIONS NETWORK .
U0011:88	Medium Speed CAN Communication Bus Performance: Bus Off	IPC	REFER to MODULE COMMUNICATIONS NETWORK .
U0028:08	Vehicle Communication Bus A: Bus Signal/Message Failures	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0028:88	Vehicle Communication Bus A: Bus Off	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0073	Control Module Communication Bus A Off	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0074	Control Module Communication Bus B Off	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0100	Lost Communication With ECM/PCM	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0100	Lost Communication With ECM/PCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	C-CM	REFER to CRUISE CONTROL .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	HCM	REFER to EXTERIOR LIGHTING .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	PAM	REFER to PARKING AID .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0100:00	Lost Communication With ECM/PCM "A": No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0100:87	Lost Communication With ECM/PCM "A": Missing Message	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U0101:00	Lost Communication With TCM: No Sub Type Information	PAM	REFER to PARKING AID .
U0102	Lost Communication with Transfer Case Control Module (4x4CM)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0102:00	Lost Communication with Transfer Case Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0104	Lost Communication With Cruise Control Module (ICCM)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0104	Lost Communication With Cruise Control Module (ICCM)	PCM	REFER to CRUISE CONTROL .
U0104:00	Lost Communication With Cruise Control Module: No Sub Type Information	Head Up Display (HUD)	REFER to COLLISION AVOIDANCE .
U0104:00	Lost Communication With Cruise Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	C-CM	REFER to CRUISE CONTROL .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	HCM	REFER to EXTERIOR LIGHTING .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	PAM	REFER to PARKING AID .
U0121:00	Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0126	Lost Communication With Steering Angle Sensor Module	SECM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0126:00	Lost Communication With Steering Angle Sensor Module: No Sub Type Information	C-CM	REFER to CRUISE CONTROL .
U0126:00	Lost Communication With Steering Angle Sensor Module: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0131	Lost Communication With Power Steering Control Module (VAPS)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0131:00	Lost Communication With Power Steering Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0131:00	Lost Communication With Power Steering Control Module: No Sub Type Information	PAM	REFER to PARKING AID .
U0140	Lost Communication With Body Control Module (GEM)	DDM	REFER to DRIVER DOOR MODULE (DDM) .
U0140	Lost Communication With Body Control Module (GEM)	DSM	REFER to DRIVER SEAT MODULE (DSM) .
U0140	Lost Communication With Body Control Module (GEM)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140	Lost Communication With Body Control Module (GEM)	ILCM	REFER to INTERIOR LIGHTING .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Front Controls Interface Module (FCIM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	Global Positioning System Module (GPSM)	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U0140:00	Lost Communication With Body Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0140:87	Lost Communication With Body Control Module: Missing Message	RFA module	REFER to REMOTE FUNCTION ACTUATOR (RFA) MODULE .
U0151	Lost Communication With Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0151	Lost Communication With Restraints Control Module	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0151:00	Lost Communication With Restraints Control Module: No Sub Type Information	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0154:00	Lost Communication With Restraints Occupant Classification System Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0154:00	Lost Communication With Restraints Occupant Classification System Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	DSM	REFER to DRIVER SEAT MODULE (DSM) .
U0155	Lost Communication with Instrument Panel Cluster (IC) Control Module	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155	Lost Communication with Instrument Panel Cluster (IC) Control Module	SASM	REFER to VEHICLE DYNAMIC SYSTEMS .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	SJB	REFER to SMART JUNCTION BOX (SJB) 3.
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	C-CM	REFER to CRUISE CONTROL .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	HCM	REFER to EXTERIOR LIGHTING .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	HUD	REFER to COLLISION AVOIDANCE .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	PAM	REFER to PARKING AID .
U0155:00	Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0155:87	Lost Communication With Instrument Panel Cluster (IPC) Control Module: Missing Message	RFA module	REFER to REMOTE FUNCTION ACTUATOR (RFA) MODULE .
U0158:00	Lost Communication With Head Up Display: No Sub Type Information	C-CM	REFER to CRUISE CONTROL .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0159:00	Lost Communication With Parking Assist Control Module "A": No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0161:00	Lost Communication With Compass Module: No Sub Type Information	IPC	REFER to ELECTRONIC COMPASS .
U0162:00	Lost Communication With Navigation Display Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0163:00	Lost Communication With Navigation Control Module: No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U0163:00	Lost Communication With Navigation Control Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0164	Lost Communication With HVAC Control Module (EATC)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0164:00	Lost Communication With HVAC Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U016A:00	Lost Communication With Electric A/C Compressor Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0180:00	Lost Communication With Automatic Lighting Control Module: No Sub Type Information	C-CM	REFER to CRUISE CONTROL .
U0184	Lost Communication With Radio (ACM)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0184:00	Lost Communication With Radio: No Sub Type Information	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193	Lost Communication With Digital Audio Control Module (SDARS)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0193:00	Lost Communication With "Digital Audio Control Module A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196	Lost Communication With Entertainment Control Module - Rear (AUX)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module - Rear "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module - Rear "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0196:00	Lost Communication With Entertainment Control Module - Rear "A": No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197	Lost Communication With Telephone Control Module	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0197:00	Lost Communication With Telephone Control Module: No Sub Type Information	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0208:00	Lost Communication With "Seat Control Module A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0214:00	Lost Communication With Remote Function Actuation: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0230:00	Lost Communication With Rear Gate Module: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0232:00	Lost Communication With Side Obstacle Detection Control Module - Left: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0233:00	Lost Communication With Side Obstacle Detection Control Module - Right: No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0238	Lost Communication With Digital Audio Control Module "D" (DSP)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0238:00	Lost Communication With Digital Audio Control Module "D": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0241:00	Lost Communication With Headlamp Control Module "A": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0242:00	Lost Communication With Headlamp Control Module "B": No Sub Type Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0249	Lost Communication With Entertainment Control Module - Rear "B" (RCU)	FDIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249:00	Lost Communication With Entertainment Control Module - Rear "B": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0249:00	Lost Communication With Entertainment Control Module - Rear "B": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0253:00	Lost Communication With Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0255:00	Lost Communication With Front Display Interface Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0256:00	Lost Communication With Front Controls Interface Module "A": No Sub Type Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U0300	Internal Control Module Software Incompatibility	PCM	REFER to MODULE CONFIGURATION .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0300:55	Internal Control Module Software Incompatibility: Not Configured	C-CM	REFER to CRUISE CONTROL .
U0401	Invalid Data Received From ECM/PCM	4X4 control module	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	C-CM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to CRUISE CONTROL .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	HCM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to EXTERIOR LIGHTING .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	OCSM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	PAM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to PARKING AID .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	PSCM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0401:00	Invalid Data Received from ECM/PCM A: No Sub Type Information	RCM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0401:68	Invalid Data Received from ECM/PCM A: Event Information	C-CM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to CRUISE CONTROL .
U0401:68	Invalid Data Received from ECM/PCM A: Event Information	IPC	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0402:00	Invalid Data Received from TCM: No Sub Type Information	PAM	RETRIEVE and FOLLOW all non-network DTCs from the PCM. REFER to PARKING AID .
U0405	Invalid Data Received from Cruise Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0405:55	Invalid Data Received From Cruise Control Module: Not Configured	IPC	RETRIEVE and FOLLOW all non-network DTCs from the C-CM . REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0405:68	Invalid Data Received From Cruise Control Module: Event Information	HUD	RETRIEVE and FOLLOW all non-network DTCs from the C-CM . REFER to COLLISION AVOIDANCE .
U0415	Invalid Data Received From Anti-Lock Brake System Control Module	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0415:00	Invalid Data Received From Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	HCM	RETRIEVE and FOLLOW all non-network DTCs from the ABS module. REFER to EXTERIOR LIGHTING .
U0415:00	Invalid Data Received From Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	PAM	RETRIEVE and FOLLOW all non-network DTCs from the ABS module. REFER to PARKING AID .
U0415:00	Invalid Data Received From Anti-Lock Brake System (ABS) Control Module: No Sub Type Information	PSCM	RETRIEVE and FOLLOW all non-network DTCs from the ABS module. REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0418:68	Invalid Data Received From Brake System Control Module: Event Information	C-CM	RETRIEVE and FOLLOW all non-network DTCs from the ABS module. REFER to CRUISE CONTROL .
U0420	Invalid Data Received From Power Steering Control Module (PSCM)	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0420:00	Invalid Data Received From Power Steering Control Module (PSCM): No Sub Type Information	PAM	REFER to PARKING AID .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0422:00	Invalid Data Received From Body Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0422:55	Invalid Data Received From Body Control Module: Not Configured	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0422:68	Invalid Data Received From Body Control Module: Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U0423:00	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0423:00	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0423:00	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: No Sub Type Information	PAM	REFER to PARKING AID .
U0423:68	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: Event Information	HUD module	REFER to COLLISION AVOIDANCE .
U0423:68	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U0423:68	Invalid Data Received From Instrument Panel Cluster (IPC) Control Module: Event Information	RFA module	REFER to REMOTE FUNCTION ACTUATOR (RFA) MODULE .
U0424:68	Invalid Data Received From HVAC Control Module: Event Information	C-CM	REFER to CRUISE CONTROL .
U0428:00	Invalid Data Received From Steering Angle Sensor Module: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U0428:68	Invalid Data Received From Steering Angle Sensor Module: Event Information	C-CM	REFER to CRUISE CONTROL .
U0430:68	Invalid Data Received From Tire Pressure Monitor Module: Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0433	Invalid Data Received From Cruise Control Front Distance Range Sensor	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0452	Invalid Data Received From Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0459:68	Invalid Data Received From Head Up Display: Event Information	C-CM	REFER to CRUISE CONTROL .
U045A:00	Invalid Data Received From Parking Assist Control Module "A": No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U045A:55	Invalid Data Received From Parking Assist Control Module "A": Not Configured	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U045A:68	Invalid Data Received From Parking Assist Control Module "A": Event Information	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U0462:68	Invalid Data Received From Compass Module: Event Information	IPC	REFER to ELECTRONIC COMPASS .
U0464:68	Invalid Data Received From Navigation Control Module: Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U046B:00	Invalid Data Received From Global Positioning System Module: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0485:00	Invalid Data Received From Radio: No Sub Type Information	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U049A:68	Invalid Data Received From "Door Control Module A": Event Information	RFA module	RETRIEVE and FOLLOW all non-network DTCs from the DDM .
U0513:68	Invalid Data Received From Yaw Rate Sensor Module: Event Information	C-CM	REFER to CRUISE CONTROL .
U0554:00	Invalid Data Received From Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0557:68	Invalid Data Received From Front Controls Interface Module "A": Event Information	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U1000:00	Solid State Driver Protection Active - Driver Disabled: No Sub Type Information	RFA module	REFER to REMOTE FUNCTION ACTUATOR (RFA) MODULE .
U1000:11	Solid State Driver Protection Active - Driver Disabled: Circuit Short To Ground	HCM-2	REFER to EXTERIOR LIGHTING .
U1000:49	Solid State Driver Protection Active - Driver Disabled: Internal Electronic Failure	HCM-2	REFER to EXTERIOR LIGHTING .
U2005:12	Vehicle Speed: Circuit Short To Battery	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U200D:12	Control Module Output Power A: Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U200E:11	Control Module Output Power B: Circuit Short To Ground	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U200E:12	Control Module Output Power B: Circuit Short To Battery	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U200E:1A	Control Module Output Power B: Circuit Resistance Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2011:49	Motor: Internal Electronic Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2011:61	Motor: Signal Calculation Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2013:63	Switch Pack: Circuit/Component Protection Time-Out	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:09	Control Module Hardware: Component Failures	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:41	Control Module Hardware: General Checksum Failure	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure Audio	DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:42	Control Module Hardware: General Memory Failure	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U2014:96	Control Module Hardware: Component Internal Failure	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U201A:51	Control Module Main Calibration Data: Not Programmed	ACM	REFER to MODULE CONFIGURATION .
U201A:51	Control Module Main Calibration Data: Not Programmed	Audio DSP module	REFER to MODULE CONFIGURATION .
U201A:51	Control Module Main Calibration Data: Not Programmed	FCIM	REFER to MODULE CONFIGURATION .
U201A:54	Control Module Main Calibration Data: Missing Calibration	HCM-2	REFER to MODULE CONFIGURATION .
U201F:31	External Receiver: No Signal	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U2023	Fault Received From External Node	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2024:41	Control Module Cal-Config Data: General Checksum Failure	PAM	REFER to PARKING AID .
U2050	No Application Present	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U2050	No Application Present	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2050	No Application Present	DCSM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	DDM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	DSM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ILCM	REFER to MODULE CONFIGURATION .
U2050	No Application Present	SASM	REFER to VEHICLE DYNAMIC SYSTEMS .
U2050	No Application Present	SJB	REFER to MODULE CONFIGURATION .
U2051	One Or More Calibration Files Missing/Corrupt	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	Audio DSP module	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	C-CM	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	HCM-2	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	IPC	REFER to MODULE CONFIGURATION .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2100:55	Initial Configuration Not Complete: Not Configured	RFA module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	ACM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	APIM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	Audio DSP module	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	C-CM	REFER to MODULE CONFIGURATION .
U2101:00	Control Module Configuration Incompatible: No Sub Type Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U210A:16	Temperature Sensor: Circuit Voltage Below Threshold	HUD	REFER to COLLISION AVOIDANCE .
U210A:17	Temperature Sensor: Circuit Voltage Above Threshold	HUD	REFER to COLLISION AVOIDANCE .
U2200:00	Control Module Configuration Memory Corrupt: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2472	Unexpected Ignition State	SJB	REFER to STEERING COLUMN SWITCHES .
U2473	Unexpected Vehicle Speed (VSS)	SJB	NOTE: Sets during the self-test if vehicle speed exceeds 3 mph (5 kph) or vehicle speed cannot be determined by the SJB . VERIFY the speedometer operates correctly.If the speedometer does not operate correctly, REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .If the speedometer operates correctly, the self-test is carried out while the vehicle is moving. STOP the vehicle and REPEAT the self-test.
U3000:04	Control Module: System Internal Failures	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:09	Control Module: Component Failures	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:11	Control Module: Circuit Short To Ground	HCM-2	REFER to EXTERIOR LIGHTING .
U3000:41	Control Module: General Checksum Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	C-CM	REFER to CRUISE CONTROL .
U3000:41	Control Module: General Checksum Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:41	Control Module: General Checksum Failure	HCM	REFER to EXTERIOR LIGHTING .
U3000:41	Control Module: General Checksum Failure	HUD	REFER to COLLISION AVOIDANCE .
U3000:41	Control Module: General Checksum Failure	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U3000:41	Control Module: General Checksum Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:41	Control Module: General Checksum Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:42	Control Module: General Memory Failure	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	C-CM	REFER to CRUISE CONTROL .
U3000:42	Control Module: General Memory Failure	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3000:42	Control Module: General Memory Failure	HCM-2	REFER to EXTERIOR LIGHTING .
U3000:42	Control Module: General Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:44	Control Module: Data Memory Failure	C-CM	REFER to CRUISE CONTROL .
U3000:44	Control Module: Data Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:45	Control Module: Program Memory Failure	PAM	REFER to PARKING AID .
U3000:46	Control Module: Calibration/Parameter Memory Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3000:46	Control Module: Calibration/Parameter Memory Failure	PAM	REFER to PARKING AID .
U3000:46	Control Module: Calibration/Parameter Memory Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:46	Control Module: Calibration/Parameter Memory Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	C-CM	REFER to CRUISE CONTROL .
U3000:49	Control Module: Internal Electronic Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:49	Control Module: Internal Electronic Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	RFA module	REFER to REMOTE FUNCTION ACTUATOR (RFA) MODULE .
U3000:4A	Control Module: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:53	Control Module: Deactivated	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:54	Control Module: Missing Calibration	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:55	Control Module: Not Configured	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U3000:61	Control Module: Signal Calculation Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:63	Control Module: Circuit/Component Protection Time-Out	C-CM	REFER to CRUISE CONTROL .
U3000:66	Control Module: Signal Has Too Many Transitions/Events	C-CM	REFER to CRUISE CONTROL .
U3000:72	Control Module: Actuator Stuck Open	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3000:88	Control Module: Bus Off	APIM	REFER to MODULE COMMUNICATIONS NETWORK .
U3000:93	Control Module: No Operation	HCM-2	REFER to EXTERIOR LIGHTING .
U3000:96	Control Module: Component Internal Failure	HCM-2	REFER to EXTERIOR LIGHTING .
U3000:96	Control Module: Component Internal Failure	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	C-CM	REFER to CRUISE CONTROL .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	HUD	REFER to COLLISION AVOIDANCE .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	ACM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	APIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	Audio DSP module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	C-CM	REFER to CRUISE CONTROL .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	FCIM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	GPSM	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	HUD	REFER to COLLISION AVOIDANCE .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	HVAC module	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:62	Battery Voltage: Signal Compare Failure	RFA module	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U3003:68	Battery Voltage: Event Information	PSCM	REFER to STEERING SYSTEM - ELECTRONIC POWER ASSIST STEERING (EPAS) .
U3004:11	Accessory Power Relay: Circuit Short To Ground	RFA module	REFER to STEERING COLUMN SWITCHES .
U3004:12	Accessory Power Relay: Circuit Short To Battery	RFA module	REFER to STEERING COLUMN SWITCHES .
U3004:13	Accessory Power Relay: Circuit Open	RFA module	REFER to STEERING COLUMN SWITCHES .
U300A:62	Ignition Switch: Signal Compare Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .
U300A:64	Ignition Switch: Signal Plausibility Failure	IPC	REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .

NOTE
Sets during the self-test if vehicle speed exceeds 3 mph (5 kph) or vehicle speed cannot be determined by the SJB .

DIAGNOSTIC TROUBLE CODE (DTC) CHART

Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Smart Junction Box (SJB) fuse 5 (10A) Wiring, terminals or connectors SJB
If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
If the scan tool does not communicate with the VCM : Check the VCM connection to the vehicle. Check the scan tool connection to the VCM . Refer to «MODULE COMMUNICATIONS NETWORK»(ref-376006) , No Power To The Scan Tool, to diagnose no power to the scan tool.
If the scan tool does not communicate with the vehicle: Verify the ignition is in the ON state. The air bag warning indicator prove-out confirms ignition ON (other indicators may not prove ignition ON). If the ignition does not turn on, refer to «STEERING COLUMN SWITCHES»(ref-376010) to diagnose no power in RUN. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-376006) to diagnose no response from the PCM.
Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-376006) . If the network test passes, retrieve and record the continuous memory DTCs.
Clear the continuous DTCs and carry out the self-test diagnostics for the SJB .
If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(ref-376007-S33576836522010103100000) . For all other DTCs, refer to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-376007-S17899367672010103100000) .
If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-376007-S28459064232010103100000) .

Smart Junction Box (SJB) DTC Chart

Note. Refer to Description and Operation, Intelligent Access (IA) with Push Button Start in ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) to review the procedures for achieving the various ignition states (ignition in accessory, ignition on, ignition start, ignition off) on vehicles with this feature.

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST A .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST A .
B1317	Battery Voltage High	GO to PINPOINT TEST B .
B1318	Battery Voltage Low	GO to PINPOINT TEST C .
B2A21	One or More Configuration Files Missing or Corrupt	CONFIGURE the Smart Junction Box (SJB). REFER to MODULE CONFIGURATION to carry out Programmable Module Installation (PMI).
P062F	No Application Present	CONFIGURE the Smart Junction Box (SJB). REFER to MODULE CONFIGURATION to carry out Programmable Module Installation (PMI). CLEAR the DTCs. REPEAT the self-test. If DTC P062F is retrieved again, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
U0155	Lost Communication with Instrument Panel Cluster (IC) Control Module	GO to PINPOINT TEST D .
U2472	Unexpected Ignition State	REFER to STEERING COLUMN SWITCHES .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

SMART JUNCTION BOX (SJB) DTC CHART

Symptom Chart

Condition	Possible Sources	Action
The Smart Junction Box (SJB) Does Not Respond To The Scan Tool	Fuse Wiring, terminals or connectors SJB	REFER to MODULE COMMUNICATIONS NETWORK .

SYMPTOM CHART

PINPOINT TEST A: DTCs B106E, B106F

A1 REVIEW THE DTCs NOTE: First follow the necessary diagnostics to resolve DTC B106E and any other present DTCs (ignoring B106F). DTC B106E is only present when there is another DTC due to software or circuitry issues that must be resolved before another self-test is run. DTC B106F is only present once the final threshold has been met. Failure to correct the fault condition first may cause damage to the new SJB , resulting in a repeat repair. Review the DTCs from the SJB self-test. Are any other DTCs present, besides B106E, B106F or B1342? Yes: CORRECT the DTCs. REFER to the «SMART JUNCTION BOX (SJB) DTC CHART»(ref-376007-S41364470382010103100000) . After the repair, GO to A2 . No: GO to A2 .
A2 REPEAT THE SJB SELF-TEST Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs and repeat the SJB self-test. Is DTC B106F or DTC B1342 present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The circuit short has been repaired.

Pinpoint Test B: DTC B1317

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

B1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-375995) to diagnose an overcharging condition. No: GO to B2 .
B2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-375995) to diagnose an overcharging condition. No: GO to B3 .
B3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the continuous memory DTCs. Carry out the SJB self-test. Is DTC B1317 present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test C: DTC B1318

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 139

Scheme 139: PINPOINT TEST C: DTC B1318

Scheme 140

C1 RECHECK THE SJB DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs. Repeat the SJB self-test. Is DTC B1318 still present? Yes: GO to C2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
C2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(ref-375995) . No: GO to C3 .
C3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-376024) . Is the battery OK and fully charged? Yes: GO to C4 . No: REFER to «CHARGING SYSTEM»(ref-375995) .
C4 CHECK THE SJB VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: SJB C2280G. Ignition ON. Measure the voltage between the SJB C2280G-1, circuit SBB01 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to C5 . No: REPAIR the circuit for high resistance. CLEAR the DTCs. REPEAT the self-test.
C5 CHECK THE SJB GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: SJB C2280D. Measure the resistance between the SJB C2280D-7, 8, 12, 24, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes: GO to C6 . No: REPAIR the circuit for high resistance. TEST the system for normal operation.
C6 CHECK FOR CORRECT SJB OPERATION Connect: Negative Battery Cable. Disconnect the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test D: DTC U0155

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

D1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to D2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: GO to D3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-376006) .
D3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST B»(ref-376007-S08644284942010103100000) . For DTC B1318, GO to «PINPOINT TEST C»(ref-376007-S17465366932010103100000) . No: GO to D4 .
D4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0155 still present? Yes: GO to D5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D5 CHECK FOR DTC U0155 IN OTHER MODULES NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during PMI or PMI may not have been carried out. Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155/U0155:00 set in other modules? Yes: INSTALL a new IPC . REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-376011) . TEST the system for normal operation. No: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation.

Pinpoint Test D

D5 VCM

D8 DSM

Driver Seat Module (DSM) DTC Chart

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST E .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST E .
B1317	Battery Voltage High	GO to PINPOINT TEST F .
B1318	Battery Voltage Low	GO to PINPOINT TEST G .
B1342	ECU is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DSM . REFER to DRIVER SEAT MODULE (DSM) . TEST the system for normal operation.
U0140	Lost Communication With Body Control Module (GEM)	GO to PINPOINT TEST H .
U0155	Lost Communication With Instrument Panel Cluster (IC) Control Module	GO to PINPOINT TEST I .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

DRIVER SEAT MODULE (DSM) DTC CHART

Condition	Possible Sources	Action
The Driver Seat Module (DSM) Does Not Respond To The Scan Tool	Fuse Wiring, terminals or connectors DSM	REFER to MODULE COMMUNICATIONS NETWORK .

SYMPTOM CHART

PINPOINT TEST E: DTCs B106E, B106F

Note. If DTC B106F is present and the Driver Seat Module (DSM) is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new DSM , resulting in a repeat repair.

E1 REVIEW THE DTCs Review the DTCs from the DSM self-test. Is only DTC B106F present? Yes: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-376007-S02690326302010103100000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTC B106E (DTC B106F may also be present). REFER to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-376007-S17899367672010103100000) . After the repair, GO to E2 .
E2 CARRY OUT THE DSM SELF-TEST Carry out the DSM self-test. Is only DTC B106F present? Yes: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-376007-S02690326302010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits, which is no longer present.

Pinpoint Test F: DTC B1317

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

F1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-375995) to diagnose an overcharging condition. No: GO to F2 .
F2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-375995) to diagnose an overcharging condition. No: GO to F3 .
F3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: DSM Self-Test. Clear the continuous memory DTCs. Carry out the DSM self-test. Is DTC B1317 present? Yes: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-376007-S02690326302010103100000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test G: DTC B1318

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 141

Scheme 141: PINPOINT TEST G: DTC B1318

Scheme 142

Scheme 143

Scheme 144

G1 RECHECK THE DSM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: DSM Self-Test. Clear the DTCs. Repeat the DSM self-test. Is DTC B1318 still present? Yes: GO to G2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
G2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(ref-375995) . No: GO to G3 .
G3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-376024) . Is the battery OK and fully charged? Yes: GO to G4 . No: REFER to «CHARGING SYSTEM»(ref-375995) .
G4 CHECK THE DSM VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: DSM C341a. Disconnect: DSM C341b. Ignition ON. Measure the voltage between the DSM C341a-1, circuit CBX05 (VT/RD), harness side and ground. Measure the voltage between the DSM C341b-1, circuit CBX03 (BU/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to G5 . No: REPAIR the circuit for high resistance. CLEAR the DTC. REPEAT the self-test.
G5 CHECK THE DSM GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the DSM C341a-2, circuit GD906 (BK/GY), harness side and ground. Measure the resistance between the DSM C341b-24, circuit GD905 (BK/GN), harness side and ground. Is the resistance less than 5 ohms? Yes: CONNECT the negative battery cable. GO to G6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
G6 CHECK FOR CORRECT DSM OPERATION Disconnect the DSM connectors. Check for: corrosion damaged pins pushed-out pins Connect the DSM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-376007-S02690326302010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test H: DTC U0140

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

H1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to H2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
H2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes: GO to H3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-376006) .
H3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DSM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST F»(ref-376007-S27683675452010103100000) . For DTC B1318, GO to «PINPOINT TEST G»(ref-376007-S12752438062010103100000) . No: GO to H4 .
H4 RECHECK THE DSM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DSM self-test. Is DTC U0140 still present? Yes: GO to H5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
H5 CHECK FOR DTC U0140 IN OTHER MODULES NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during PMI or the PMI may not have been carried out. Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140:00/U0140 set in other modules? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation. No: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-376007-S02690326302010103100000) . TEST the system for normal operation.

Pinpoint Test I: DTC U0155

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

I1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to I2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
I2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: GO to I3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-376006) .
I3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DSM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST F»(ref-376007-S27683675452010103100000) . For DTC B1318, GO to «PINPOINT TEST G»(ref-376007-S12752438062010103100000) . No: GO to I4 .
I4 RECHECK THE DSM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DSM self-test. Is DTC U0155 still present? Yes: GO to I5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
I5 CHECK FOR DTC U0155 IN OTHER MODULES NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during PMI or the PMI may not have been carried out. Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155/U0155:00 set in other modules? Yes: INSTALL a new IPC . REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-376011) . TEST the system for normal operation. No: INSTALL a new DSM . REFER to «DRIVER SEAT MODULE (DSM)»(ref-376007-S02690326302010103100000) . TEST the system for normal operation.

Pinpoint Test I

I5 VCM

I8 DDM

Driver Door Module (DDM) DTC Chart

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST J .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST J .
B1317	Battery Voltage High	GO to PINPOINT TEST K .
B1318	Battery Voltage Low	GO to PINPOINT TEST L .
B1342	ECU is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DDM . REFER to DRIVER DOOR MODULE (DDM) . TEST the system for normal operation.
U0140	Lost Communication With Body Control Module (GEM)	GO to PINPOINT TEST M .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

DRIVER DOOR MODULE (DDM) DTC CHART

Condition	Possible Sources	Action
The Driver Door Module (DDM) Does Not Respond To The Scan Tool	Fuse Wiring, terminals or connectors DDM	REFER to MODULE COMMUNICATIONS NETWORK .

SYMPTOM CHART

PINPOINT TEST J: DTCs B106E, B106F

Note. If DTC B106F is present and the Driver Door Module (DDM) is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new DDM , resulting in a repeat repair.

J1 REVIEW THE DTCs Review the DTCs from the DDM self-test. Is only DTC B106F present? Yes: INSTALL a new DDM . REFER to «DRIVER DOOR MODULE (DDM)»(ref-376007-S22863592192010103100000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTC B106E (DTC B106F may also be present). REFER to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-376007-S17899367672010103100000) . After the repair, GO to J2 .
J2 CARRY OUT THE DDM SELF-TEST Carry out the DDM self-test. Is only DTC B106F present? Yes: INSTALL a new DDM . REFER to «DRIVER DOOR MODULE (DDM)»(ref-376007-S22863592192010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits, which is no longer present.

Pinpoint Test K: DTC B1317

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

K1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-375995) to diagnose an overcharging condition. No: GO to K2 .
K2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-375995) to diagnose an overcharging condition. No: GO to K3 .
K3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: DDM Self-Test. Clear the continuous memory DTCs. Carry out the DDM self-test. Is DTC B1317 present? Yes: INSTALL a new DDM . REFER to «DRIVER DOOR MODULE (DDM)»(ref-376007-S22863592192010103100000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test L: DTC B1318

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 145

Scheme 145: PINPOINT TEST L: DTC B1318

Scheme 146

L1 RECHECK THE DDM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: DDM Self-Test. Clear the DTCs. Repeat the DDM self-test. Is DTC B1318 still present? Yes: GO to L2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
L2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(ref-375995) . No: GO to L3 .
L3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-376024) . Is the battery OK and fully charged? Yes: GO to L4 . No: REFER to «CHARGING SYSTEM»(ref-375995) .
L4 CHECK THE DDM VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: DDM C501A. Ignition ON. Measure the voltage between the DDM C501A-1, circuit SBP13 (GY/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to L5 . No: REPAIR the circuit for high resistance. CLEAR the DTC. REPEAT the self-test.
L5 CHECK THE DDM GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the DDM C501A-24, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes: CONNECT the negative battery cable. GO to L6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
L6 CHECK FOR CORRECT DDM OPERATION Disconnect the DDM connectors. Check for: corrosion damaged pins pushed-out pins Connect the DDM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new DDM . REFER to «DRIVER DOOR MODULE (DDM)»(ref-376007-S22863592192010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test M: DTC U0140

The Driver Door Module (DDM) and the Smart Junction Box (SJB) communicate using the Medium Speed Controller Area Network (MS-CAN). Messages are exchanged between the modules on the MS-CAN for the purposes of determining what functions are being carried out.

DTC U0140 (Lost Communication With Body Control Module (GEM) - set by the DDM if data messages received from the Smart Junction Box (SJB) over the Medium Speed Controller Area Network (MS-CAN) are missing for 15 seconds or longer.

This pinpoint test is intended to diagnose the following

Module communication
DDM
SJB

M1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to M2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
M2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes: GO to M3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-376006) .
M3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded DDM DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST K»(ref-376007-S30779271432010103100000) . For DTC B1318, GO to «PINPOINT TEST L»(ref-376007-S27385489972010103100000) . No: GO to M4 .
M4 RECHECK THE DDM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the DDM self-test. Is DTC U0140 still present? Yes: GO to M5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
M5 CHECK FOR DTC U0140 IN OTHER MODULES NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during PMI or the PMI may not have been carried out. Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140:00/U0140 set in other modules? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation. No: INSTALL a new DDM . REFER to «DRIVER DOOR MODULE (DDM)»(ref-376007-S22863592192010103100000) . TEST the system for normal operation.

Pinpoint Test M

M5 VCM

M8 RFA

Remote Function Actuator (RFA) Module DTC Chart

Note. This module utilizes a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

DTC	Description	Action
U0140:87	Lost Communication With Body Control Module: Missing Message	GO to PINPOINT TEST O .
U0155:87	Lost Communication With Instrument Panel Cluster (IPC) Control Module: Missing Message	GO to PINPOINT TEST P .
U1000:00	Solid State Driver Protection Active - Driver Disabled: No Sub Type Information	GO to PINPOINT TEST N .
U3000:49	Control Module: Internal Electronic Failure	GO to PINPOINT TEST N .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

REMOTE FUNCTION ACTUATOR (RFA) MODULE DTC CHART

Condition	Possible Sources	Action
The Remote Function Actuator (RFA) Module Does Not Respond To The Scan Tool	Fuse Wiring, terminals or connectors RFA module	REFER to MODULE COMMUNICATIONS NETWORK .

SYMPTOM CHART

PINPOINT TEST N: DTC U1000:00 OR DTC U3000:49

Note. If DTC U3000:49 is present and the Remote Function Actuator (RFA) module is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new RFA module, resulting in a repeat repair.

Note. The ignition must be OFF to carry out the RFA module self-test.

N1 REVIEW THE DTCs Review the DTCs from the RFA module self-test. Is only DTC U3000:49 present? Yes: INSTALL a new RFA module. REFER to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-376007-S37586134802010103100000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTC U1000:00 (DTC U3000:49 may also be present). REFER to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-376007-S17899367672010103100000) . After the repair, GO to N2 .
N2 CARRY OUT THE RFA MODULE SELF-TEST Carry out the RFA module self-test. Is only DTC U3000:49 present? Yes: INSTALL a new RFA module. REFER to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-376007-S37586134802010103100000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits, which is no longer present.

PINPOINT TEST O: DTC U0140:87

Note. The ignition must be OFF to carry out the RFA module self-test.

O1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to O2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
O2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes: GO to O3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-376006) .
O3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:62 recorded? Yes: REFER to «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-376012) . No: GO to O4 .
O4 RECHECK THE RFA MODULE DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0140:87 still present? Yes: GO to O5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
O5 CHECK FOR DTC U0140:87 IN OTHER MODULES NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during PMI or the PMI may not have been carried out. Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140:00/U0140 set in other modules? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-376007-S00326653172010103100000) . TEST the system for normal operation. No: INSTALL a new RFA module. REFER to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-376007-S37586134802010103100000) . RESET the parameters in both the RFA module and the PCM. REFER to Passive Anti-Theft System (PATS) Parameter Reset - Intelligent Access (IA) in «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-376012) . TEST the system for normal operation.

PINPOINT TEST P: DTC U0155:87

Note. The ignition must be OFF to carry out the RFA module self-test.

P1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to P2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
P2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: GO to P3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-376006) .
P3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:62 recorded? Yes: REFER to «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-376012) . No: GO to P4 .
P4 RECHECK THE RFA MODULE DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0155:87 still present? Yes: GO to P5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
P5 CHECK FOR DTC U0155:87 IN OTHER MODULES NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during PMI or the PMI may not have been carried out. Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155/U0155:00 set in other modules? Yes: INSTALL a new IPC . REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-376011) . TEST the system for normal operation. No: INSTALL a new RFA module. REFER to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-376007-S37586134802010103100000) . RESET the parameters in both the RFA module and the PCM. REFER to Passive Anti-Theft System (PATS) Parameter Reset - Intelligent Access (IA) in «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-376012) . TEST the system for normal operation.

Scheme 147

Scheme 147: Smart Junction Box (SJB)

Item	Part Number	Description
1		Smart Junction Box (SJB) electrical connectors (part of 14401)
2		SJB electrical connectors (part of 14290)
3		SJB electrical connectors (part of 14A005)
4		Harness pushpins (2 required)
5		SJB release tab
6	15604	SJB

ITEM DESCRIPTION CHART

Multifunction Electronic Modules: Diagnosis Lincoln MKS I

Diagnostic Trouble Code (DTC) Chart

Inspection and Verification

Smart Junction Box (SJB) DTC Chart

Symptom Chart

PINPOINT TEST A: DTCs B106E, B106F

Pinpoint Test B: DTC B1317

Pinpoint Test C: DTC B1318

Scheme 139

Scheme 140

Pinpoint Test D: DTC U0155

Pinpoint Test D

Driver Seat Module (DSM) DTC Chart

PINPOINT TEST E: DTCs B106E, B106F

Pinpoint Test F: DTC B1317

Pinpoint Test G: DTC B1318

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Pinpoint Test H: DTC U0140

Pinpoint Test I: DTC U0155

Pinpoint Test I

Driver Door Module (DDM) DTC Chart

PINPOINT TEST J: DTCs B106E, B106F

Pinpoint Test K: DTC B1317

Pinpoint Test L: DTC B1318

Scheme 145

Scheme 146

Pinpoint Test M: DTC U0140

Pinpoint Test M

Remote Function Actuator (RFA) Module DTC Chart

PINPOINT TEST N: DTC U1000:00 OR DTC U3000:49

PINPOINT TEST O: DTC U0140:87

PINPOINT TEST P: DTC U0155:87

Scheme 147

More articles — Multifunction Electronic Modules

Login / Signup

Enter the code

You have successfully logged in!
