Automatic Transmission - Automatic Transaxle/transmission - External Controls: Wiring Lincoln MKS I

Automatic Trans 2 illustrations

Steering Wheel Wiring Harness Paddle Shifter Circuits

Note. Both RH and LH paddle shifter connectors are the same and share the same circuits.

Scheme 36: Steering Wheel Wiring Harness Paddle Shifter Circuits

Paddle Shifter Connector Pin Number	Steering Wheel C218B Pin Number	Circuit Function (Color)
1	6	Upshift signal (VT/OG)
2	2	Ground supplied from PCM (GY)
3	12	Downshift signal (YE/RD)

CIRCUIT FUNCTION CHART

Scheme 37: Clockspring Internal Paddle Shifter Circuits

Clockspring Pin Number C218B End Component Side	Clockspring Pin Number C218A End Component Side	Circuit Function
6	3	Upshift signal
2	7	Ground supplied from PCM
12	11	Downshift signal

CIRCUIT FUNCTION CHART
