Automatic Transmission - Automatic Transaxle/transmission - External Controls: Removal & Installation Lincoln MKS I

Automatic Trans 22 illustrations ~744 words

Installation

Pinpoint Test B

B16 ACL

Scheme 14

Scheme 14: Selector Lever - Paddle Shift
ItemPart NumberDescription
1Paddle shifter cover (part of 3F884 RH or 3F885 LH)
21007728Paddle shifter screws (2 required per shifter)
31015006Back steering wheel trim cover
41015100Paddle shifter electrical connector
53F884RH paddle shifter
53F885LH paddle shifter

PART DESCRIPTION CHART

Removal

Note. This procedure shows removal and installation of the LH paddle shifter. Removal and installation of the RH paddle shifter is similar.

Scheme 15

Scheme 15: Removal

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19
  1. Turn the steering wheel far enough to access the inner paddle shifter screw. Turn the steering wheel clockwise if removing the LH paddle shifter. Turn the steering wheel counterclockwise if removing the RH paddle shifter.
  2. Using a suitable tool, gently pry the bottom of the paddle shifter cover up and remove the paddle shifter cover.
  3. Remove the 2 paddle shifter screws.
  4. Using a suitable nylon trim tool, gently pry the corner of the back steering wheel trim cover loose from the steering wheel. Position aside the back steering wheel trim cover and remove the paddle shifter from the steering wheel.
  5. Disconnect the electrical connector and remove the paddle shifter.

Scheme 20

Scheme 20

Scheme 21

Scheme 21
  1. Connect the paddle shifter electrical connector.
  2. Install the paddle shifter on the steering wheel and position the corner of the back steering wheel trim cover back in place.
  3. Install the 2 paddle shifter screws.
  4. Install the paddle shifter cover.

Scheme 22

Scheme 22: Selector Lever
ItemPart NumberDescription
154061A16Center console side trim panels
25404569Cup holder lid trim panel
3W707628-S424Cup holder retaining screws
45406010Cup holder
55413560Cup holder illumination electrical connector
67L010Selector lever knob
7W790088-S901Selector lever knob screws (2 required)
854045A76Selector lever bezel
914489PRNDL illumination electrical connector
1014489Power outlet electrical connector
1114489Auto PARK button electrical connector
1214489Storage compartment illumination electrical connector
137E395Selector lever cable
1414489Selector lever electrical connector
15W503926-S424Selector lever bolts (4 required)
167210Selector lever

PART DESCRIPTION CHART

Scheme 23

Scheme 23

Scheme 24

Scheme 24
  1. Remove the selector lever knob and bezel. For additional information, refer to «SELECTOR LEVER BEZEL»(ref-376034-S18051176402010103100000) and «SELECTOR LEVER KNOB»(ref-376034-S14407159522010103100000) .
  2. Disconnect the selector lever cable end from the selector lever.
  3. Depress the 2 tabs and remove the selector lever cable from the selector lever.
  4. Disconnect the electrical connector.
  5. Remove the 4 selector lever bolts and the selector lever from the vehicle.
  1. Install the selector lever and the 4 selector lever bolts. Tighten to 10 Nm (89 lb-in).
  2. Connect the electrical connector.
  3. Install the selector lever cable on the selector lever cable retainer. Be sure the tabs are locked in place.
  4. Connect the selector lever cable end to the selector lever.
  5. Install the selector lever bezel and knob. For additional information, refer to «SELECTOR LEVER BEZEL»(ref-376034-S18051176402010103100000) and «SELECTOR LEVER KNOB»(ref-376034-S14407159522010103100000) .
  6. Check the selector lever cable adjustment. Make sure that the vehicle starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE. If an adjustment is necessary, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-376034-S05466088092010103100000) .

Scheme 25

Scheme 25: Selector Lever Knob
ItemPart NumberDescription
17E026Lower selector lever knob bezel
2W790088-S901Selector lever knob screw
37L010Selector lever knob

PART DESCRIPTION CHART

Scheme 26

Scheme 26: Removal

Scheme 27

Scheme 27
  1. Using 2 flat-head screwdrivers, gently pry the lower selector lever knob bezel at the front and back of the selector lever knob out to release it from the retaining tabs and slide the lower selector lever knob bezel downward.
  2. Remove the 2 screws and remove the selector lever knob.

Scheme 28

Scheme 28
  1. Position the selector lever knob on the selector lever and install the 2 screws.
  2. Slide the lower selector lever bezel up and snap into place.

Scheme 29

Scheme 29: Selector Lever Bezel
ItemPart NumberDescription
154061A16Center console side trim panels
25404569Cup holder lid trim panel
3W707628-S424Cup holder retaining screws
45406010Cup holder
55413560Cup holder illumination electrical connector
67L010Selector lever knob
7W790088-S901Selector lever knob screws (2 required)
854045A76Selector lever bezel
914489PRNDL illumination electrical connector
1014489Power outlet electrical connector
1114489Auto PARK button electrical connector
1214489Storage compartment illumination electrical connector
137B118Selector lever boot
1454045A76Selector lever bezel trim ring

PART DESCRIPTION CHART

Scheme 30

Scheme 30: Removal

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34
  1. Remove the selector lever knob. For additional information, refer to «SELECTOR LEVER KNOB»(ref-376034-S14407159522010103100000) .
  2. Remove the center console trim.
  3. Remove the cup holder lid trim panel.
  4. Remove the cup holder retaining screws and position the cupholder out of the center console to access the electrical connector.
  5. Disconnect the cupholder electrical connector and remove the cupholder.
  6. Place the selector lever in M. Slide the selector lever bezel back and lift to access the electrical connectors.
  7. Disconnect the 4 electrical connectors and remove the selector lever bezel from the center console.
  8. Release the 7 tabs and remove the selector lever boot from the selector lever bezel.
  9. Release the 6 tabs and remove the selector lever boot bezel from the selector lever bezel.

Scheme 35

Scheme 35
  1. Install the selector lever boot bezel in the selector lever bezel. Check to make sure the 6 tabs are correctly installed.
  2. Install the selector lever boot in the selector lever bezel. Check to make sure the 7 tabs are correctly installed.
  3. Connect the 4 electrical connectors and position the selector lever bezel over the selector lever, on the center console.
  4. Push forward on the selector lever bezel and install it in the center console.
  5. Connect the cupholder electrical connector and position the cupholder in place.
  6. Position the cup holder in place and install the 4 screws.
  7. Position the cup holder trim cover in place and install.
  8. Position the center counsel trim in place and install.
  9. Install the selector lever knob. For additional information, refer to «SELECTOR LEVER KNOB»(ref-376034-S14407159522010103100000) .
