Interior Trim: Other Lincoln LS I рестайлинг

Console

The floor console houses the electronic parking brake, traction/advance trac switch, auxiliary power point, two cup holders and extra storage space in the rear of the passenger compartment. The overhead console incorporates two interior lights with switches, roof opening panel switch and the parking aid switch.

Roof Opening Panel

The roof opening panel is an electronically operated panel that can be opened, closed or vented (tilted) by the roof opening panel switch. The switch has two detents for opening, two detents for closing and a center position for venting operations. Manual open and close are provided by the motor as long as the switch is held in the first detent. Express open or express close will occur if the switch is moved to the second detent, at which time it may be released. Proportional tilt-up occurs when the vent/tilt switch is pressed while the roof opening panel is in the fully closed or tilt range. Proportional tilt-up stops when the vent/tilt switch is released. One-touch tilt occurs when the vent/tilt switch is pressed and released while the moonroof is in fully open or slide. When commanded, the roof opening panel will express close then move to the full vent position.

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Scheme 4

Possible Causes

1. roof opening panel adjustment
2. roof opening panel seal

1. roof opening panel adjustments
2. roof opening panel drain hoses
3. roof opening panel seal
4. roof opening panel
5. roof opening panel assembly

1. roof opening panel operation
2. roof opening panel tracks
3. roof opening panel water trough
4. roof opening panel lifter assemblies
5. headliner
6. roof opening panel motor pad

1. roof opening panel
2. roof opening panel lifter assemblies
3. roof opening panel adjustment
4. roof opening panel motor

1. circuit 9-AG7 (BN/RD) shorted to ground or open
2. circuit 30-AG12 (RD/GN) open
3. circuit 31-AG12 (BK/GN) open
4. circuit 10-AJ43B (GY/VT) open
5. roof opening panel lifter assemblies
6. roof opening panel adjustment
7. roof opening panel motor
8. roof opening panel control switch
9. rear battery junction box (BJB) fuse 16 (20A) open

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. E1 VERIFY POWER WINDOWS ARE OPERATIONAL Operate the power windows. Do the power windows operate? Yes : GO to E2. No : REFER to «EXTERIOR TRIM»(ref-207571) to diagnose the inoperative windows.
2. E2 VERIFY THE ROOF OPENING PANEL ADJUSTMENT Verify the roof opening panel is adjusted correctly. Is the roof opening panel adjusted correctly? Yes : GO to E3. No : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(ref-207570-S12476489112005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
3. E3 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES FOR OBSTRUCTIONS AND DAMAGE Check the roof opening panel lifter assemblies for obstructions and damage. Are the roof opening panel lifter assemblies OK? Yes : GO to E4. No : REMOVE all obstructions and REPAIR any damage. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
4. E4 CHECK CIRCUIT 30-AG12 (RD/GN) FOR VOLTAGE Disconnect: Roof Opening Panel Motor C920. Measure the voltage between the roof opening panel motor C920-1, circuit 30-AG12 (RD/GN), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to E5. No : REPAIR the circuit. TEST the system for normal operation.
5. E5 CHECK CIRCUIT 31-AG12 (BK/GN) FOR AN OPEN Measure the resistance between the roof opening panel motor C920-10, circuit 31-AG12 (BK/GN), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to E6. No : REPAIR the circuit. TEST the system for normal operation.
6. E6 CHECK THE ROOF OPENING PANEL CONTROL SWITCH Disconnect: Roof Opening Panel Control Switch C912. Carry out the roof opening panel control switch component test. Refer to «COMPONENT TEST»(ref-207570-S36939268382005113000000) . Is the roof opening panel control switch OK? Yes : GO to E7. No : INSTALL a new roof opening panel control switch. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
7. E7 CHECK CIRCUIT 9-AG7 (BN/RD) FOR A SHORT TO GROUND OR AN OPEN Measure the resistance between the roof opening panel motor C920-7, circuit 9-AG7 (BN/RD), harness side and ground; and between the roof opening panel motor C920-7, circuit 9-AG7 (BN/RD), harness side and the roof opening panel control switch C912-3, circuit 9-AG7 (BN/RD), harness side. Is the resistance greater than 10,000 ohms between the roof opening panel motor and ground and less than 5 ohms between the roof opening panel control switch and the roof opening panel motor? Yes : GO to E8. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
8. E8 CHECK CIRCUIT 10-AJ43B (GY/VT) FOR AN OPEN Disconnect: DDM C501d. Measure the resistance between the roof opening panel motor C920-3, circuit 10-AJ43B (GY/VT), harness side and the DDM C501d-1, circuit 10-AJ43B (GY/VT), harness side. Is the resistance less than 5 ohms? Yes : INSTALL a new roof opening panel motor. REFER to «ROOF OPENING PANEL»(ref-207570-S40093324652005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.

1. circuit 32-AG10 (WH/BU) shorted to ground or open
2. circuit 33-AG10 (YE/BU) shorted to ground or open
3. roof opening panel lifter assemblies
4. roof opening panel adjustment
5. roof opening panel motor
6. roof opening panel control switch

Scheme 9

Scheme 10

1. F1 VERIFY THE ROOF OPENING PANEL ADJUSTMENT Verify the roof opening panel is adjusted correctly. Is the roof opening panel adjusted correctly? Yes : GO to F2. No : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(ref-207570-S12476489112005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
2. F2 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES FOR OBSTRUCTIONS AND DAMAGE Check the roof opening panel lifter assemblies for obstructions and damage. Are the roof opening panel lifter assemblies OK? Yes : GO to F3. No : REMOVE all obstructions and REPAIR any damage. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
3. F3 CHECK THE ROOF OPENING PANEL CONTROL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Control Switch C912. Carry out the roof opening panel control switch component test. REFER to «COMPONENT TEST»(ref-207570-S36939268382005113000000) . Is the roof opening panel control switch OK? Yes : If the open function is inoperative, GO to F4. If the close function is inoperative, GO to F5 . No : INSTALL a new roof opening panel control switch. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
4. F4 CHECK CIRCUIT 32-AG10 (WH/BU) FOR A SHORT TO GROUND OR AN OPEN Disconnect: Roof Opening Panel Motor C920. Measure the resistance between the roof opening panel motor C920-9, circuit 32-AG10 (WH/BU), harness side and ground; and between the roof opening panel motor C920-9, circuit 32-AG10 (WH/BU), harness side and the roof opening panel control switch C912-2, circuit 32-AG10 (WH/BU), harness side. Is the resistance greater than 10,000 ohms between the roof opening panel motor and ground and less than 5 ohms between the roof opening panel control switch and the roof opening panel motor? Yes : INSTALL a new roof opening panel motor. Refer to «ROOF OPENING PANEL»(ref-207570-S40093324652005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
5. F5 CHECK CIRCUIT 33-AG10 (YE/BU) FOR A SHORT TO GROUND AN OPEN Disconnect: Roof Opening Panel Motor C920. Measure the resistance between the roof opening panel motor C920-8, circuit 33-AG10 (YE/BU), harness side and ground; and between the roof opening panel motor C920-8, circuit 33-AG10 (YE/BU), harness side and the roof opening panel control switch C912-5, circuit 33-AG10 (YE/BU), harness side. Is the resistance greater than 10,000 ohms between the roof opening panel motor and ground and less than 5 ohms between the roof opening panel control switch and the roof opening panel motor? Yes : INSTALL a new roof opening panel motor. Refer to «ROOF OPENING PANEL»(ref-207570-S40093324652005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.

1. circuit 32-AG12 (WH/GN) shorted to ground or open
2. circuit 33-AG10 (YE/BU) shorted to ground or open
3. roof opening panel lifter assemblies
4. roof opening panel adjustment
5. roof opening panel motor
6. roof opening panel control switch

Scheme 11

Scheme 12

1. G1 VERIFY THE ROOF OPENING PANEL ADJUSTMENT Verify the roof opening panel is adjusted correctly. Is the roof opening panel adjusted correctly? Yes : GO to G2. No : ADJUST the roof opening panel. REFER to «ROOF OPENING PANEL ALIGNMENT»(ref-207570-S12476489112005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
2. G2 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES FOR OBSTRUCTIONS AND DAMAGE Check the roof opening panel lifter assemblies for obstructions and damage. Are the roof opening panel lifter assemblies OK? Yes : GO to G3. No : REMOVE all obstructions and REPAIR any damage. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
3. G3 CHECK THE ROOF OPENING PANEL CONTROL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Control Switch C912. Carry out the roof opening panel control switch component test. REFER to «COMPONENT TEST»(ref-207570-S36939268382005113000000) . Is the roof opening panel control switch OK? Yes : GO to G4. No : INSTALL a new roof opening panel control switch. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
4. G4 CHECK CIRCUIT 32-AG12 (WH/GN) FOR A SHORT TO GROUND OR AN OPEN Disconnect: Roof Opening Panel Motor C920. Measure the resistance between the roof opening panel motor C920-4, circuit 32-AG12 (WH/GN), harness side and ground; and between the roof opening panel motor C920-4, circuit 32-AG12 (WH/GN), harness side and the roof opening panel control switch C912-4, circuit 32-AG12 (WH/GN), harness side. Is the resistance greater than 10,000 ohms between the roof opening panel motor and ground and less than 5 ohms between the roof opening panel control switch and the roof opening panel motor? Yes : GO to G5. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.
5. G5 CHECK CIRCUIT 33-AG10 (YE/BU) FOR A SHORT TO GROUND OR AN OPEN Measure the resistance between the roof opening panel motor C920-8, circuit 33-AG10 (YE/BU), harness side and ground; and between the roof opening panel motor C920-8, circuit 33-AG10 (YE/BU), harness side and the roof opening panel control switch C912-5, circuit 33-AG10 (YE/BU), harness side. Is the resistance greater than 10,000 ohms between the roof opening panel motor and ground and less than 5 ohms between the roof opening panel motor and the roof opening panel control switch? Yes : INSTALL a new roof opening panel motor. Refer to «ROOF OPENING PANEL»(ref-207570-S40093324652005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.

1. circuit 8-AJ43 (WH/BU) open
2. roof opening panel motor
3. driver door module (DDM)

Scheme 13

1. H1 VERIFY POWER WINDOWS ARE OPERATIONAL Operate the power windows, using the global open/close procedure. Do the power windows operate correctly? Yes : GO to H2. No : REFER to «EXTERIOR TRIM»(ref-207571) to diagnose the inoperative windows.
2. H2 CHECK CIRCUIT 8-AJ43 (WH/BU) FOR AN OPEN Disconnect: Roof Opening Panel Motor C920. Disconnect: DDM C501d. Measure the resistance between the roof opening panel motor C920-6, circuit 8-AJ43B (WH/BU), harness side and the DDM C501d-26, circuit 8-AJ43 (WH/BU), harness side. Is the resistance less than 5 ohms? Yes : INSTALL a new roof opening panel motor. Refer to «ROOF OPENING PANEL»(ref-207570-S40093324652005113000000) . REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation. No : REPAIR the circuit. REINITIALIZE the roof opening panel. REFER to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) . TEST the system for normal operation.

1. roof opening panel control switch
2. roof opening panel motor

Roof Opening Panel Control Switch

1. Measure the resistance between the following roof opening panel control switch C912 pins (component side) as follows: COMPONENT TEST Switch Position Pin Resistance Value Off Between All Pins Greater than 10,000 ohms Tilt Up 3 and 4 Less than 5 ohms Open 2 and 3 Less than 5 ohms One Touch Open 2, 3 and 4 Less than 5 ohms Close/Tilt Down 3 and 5 Less than 5 ohms One Touch Close 2, 3 and 5 Less than 5 ohms

Roof Opening Panel Motor Initialization

Note. This procedure must be carried out when repairs (including lubrication) are performed on any part of the roof opening panel system.

Vehicles with existing roof opening panel and the glass in the slide range fore/aft

Scheme 14

1. Cycle the roof opening panel glass through the fully-open to the fully-closed position.
2. Loosen the 4 roof opening panel glass screws.
3. Adjust the roof opening panel glass to specification.
4. Tighten the 4 roof opening panel glass screws. Tighten to 4 N.m (35 lb-in).
5. Initialize the roof opening panel motor. For additional information, refer to «ROOF OPENING PANEL MOTOR INITIALIZATION»(ref-207570-S39240458662005113000000) .

Scheme 15

Scheme 16

1. To remove individual components only, carry out the listed steps. COMPONENT STEPS Component Steps Windshield side garnish mouldings 1 A-pillar lower trim panel 2-4 Upper B-pillar trim panel 9-12 Lower B-pillar trim panel 9-13 Quarter trim panel 6, 7 Front door scuff plate 2 Rear door scuff plate 5 Package tray 6, 7, 14-16
2. Remove the components in the order indicated in the following illustration and table.
3. To install, reverse the removal procedure.

Item 3: Front Door Weatherstrip Removal Note

1. Position the weatherstrip aside.

Item 6: Rear Safety Belt Anchor Bolt Removal Note

Scheme 17

1. Remove the seat bolster. Refer to «SEATING»(ref-207572) for additional information.
2. Using the special tool, remove the rear safety belt anchor bolt.

Item 8: Rear Door Weatherstrip Removal Note

1. Position the weatherstrip aside.

Item 12: Upper B-pillar Trim Panel Removal Note

1. If the supplemental restraint system (side air curtains) has deployed, check the upper B-pillar trim panel for damage.

Item 13: Lower B-pillar Trim Panel Removal Note

1. If the supplemental restraint system (side air curtains) has deployed, check the lower B-pillar trim panel for damage.

Scheme 18

1. Disconnect the battery.
2. To remove individual components only, carry out the listed steps. COMPONENT STEPS Component Steps Door trim panel 1-7 Garnish molding 1-8 Speaker cover 1-9 Applique 1-11
3. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Item 1: Window Regulator Control Switch Panel Removal Note

1. Disconnect the electrical connectors.

Item 2: Screw Cover Removal Note

1. From the top of the cover on center, use a suitable tool, insert 2-3 mm and rotate to disengage the snap feature.

Item 7: Front Door Trim Panel Removal Note

1. Disconnect the door lock control switch electrical connector.
2. If equipped, disconnect the driver seat memory switch electrical connector.

Scheme 19

1. Disconnect the battery.
2. To remove individual components only, carry out the listed steps. COMPONENT STEPS Component Steps Door trim panel 1-7 Garnish molding 1-8 Speaker cover 1-7, 9 Applique 1-7, 10, 11
3. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Item 1: Window Regulator Control Switch Panel Removal Note

1. Disconnect the electrical connectors.

Item 2: Screw Cover Removal Note

1. From the top of the cover on center, use a suitable tool, insert 2-3 mm and rotate to disengage the snap feature.

Material

MATERIAL

Item 3: Overhead Console Removal Note

1. Disconnect the electrical connectors.

Item 7: Sun Visor Removal Note

1. Disconnect the electrical connectors.

Item 10: Passenger Assist Handle Removal Note

1. If required, disconnect the electrical connector(s).

Item 12: Headliner Removal Note

1. For vehicles without a roof opening panel, use a plastic scraper to detach the headliner from the roof.

Item 12: Headliner Installation Note

1. Carefully position the headliner in the vehicle.
2. Apply headliner adhesive in a triangular pattern to the center of the headliner.

Scheme 20

1. If removing the roof opening panel assembly, remove the headliner. For additional information, refer to «HEADLINER»(ref-207570-S08188942882005113000000) .
2. If removing the roof opening panel wiring harness or the roof opening panel motor and module, remove the overhead console. For additional information, refer to «HEADLINER»(ref-207570-S08188942882005113000000) .
3. To remove individual components, only carry out the listed steps. COMPONENT STEPS Component Steps Roof opening panel assembly 1-4 Roof opening panel glass 5, 6 Roof opening panel wiring harness 9 Roof opening panel motor and module 7-9
4. Remove the components in the order indicated in the following illustration and table.
5. To install, reverse the removal procedure.

Item 3: Roof Opening Panel Bolts Removal Note

1. An assistant is required to carry out this procedure.

Item 5: Roof Opening Panel Glass Screws Removal Note

1. Move the roof opening panel to the vent position to access the screws.

Instrument Panel

Scheme 21

Scheme 22

Scheme 23

1. If removing the instrument panel, depower the supplemental restraint system (SRS). For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in «AIR BAG RESTRAINT SYSTEMS»(ref-170294) .
2. Remove the front floor console. For additional information, refer to «FLOOR CONSOLE»(ref-207570-S13363953282005113000000) .
3. Remove the transmission range selector lever. For additional information, refer to «AUTOMATIC TRANSMISSION - 5R55S»(ref-207557) .
4. If removing the instrument panel, remove the LH and RH A-pillar lower trim panels. For additional information, refer to «INTERIOR TRIM PANELS»(ref-207570-S03149979552005113000000) .
5. If removing the instrument panel, remove the LH and RH windshield side garnish mouldings. For additional information, refer to «INTERIOR TRIM PANELS»(ref-207570-S03149979552005113000000) .
6. To remove individual components only, carry out the following steps. COMPONENT STEPS Component Steps Glove Compartment 1-9 Instrument panel reinforcement panel cover panel 14-15 Instrument panel reinforcement panel 12-18 Instrument panel cluster finish panel 14-15, 23-26 Instrument panel 10-21, 27-38
7. View 1 of 3. Remove the components in the order indicated in the following illustration and table.
8. View 2 of 3. Remove the components in the order indicated in the following illustration and table.
9. View 3 of 3. Remove the components in the order indicated in the following illustration and table.
10. To install, reverse the removal procedure.

Item 1: Instrument Panel Trim Panel Removal Note

Scheme 24

1. If equipped, remove the instrument panel trim panel nut.

Item 3: Assist Arm Removal Note

1. Lift up on the arms when lowering the glove compartment door.

Item 6: Glove Compartment Bin Removal Note

1. Disconnect the electrical connector.

Item 20: Intermediate Shaft Removal Note

1. Separate the intermediate shaft from the steering column.

Item 27: Defroster Grille Removal Note

1. Disconnect the electrical connector.

Item 38: Instrument Panel Removal Note

1. An assistant is required to carry out this procedure.

Scheme 25

1. Position the seats as needed to remove the console.
2. Disconnect the battery.
3. To remove individual components only, carry out the following steps. COMPONENT STEPS Component Steps Floor console 1-7 Console arm rest 1 Storage bin 1, 2 Finish panel (front) 3 Finish panel (center) 1, 2, 4 Cup holder 1-6 Floor console 1-3, 7-10
4. Remove the components in the order indicated in the following illustration and table.
5. To install, reverse the removal procedure.

Item 1: Armrest Removal Note

Scheme 26

1. Remove the armrest hinge screws.
2. Remove the screw.
3. Remove the rivet.

Item 2: Console Storage Bin Removal Note

1. Pull upward to release the retainers.
2. Disconnect the electrical connectors.

Item 3: Lower Instrument Panel Finish Panel Removal Note

1. Pull upward from the front of the trim panel to release the retainers.
2. Disconnect the electrical connectors.

Item 6: Cup Holder Removal Note

1. Disconnect the electrical connectors.

Item 10: Floor Console Assembly Removal Note

1. Disconnect the electrical connectors.
2. Lift the console from the rear and slide it rearward to release the rear seat heater ducts from the instrument panel.

Scheme 27

1. Remove the roof opening panel. Refer to «ROOF OPENING PANEL»(ref-207570-S40093324652005113000000) for additional information.
2. To disassemble individual components only, carry out the following steps. COMPONENT STEPS Component Steps Roof opening panel shield 1-6 Roof opening panel 3, 4 Roof opening panel trough 3-5 Lifting arm 1-11
3. Disassemble the components in the order indicated in the following illustration and table.
4. To assemble, reverse the disassembly procedure.

Item 5: Roof Opening Panel Trough Disassembly Note

1. Unsnap the trough arms.
2. Rotate the trough 90° and lift it from its guide.

Item 3: Roof Opening Panel Screws Assembly Note

1. The glass panel will be adjusted during the roof opening panel installation. Do not tighten the screws to allow for movement of the glass panel during the adjustment procedure. After the adjustment procedure has been completed, tighten the screws to the specification provided
