Module Communications Network: Diagnosis — Lincoln LS I рестайлинг (2003-2006)

Inspection and Verification

Visually inspect for obvious signs of electrical damage. Refer to the following chart: Visual Inspection Chart VISUAL INSPECTION Electrical Wiring harness Connectors

Diagnostic Trouble Code (DTC) Chart

DTC	Description	Source	Action
B1201	Fuel Sender Circuit Failure	REM	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1202	Fuel Sender Circuit Open	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1204	Fuel Sender Circuit Short to Ground	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1205	EICSwitch-1 Assembly Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1205	EICSwitch-1 Assembly Circuit Failure	Message Center	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1209	EIC Switch-2 Assembly Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1213	Anti-Theft Number of Programmed Keys is Below Minimum	Instrument Cluster	REFER to ANTI-THEFT .
B1231	Longitudinal Acceleration Threshold Exceeded	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1242	Air Flow Recirculation Door Driver Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1246	Dim Panel Potentiometer Switch Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1251	Air Temperature Internal Sensor Circuit Open	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1253	Air Temperature Internal Sensor Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1255	Air Temperature External Sensor Circuit Open	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1257	Air Temperature External Sensor Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1262	Servo Motor Defrost Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1263	Servo Motor Vent Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1264	Servo Motor Floor Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1265	Servo Motor Cold Air Bypass Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1299	Power Supply Sensor Circuit Short to Ground	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1300	Power Door Lock Circuit Failure	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1309	Power Door Lock Circuit Short to Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1310	Power Door Unlock Switch Circuit Failure	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1317	Battery Voltage High	Instrument Cluster	REFER to GENERATORS & REGULATORS .
B1317	Battery Voltage High	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1317	Battery Voltage High	Electronic Parking Brake Module	REFER to GENERATORS & REGULATORS .
B1318	Battery Voltage Low	Instrument Cluster	REFER to GENERATORS & REGULATORS .
B1318	Battery Voltage Low	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1318	Battery Voltage Low	Electronic Parking Brake Module	REFER to GENERATORS & REGULATORS .
B1319	Driver Door Ajar Circuit Failure	FEM	REFER to Section INTERIOR LIGHTING - LS .
B1327	Passenger Door Ajar Circuit Failure	FEM	REFER to Section INTERIOR LIGHTING - LS .
B1331	Decklid Ajar Rear Door Circuit Failure	REM	REFER to Section INTERIOR LIGHTING - LS .
B1341	Power Door Unlock Circuit Short to Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1342	ECU is Defective	Parking Aid Module	CLEAR the DTC. REPEAT the parking aid module self-test. If DTC B1342 is retrieved again, INSTALL a new parking aid module. REFER to INFORMATION, GAUGES & WARNING DEVICES . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	FEM	CLEAR the DTC. REPEAT the FEM self-test. If DTC B1342 is retrieved again, INSTALL a new FEM. REFER to FRONT ELECTRONIC MODULE (FEM) . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	DATC	CLEAR the DTC. REPEAT the DATC module self-test. If DTC B1342 is retrieved again, INSTALL a new DATC module. REFER to CLIMATE CONTROL SYSTEM . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	Climate Control Seat Module	CLEAR the DTC. REPEAT the climate control seat module self-test. If DTC B1342 is retrieved again, INSTALL a new climate control seat module. REFER to SEATING . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	Instrument Cluster	CLEAR the DTC. REPEAT the instrument cluster self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to INFORMATION, GAUGES & WARNING DEVICES . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	DSM	REPEAT the DSM self-test. If DTC B1342 is retrieved again, INSTALL a new DSM. REFER to DRIVER SEAT MODULE (DSM) . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	DDM	CLEAR the DTC. REPEAT the DDM self-test. If DTC B1342 is retrieved again, INSTALL a new DDM. REFER to DRIVER DOOR MODULE (DDM) . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	REM	CLEAR the DTC. REPEAT the REM self-test. If DTC B1342 is retrieved again, INSTALL a new REM. REFER to REAR ELECTRONIC MODULE (REM) . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	RCM.	CLEAR the DTC. REPEAT the RCM self-test. If DTC B1342 is retrieved again, INSTALL a new RCM REFER to AIR BAG RESTRAINT SYSTEMS . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	ABS/TC Module or Stability Assist Module	CLEAR the DTC. REPEAT the ABS/TC module self-test. If DTC B1342 is retrieved again, INSTALL a new ABS/TC module. REFER to ANTI-LOCK CONTROL . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU Defective	Message Center	NOTE: The message center is part of the instrument cluster. CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to INFORMATION, GAUGES & WARNING DEVICES . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	Navigation System Module	CLEAR the DTCs. RETRIEVE the DTCs. If DTC B1342 is retrieved again, INSTALL a new navigation system module. REFER to ELECTRONIC FEATURE . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	ACM	CLEAR the DTCs. CARRY OUT the ACM On-Demand Self-Test. REMOVE the ACM, REFER to ENTERTAINMENT SYSTEM - LS and SEND it to an authorized Ford audio system repair facility if DTC B1342 is retrieved again. TEST the system for normal operation.
B1342	ECU is Defective	Electronic Parking Brake Module	CLEAR the DTCs. RETRIEVE the DTCs. If DTC B1342 is retrieved again, INSTALL a new electronic parking brake module. REFER to BRAKE SYSTEM . CLEAR the DTCs REPEAT the self-test.
B1352	Ignition Key-in Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1358	Ignition Switch or Blower Electronics Circuit Short to Ground	Climate Control Seat Module	REFER to SEATING .
B1416	Power Window LR Motor Circuit Short to Battery	DDM	REFER to EXTERIOR TRIM .
B1424	Power Window RR Switch Circuit Short to Battery	DDM	REFER to EXTERIOR TRIM .
B1470	Lamp Headlamp Input Circuit Failure	Instrument Cluster	REFER to EXTERIOR LIGHTING - LS .
B1479	Low Washer Fluid Level Switch Circuit Failure	FEM	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1483	Brake Pedal Input Circuit Failure	REM	REFER to ANTI-LOCK CONTROL .
B1483	Brake Pedal Input Circuit Failure	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B1485	Brake Pedal Input Circuit Battery Short	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B1499	Lamp Turn Signal Left Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - LS .
B1499	Lamp Turn Signal Left Circuit Failure	REM	REFER to EXTERIOR LIGHTING - LS .
B1501	Lamp Turn Signal Left Circuit Short to Battery	FEM	REFER to EXTERIOR LIGHTING - LS .
B1501	Lamp Turn Signal Left Circuit Short to Battery	REM	REFER to EXTERIOR LIGHTING - LS .
B1503	Lamp Turn Signal Right Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - LS .
B1503	Lamp Turn Signal Right Circuit Failure	REM	REFER to EXTERIOR LIGHTING - LS .
B1505	Lamp Turn Signal Right Circuit Short to Battery	FEM	REFER to EXTERIOR LIGHTING - LS .
B1505	Lamp Turn Signal Right Circuit Short to Battery	REM	REFER to EXTERIOR LIGHTING - LS .
B1519	Hood Switch Circuit Failure	FEM	REFER to ANTI-THEFT .
B1526	Keyless Entry Circuit Short to Ground	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1530	Memory Set Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1534	Memory 1 Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1538	Memory 2 Switch Circuit Short to Ground	DDM	REFER to SEATING .
B1551	Decklid Release Circuit Failure	FEM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1567	Headlamp High-Beam Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - LS .
B1567	Headlamp High-Beam Circuit Failure	Instrument Cluster	REFER to EXTERIOR LIGHTING - LS .
B1600	PATS Ignition Key Transponder Signal is Not Received	Instrument Cluster	REFER to ANTI-THEFT .
B1601	PATS Received Incorrect Key-code From Ignition Key Transponder	Instrument Cluster	REFER to ANTI-THEFT .
B1602	PATS Received Invalid Format of Key-code From Ignition Key Transponder	Instrument Cluster	REFER to ANTI-THEFT .
B1627	PRNDL Reverse Input Circuit Failure	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B1676	Battery Voltage Out of Range	FEM	REFER to GENERATORS & REGULATORS .
B1676	Battery Voltage Out of Range	REM	REFER to GENERATORS & REGULATORS /
B1676	Battery Voltage Out of Range	Message Center	REFER to GENERATORS & REGULATORS .
B1676	Battery Voltage Out of Range	DATC	REFER to GENERATORS & REGULATORS .
B1676	Battery Voltage Out of Range	DSM	REFER to GENERATORS & REGULATORS .
B1676	Battery Voltage Out of Range	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B1676	Battery Voltage Out of Range	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1681	PATS Transceiver Module Signal is Not Received	Instrument Cluster	REFER to ANTI-THEFT .
B1689	Autolamp Delay Circuit Failure	Instrument Cluster	REFER to EXTERIOR LIGHTING - LS .
B1703	Seat Driver Recline Forward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1707	Seat Driver Recline Rearward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1711	Seat Driver Front Up Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1715	Seat Driver Front Down Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1719	Seat Driver Forward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1723	Seat Driver Rearward Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1727	Seat Driver Rear Up Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1731	Seat Driver Rear Down Switch Circuit Short to Battery	DSM	REFER to SEATING .
B1757	Seat Driver Rear Up/Down Circuit Failure	DSM	REFER to SEATING .
B1761	Seat Driver Front Up/Down Circuit Failure	DSM	REFER to SEATING .
B1765	Seat Driver Forward/Rearward Circuit Failure	DSM	REFER to SEATING .
B1769	Seat Driver Recliner F/R Circuit Failure	DSM	REFER to SEATING .
B1794	Lamp Headlamp Low-Beam Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - LS .
B1869	Lamp Air Bag Warning Indicator Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1870	Lamp Air Bag Warning Indicator Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1875	Turn Signal/Hazard Switch Signal Circuit Failure	Instrument Cluster	REFER to EXTERIOR LIGHTING - LS .
B1891	Air Bag Tone Warning Indicator Circuit Shorted to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1892	Air Bag Tone Warning Indicator Circuit Failure	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1921	Air Bag Diagnostic Monitor Ground Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1946	Climate Control A/C Post Evaporator Sensor Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1947	Climate Control A/C Post Evaporator Sensor Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1966	A/C Post Heater Sensor Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1967	A/C Post Heater Sensor Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B1984	Luggage Compartment Lid Anti-theft Disarm Circuit Short to Ground	REM	REFER to ANTI-THEFT .
B1990	Pedal Forward/Rearward Potentiometer Feedback Circuit Failure	FEM	REFER to SEATING .
B2078	Driver Airbag Deactivation Indicator Inoperative	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2103	Antenna Not Connected	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2103	Antenna Not Connected	Navigation System Module	REFER to ELECTRONIC FEATURE .
B2112	Door Driver Set Switch Stuck Failure	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2116	Door Driver Reset Switch Stuck Failure	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2139	SCP Not Configured PCM ID Does Not Match	Instrument Cluster	REFER to ANTI-THEFT .
B2139	Data Mismatch	Navigation System Module	REFER to ELECTRONIC FEATURE .
B2141	NVM Configuration Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2143	NVM Memory Failure	DSM	CARRY OUT seat calibration of the DSM. CLEAR the DTCs. REPEAT the self-test. IF the DTC resets, INSTALL a new DSM. REFER to DRIVER SEAT MODULE (DSM) . CARRY OUT seat calibration of the new DSM.
B2143	NVM Memory Failure	Instrument Cluster	CARRY OUT seat calibration of the instrument cluster. CLEAR the DTCs. REPEAT the self-test. IF the DTC resets, INSTALL a new instrument cluster. REFER to INFORMATION, GAUGES & WARNING DEVICES . CARRY OUT seat calibration of the new DSM.
B2146	Seat Recline Motor Position Out of Range	DSM	REFER to SEATING .
B2149	Seat Front Vertical Motor Position Out of Range	DSM	REFER to SEATING .
B2152	Seat Rear Vertical Motor Position Out of Range	DSM	REFER to SEATING .
B2155	Seat Horizontal Motor Position Out of Range	DSM	REFER to SEATING .
B2158	Seat Recline Motor Memory Position Out of Range	DSM	REFER to SEATING .
B2161	Seat Front Vertical Motor Memory Position Out of Range	DSM	REFER to SEATING .
B2162	Data Mismatch No.2 (received data does not match what was expected)	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2164	Seat Rear Vertical Motor Memory Position Out of Range	DSM	REFER to SEATING .
B2167	Seat Horizontal Motor Memory Position Out of Range	DSM	REFER to SEATING .
B2172	Inertia Switch Input Circuit Open	REM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
B2174	Window Driver Rear Remote Up Switch Short to Battery	REM	REFER to EXTERIOR TRIM .
B2178	Window Driver Rear Remote Down Switch Short to Battery	REM	REFER to EXTERIOR TRIM .
B2190	Window Passenger Rear Remote Up Switch Short to Battery	REM	REFER to EXTERIOR TRIM .
B2194	Window Passenger Rear Remote Down Switch Short to Battery	REM	REFER to EXTERIOR TRIM .
B2204	GPS Antenna Connection Open or Short	Navigation System Module	REFER to ELECTRONIC FEATURE .
B2208	Navigation to Head Unit Communication Error	Navigation System Module	REFER to ELECTRONIC FEATURE .
B2243	Driver Rear Door Ajar Circuit Open	REM	REFER to Section INTERIOR LIGHTING - LS .
B2245	Passenger Rear Door Ajar Circuit Open	REM	REFER to Section INTERIOR LIGHTING - LS .
B2290	Occupant Classification System Fault Front Passenger Side	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2292	Restraint System Seatbelt Pretensioner Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2293	Restraint System Airbag Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2294	Restraint System Curtain Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2295	Restraint System Side Airbag Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2296	Restraint System Impact Sensor Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2312	Mirror Passenger Horizontal Sensor Circuit Failure	FEM	REFER to EXTERIOR TRIM .
B2316	Mirror Passenger Vertical Sensor Circuit Failure	FEM	REFER to EXTERIOR TRIM .
B2320	Mirror Driver Horizontal Feedback Potentiometer Circuit Failure	DDM	REFER to EXTERIOR TRIM .
B2324	Mirror Driver Vertical Feedback Potentiometer Circuit Failure	DDM	REFER to EXTERIOR TRIM .
B2336	Mirror Switch Assembly Circuit Failure	DDM	REFER to EXTERIOR TRIM .
B2328	Column Reach Feedback Potentiometer Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2332	Column Tilt Feedback Potentiometer Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2351	Steering Column Switch Signal Circuit Failure	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2358	Adjustable Pedal Switch Failure	FEM	REFER to BRAKE SYSTEM .
B2359	Accessory Delay Output Circuit Failure	DDM	REFER to EXTERIOR TRIM .
B2360	Window Motor Control Output Circuit Failure	DDM	REFER to EXTERIOR TRIM .
B2380	Heater Coolant Temperature Sensor Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2381	Heater Coolant Temperature Sensor Circuit Open	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2401	Audio Tape Deck Mechanism Fault	ACM	VERIFY that no tape is inserted in the ACM. CLEAR and DOCUMENT the DTCs. CARRY OUT the ACM On-Demand self-test. If DTC B2401 is retrieved again, REMOVE the ACM, REFER to ENTERTAINMENT SYSTEM - LS and SEND it to an authorized Ford audio system repair facility. TEST the system for normal operation.
B2402	Audio CD/DJ Thermal Shutdown Fault	ACM	REFER to ENTERTAINMENT SYSTEM - LS .
B2403	Audio CD/DJ Internal Fault	ACM	REFER to ENTERTAINMENT SYSTEM - LS .
B2403	Audio CD/DJ Internal Fault	Navigation System Module	REFER to ENTERTAINMENT SYSTEM - LS .
B2404	Audio Steering Wheel Switch Circuit Fault	ACM	REFER to ENTERTAINMENT SYSTEM - LS .
B2404	Audio Steering Wheel Switch Circuit Fault	Navigation System Module	REFER to ENTERTAINMENT SYSTEM - LS .
B2405	Audio Single-Disc CD Player Thermal Shutdown Fault	ACM	REFER to ENTERTAINMENT SYSTEM - LS /
B2406	Audio Single-Disc CD Player Internal Fault	ACM	REFER to ENTERTAINMENT SYSTEM - LS .
B2425	Remote Keyless Entry Rolling Code Out of Synchronization	DDM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2426	Pass Solar Radiation Sensor Circuit Open	DATC	REFER to ENGINE COOLING .
B2427	Pass Solar Radiation Sensor Circuit Short to Ground	DATC	REFER to ENGINE COOLING .
B2428	A/C Post Heater Sensor No.2 Circuit Failure	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2429	A/C Post Heater Sensor No.2 Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2431	Transponder Programming Failed	Instrument Cluster	REFER to ANTI-THEFT .
B2434	Drivers Seat Belt Buckle Switch Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2435	Drivers Seat Belt Buckle Switch Resistance Out of Range	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2438	Passengers Seat Belt Buckle Switch Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2439	Passengers Seat Belt Buckle Switch Resistance Out of Range	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2472	Fog Lamp Switch Failure	Instrument Cluster	REFER to EXTERIOR LIGHTING - LS .
B2477	Module Configuration Failure	Electronic Parking Brake Module REFER	To MODULE CONFIGURATION .
B2477	Module Configuration Failure	DDM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	ACM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	RCM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Navigation System Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Message Center	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Instrument Cluster	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Stability Assist Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DATC	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	DDM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	REM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	ABS/TC Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Climate Control Seat Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	Instrument Cluster	REFER to MODULE CONFIGURATION .
B2486	Climate Controlled Seat Module Voltage Out of Range	Climate Control Seat Module	REFER to SEATING .
B2521	Tach Circuit Failure	Climate Control Seat Module	REFER to SEATING .
B2627	Fuel Sender Circuit Open No. 2	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2628	Fuel Sender Circuit Short to Ground No. 2	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2633	Driver Front Microphone Circuit Failure	Navigation System Module	REFER to ELECTRONIC FEATURE .
B2691	Front Drivers Seat Belt Buckle Switch Circuit Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2692	Front Passengers Seat Belt Buckle Switch Resistance Circuit Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2729	Cushion Over-Temp Detected	Climate Control Seat Module	REFER to SEATING .
B2730	Back-Over Temp Detected	Climate Control Seat Module	REFER to SEATING .
B2731	Differential Temperature Fault	Climate Control Seat Module	REFER to SEATING .
B2734	Pedal Travel Sensor Supply Error	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B2736	Pedal Travel Sensor Circuit Fault	ABS/TC	REFER to ANTI-LOCK CONTROL .
B2737	Pedal Travel Sensor Jammed Error	Stability Assist Module ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B2738	Pedal Travel Sensor Velocity Error	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B2740	Pedal Travel Sensor Spike Error	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B2741	Sensor Cluster Loop End	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B2795	Driver Solar Radiation Sensor Circuit Short to Ground	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2796	Driver Solar Radiation Sensor Circuit Open	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2797	Driver Water Valve Circuit Open	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2798	Driver Water Valve Circuit Short	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2799	Pass Water Valve Circuit Open	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2800	Pass Water Valve Circuit Short	DATC	REFER to CLIMATE CONTROL SYSTEM .
B2844	Ignition Voltage Out of Range	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2858	H/U is Defective	Navigation System Module	REFER to ELECTRONIC FEATURE .
B2879	Fuel Tank Jet Pump Fault	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
B2900	VIN Mismatch	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
B2913	Audio Sub-Woofer Not Connected	Navigation System Module	REFER to ELECTRONIC FEATURE .
C1094	Park Brake Apply Switch Circuit Failure	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1095	Hydraulic Pump Motor Circuit Failure	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1132	Clutch Position Circuit Short to Ground	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1133	Clutch Position Circuit Short to Battery	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1134	Gear Shift Position Circuit Short to Ground	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1135	Gear Shift Position Circuit Short to Battery	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1192	Vehicle Speed Circuit Failure	Navigation System Module	REFER to ELECTRONIC FEATURE .
C1233	Speed Wheel LF Input Signal Missing	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1234	Speed Wheel RF Input Signal Missing	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1235	Speed Wheel RR Input Signal Missing	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1236	Speed Wheel LR Input Signal Missing	ABS/TC Module or Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1277	Steering Wheel Angle 1 and 2 Circuit Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1278	Steering Wheel Angle 1 and 2 Signal Faulted	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1279	Yaw Rate Sensor Circuit Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1280	Yaw Rate Sensor Signal Fault	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1281	Lateral Accelerometer Circuit Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1282	Lateral Accelerometer Signal Fault	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1284	Oil Pressure Switch Failure	FEM	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1285	Booster Solenoid Circuit Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1287	Booster Pedal Force Switch Circuit Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1408	Parking Brake Release Switch Circuit Out of Range	Electronic Parking Brake Module	REFER to ANTI-LOCK CONTROL .
C1409	Parking Brake Apply Switch Circuit Out of Range	Electronic Parking Brake Module	REFER to ANTI-LOCK CONTROL .
C1414	Incorrect Module Design Level	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
C1440	Pressure Transducer Main/Primary Signal Faulted	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1700	LR Sensor Circuit Failure or Blockage	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1703	RR Sensor Circuit Failure or Blockage	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1730	Reference Voltage Out of Range (+5V)	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1769	Park Brake Apply Switch Circuit Short to Ground	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1782	Park Brake Release Switch Circuit Failure	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1783	Park Brake Release Switch Circuit Short to Ground	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1784	EBP Motor Output Short to Ground	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1785	EBP Motor Output Open Circuit	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1786	EBP Motor Output Battery Short to Ground	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1799	Hall Effect Circuit Failure	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1801	Motor Engage Current Reached Before Full Apply Travel Distance	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1802	Motor Engage Current Not Reached or Traveled Too Far Upon Apply	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1803	Motor Disengage Full Travel Distance Not Reached Upon Release	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1805	Mismatched PCM and/or Stability Assist Module	Stability Assist Module Check for correct component and configuration for the PCM and stability assist module, INSTALL a new stability assist module as necessary.	REFER to ANTI-LOCK CONTROL . CLEAR the DTC. REPEAT the self-test.
C1924	VAPS Solenoid Actuator Output Circuit Short to Ground	FEM	REFER to STEERING SYSTEM .
C1925	VAPS Solenoid Actuator Return Circuit Failure	FEM	REFER to STEERING SYSTEM .
C1947	Seat Track Position Switch Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
C1948	Seat Track Position Switch Circuit Resistance Out of Range	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
C1963	Stability Control Inhibit Warning	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1969	TC/YC Switch Lamp Circuit Fault	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1981	Front Drivers Seat Track Position Switch Circuit Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
C1983	Radar Sensor Fault	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1984	Radar Sensor Circuit Failure	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1985	Back Up Aid Disable Switch Stuck Low	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1987	Yellow Fault Warning Lamp Indicator Short to Battery	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1988	Yellow Fault Warning Lamp Indicator Circuit Failure	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1989	Park Brake Apply and Release Switch Contacts Energized Simultaneously	Electronic Parking Brake Module	REFER to BRAKE SYSTEM .
C1991	Module Calibration Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1992	Vehicle Speed Circuit Failure	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
C1996	Active Yaw Control Disabled	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C1998	Module Calibration Not Complete	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C2777	Sensor Cluster Bus Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
C2778	Sensor Power Supply Failure	Stability Assist Module	REFER to ANTI-LOCK CONTROL .
P0117	ECT Circuit Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0707	Transmission Range Sensor Circuit Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0112	IAT Circuit Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0113	IAT Indicates -40°C(-40°F) Open Circuit	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0114	IAT Out of On-board Diagnostic Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1116	ECT Out of On-board Diagnostic Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0118	ECT Indicates -40°C(-40°F)	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0122	TP Sensor A Circuit Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0123	TP Sensor A Circuit High Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0442	Small Leak Detected in EVAP System (As small as 1.02 mm [0.040 inch])	PCM	REFER to FUEL SYSTEM .
P0455	Major Leak or No Flow Detected	PCM	REFER to FUEL SYSTEM .
P0457	Check for Missing or Leaking Fuel Filler Cap	PCM	REFER to FUEL SYSTEM .
P0500	Vehicle Speed Sensor Malfunction	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0501	Vehicle Speed Sensor Range/Performance	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0502	Vehicle Speed Sensor Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0503	Vehicle Speed Sensor Intermittent	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0703	Brake Switch Input Malfunction	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0705	Digital TR Circuit Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0708	Digital TR Sensor	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0712	Transmission Fluid Temperature (TFT) Sensor Circuit Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0713	40°C (-40°F) Indicated TFT Sensor Circuit Open	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0715	TSS	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0717	TSS	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0718	TSS	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0720	OSS	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0721	Output Shaft Speed Sensor Signal Noisy	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0722	OSS	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0731	1st Gear Error	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0732	2nd Gear Error	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0733	3rd Gear Error	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0734	4th Gear Error	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0735	5th Gear Error	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0741	TCC	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0743	TCC Solenoid Circuit Fails to Provide Voltage Drop Across Solenoid. Circuit Open or Shorted or PCM Driver Failure During On-board Diagnostics.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0745, P1747	PCA	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0750	SSA Solenoid Circuit Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0753	SSA	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0755	SSB	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0758	SSB Solenoid Circuit Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0760	SSC Solenoid Circuit Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0763	Ssc	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0765	SSD Solenoid Circuit Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0768	SSD Solenoid circuit Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0775, P1789	PCB Solenoid Circuit Failure, Shorted Circuit	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0779	PCB Solenoid Intermittent Short to Ground	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0791	Intermediate Shaft Speed Sensor Signal Failure.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0794	Intermediate Shaft Speed Sensor Signal Intermittent	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0795, P0797	PCC	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0796	PCC Solenoid Circuit Open	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0799	PCC Solenoid Intermittent Short to Ground	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P0814	J-GATE Circuit Input Signal Failed.	PCM	REFER to AUTOMATIC TRANSMISSION - 5R55S .
P0815	SST +/- Circuit Input Signal Failed.	PCM	REFER to AUTOMATIC TRANSMISSION - 5R55S .
P0840	Reverse Pressure Switch Circuit Input Signal Failed.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1120	TP Sensor Out of Range Low (Ratch too low)	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1124	TP Voltage High/low for Onboard Diagnostic.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1183	Engine Oil Temperature Circuit Malfunction	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1184	Engine Oil Temperature Out of Self-Test Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1430	SCP(J1850) Invalid Data for Function Read Fuel System	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1443	Very Small or No Purge Flow Detected	PCM	REFER to FUEL SYSTEM .
P1450	Excessive Vacuum Detected in the Fuel Tank	PCM	REFER to FUEL SYSTEM .
P1460	WOT A/C Cutout Internal Driver Malfunction	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1461	A/C Pressure Sensor Circuit High Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1462	A/C Pressure Sensor Circuit Low Input	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1463	A/C Pressure Sensor Insufficient Pressure Variation	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1464	A/C Demand Out of Self-test Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1469	Low A/C Cycling Period	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1474	Low Speed Fan Internal Driver Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1479	High Speed Fan Internal Driver Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1565	Speed Control Command Switches High/Out of Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1566	Speed Control Command Switches Low/Out of Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1567	NGSC Drive Fault	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1572	Brake On/Off Failure	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1636	SSx ISIG Communication Error	PCM	INSTALL a new PCM INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V) - LS or INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L - LS .
P1641	SCP (J1850) Invalid or Missing Data for Odometer Rolling Count	ABS/TC Module or Stability Assist Module	CARRY OUT the ABS/TC control module or stability assist module self-test.
P1641	Fuel Pump Primary Circuit Failure	REM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1700	Internal Component Failure. Direct One-way Clutch Failure.	PCM	If other solenoid DTCs are present, diagnose and repair them first. CLEAR DTCs and drive vehicle. If P1700 returns, disassemble transmission and inspect the direct one-way clutch. Repair as required. CLEAR DTC. Drive vehicle and verify repair.
P1702	Digital TR Signal Intermittent, Code P0705, P0708 Are Set.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1703	BPP	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1704	Digital TR Not in P Or N Positions During KOEO/KOER.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1705	Digital TR Not in PARK or NEUTRAL During KOEO/KOER.	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1711	TFT Out of On-board Diagnostic Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1713	No Change in TFT - Low Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1714	SSA Inoperative	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1715	SSB Inoperative	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1716	SSC Inoperative	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1717	SSD Inoperative	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1718	No Change in TFT - High Range	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1740	TCC Inoperative	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1746	PCA Solenoid Circuit Open	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1760	PCA Solenoid Intermittent Short to Ground	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1780	TCS Input Incorrect Per Selected Position	PCM	RERUN on-board diagnostic and cycle switch. REFER to AUTOMATIC TRANSMISSION - 5R55S .
P1783	Transmission Overtemp Condition Indicated	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
P1788	PCB Solenoid Circuit Open	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
U1009	SCP (J1850) Invalid or Missing Data for Engine Torque	ABS/TC Module or Stability Assist Module	CARRY OUT the PCM self-test.
U1016	SCP Invalid DATA (PCM)	Navigation System Module	REFER to ELECTRONIC FEATURE .
U1027	SCP (J1850) Invalid or Missing Data for Engine	RPM	Electronic Parking Brake Module CARRY OUT the electronic parking brake module self-test.
U1027	SCP (J1850) Invalid or Missing Data for Engine RPM	PCM	CARRY OUT the PCM self-test.
U1027	SCP (J1850) Bus Invalid or Missing Data for Engine RPM	ABS/TC Module or Stability Assist Module	CARRY OUT the ABS/TC Control Module/Stability Assist Module self-test.
U1027	SCP (J1850) Bus Invalid or Missing Data for Engine RPM	FEM	CARRY OUT the FEM self-test.
U1040	SCP (J1850) Invalid or Missing Data for Vehicle Speed	Electronic Parking Brake Module	CARRY OUT the electronic parking brake module self-test.
U1041	SCP (J1850) Invalid or Missing Data for Vehicle Speed	FEM	CARRY OUT the FEM self-test.
U1041	SCP (J1850) Invalid or Missing Data for Vehicle Speed	REM	CARRY OUT the REM self-test.
U1041	SCP (J1850) Invalid or Missing Data for Vehicle Speed	DDM	CARRY OUT the DDM self-test.
U1041	SCP (J1850) Invalid or Missing Data for Vehicle Speed	Instrument Cluster	CARRY OUT the instrument cluster self-test.
U1051	SCP (J1850) Invalid or Missing Data for Brakes	Electronic Parking Brake Module	CARRY OUT the electronic parking brake module self-test.
U1053	SCP (J1850) Invalid or Missing Data for Steering / Steering Wheel	PCM	CARRY OUT the PCM self-test.
U1058	SCP (J1850) Invalid or Missing Data for Transmission / Transaxle/PRNDL	Electronic Parking Brake Module	CARRY OUT the electronic parking brake module self-test.
U1059	SCP (J1850) Invalid or Missing Data for Transmission / Transaxle/PRNDL	PCM	CARRY OUT the PCM self-test.
U1059	SCP (J1850) Invalid or Missing Data for Transmission / Transaxle/PRNDL	ABS/TC Module or Stability Assist Module	CARRY OUT the ABS/TC Module or Stability Assist Module self-test.
U1059	SCP (J1850) Invalid or Missing Data for Transmission / Transaxle/PRNDL	FEM	CARRY OUT the FEM self-test.
U1059	SCP (J1850) Invalid or Missing Data for Transmission / Transaxle/PRNDL	REM	CARRY OUT the REM self-test.
U1059	SCP (J1850) Invalid or Missing Data for Transmission/Transaxle/PRNDL	DDM	CARRY OUT the DDM self-test.
U1073	SCP (J1850) Invalid Or Missing Data for Engine Coolant	ABS/TC Module or Stability Assist Module	CARRY OUT the ABS/TC Module or Stability Assist Module self-test.
U1073	SCP (J1850) Invalid or Missing Data for Engine Coolant	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
U1073	SCP (J1850) Invalid or Missing Data for Engine Coolant	Instrument Cluster	REFER to INFORMATION, GAUGES & WARNING DEVICES .
U1083	SCP (J1850) Invalid or Missing Data for Engine Systems Other	PCM	CARRY OUT the PCM self-test.
U1098	SCP (J1850) Invalid or Missing Data for Vehicle Speed Control	PCM	CARRY OUT the PCM self-test.
U1123	SCP (J1850) Invalid or Missing Data for Odometer	Instrument Cluster	CARRY OUT the instrument cluster self-test.
U1123	SCP (J1850) Invalid or Missing Data for Odometer	Message Center	CARRY OUT the Message Center self-test.
U1134	SCP (J1850) Invalid or Missing Data Ignition Switch/Starter	Electronic Parking Brake Module	CARRY OUT the electronic parking brake module self-test.
U1136	SCP (J1850) Invalid or Missing Data for Telltales	PCM	CARRY OUT the PCM self-test.
U1147	SCP (J1850) Invalid or Missing Data for Vehicle Security System	ABS/TC Module or Stability Assist Module	CARRY OUT the ABS/TC Module or Stability Assist Module self-test.
U1147	SCP (J1850) Invalid or Missing Data for Vehicle Security System	PCM, Instrument Cluster	CARRY OUT the PCM or Instrument Cluster self-test.
U1218	SCP (J1850) Invalid or Missing Data for External Lamps	FEM, REM	CARRY OUT the FEM and REM self-test.
U1222	SCP (J1850) Invalid or Missing Data for Interior Lamps	FEM	CARRY OUT the FEM self-test.
U1243	SCP (J1850) Invalid or Missing Data for Exterior Environment	PCM	REFER to the INTRODUCTION article in ENGINE PERFORMANCE .
U1262	SCP (J1850) Communication Bus Fault	Electronic Parking Brake Module	CARRY OUT the electronic parking brake module self-test.
U1262	SCP (J1850) Communication Bus Fault	Network Fault	REFER to COMMUNICATIONS NETWORK .
U1262	SCP (J1850) Communication Bus Fault	Instrument Cluster	REFER to COMMUNICATIONS NETWORK .
U1262	SCP (J1850) Communication Bus Fault	ABS/TC Module Or Stability Assist Module	REFER to COMMUNICATIONS NETWORK .
U1262	SCP (J1850) Communication Bus Fault	Message Center	Go To PINPOINT TEST O: NO STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUNICATION .
U1430	SCP (J1850) Invalid Data for Function Read Fuel System	Message Center	CARRY OUT the Message Center self-test.
U1751	SCP (J1850) SCLM System Status Missing From REM	Instrument Cluster	CARRY OUT the REM self-test.
U1752	SCP (J1850) SCLM System Status Missing From FEM	Instrument Cluster	CARRY OUT the FEM self-test.
U1901	CAN Network #2 Communication BUS Fault Receive Error	ABS/TC Module or Stability Assist Module	CARRY OUT the ABS/TC Control Module or Stability Assist self-test.
U1950	UBP Communication Bus Fault	Parking Aid Module	Go To PINPOINT TEST S: THE PARKING AID MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
U2003	Audio CD/Disc Jockey is Not Responding	ACM	U2003 is retrieved if CD/DJ is not present, disconnected, or inoperative. REFER to ENTERTAINMENT SYSTEM - LS .
U2003	Audio CD/DJ is Not Responding	Navigation System Module	U2003 is retrieved if CD/DJ is not present, disconnected, or inoperative. REFER to ENTERTAINMENT SYSTEM - LS .
U2005	Audio Rear Integrated Control Panel Unit is Not Responding	Navigation System Module	NOTE: U2005 is retrieved if RICP is not present, disconnected, or inoperative. REFER to ENTERTAINMENT SYSTEM - LS .
U2306	Transmission PRNDL Range Selected Status Invalid	Parking Aid Module	REFER to INFORMATION, GAUGES & WARNING DEVICES .
U2008	Audio Phone is Not Responding	ACM	REFER to ENTERTAINMENT SYSTEM - LS .
U2150	SCP (J1850) Invalid Data From REM	Instrument Cluster	CARRY OUT the REM self-test.
U2152	SCP (J1850) Invalid Data From FEM	Instrument Cluster	CARRY OUT the FEM self-test.
U2195	SCP (J1850) Invalid DATA From SCLM	Instrument Cluster	CARRY OUT the instrument cluster self-test.
U2362	UBP Invalid Data From Node ID $98	Climate Control Seat Module	REFER to SEATING .

NOTE
The message center is part of the instrument cluster.

NOTE
U2005 is retrieved if RICP is not present, disconnected, or inoperative. REFER to ENTERTAINMENT SYSTEM - LS .

DIAGNOSTIC TROUBLE CODE

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Scheme 1

Scheme 1: Special Tool(s)

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. Visual Inspection Chart VISUAL INSPECTION Electrical Central junction box (CJB) fuse 6 (10A) Wiring harness Loose or corroded connections
If the cause is not visually evident, connect the diagnostic tool to the data link connector and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position. If the diagnostic tool still does not communicate with the vehicle, Go To «PINPOINT TEST T: NO MODULE/NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL»(ref-207567-S05390913692005113000000) .
Go To «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .

PINPOINT TEST PC: DATA LINK DIAGNOSTICS NETWORK TEST

Test Step

PC1 RUN THE DATA LINK DIAGNOSTICS NETWORK TEST Carry out the data link diagnostics test. Is system passed obtained? Result / Action to Take Yes : Test passed. RETURN to the Symptom Chart of the article for the module in question. No : If no response from the diagnostic tool, Go To «PINPOINT TEST T: NO MODULE/NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL»(ref-207567-S05390913692005113000000) . If ISO, SCP+ and/or SCP- = SOME ECUS NO RESP/NOT EQUIP, REFER to the «SYMPTOM CHART»(ref-207567-S16551942102005113000000) . If ISO = ALL ECUS NO RESP/NOT EQUIP, Go To «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . If SCP+ = ALL ECUS NO RESP/NOT EQUIP, Go To «PINPOINT TEST O: NO STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUNICATION»(ref-207567-S33034959422005113000000) . If SCP- = ALL ECUS NO RESP/NOT EQUIP, Go To «PINPOINT TEST O: NO STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUNICATION»(ref-207567-S33034959422005113000000) . If the module in question is NO RESPONSE/NOT EQUIPPED, REFER to the «SYMPTOM CHART»(ref-207567-S16551942102005113000000) . If the module in question is NO RESPONSE ON SCP+, REFER to the «SYMPTOM CHART»(ref-207567-S16551942102005113000000) . If the module in question is NO RESPONSE ON SCP-, REFER to the «SYMPTOM CHART»(ref-207567-S16551942102005113000000) .

Symptom Chart

Condition	Possible Sources	Action
The anti-lock brake/traction control (ABS/TC) module or stability assist module does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. ABS/TC module. Stability assist module.	Go To PINPOINT TEST A: THE ANTI-LOCK BRAKE/TRACTION CONTROL (ABS/TC) MODULE OR STABILITY ASSIST MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The front electronic module (FEM) does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. FEM.	Go To PINPOINT TEST B: THE FRONT ELECTRONIC MODULE (FEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The restraint control module (RCM) does not respond to the diagnostic tool	Circuit or connection in International Standards Organization (ISO) 9141 network. RCM.	Go To PINPOINT TEST C: THE RESTRAINT CONTROL MODULE (RCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The instrument cluster does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. Instrument cluster.	Go To PINPOINT TEST D: THE INSTRUMENT CLUSTER DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
No powertrain control module (PCM) standard corporate protocol (SCP) network communication	Circuit or connection in the standard corporate protocol (SCP) communication network. PCM.	Go To PINPOINT TEST E: NO POWERTRAIN CONTROL MODULE (PCM) STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUNICATION .
The dual automatic temperature control (DATC) module does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. DATC module.	Go To PINPOINT TEST F: THE DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The audio control module (ACM) does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. ACM.	Go To PINPOINT TEST G: THE AUDIO CONTROL MODULE (ACM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The powertrain control module (PCM) does not respond to the diagnostic tool	Circuit or connection in the controller area network (CAN) communication network. PCM.	Go To PINPOINT TEST H: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The driver seat module (DSM) does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. DSM.	Go To PINPOINT TEST I: THE DRIVER SEAT MODULE (DSM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The driver door module (DDM) does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. DDM.	Go To PINPOINT TEST J: THE DRIVER DOOR MODULE (DDM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The rear electronic module (REM) does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. REM.	Go To PINPOINT TEST K: THE REAR ELECTRONIC MODULE (REM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The navigation system module does not respond to the diagnostic tool	Circuit or connection in the standard corporate protocol (SCP) communication network. Navigation system module.	Go To PINPOINT TEST L: THE NAVIGATION SYSTEM MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The driver temperature controlled seat module does not respond to the diagnostic tool	Circuit or connection in the universal asynchronous receiver -transmitter (UART) based protocol (UBP) network. Driver temperature seat controlled module.	Go To PINPOINT TEST M: THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The passenger temperature controlled seat module does not respond to the diagnostic tool	Circuit or connection in the universal asynchronous reciever-transmitter (UART) based protocol (UBP) network. Passenger temperature seat controlled module.	Go To PINPOINT TEST N: THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
No standard corporate protocol (SCP) network communication	Circuit or connection in the (SCP) communication network. SCP networked modules.	Go To PINPOINT TEST O: NO STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUNICATION .
No international standards organization (ISO) 9141 network communication	Circuit or connection in the ISO 9141 network. ISO 9141 networked modules.	Go To PINPOINT TEST PC: data link diagnostics network test .
No universal asynchronous reciever-transmitter (UART) based protocol (UBP) network communication	Circuit or connection in the UBP network. UBP networked modules.	Go To PINPOINT TEST Q: NO UNIVERSAL ASYNCHRONOUS RECIEVE-TRANSMIT (UART) BASED PROTOCOL (UBP) NETWORK COMMUNICATION .
The electronic parking brake module does not respond to the diagnostic tool	Circuit or connection in the UBP network. Electronic parking brake module.	Go To PINPOINT TEST R: THE ELECTRONIC PARKING BRAKE MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
The parking aid module does not respond to the diagnostic tool	Circuit or connection in the universal asynchronous reciever-transmitter (UART) based protocol (UBP) network. Parking aid module.	Go To PINPOINT TEST S: THE PARKING AID MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL .
No module/network communication - no power to the diagnostic tool	CJB fuse: 6(10A). DLC pins. Diagnostic tool. Circuitry.	Go To Pinpoint Rest T.

SYMPTOM

Scheme 2

Scheme 2: Data Link Connector (DLC) C251

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
2	4-EG7 (GY/RD) SCP communications circuit.	Less than 5 ohms between the DLC and the module in concern disconnected. Greater than 10,000 ohms between the DLC and ground with all network modules disconnected.
3	4-ED6 (GY) UBP communications circuit.	Less than 5 ohms between the DLC and the module in concern disconnected. Greater than 10,000 ohms between the DLC and ground.
4	31-ED6 (BK) ground.	Less than 5 ohms to ground.
5	91-ED6(BN) ground.	Less than 5 ohms to ground.
6	4-EC7 (GY/RD) CAN communication circuit.	Less than 5 ohms between the DLC and the module in concern disconnected. Greater than 10,000 ohms to ground with all network modules disconnected.
7	4-EE10 (GY/BK) ISO 9141 communication circuit.	Less than 5 ohms between the DLC and the module in concern disconnected. Greater than 10,000 ohms to ground with all network modules disconnected.
10	5-EG7 (BU/RD) SCP communication circuit.	Less than 5 ohms between the DLC and the module in concern disconnected. Greater than 10,000 ohms to ground with all network modules disconnected.
14	5-EC7 (BU/RD) CAN communication circuit.	Less than 5 ohms between the DLC and the module in concern disconnected. Greater than 10,000 ohms to ground with all network modules disconnected.
16	29-ED6 (OG/YE) B+ power feed in RUN position.	10 volts or greater with the key ON. Greater than 10,000 ohms to ground.

DATA LINK CONNECTOR (DLC) C251 PINS DESCRIPTION

Scheme 3

Scheme 3: Climate Control Seat Module Driver C3031a, Passenger C3036a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1 (C3031a)	4-HC21 (GY/OG) UBP communication circuit.	Less than 5 ohms between the DLC and the driver climate control seat module. Greater than 10,000 ohms to ground with all network modules disconnected.
1 (C3036a)	4-HC22 (GY) UBP communication circuit.	Less than 5 ohms between the DLC and the passenger climate control seat module. Greater than 10,000 ohms to ground with all network modules disconnected.

CLIMATE CONTROL SEAT MODULE DRIVER C3031A, PASSENGER C3036A PINS DESCRIPTION

Scheme 4

Scheme 4: Driver Seat Module (DSM) C341c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	4-AH80 (GY/WH) SCP communication circuit.	Less than 5 ohms between the DLC and the DSM. Greater than 10,000 ohms to ground with all network modules disconnected.
9	5-AH80 (BU/OG) SCP communication circuit.	Less than 5 ohms between the DLC and the DSM. Greater than 10,000 ohms to ground with all network modules disconnected.

DRIVER SEAT MODULE (DSM) C341C PINS DESCRIPTION

Scheme 5

Scheme 5: Parking Aid Module C4014b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	4-GN10 (GY) UBP communication circuit.	Less than 5 ohms between the DLC and the parking aid module. Greater than 10,000 ohms to ground with all network modules disconnected.

PARKING AID MODULE C4014B PINS DESCRIPTION

Scheme 6

Scheme 6: Restraint Control Module (RCM) C310a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
11	4-EE1 (GY/RD) ISO 9141 communication circuit.	Less than 5 ohms between the DLC and the RCM. Greater than 10,000 ohms to ground with all network modules disconnected.

RESTRAINT CONTROL MODULE (RCM) C310A PINS DESCRIPTION

Scheme 7

Scheme 7: Instrument Cluster C220b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
15	4-EG8 (GY/VT) SCP communication circuit	Less than 5 ohms between the instrument cluster and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
16	5-EG8 (BU/WH) SCP communication circuit	Less than 5 ohms between the instrument cluster and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

INSTRUMENT CLUSTER C220B PINS DESCRIPTION

Scheme 8

Scheme 8: Dual Automatic Temperature Control (DATC) C228a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	5-FA10 (BU/YE) SCP communication circuit	Less than 5 ohms between the DATC and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
12	4-FA10 (GY/BK) SCP communication circuit	Less than 5 ohms between the DATC and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) C228A PINS DESCRIPTION

Scheme 9

Scheme 9: Navigation System Module C4209

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
4	4-EG17 (GY/BK) SCP communication circuit	Less than 5 ohms between the navigation system module and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
16	5-EG17 (BU/YE) SCP communication circuit	Less than 5 ohms between the navigation system module and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

NAVIGATION SYSTEM MODULE C4209 PINS DESCRIPTION

Scheme 10

Scheme 10: Powertrain Control Module (PCM) C175a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
3	4-RE8 (GY) SCP communication circuit	Less than 5 ohms between the PCM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
4	5-RE8 (BU) SCP communication circuit	Less than 5 ohms between the PCM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
53	4-EC7 (GY/RD) SCP communication circuit	Less than 5 ohms between the PCM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
54	5-EC-7 (BU/RD) SCP communication circuit	Less than 5 ohms between the PCM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

POWERTRAIN CONTROL MODULE (PCM) C175A PINS DESCRIPTION

Scheme 11

Scheme 11: Anti-Lock Brake System/Traction Control (ABS/TC) Module C135 or Stability Assist Module C155

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
12	4-CF6 (GY) SCP communication circuit	Less than 5 ohms between the ABS/TC module or stability assist module, and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
14	5-CF6 (BU) SCP communication circuit	Less than 5 ohms between the ABS/TC module or stability assist module, and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

ANTI-LOCK BRAKE SYSTEM/TRACTION CONTROL (ABS/TC) MODULE C135 OR STABILITY ASSIST MODULE C155 PINS DESCRIPTION

Scheme 12

Scheme 12: Electronic Parking Brake Module C4205b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	4-CG16 (GY/RD)SCP communication circuit.	Less than 5 ohms between the electronic parking brake module and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
7	5-CG16 (BU/RD) SCP communication circuit.	Less than 5 ohms between the electronic parking brake module and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

ELECTRONIC PARKING BRAKE MODULE C4205B PINS DESCRIPTION

Scheme 13

Scheme 13: Rear Electronic Module (REM) C420b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	4-EG12 (GY/WH) SCP communication circuit.	Less than 5 ohms between the REM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
2	5-EG12 (BU/OG) SCP communication circuit.	Less than 5 ohms between the REM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

REAR ELECTRONIC MODULE (REM) C420B PINS DESCRIPTION

Scheme 14

Scheme 14: Front Electronic Module (FEM) C201c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	5-EG11 (BU) SCP communication circuit.	Less than 5 ohms between the FEM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.
7	4-EG11 (GY) SCP communication circuit.	Less than 5 ohms between the FEM and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

FRONT ELECTRONIC MODULE (FEM) C201C PINS DESCRIPTION

Scheme 15

Scheme 15: In-line C212M,C212F

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
8	4-EE10 (GY/BK) ISO 9141 communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

IN-LINE C212M,C212F PINS DESCRIPTION

Scheme 16

Scheme 16: In-line C213M, C213F

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
11	4-HC1 (GY/RD) UBP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

IN-LINE C213M, C213F PINS DESCRIPTION

Scheme 17

Scheme 17: In-line C313M, C313F

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
10	4-HC22 (GY) UBP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

IN-LINE C313M, C313F PINS DESCRIPTION

Scheme 18

Scheme 18: In-line C315M, C315F

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
6	4-AH80 (GY/WH) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
10	4-HC21 (GY/OG) UBP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
13	5-AH80 (BU/OG) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

IN-LINE C315M, C315F PINS DESCRIPTION

Scheme 19

Scheme 19: Joint Connector No. 1 C261

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
10	4-ED6 (GY) UBP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
11	4-HC1 (GY/RD) UBP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

JOINT CONNECTOR NO. 1 C261 PINS DESCRIPTION

Scheme 20

Scheme 20: Joint Connector No. 4 C223

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
7	5-EG10 (BU/YE) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
8	5-FA10 (BU/YE) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
9	5-EG7 (BU/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
10	5-EG8 (BU/WH) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
11	5-EG1 (BU/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
12	4-EG1 (GY/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
13	4-EG8 (GY/VT) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
14	4-EG7 (GY/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
15	4-FA10 (GY/BK) SCP communication circuit	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
16	4-EG10 (GY/BK) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

JOINT CONNECTOR NO. 4 C223 PINS DESCRIPTION

Scheme 21

Scheme 21: Audio Control Module (ACM) C240c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
3	4-EG10 (GY/BK) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
4	5-EG10 (BU/YE) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

AUDIO CONTROL MODULE (ACM) C240C PINS DESCRIPTION

Scheme 22

Scheme 22: Interior Auxiliary Junction Box (AJB) C283a, C283b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
4 (C283a)	5-EG13 (BU/BK) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
4 (C283b)	5-CG16 (BU/RD) SCP communication circuit without Navigation system. 5-EG1 (BU) SCP communication circuit with Navigation system.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
8 (C283a)	4-EG13 (GY/OG) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected with all network modules disconnected.
8 (C283b)	4-EG16 (GY/RD) SCP communication circuit without navigation system. 4-EG1 (GY) SCP communication circuit with navigation system.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
12 (C283a)	5-AH80 (BU/OG) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
12 (C283b)	5-EG12 (BU/OG) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
16 (C283a)	4-AH80 (GY/WH) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
16 (C283b)	4-EG12 (GY/WH) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.

INTERIOR AUXILIARY JUNCTION BOX (AJB) C283A, C283B PINS DESCRIPTION

Scheme 23

Scheme 23: Interior Auxiliary Junction Box (AJB) C283c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	5-RE8 (BU) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
4	4-RE8 (GY) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
5	4-CF6 (GY) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
6	5-CF6 (BU) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
8	5-EG11 (BU) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
10	4-EG11 (GY)SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

INTERIOR AUXILIARY JUNCTION BOX (AJB) C283C PINS DESCRIPTION

Scheme 24

Scheme 24: Interior Auxiliary Junction Box (AJB) C283d

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
12	5-EG1 (BU/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in -line connector. Greater than 10,000 ohms to ground with all network modules disconnected.
16	4-EG1 (GY/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or in-line connector. Greater than 10,000 ohms to ground with all network modules disconnected.

INTERIOR AUXILIARY JUNCTION BOX (AJB) C283D PINS DESCRIPTION

Scheme 25

Scheme 25: Joint Connector No. 5 C427

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	4-EG1 (GY/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
2	4-CG16 (GY/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
4	4-EG17 (GY/BK) SCP communication circuit	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
12	5-EG1 (BU/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
13	5-CG16 (BU/RD) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.
15	5-EG17 (BU/YE) SCP communication circuit.	Less than 5 ohms between the module connector, DLC or inline connector. Greater than 10,000 ohms to ground with all network modules disconnected.

JOINT CONNECTOR NO. 5 C427 PINS DESCRIPTION

Scheme 26

Scheme 26: Audio Control Module (ACM) C29c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	4-EG10 (GY/BK) standard corporate protocol (SCP)	Less than 5 ohms between the audio unit and data link connector. Greater than 10,000 ohms between the audio unit and ground.
4	5-EG10 (BU/YE) standard corporate protocol (SCP)	Less than 5 ohms between the audio unit and data link connector. Greater than 10,000 ohms between the audio unit and ground.

AUDIO CONTROL MODULE (ACM) C29C PINS DESCRIPTION

Scheme 27

Scheme 27: Driver Door Module (DDM) C501a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
3	4-EG13 (GY/OG) SCP communication circuit.	Less than 5 ohms between the driver door module and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected
4	5-EG13 (BU/BK) SCP communication circuit.	Less than 5 ohms between the driver door module and the DLC. Greater than 10,000 ohms to ground with all network modules disconnected.

DRIVER DOOR MODULE (DDM) C501A CONNECTOR PINS DESCRIPTION

PINPOINT TEST A: The Anti-Lock Brake/Traction Control (ABS/TC) Module Or Stability Assist Module Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 28

Scheme 28: PINPOINT TEST A: THE ANTI-LOCK BRAKE/TRACTION CONTROL (ABS/TC) MODULE OR STABILITY ASSIST MODULE DOE

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

A1 CHECK THE ABS/TC OR STABILITY ASSIST CONTROL MODULE FOR DAMAGE Key in OFF position. Disconnect: the ABS/TC control module C135, or the stability assist module C155. Inspect the ABS/TC control module C135 or stability assist module C155 for damage. Is the ABS/TC C135 or stability assist module C155 ok? Result / Action to Take Yes : GO to A2. No : REPAIR the ABS/TC module C135 or stability assist module C155 as necessary. TEST the system for normal operation.
A2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE ABS/TC MODULE C135 OR STABILITY ASSIST MODULE C155 If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-12, circuit 4-CF6 (GY), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-12, circuit 4-CF6 (GY), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-14, circuit 5-CF6 (BU), harness side and the C251 -10, circuit 5 -EG7 (BU/RD), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-14, circuit 5-CF6 (BU), harness side and the C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to A7 . No : GO to A3.
A3 CHECK FOR AN OPEN BETWEEN THE INTERIOR AUXILIARY JUNCTION BOX (AJB) C283c AND ABS/TC C135 OR STABILITY ASSIST MODULE C155 Disconnect: Interior AJB C283c. If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-12, circuit 4-CF6 (GY), harness side and the interior AJB C283c-5, circuit 4-CF6 (GY), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-12, circuit 4-CF6 (GY), harness side and the interior AJB C283c-5, circuit 4-CF6 (GY), harness side. If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-14, circuit 5-CF6 (BU), harness side and the interior AJB C283c-6, circuit 5-CF6 (BU), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-14, circuit 5-CF6 (BU), harness side and the interior AJB C283c-6, circuit 5-CF6 (BU), harness side. Are the resistances less than 5 ohms? Yes : GO to A4. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
A4 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283c-5, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283c-6, component side. Are the resistances less than 5 ohms? Yes : GO to A5. No : INSTALL a new interior AJB. TEST the system for normal operation.
A5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to A6. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
A6 CHECK FOR AN OPEN BETWEEN JOINT CONNECTOR No. C223 Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4. TEST the system for normal operation.
A7 CHECK FOR CORRECT ABS/TC MODULE OR STABILITY ASSIST MODULE OPERATION Disconnect all the ABS/TC or stability assist module connectors. Check for: corrosion push-out pins Connect all the ABS/TC or stability assist control module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new ABS/TC or stability assist module. REFER to «ANTI-LOCK CONTROL»(ref-207549) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST B: The Front Electronic Module (FEM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 38

Scheme 38: PINPOINT TEST B: THE FRONT ELECTRONIC MODULE (FEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

B1 CHECK THE FEM C201c FOR DAMAGE Key in OFF position. Disconnect: the FEM C201c. Inspect the FEM C201 c for damage; repair as necessary. Is the FEM C201c OK? Result / Action to Take Yes : GO to B2. No : GO to B7 .
B2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE FEM C201c Measure the resistance between the FEM C201 c-7, circuit 4-EG11 (GY), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the FEM C201 c-1, circuit 5-EG11 (BU), harness side and the DLCC251-10, circuit 5-EG7 (BU/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to B7 . No : GO to B3.
B3 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE FEM C201c Measure the resistance between the FEM C201 c-7, circuit 4-EG11 (GY), harness side and the interior AJB C283c-10, circuit 4-EG11 (GY), harness side. Measure the resistance between the FEM C201 c-1, circuit 5-EG11 (BU), harness side and the interior AJB C283c-8, circuit 5-EG11 (BU), harness side. Is the resistance less than 5 ohms? Yes : GO to B4. No : REPAIR the circuit in question. TEST the system for normal operation.
B4 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283c-10, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283c-8, component side. Are the resistances less than 5 ohms? Yes : GO to B5. No : INSTALL a new interior AJB. TEST the system for normal operation
B5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior the AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to B6. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
B6 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4. TEST the system for normal operation.
B7 CHECK FOR CORRECT FEM OPERATION Disconnect all the FEM connectors. Check for: corrosion push-out pins Connect all the FEM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new FEM. REFER to «FRONT ELECTRONIC MODULE (FEM)»(ref-207567-S09203141492005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST C: The Restraint Control Module (RCM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 48

Scheme 48: PINPOINT TEST C: THE RESTRAINT CONTROL MODULE (RCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 49

C1 CHECK FOR AN OPEN CIRCUIT BETWEEN THE RCM C310a AND THE DLC C251 KEY in OFF position. Deactivate the air bag system. Refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . Disconnect: RCM C31 0b. Inspect the RCM C31 0b for damage. Is the RCM C301b OK? Result / Action to Take Yes : GO to C2. No : REPAIR the RCM C31 0b as necessary. TEST the system for normal operation.
C2 CHECK FOR AN OPEN CIRCUIT BETWEEN THE RCM C310a AND THE DLC C251 Measure the resistance between the DLC C251 -7, circuit 4-EE10 (GY/BK), harness side and the RCM C31 0b-11, circuit 4-EE1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to C4 . No : GO to C3.
C3 CHECK FOR AN OPEN CIRCUIT BETWEEN THE DLC C251 AND IN-LINE C212M Disconnect: in-line C212. Measure the resistance between the DLC C251 -7, circuit 4-EE10 (GY/BK), harness side and in-line C212F-8, circuit 4-EE10 (GY/BK), harness side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between the RCM C310b and in-line C212M. TEST the system for normal operation. No : REPAIR the circuit between the DLCC251 and in-line C212F. TEST the system for normal operation.
C4 CHECK FOR CORRECT RCM OPERATION Disconnect all the RCM connectors. Check for: corrosion push-out pins Connect all the RCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new RCM. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST D: The Instrument Cluster Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 50

Scheme 50: PINPOINT TEST D: THE INSTRUMENT CLUSTER DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

D1 CHECK THE INSTRUMENT CLUSTER C220b FOR DAMAGE Key In OFF position. Disconnect: Instrument Cluster C220b. Inspect the instrument cluster C220b for damage. Is the instrument cluster C220b OK? Result / Action to Take Yes : GO to D2. No : REPAIR the instrument cluster C220b as necessary. TEST the system for normal operation.
D2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE INSTRUMENT CLUSTER C220b Measure the resistance between the instrument cluster C220b-15, circuit 4-EG8 (GY/VT), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the instrument cluster C220b-16, circuit 5-EG8 (BU/WH), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to D5 . No : GO to D3.
D3 CHECK FOR OPEN BETWEEN INSTRUMENT CLUSTER C220b AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the instrument cluster C220b-15, circuit 4-EG8 (GY/VT), harness side and joint connector No. 4 C223-13, circuit 4-EG8 (GY/VT), harness side. Measure the resistance between the instrument cluster C220b-16, circuit 5-EG8 (BU/WH), harness side and joint connector No. 4 C223-10, circuit 5-EG8 (BU/WH), harness side. Is the resistance less than 5 ohms? Yes : GO to D4. No : REPAIR the circuit in question. TEST the system for normal operation.
D4 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-10, component side. Measure the resistance between joint connector No. 4 C223-13, component side and joint connector No. 4 C223-14, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. TEST the system for normal operation. No : REPAIR joint connector No. 4 as necessary. TEST the system for normal operation.
D5 CHECK FOR CORRECT INSTRUMENT CLUSTER OPERATION Disconnect all the instrument cluster connectors. Check for: corrosion push-out pins Connect all the instrument cluster connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new instrument cluster. REFER to «INFORMATION, GAUGES & WARNING DEVICES»(ref-207563) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST E: No Powertrain Control Module (PCM) Standard Corporate Protocol (SCP) Network Communication

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 56

Scheme 56: PINPOINT TEST E: NO POWERTRAIN CONTROL MODULE (PCM) STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUN

Scheme 57

E1 CHECK THE PCM C175a FOR DAMAGE Key in OFF position. Disconnect: PCM C175a. Inspect the PCM C175a for damage. Is the PCM C175 a OK? Result / Action to Take Yes : GO to E2. No : REPAIR the PCM C175a as necessary. TEST the system for normal operation.
E2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE PCM C175a Measure the resistance between the PCM C175a-3, circuit 4-RE8 (GY), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the PCM C175a-4, circuit 5-RE8(BU), harness side and the DLCC251-10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to E3. No : REPAIR the circuit in question. TEST the system for normal operation.
E3 CHECK FOR CORRECT PCM OPERATION Disconnect all the PCM connectors. Check for: corrosion push-out pins Connect all the PCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new PCM. REFER to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V) - LS»(ref-207555) or «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L - LS»(ref-207556) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST F: The Dual Automatic Temperature Control (DATC) Module Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 58

Scheme 58: PINPOINT TEST F: THE DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) MODULE DOES NOT RESPOND TO THE DIAGNO

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

F1 CHECK THE DATC MODULE C228a FOR DAMAGE Key in OFF position. Disconnect: DATC Module C228a. Inspect the DATC module C228a for damage. Is the DATC module C228a ok? Result / Action to Take Yes : GO to F2. No : REPAIR the DATC module C228a as necessary. TEST the system for normal operation.
F2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE DATC MODULE C228a Measure the resistance between the DATC module C228a-12, circuit 4-FA10 (GY/BK), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the DATC module C228a-1, circuit 5-FA10 (BU/YE), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to F5 . No : GO to F3.
F3 CHECK FOR AN OPEN BETWEEN THE DATC MODULE C228a AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the DATC module C228a-12, circuit 4-FA10 (GY/BK), harness side and joint connector No. 4 C223-15, circuit 4-FA10 (GY/BK), harness side. Measure the resistance between the DATC module C228a-1, circuit 5-FA10 (BU/YE), harness side and joint connector No. 4 C223-8, circuit 5-FA10 (BU/YE), harness side. Are the resistances less than 5 ohms? Yes : GO to F4. No : REPAIR the circuit in question. TEST the system for normal operation.
F4 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-14, component side and joint connector No. 4 C223-15, component side. Measure the resistance between joint connector No. 4 C223-8, component side and joint connector No. 4 C223-9, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
F5 CHECK FOR CORRECT DATC MODULE OPERATION Disconnect all the DATC module connectors. Check for: corrosion push-out pins Connect all the DATC module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new DATC module. REFER to «CLIMATE CONTROL SYSTEM»(ref-207561) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST G: The Audio Control Module (ACM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 64

Scheme 64: PINPOINT TEST G: THE AUDIO CONTROL MODULE (ACM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

G1 CHECK THE ACM C240c FOR DAMAGE Key in OFF position. Disconnect: ACM C240c. Inspect the ACM C240c for damage. Is the ACM C240c OK? Result / Action to Take Yes : GO to G2. No : REPAIR the ACM C240c as necessary. TEST the system for normal operation.
G2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE ACM Measure the resistance between the ACM C240c-3, circuit 4-EG10 (GY/BK), or ACM C290c-1, circuit 4-EG10 (GY/BK) DM1 00i only, harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the ACM C240c-4, circuit 5-EG10 (BU/YE), or ACM C290c-4, circuit 5-EG10 (BU/YE) DM1 00i only, harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to G5 . No GO to G3.
G3 CHECK FOR AN OPEN BETWEEN THE ACM AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the ACM C240c-3, circuit 4-EG10 (GY/BK), or ACM C290c-1, circuit 4-EG10 (GY/BK) DM1 00i only, harness side and joint connector No. 4 C223-16, circuit 4-EG10 (GY/BK), harness side. Measure the resistance between the ACM C290c-4, circuit 5-EG10 (BU/YE), or ACM C290c-4, circuit 5-EG10 (BU/YE) DM1 00i only, harness side and joint connector No. 4 C223-7, circuit 5-EG10 (BU/YE), harness side. Are the resistances less than 5 ohms? Yes : GO to G4. No : REPAIR the circuit in question. TEST the system for normal operation.
G4 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-14, component side and joint connector No. 4 C223-16, component side. Measure the resistance between joint connector No. 4 C223-7, component side and joint connector No. 4 C223-9, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No.4C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
G5 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion push-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new ACM. REFER to «ENTERTAINMENT SYSTEM - LS»(ref-207564) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST H: The Powertrain Control Module (PCM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 70

Scheme 70: PINPOINT TEST H: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 71

H1 CHECK THE PCM C175a FOR DAMAGE Key in OFF position. Disconnect: PCM C175a. Inspect the PCM C175a for damage. Is the PCM C175 a OK? Result / Action to Take Yes : GO to H2. No : REPAIR the PCM C175a as necessary. TEST the system for normal operation.
H2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE PCM C175a Measure the resistance between the PCM C175a-53, circuit 4-EC7 (GY/RD), harness side and the DLC C251 -6, circuit 4-EC7 (GY/RD), harness side. Measure the resistance between the PCM C175a-54, circuit 5-EC7 (BU/RD), harness side and the DLC C251 -14, circuit 5-EC7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to H3. No : REPAIR the circuit in question. TEST the system for normal operation.
H3 CHECK FOR CORRECT PCM OPERATION Disconnect all the PCM connectors. Check for: corrosion push-out pins Connect all the PCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new PCM. REFER to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V) - LS»(ref-207555) or «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L - LS»(ref-207556) .TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST I: The Driver Seat Module (DSM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 72

Scheme 72: PINPOINT TEST I: THE DRIVER SEAT MODULE (DSM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

I1 CHECK THE DSM 341c FOR DAMAGE Key in OFF position. Disconnect: DSM C341c. Inspect the DSM C341 c for damage. Is the DSM C341c OK? Result / Action to Take Yes : GO to I2. No : REPAIR the DSMC341cas necessary. TEST the system for normal operation.
I2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE DSM 341c Measure the resistance between the DSM C341c-1, circuit 4-AH80 (GY/WH), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the DSM C341c-9, circuit 5-AH80 (BU/OG), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to I7 . No : GO to I3.
I3 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE DSM 341c Disconnect: Interior AJB C283a. Measure the resistance between the DSM C341c-1, circuit 4-AH80 (GY/WH), harness side and the interior AJB C283a-16, circuit 4-AH80 (GY/WH), harness side. Measure the resistance between the DSM C341c-9, circuit 5-AH80 (BU/OG), harness side and the interior AJB C283a-12, circuit 5-AH80 (BU/OG), harness side. Are the resistances less than 5 ohms? Yes : GO to I4. No : Repair the circuit in question. TEST the system for normal operation.
I4 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE INTERIOR AJB C283d Disconnect: Interior AJB C293d. Measure the resistance between the interior AJB C283a-16, component side and the interior AJB C283d-16, component side. Measure the resistance between the interior AJB C283a-12, component side and the interior AJB C283d-12, component side. Are the resistances less than 5 ohms? Yes : GO to I5. No : INSTALL a new AJB. TEST the system for normal operation.
I5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to I6. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
I6 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN BETWEEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
I7 CHECK FOR CORRECT DSM OPERATION Disconnect all the DSM connectors. Check for: corrosion push-out pins Connect all the DSM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new DSM. REFER to «DRIVER SEAT MODULE (DSM)»(ref-207567-S25576335262005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST J: The Driver Door Module (DDM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 82

Scheme 82: PINPOINT TEST J: THE DRIVER DOOR MODULE (DDM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

J1 CHECK THE DDM C501a FOR DAMAGE Key in OFF position. Disconnect: DDM C501 a. Inspect the DDM C501 a for damage. Is the DDM C501 a OK? Result / Action to Take Yes : GO to J2. No : REPAIR the DDM C501a as necessary. TEST the system for normal operation.
J2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE DDM C501a Measure the resistance between the DDM 501 a-3, circuit 4-EG13(GY/OG), harness side and the DLCC251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the DDM 501 a-4, circuit 5-EG13 (BU/BK), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to J7 . No : GO to J3.
J3 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE DDM C501a Disconnect: Interior AJB C283a. Measure the resistance between the DDM 501 a-3, circuit 4-EG13 (GY/OG), harness side and the interior AJB C283a-8, circuit 4-EG13 (GY/OG), harness side. Measure the resistance between the DDM 501 a-4, circuit 5-EG13 (BU/BK), harness side and the interior AJB C283a-4, circuit 5-EG13 (BU/BK), harness side. Are the resistances less than 5 ohms? Yes : GO to J4. No : REPAIR the circuit in question. TEST the system for normal operation.
J4 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283a-8, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283a-4, component side. Are the resistances less than 5 ohms? Yes : GO to J5. No : INSTALL a new AJB. TEST the system for normal operation.
J5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to J6. No : REPAIR the circuit in question. TEST the system for normal operation.
J6 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
J7 CHECK FOR CORRECT DDM OPERATION Disconnect all the DDM connectors. Check for: corrosion push-out pins Connect all the DDM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new DDM. REFER to «DRIVER DOOR MODULE (DDM)»(ref-207567-S36459878162005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST K: The Rear Electronic Module (REM) Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 92

Scheme 92: PINPOINT TEST K: THE REAR ELECTRONIC MODULE (REM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

K1 CHECK THE REM C420b FOR DAMAGE Key in OFF position. Disconnect: REM C420b. Inspect the REM C420b for damage. Is the REM C420b OK? Result / Action to Take Yes : GO to K2. No : REPAIR the REM C420b as necessary. TEST the system for normal operation.
K2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE REM C420b Measure the resistance between the REM C420b-1, circuit 4-EG12 (GY/WH), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the REM C420b-2, circuit 5-EG12 (BU/OG), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to K7 . No : GO to K3.
K3 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE REM C420b Disconnect the interior AJB C283b. Measure the resistance between the REM C420b-1, circuit 4-EG12 (GY/WH), harness side and the interior AJB C283b-16, circuit 4-EG12 (GY/WH), harness side. Measure the resistance between the REM C420b-2, circuit 5-EG12 (BU/OG), harness side and the interior AJB C283b-12, circuit 5-EG12 (BU/OG), harness side. Are the resistances less than 5 ohms? Yes : GO to K4. No : REPAIR the circuit in question. TEST the system for normal operation.
K4 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283b-16, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283b-12, component side. Are the resistances less than 5 ohms? Yes : GO to K5. No : INSTALL a new interior AJB. TEST the system for normal operation.
K5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to K6. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
K6 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
K7 CHECK FOR CORRECT REM OPERATION Disconnect all the REM connectors. Check for: corrosion push-out pins Connect all the REM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new REM. REFER to «REAR ELECTRONIC MODULE (REM)»(ref-207567-S36410120272005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 102

Scheme 102: PINPOINT TEST L: THE NAVIGATION SYSTEM MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

L1 CHECK THE NAVIGATION SYSTEM MODULE C4209 FOR DAMAGE Key in OFF position. Disconnect: Navigation System Module C4209. Inspect the navigation system module C4209 for damage. Is the navigation system module C4209 OK? Result / Action to Take Yes : GO to L2. No : REPAIR the navigation system module C4209 as necessary. TEST the system for normal operation.
L2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE NAVIGATION SYSTEM MODULE C4209 Measure the resistance between the navigation system module C4209-4, circuit 4-EG17 (GY/BK), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the navigation system module C4209-16, circuit 5-EG17 (BU/YE), harness side and the DLC C251-10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to L9 . No : GO to L3.
L3 CHECK FOR AN OPEN BETWEEN JOINT CONNECTOR No. 5 C427 AND THE NAVIGATION SYSTEM MODULE C4209 Disconnect: Joint Connector No. 5 C427. Measure the resistance between the navigation system module C4209-4, circuit 4-EG17 (GY/BK), harness side and joint connector No. 5 C427-4, circuit 4-EG17 (GY/BK), harness side. Measure the resistance between the navigation system module C4209-16, circuit 5-EG17 (BU/YE), harness side and joint connector No. 5 C427-15, circuit 5-EG17 (BU/YE), harness side. Are the resistances less than 5 ohms? Yes : GO to L4. No : REPAIR the circuit in question. TEST the system for normal operation.
L4 CHECK JOINT CONNECTOR No. 5 FOR AN OPEN Measure the resistance between joint connector No. 5 C427-1, component side and joint connector No. 5 C427-4, component side. Measure the resistance between joint connector No. 5 C427-12, component side and joint connector No. 5 C427-15, component side. Are the resistances less than 5 ohms? Yes : GO to L5. No : REPAIR joint connector No. 5 C427 as necessary. TEST the system for normal operation.
L5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND JOINT CONNECTOR No. 5 C427 Disconnect: Interior AJB C283b. Measure the resistance between the interior AJB C283b-8, circuit 4-EG1 (GY/RD), harness side and joint connector No. 5 C427-1, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283b-4, circuit 5-EG1 (BU/RD), harness side and joint connector No. 5 C427-12, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to L6. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
L6 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283b-8, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283b-4, component side. Are the resistances less than 5 ohms? Yes : GO to L7. No : INSTALL a new interior AJB. TEST the system for normal operation.
L7 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to L8. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
L8 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
L9 CHECK FOR CORRECT NAVIGATION SYSTEM MODULE OPERATION Disconnect all the navigation system module connectors. Check for: corrosion push-out pins Connect all the navigation system module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new navigation system module. REFER to «ELECTRONIC FEATURE»(ref-207569) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST M: The Driver Temperature Controlled Seat Module Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 116

Scheme 116: PINPOINT TEST M: THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TO

Scheme 117

Scheme 118

Scheme 119

Scheme 120

M1 CHECK THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE C3031a FOR DAMAGE Key in OFF position. Disconnect: Driver Temperature Controlled Seat Module C3031a. Inspect the driver temperature controlled seat module C3031a for damage. Is the driver temperature controlled seat module C3031a OK? Result / Action to Take Yes : GO to M2. No : REPAIR the driver temperature controlled seat module C3031a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M2 CHECK CIRCUIT 4-HC21 (GY/OG) BETWEEN THE DLC C251 AND THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE C3031a FOR AN OPEN Measure the resistance between the driver temperature controlled seat module C3031 a-1, circuit 4-HC21 (GY/OG), harness side and the DLC C251-3, circuit 4-ED6 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to M9 . No : GO to M3.
M3 CHECK IN-LINE C315 FOR DAMAGE Disconnect: In-Line C315. Inspect in-lines C315M and C315F for damage. Are in-lines C315M and OK? Yes : GO to M4. No : REPAIR in-lines C315M and CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M4 CHECK CIRCUIT 4-HC21 (GY/OG) BETWEEN IN-LINE C315F AND THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE C3031a FOR AN OPEN Measure the resistance between the driver temperature controlled seat module C3031 a-1, circuit 4-HC21 (GY/OG), harness side and in-line C315M-10, circuit 4-HC21 (GY/OG), harness side. Is the resistance less than 5 ohms? Yes : GO to M5. No : REPAIR the circuit between in-line C315M and the driver temperature controlled seat module C3031a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M5 CHECK IN-LINE C213 FOR DAMAGE Disconnect: In-Line C213. Inspect in-lines C213M and C213F for damage. Are in-lines C213M and OK? Yes : GO to M6. No : REPAIR in-lines C213M and C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M6 CHECK CIRCUIT 4-HC21 (GY/OG) BETWEEN IN-LINE C315F AND IN-LINE C213F FOR AN OPEN Measure the resistance between in-line C213F-11, circuit 4-HC1 (GY/RD), harness side and in-line C315M-10, circuit 4-HC21 (GY/OG), harness side. Is the resistance less than 5 ohms? Yes : GO to M7. No : REPAIR the circuit between in-line C315F and in-line C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M7 CHECK CIRCUIT 4-HC1 (GY/RD) BETWEEN IN-LINE C213M AND JOINT CONNECTOR No. 1 C261 FOR AN OPEN Measure the resistance between in-line C213M-11, circuit 4-HC1 (GY/RD), harness side and joint connector No. 1 C261 -11, circuit 4-HC1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to M8. No : REPAIR the circuit between in-line C213M and joint connector No. 1 C261. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M8 CHECK JOINT CONNECTOR No. 1 FOR AN OPEN Measure the resistance between joint connector No. 1 C261 -10, component side and joint connector No. 1 C261 -11, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between joint connector No. 1 C261 and the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 1 C261 as necessary. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
M9 CHECK FOR CORRECT DRIVER TEMPERATURE CONTROLLED SEAT MODULE OPERATION Disconnect all the driver temperature controlled seat module connectors. Check for: Corrosion push-out pins Connect all the driver temperature controlled seat module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new driver temperature controlled seat module. REFER to «SEATING»(ref-207572) .TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST N: The Passenger Temperature Controlled Seat Module Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 121

Scheme 121: PINPOINT TEST N: THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE DOES NOT RESPOND TO THE DIAGNOSTIC

Scheme 122

Scheme 123

Scheme 124

Scheme 125

N1 CHECK THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE C3036a FOR DAMAGE Key in OFF position. Disconnect: Passenger Temperature Controlled Seat Module C3036a. Inspect the passenger temperature controlled seat module C3036a for damage. Is the passenger temperature controlled seat module C3036a OK? Result / Action to Take Yes : GO to N2. No : REPAIR the passenger temperature controlled seat module C3036a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N2 CHECK CIRCUIT 4-HC22 (GY) BETWEEN THE DLC C251 AND THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE C3036a FOR AN OPEN Measure the resistance between the passenger temperature controlled seat module C3036a-1, circuit 4-HC22 (GY), harness side and the DLC C251 -3, circuit 4-ED6 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to N9 . No : GO to N3.
N3 CHECK IN-LINE C313 FOR DAMAGE Disconnect: In-Line C313. Inspect in-lines C313M and C313F for damage. Are in-lines C313M and C313FOK? Yes : GO to N4. No : REPAIR in-lines C313M and C313F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N4 CHECK CIRCUIT 4-HC22 (GY) BETWEEN IN-LINE C313F AND THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE C3036a FOR AN OPEN Measure the resistance between the passenger temperature controlled seat module C3036a-1, circuit 4-HC22 (GY), harness side and in-line C313M-10, circuit 4-HC22 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to N5. No : REPAIR the circuit between in-line C313M and the passenger temperature controlled seat module C3036a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N5 CHECK IN-LINE C213 FOR DAMAGE Disconnect: In-Line C213. Inspect in-lines C213M and C213F for damage. Are in-lines C213M and C213FOK? Yes : GO to N6. No : REPAIR in-lines C213M and C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N6 CHECK CIRCUIT 4-HC22 (GY) BETWEEN IN-LINE C313F AND IN-LINE C213F FOR AN OPEN Measure the resistance between in-line C213F-11, circuit 4-HC1 (GY/RD), harness side and in-line C313F-10, circuit 4-HC22 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to N7. No : REPAIR the circuit between in-line C313F and in-line C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N7 CHECK CIRCUIT 4-HC1 (GY/RD) BETWEEN IN-LINE C213M AND JOINT CONNECTOR No. 1 C261 FOR AN OPEN Measure the resistance between in-line C213M-11, circuit 4-HC1 (GY/RD), harness side and joint connector No. 1 C261 -11, circuit 4-HC1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to N8. No : REPAIR the circuit between in-line C213M and joint connector No. 1 C261. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N8 CHECK JOINT CONNECTOR No. 1 FOR AN OPEN Measure the resistance between joint connector No. 1 C261 -10, component side and joint connector No. 1 C261 -11, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between joint connector No. 1 C261 and the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 1 C261 as necessary. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
N9 CHECK FOR CORRECT PASSENGER TEMPERATURE CONTROLLED SEAT MODULE OPERATION Disconnect all the passenger temperature controlled seat module connectors. Check for: corrosion push-out pins Connect all the passenger temperature controlled seat module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new passenger temperature controlled seat module. REFER to «SEATING»(ref-207572) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST O: No Standard Corporate Protocol (SCP) Network Communication

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 126

Scheme 126: PINPOINT TEST O: NO STANDARD CORPORATE PROTOCOL (SCP) NETWORK COMMUNICATION

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

O1 CHECK THE DLC C251 FOR DAMAGE Key in OFF position. Inspect the DLC C251 for damage. Is the DLC C251 OK? Result/ Action to Take Yes : GO to O2. No : REPAIR the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O2 CHECK THE PCM C175a FOR DAMAGE Key in OFF position. Disconnect: PCM C175a. Inspect the PCM C175a for damage. Is the PCM C175a OK? Yes : GO to O3. No : REPAIR the PCM C175a as necessary. TEST the system for normal operation.
O3 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE PCM C175a Measure the resistance between the PCM C175a-3, circuit 4-RE8 (GY), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the PCM C175a-4, circuit 5-RE8 (BU), harness side and the DLC C251-10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O8 . No : GO to O4.
O4 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE PCM C175a Disconnect: Interior AJB C283c. Measure the resistance between the PCM C175a-3, circuit 4-RE8 (GY), harness side and the interior AJB C283c-4, circuit 4-RE8 (GY), harness side. Measure the resistance between the PCM C175a-4, circuit 5-RE8 (BU), harness side and the interior AJB C283c-1, circuit 5-RE8 (BU), harness side. Are the resistances less than 5 ohms? Yes : GO to O5. No : REPAIR the circuit in question. TEST the system for normal operation.
O5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283c-4, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283c-1, component side. Are the resistances less than 5 ohms? Yes : GO to O6. No : INSTALL a new AJB. TEST the system for normal operation.
O6 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O7. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O7 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O8 CHECK THE SCP NETWORK WITH THE PCM C175a DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O77 . No : GO to O9.
O9 CHECK THE ABS/TC CONTROL MODULE OR STABILITY ASSIST MODULE FOR DAMAGE Key in OFF position. Connect: PCM C175a. Connect: Interior AJB C283c and C283d. Connect: Joint Connector No. 4 C223. Disconnect: ABS/TC module C135, or the stability assist module C155. Inspect the ABS/TC module C135 or stability assist module C155 for damage. Is the ABS/TC module C135 or stability assist module C155 ok? Yes : GO to O10. No : REPAIR the ABS/TC module C135 or stability assist module C155 as necessary. TEST the system for normal operation.
O10 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE ABS/TC MODULE C135 OR THE STABILITY ASSIST MODULE C155 If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-12, circuit 4-CF6 (GY), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-12, circuit 4-CF6 (GY), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-14, circuit 5-CF6 (BU), harness side and the C251 -10, circuit 5 -EG7 (BU/RD), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-14, circuit 5-CF6 (BU), harness side and the C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O15 . No : GO to O11.
O11 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND ABS/TC MODULE C135 OR STABILITY ASSIST MODULE C155 Disconnect: Interior AJB C283c. If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-12, circuit 4-CF6 (GY), harness side and the interior AJB C283c-5, circuit 4-CF6 (GY), harness side. If equipped with a stability assist module, measure the resistance between the stability assist module C155-12, circuit 4-CF6 (GY), harness side and the interior AJB C283c-5, circuit 4-CF6 (GY), harness side. If equipped with an ABS/TC module, measure the resistance between the ABS/TC module C135-14, circuit 5-CF6 (BU), harness side and the interior AJB C283c-6, circuit 5-CF6 (BU), harness side. If equipped with a stability assist module, measure the resistance between the stability assist control module C155-14, circuit 5 -CF6 (BU), harness side and the interior AJB C283c-6, circuit 5-CF6 (BU), harness side. Are the resistances less than 5 ohms? Yes : GO to O12. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O12 CHECK FOR AN OPEN BETWEEN INTERIOR AJB C283c AND INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, and the interior AJB C283c-5, component side. Measure the resistance between the interior AJB C283d-12, and the interior AJB C283c-6, component side. Are the resistances less than 5 ohms? Yes : GO to O13. No : INSTALL a new interior AJB. TEST the system for normal operation.
O13 CHECK FOR AN OPEN BETWEEN INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-22, circuit 5 -EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O14. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O14 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O15 CHECK THE SCP NETWORK WITH THE ABS/TC C135 OR STABILITY ASSIST MODULE C155 DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O78 . No : GO to O16.
O16 CHECK THE DATC MODULE C228a FOR DAMAGE Key in OFF position. Connect: ABS/TC module C135, or stability assist module C155. Connect: Interior AJB C283c and C283d. Connect: Joint Connector No. 4 C223. Disconnect: DATC Module C228a. Inspect the DATC module C228a for damage. Is the DATC module C228a ok? Yes : GO to O17. No : REPAIR the DATC module C228a as necessary. TEST the system for normal operation.
O17 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE DATC MODULE C228a Measure the resistance between the DATC module C228a-12, circuit 4-FA10 (GY/BK), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the DATC module C228a-1, circuit 5-FA10 (BU/YE), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O20 . No : GO to O18.
O18 CHECK FOR AN OPEN BETWEEN THE DATC MODULE C228a AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the DATC module C228a-12, circuit 4-FA10 (GY/BK), harness side and joint connector No. 4 C223-15, circuit 4-FA10 (GY/BK), harness side. Measure the resistance between the DATC module C228a-1, circuit 5-FA10 (BU/YE), harness side and joint connector No. 4 C223-8, circuit 5-FA10 (BU/YE), harness side. Are the resistances less than 5 ohms? Yes : GO to O19. No : REPAIR the circuit in question. TEST the system for normal operation.
O19 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-14, component side and joint connector No. 4 C223-15, component side. Measure the resistance between joint connector No. 4 C223-8, component side and joint connector No. 4 C223-9, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O20 CHECK THE SCP NETWORK WITH THE DATC MODULE C228b DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O79 . No : GO to O21.
O21 CHECK THE INSTRUMENT CLUSTER C220b FOR DAMAGE Key In OFF position. Connect: DATC module C228a. Connect: Joint Connector No. 4 C223. Disconnect: Instrument Cluster C220b. Inspect the instrument cluster C220b for damage. Is the instrument cluster C220b OK? Yes : GO to O22. No : REPAIR the instrument cluster C220b as necessary. TEST the system for normal operation.
O22 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE INSTRUMENT CLUSTER C220b Measure the resistance between the instrument cluster C220b-15, circuit 4-EG8 (GY/VT), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the instrument cluster C220b-16, circuit 5-EG8 (BU/WH), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to O25 . No : GO to O23.
O23 CHECK FOR AN OPEN BETWEEN THE INSTRUMENT CLUSTER C220b AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between instrument cluster C220b-15, circuit 4-EG8 (GY/VT), harness side and joint connector No. 4 C223-13, circuit 4-EG8 (GY/VT), harness side. Measure the resistance between instrument cluster C220b-16, circuit 5-EG8 (BU/WH), harness side and joint connector No. 4 C223-10, circuit 5-EG8 (BU/WH), harness side. Is the resistance less than 5 ohms? Yes : GO to O24. No : REPAIR the circuit in question. TEST the system for normal operation.
O24 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-13, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-10, component side and joint connector No. 4 C223-9, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. TEST the system for normal operation. No : REPAIR joint connector No. 4 as necessary. TEST the system for normal operation.
O25 CHECK SCP NETWORK WITH THE INSTRUMENT CLUSTER C220b DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O80 . No : GO to O26.
O26 CHECK THE NAVIGATION SYSTEM MODULE C4209 FOR DAMAGE Key in OFF position. Connect: Instrument Cluster C220b. Connect: Joint Connector No. 4 C223. Disconnect: Navigation System Module C4209. Inspect the navigation system module C4209 for damage. Is the navigation system module C4209 OK? Yes : GO to O27. No : REPAIR the navigation system module C4209 as necessary. TEST the system for normal operation.
O27 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE NAVIGATION SYSTEM MODULE C4209 Measure the resistance between the navigation system module C4209-4, circuit 4-EG17 (GY/BK), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the navigation system module C4209-16, circuit 5-EG17 (BU/YE), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O34 . No : GO to O28.
O28 CHECK FOR AN OPEN BETWEEN JOINT CONNECTOR No. 5 C427 AND THE NAVIGATION SYSTEM MODULE C4209 Disconnect: Joint Connector No. 5 C427. Measure the resistance between the navigation system module C4209-4, circuit 4-EG17 (GY/BK), harness side and joint connector No. 5 C427-4, circuit 4-EG17 (GY/BK), harness side. Measure the resistance between the navigation system module C4209-16, circuit 5-EG17 (BU/YE), harness side and joint connector No. 5 C427-15, circuit 5-EG17 (BU/YE), harness side. Are the resistances less than 5 ohms? Yes : GO to O29. No : REPAIR the circuit in question. TEST the system for normal operation.
O29 CHECK JOINT CONNECTOR No. 5 FOR AN OPEN Measure the resistance between joint connector No. 5 C427-1, component side and joint connector No. 5 C427-4, component side. Measure the resistance between joint connector No. 5 C427-12, component side and joint connector No. 5 C427-15, component side. Are the resistances less than 5 ohms? Yes : GO to O30. No : REPAIR joint connector No. 5 C427 as necessary. TEST the system for normal operation.
O30 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND JOINT CONNECTOR No. 5 C427 Disconnect: Interior AJB C283b. Measure the resistance between the interior AJB C283b-8, circuit 4-EG1 (GY/RD), harness side and joint connector No. 5 C427-1, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283b-4, circuit 5-EG1 (BU/RD), harness side and joint connector No. 5 C427-12, circuit 5 -EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O31. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O31 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283b-8, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283b-4, component side. Are the resistances less than 5 ohms? Yes : GO to O32. No : INSTALL a new interior AJB. TEST the system for normal operation.
O32 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O33. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O33 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O34 CHECK THE SCP NETWORK WITH THE NAVIGATION SYSTEM MODULE C4209 DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O81 . No : GO to O35.
O35 CHECK THE ACM C240c FOR DAMAGE Key in OFF position. Connect: Navigation System Module C4209. Connect: Interior AJB C283b and C283d. Connect: Joint Connector No. 5 C427. Connect: Joint Connector No. 4 C223. Disconnect: ACM C290c. Inspect ACM C290c for damage. Is the ACM C290c OK? Yes : GO to O36. No : REPAIR the ACM C290c as necessary. TEST the system for normal operation.
O36 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE ACM Measure the resistance between the ACM C290c-3, circuit 4-EG10 (GY/BK), or ACM C290c-1, circuit 4-EG10 (GY/BK) DM1 00i only, harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the ACM C290c-4, circuit 5-EG10 (BU/YE), or ACM C290c-4, circuit 5-EG10 (BU/YE) DM1 00i only, harness side and the DLC C251-10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O39 . No : GO to O37.
O37 CHECK FOR AN OPEN BETWEEN THE ACM AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the ACM C290c-3, circuit 4-EG10 (GY/BK), or ACM C290c-1 circuit 4-EG10 (GY/BK) DM1 00i only, harness side and joint connector No. 4 C223-16, circuit 4-EG10 (GY/BK), harness side. Measure the resistance between the ACM C290c-4, circuit 5-EG10 (BU/YE), or ACM C290c-4 circuit 5-EG10 (BU/YE) DM1 00i only, harness side and joint connector No. 4 C223-7, circuit 5-EG10 (BU/YE), harness side. Are the resistances less than 5 ohms? Yes : GO to O38. No : REPAIR the circuit in question. TEST the system for normal operation.
O38 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-16, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-7, component side and joint connector No. 4 C223-9, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O39 CHECK THE SCP NETWORK WITH THE ACM C240c DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O82 . No : GO to O40.
O40 CHECK THE REM C420b FOR DAMAGE Key in OFF position. Connect: ACM C290c. Connect: Joint Connector No. 4 C223. Disconnect: REM C420b. Inspect the REM C420b for damage. Is the REM C420b OK? Yes : GO to O41. No : REPAIR the REM C420b as necessary. TEST the system for normal operation.
O41 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE REM C420b Measure the resistance between the REM C420b-1, circuit 4-EG12 (GY/WH), harness side and the DLC C251 -2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the REM C420b-2, circuit 5-EG12 (BU/OG), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O46 . No : GO to O42.
O42 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE REM C420b Disconnect: Interior AJB C283b. Measure the resistance between the REM C420b-1, circuit 4-EG12 (GY/WH), harness side and the interior AJB C283b-16, circuit 4 -EG11 (GY), harness side. Measure the resistance between the REM C420b-2, circuit 5-EG12 (BU/OG), harness side and the interior AJB C283b-12, circuit 5-EG11 (BU), harness side. Are the resistances less than 5 ohms? Yes : GO to O43. No : REPAIR the circuit in question. TEST the system for normal operation.
O43 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283b-16, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283b-12, component side. Are the resistances less than 5 ohms? Yes : GO to O44 . No : INSTALL a new AJB. TEST the system for normal operation.
O44 CHECK FOR AN OPEN BETWEEN INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between interior the AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O45. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O45 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O46 CHECK THE SCP NETWORK WITH THE REM C420b DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O83 . No : GO to O47.
O47 CHECK THE FEM C201c FOR DAMAGE Key in OFF position. Connect: REM C420b. Connect: Interior AJB C283b and C283d. Connect: Joint Connector No. 4 C223. Disconnect: the FEM C201c. Inspect the FEM C201 c for damage; repair as necessary. Is the FEM C201c OK? Yes : GO to O48. No : REPAIR the FEM C201c as necessary. TEST the system for normal operation.
O48 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE FEM C201c Measure the resistance between the FEM C201 c-7, circuit 4-EG11 (GY), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the FEM C201 c-1, circuit 5-EG11 (BU), harness side and the DLC C251-10, circuit 5-EG7 (BU/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to O53 . No : GO to O49.
O49 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE FEM C201c Disconnect: Interior ABJ C283c. Measure the resistance between the FEM C201 c-7, circuit 4-EG11 (GY), harness side and the interior AJB C283c-10, circuit 4-EG11 (GY), harness side. Measure the resistance between the FEM C201 c-1, circuit 5-EG11 (BU), harness side and the interior AJB C283c-8, circuit 5-EG11 (BU), harness side. Is the resistance less than 5 ohms? Yes : GO to O50. No : REPAIR the circuit in question. TEST the system for normal operation.
O50 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283c AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283c-10, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283c-8, component side. Are the resistances less than 5 ohms? Yes : GO to O51 . No : INSTALL a new AJB. TEST the system for normal operation.
O51 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-11, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-12, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O52. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O52 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-11, component side and joint connector No. 4 C223-9, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O53 CHECK THE SCP NETWORK WITH THE FEM C201c DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O84 . No : GO to O54.
O54 CHECK THE ELECTRONIC PARKING BRAKE MODULE C4205b FOR DAMAGE Key in OFF position. Connect: FEM C201c. Connect: Interior AJB C283c and C283d. Connect: Joint Connector No. 4 C223. Disconnect: Electronic Parking Brake Module C4205b. Inspect the electronic parking brake module C4205b for damage. Is the electronic parking brake module C4205b OK? Yes : GO to O55. No : REPAIR the electronic parking brake module C4205b as necessary. TEST the system for normal operation.
O55 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE ELECTRONIC PARKING BRAKE MODULE C4205b Measure the resistance between the electronic parking brake module C4205b-1, circuit 4-CG16 (GY/RD), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the electronic parking brake module C4205b-7, circuit 5-CG16 (BU/RD), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O62 . No : GO to O56.
O56 CHECK FOR AN OPEN BETWEEN JOINT CONNECTOR No. 5 C427 AND THE ELECTRONIC PARKING BRAKE MODULE C4205b Disconnect: Joint Connector No. 5 C427. Measure the resistance between the electronic parking brake module C4205b-1, circuit 4-CG16 (GY/RD), harness side and joint connector No. 5 C427-2, circuit 4-CG16 (GY/RD), harness side. Measure the resistance between the electronic parking brake module C4205b-7, circuit 5-CG16 (BU/RD), harness side and joint connector No. 5 C427-13, circuit5-CG16 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O57. No : REPAIR the circuit in question. TEST the system for normal operation.
O57 CHECK JOINT CONNECTOR No. 5 FOR AN OPEN Measure the resistance between joint connector No. 5 C427-1, component side and joint connector No. 5 C427-2, component side. Measure the resistance between joint connector No. 5 C427-12, component side and joint connector No. 5 C427-13, component side. Are the resistances less than 5 ohms? Yes : GO to O58. No : REPAIR joint connector No. 5 C427 as necessary. TEST the system for normal operation.
O58 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND JOINT CONNECTOR No. 5 C427 Disconnect: Interior Joint Connector No. 4 C283b. Measure the resistance between the interior AJB C283b-8, circuit 4-EG1 (GY/RD), harness side and joint connector No. 5 C427-1, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283b-4, circuit 5-EG1 (BU/RD), harness side and joint connector No. 5 C427-12, circuit 5 -EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O59. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O59 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283b-8, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283b-4, component side. Are the resistances less than 5 ohms? Yes : GO to O60. No : INSTALL a new interior AJB. TEST the system for normal operation.
O60 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O61. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O61 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O62 CHECK THE SCP NETWORK WITH THE ELECTRONIC PARKING BRAKE C4205b DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O85 . No : GO to O63.
O63 CHECK THE DSM C341c FOR DAMAGE Key in OFF position. Connect: Electronic Parking Brake Module C4205b. Connect: Interior AJB C283b, C283c. Connect: Joint Connector No. 4 C223. Connect: Joint Connector No. 5 C427. Disconnect: DSM C341c. Inspect the DSM C341 c for damage. Is the DSM C341c OK? Yes : GO to O64. No : REPAIR the DSM C341c as necessary. TEST the system for normal operation.
O64 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE DSM 341c Measure the resistance between the DSM C341c-1, circuit 4-AH80 (GY/WH), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the DSM C341c-9, circuit 5-AH80 (BU/OG), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O69 . No : GO to O65.
O65 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE DSM 341c Disconnect: Interior AJB C283a. Measure the resistance between the DSM C341c-1, circuit 4-AH80 (GY/WH), harness side and the interior AJB C283a-16, circuit 4-AH80 (GY/WH), harness side. Measure the resistance between the DSM C341c-9, circuit 5-AH80 (BU/OG), harness side and the interior AJB C283a-12, circuit 5-AH80 (BU/OG), harness side. Are the resistances less than 5 ohms? Yes : GO to O66. No : Repair the circuit in question. TEST the system for normal operation.
O66 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283a-16, component side and the interior AJB C283d-16, component side. Measure the resistance between the interior AJB C283a-12, component side and the interior AJB C283d-12, component side. Are the resistances less than 5 ohms? Yes : GO to O67. No : INSTALL a new interior AJB. TEST the system for normal operation.
O67 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O68. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
O68 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLCC251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O69 CHECK THE SCP NETWORK WITH THE DSM C341c DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O86 . No : GO to O70.
O70 CHECK THE DDM C501a FOR DAMAGE Key in OFF position. Connect: DSM C341c. Connect: In-line C315. Connect: Interior AJB C283a, C283c. Connect: Joint Connector No. 4 C223. Disconnect: DDM C501a. Inspect the DDM C501 a for damage. Is the DDM C501a OK? Yes : GO to O71. No : REPAIR the DDM C501a as necessary. TEST the system for normal operation.
O71 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE DDM C501a Measure the resistance between the DDM 501 a-3, circuit 4-EG13 (GY/OG), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the DDM 501 a-4, circuit 5-EG13 (BU/BK), harness side and the DLC C251 -10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O76 . No : GO to O72.
O72 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE DDM C501a Disconnect: Interior AJB C283a. Measure the resistance between the DDM 501 a-3, circuit 4-EG13 (GY/OG), harness side and the interior AJB C283a-8, circuit 4-EG13 (GY/OG), harness side. Measure the resistance between the DDM 501 a-4, circuit 5-EG13 (BU/BK), harness side and the interior AJB C283a-4, circuit 5-EG13 (BU/BK), harness side. Are the resistances less than 5 ohms? Yes : GO to O73. No : REPAIR the circuit in question. TEST the system for normal operation.
O73 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283a AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283a-8, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283a-4, component side. Are the resistances less than 5 ohms? Yes : GO to O74. No : INSTALL a new AJB. TEST the system for normal operation.
O74 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to O75. No : REPAIR the circuit in question. TEST the system for normal operation.
O75 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
O76 CHECK THE SCP NETWORK WITH THE DDM C501a DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to O87 . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O77 CHECK FOR CORRECT PCM OPERATION Disconnect all the PCM connectors. Check for: corrosion push-out pins Connect all the PCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new PCM. REFER to «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.0L (4V) - LS»(ref-207555) or «INTAKE AIR, FUEL CHARGING, STARTING & ENGINE ELECTRONICS - 3.9L - LS»(ref-207556) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O78 CHECK FOR CORRECT ABS/TC CONTROL MODULE OR STABILITY ASSIST MODULE OPERATION Disconnect all the ABS/TC or stability assist module connectors. Check for: corrosion push-out pins Connect all the ABS/TC or stability assist control module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new ABS/TC module or stability assist module. REFER to «ANTI-LOCK CONTROL»(ref-207549) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O79 CHECK FOR CORRECT DATC OPERATION Disconnect all the DATC connectors. Check for: corrosion push-out pins Connect all the DATC connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new DATC module. REFER to «CLIMATE CONTROL SYSTEM»(ref-207561) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O80 CHECK FOR CORRECT INSTRUMENT CLUSTER OPERATION Disconnect all the instrument cluster connectors. Check for: corrosion push-out pins Connect all the instrument cluster connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new instrument cluster. REFER to «INFORMATION, GAUGES & WARNING DEVICES»(ref-207563) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O81 CHECK FOR CORRECT NAVIGATION SYSTEM MODULE OPERATION Disconnect all the navigation system module connectors. Check for: corrosion push-out pins Connect all the navigation system module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new navigation system module. REFER to «ELECTRONIC FEATURE»(ref-207569) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O82 CHECK FOR CORRECT ACM OPERATION Disconnect all the ACM connectors. Check for: corrosion push-out pins Connect all the ACM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new ACM. REFER to «ENTERTAINMENT SYSTEM - LS»(ref-207564) .TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O83 CHECK FOR CORRECT REM OPERATION Disconnect all the REM connectors. Check for: corrosion push-out pins Connect all the REM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new REM. REFER to «REAR ELECTRONIC MODULE (REM)»(ref-207567-S36553694272005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O84 CHECK FOR CORRECT FEM OPERATION Disconnect all the FEM connectors. Check for: corrosion push-out pins Connect all the FEM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new FEM. REFER to «FRONT ELECTRONIC MODULE (FEM)»(ref-207567-S09203141492005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O85 CHECK FOR CORRECT ELECTRONIC PARKING BRAKE MODULE OPERATION Disconnect all the electronic parking brake module connectors. Check for: corrosion push-out pins Connect all the electric parking brake module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new electronic parking brake module. REFER to «BRAKE SYSTEM»(ref-207548) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O86 CHECK FOR CORRECT DSM OPERATION Disconnect all the DSM connectors. Check for: corrosion push-out pins Connect all the DSM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new DSM. REFER to «DRIVER SEAT MODULE (DSM)»(ref-207567-S25576335262005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
O87 CHECK FOR CORRECT DDM OPERATION Disconnect all the DDM connectors. Check for: corrosion push-out pins Connect all the DDM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new DDM. REFER to «DRIVER DOOR MODULE (DDM)»(ref-207567-S36459878162005113000000) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST P: No International Standards Organization (ISO) 9141 Network Communication

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 232

Scheme 232: PINPOINT TEST P: NO INTERNATIONAL STANDARDS ORGANIZATION (ISO) 9141 NETWORK COMMUNICATION

Scheme 233

P1 CHECK THE DLC C251 FOR DAMAGE Key in OFF position. Inspect the DLC C251. Is the DLC C251 OK? Result / Action to Take Yes : GO to P2. No : REPAIR the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
P2 CHECK FOR AN OPEN CIRCUIT BETWEEN THE RCM C310a AND THE DLC C251 Deactivate the air bag system. Refer to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . Disconnect: RCM C31 0b. Inspect the RCM C31 0b for damage. Is the RCMC31 OK? Yes : GO to P3. No : REPAIR the RCM C31 0b as necessary. TEST the system for normal operation.
P3 CHECK FOR AN OPEN CIRCUIT BETWEEN THE RCM C310aANDTHEDLCC251 Measure the resistance between the DLC C251 -7, circuit 4-EE10 (GY/BK), harness side and the RCM C310b-11, circuit 4-EE1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to P5 . No : GO to P4.
P4 CHECK FOR AN OPEN CIRCUIT BETWEEN DLC C251 AND IN-LINE C212M Disconnect: in-line C212. Measure the resistance between the DLC C251 -7, circuit 4-EE10 (GY/BK), harness side and in-line C212F-8, circuit 4-EE10 (GY/BK), harness side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between the RCM C310b and in-line C212M. TEST the system for normal operation. No : REPAIR the circuit between the DLCC251 and in-line C212F. TEST the system for normal operation.
P5 CHECK THE ISO 9141 NETWORK WITH THE RCM C310a DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to P6. No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
P6 CHECK FOR CORRECT RCM OPERATION Disconnect all the RCM connectors. Check for: corrosion push-out pins Connect all the RCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new RCM. REFER to «AIR BAG RESTRAINT SYSTEMS»(ref-170294) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST Q: No Universal Asynchronous Recieve-Transmit (UART) Based Protocol (UBP) Network Communication

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 234

Scheme 234: PINPOINT TEST Q: NO UNIVERSAL ASYNCHRONOUS RECIEVE-TRANSMIT (UART) BASED PROTOCOL (UBP) NETWORK COMM

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Q1 CHECK THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE C3031a FOR DAMAGE Key in OFF position. Disconnect: driver temperature controlled seat module C3031 a. Inspect the driver temperature controlled seat module C3031 a for damage. Is the driver temperature controlled seat module C3031a OK? Result / Action to Take Yes : GO to Q2. No : REPAIR the driver temperature controlled seat module C3031a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q2 CHECK CIRCUIT 4-HC21 (GY/OG) BETWEEN THE DLC C251 AND THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE C3031a FOR AN OPEN Measure the resistance between the driver temperature controlled seat module C3031 a-1, circuit 4-HC21 (GY/OG), harness side and the DLC C251-3, circuit 4-ED6 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to Q9 . No : GO to Q3.
Q3 CHECK IN-LINE C315 FOR DAMAGE Disconnect: In-Line C315. Inspect in-lines C315M and C315F for damage. Are in-lines C315M and C315F OK? Yes : GO to Q4. No : REPAIR in-lines C315M and C315F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q4 CHECK CIRCUIT 4-HC21 (GY/OG) BETWEEN IN-LINE C315F AND THE DRIVER TEMPERATURE CONTROLLED SEAT MODULE C3031a FOR AN OPEN Measure the resistance between the driver temperature controlled seat module C3031 a-1, circuit 4-HC21 (GY/OG), harness side and in-line C315M-10, circuit 4-HC21 (GY/OG), harness side. Is the resistance less than 5 ohms? Yes : GO to Q5. No : REPAIR the circuit between in-line C315M and the driver temperature controlled seat module C3031a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q5 CHECK IN-LINE C213 FOR DAMAGE Disconnect: In-Line C213. Inspect in-lines C213M and C213F for damage. Are in-lines C213M and C213FOK? Yes : GO to Q6. No : REPAIR in-lines C213M and C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q6 CHECK CIRCUIT 4-HC21 (GY/OG) BETWEEN IN-LINE C315F AND IN-LINE C213F FOR AN OPEN Measure the resistance between in-line C213F-11, circuit 4-HC1 (GY/RD), harness side and in-line C315M-10, circuit 4-HC21 (GY/OG), harness side. Is the resistance less than 5 ohms? Yes : GO to Q7. No : REPAIR the circuit between in-line C315F and in-line C213. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q7 CHECK CIRCUIT 4-HC1 (GY/RD) BETWEEN IN-LINE C213M AND JOINT CONNECTOR No. 1 C261 FOR AN OPEN Measure the resistance between in-line C213M-11, circuit 4-HC1 (GY/RD), harness side and joint connector No. 1 C261 -11, circuit 4-HC1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to Q8. No : REPAIR the circuit between in-line C213M and joint connector No. 1 C261. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q8 CHECK JOINT CONNECTOR No. 1 FOR AN OPEN Measure the resistance between joint connector No. 1 C261 -10, component side and joint connector No. 1 C261 -11, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between joint connector No. 1 C261 and the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 1 C261 as necessary. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q9 CHECK THE UBP NETWORK WITH THE DRIVER CLIMATE CONTROL SEAT MODULE DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to Q26 . No : GO to Q10.
Q10 CHECK THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE C3036a FOR DAMAGE Key in OFF position. Connect: Driver Climate Control Seat Module C3031a. Connect: In-line C315. Connect: In-line C213. Connect: Joint Connector No. 1 C261. Disconnect: passenger temperature controlled seat module C3036a. Inspect the passenger temperature controlled seat module C3036a for damage. Is the passenger temperature controlled seat module C3036a OK? Yes : GO to Q11. No : REPAIR the passenger temperature controlled seat module C3036a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q11 CHECK CIRCUIT 4-HC22 (GY) BETWEEN THE DLC C251 AND THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE C3036a FOR AN OPEN Measure the resistance between the passenger temperature controlled seat module C3036a-1, circuit 4-HC22 (GY), harness side and the DLC C251 -3, circuit 4-ED6 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to Q18 . No : GO to Q12.
Q12 CHECK IN-LINE C313 FOR DAMAGE Disconnect: In-Line C313. Inspect in-lines C313M and C313F for damage. Are in-lines C313M and C313F OK? Yes : GO to Q13. No : REPAIR in-lines C313M and C313F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q13 CHECK CIRCUIT 4-HC22 (GY) BETWEEN IN-LINE C313F AND THE PASSENGER TEMPERATURE CONTROLLED SEAT MODULE C3036a FOR AN OPEN Measure the resistance between the passenger temperature controlled seat module C3036a-1, circuit 4-HC22 (GY), harness side and in-line C313M-10, circuit 4-HC22 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to Q14. No : REPAIR the circuit between in-line C313M and the passenger temperature controlled seat module C3036a. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q14 CHECK IN-LINE C213 FOR DAMAGE Disconnect: In-Line C213. Inspect in-lines C213M and C213F for damage. Are in-lines C213M and C213F OK? Yes : GO to Q15. No : REPAIR in-lines C213M and C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q15 CHECK CIRCUIT 4-HC22 (GY) BETWEEN IN-LINE C313F AND IN-LINE C213F FOR AN OPEN Measure the resistance between in-line C213F-11, circuit 4-HC1 (GY/RD), harness side and in-line C313F-10, circuit 4-HC22 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to Q16. No : REPAIR the circuit between in-line C313F and in-line C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q16 CHECK CIRCUIT 4-HC1 (GY/RD) BETWEEN IN-LINE C213M AND JOINT CONNECTOR No. 1 C261 FOR AN OPEN Measure the resistance between in-line C213M-11, circuit 4-HC1 (GY/RD), harness side and joint connector No. 1 C261 -11, circuit 4-HC1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to Q17. No : REPAIR the circuit between in-line C213M and joint connector No. 1 C261. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q17 CHECK JOINT CONNECTOR No. 1 FOR AN OPEN Measure the resistance between joint connector No. 1 C261 -10, component side and joint connector No. 1 C261 -11, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between joint connector No. 1 C261 and the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 1 C261 as necessary. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q18 CHECK THE UBP NETWORK WITH THE PASSENGER CLIMATE CONTROL SEAT MODULE DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to Q27 . No : GO to Q19.
Q19 CHECK THE PARKING AID MODULE C4014b FOR DAMAGE Key in OFF position. Connect: Passenger Climate Control Seat Module C3036a. Connect: In-line C313. Connect: In-line C213. Connect: Joint Connector No. 1 C261. Disconnect: Parking Aid Module C4014b. Inspect the parking aid module C4014b for damage. Is the parking aid module C4014 OK? Yes : GO to Q20. No : REPAIR the parking aid module C4014b. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q20 CHECK CIRCUIT 4-GN10 (GY) BETWEEN THE DLC C251 AND THE PARKING AID MODULE C4014b FOR AN OPEN Measure the resistance between the parking aid module C4014b-1, circuit 4-GN10 (GY), harness side and the DLC C251 -3, circuit 4-ED6 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to Q25 . No : GO to Q21.
Q21 CHECK IN-LINE C213 FOR DAMAGE Disconnect: In-Line C213. Inspect in-lines C213M and C213F for damage. Are in-lines C213M and C213F OK? Yes : GO to Q22. No : REPAIR in-lines C213M and C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q22 CHECK CIRCUIT 4-GN10 (GY) BETWEEN THE PARKING AID MODULE C4014b AND IN-LINE C213F FOR AN OPEN Measure the resistance between in-line C213F-11, circuit 4-HC1 (GY/RD), harness side and the parking aid module C4014b-1, circuit 4-GN10 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to Q23. No : REPAIR the circuit between the parking aid module C4014band in-line C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q23 CHECK CIRCUIT 4-HC1 (GY/RD) BETWEEN IN-LINE C213M AND JOINT CONNECTOR No. 1 C261 FOR AN OPEN Measure the resistance between in-line C213M-11, circuit 4-HC1 (GY/RD), harness side and joint connector No. 1 C261 -11, circuit 4-HC1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to Q24. No : REPAIR the circuit between in-line C213M and joint connector No. 1 C261. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q24 CHECK JOINT CONNECTOR No. 1 FOR AN OPEN Measure the resistance between joint connector No. 1 C261 -10, component side and joint connector No. 1 C261-11, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between joint connector No. 1 C261 and the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 1 as necessary. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
Q25 CHECK THE UBP NETWORK WITH THE PARKING AID MODULE DISCONNECTED Key in ON position. Enter the following diagnostic mode on the diagnostic tool: DATA LINK DIAGNOSTICS Test. Did the diagnostic tool indicate system passed? Yes : GO to Q28 . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Q26 CHECK FOR CORRECT DRIVER TEMPERATURE CONTROLLED SEAT MODULE OPERATION Disconnect all the driver temperature controlled seat module connectors. Check for: corrosion push-out pins Connect all the driver temperature controlled seat module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new driver temperature controlled seat module. REFER to «SEATING»(ref-207572) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Q27 CHECK FOR CORRECT PASSENGER TEMPERATURE CONTROLLED SEAT MODULE OPERATION Disconnect all the passenger temperature controlled seat module connectors. Check for: corrosion push-out pins Connect all the passenger temperature controlled seat module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new passenger temperature controlled seat module. REFER to «SEATING»(ref-207572) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Q28 CHECK FOR CORRECT PARKING AID MODULE OPERATION Disconnect all the parking aid module connectors. Check for: corrosion push-out pins Connect all the parking aid module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new parking aid module. REFER to «INFORMATION, GAUGES & WARNING DEVICES»(ref-207563) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST R: The Electronic Parking Brake Module Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 248

Scheme 248: PINPOINT TEST R: THE ELECTRONIC PARKING BRAKE MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

R1 CHECK THE ELECTRONIC PARKING BRAKE MODULE C4205b FOR DAMAGE Key in OFF position. Disconnect: Electronic Parking Brake Module C4205b. Inspect the electronic parking brake module C4205b for damage. Is the electronic parking brake module C4205b OK? Result / Action to Take Yes : GO to R2. No : REPAIR the electronic parking brake module C4205b as necessary. TEST the system for normal operation.
R2 CHECK FOR AN OPEN BETWEEN THE DLC C251 AND THE ELECTRONIC PARKING BRAKE MODULE C4205b Measure the resistance between the electronic parking brake module C4205b-1, circuit 4-CG16 (GY/RD), harness side and the DLC C251-2, circuit 4-EG7 (GY/RD), harness side. Measure the resistance between the electronic parking brake module C4205b-7, circuit 5-CG16 (BU/RD), harness side and the DLC C251-10, circuit 5-EG7 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to R9 . No : GO to R3.
R3 CHECK FOR AN OPEN BETWEEN JOINT CONNECTOR No. 5 C427 AND THE ELECTRONIC PARKING BRAKE MODULE C4205b Disconnect: Joint Connector No. 5 C427. Measure the resistance between the electronic parking brake module C4205b-1, circuit 4-CG16 (GY/RD), harness side and joint connector No. 5 C427-2, circuit 4-CG16 (GY/RD), harness side. Measure the resistance between the electronic parking brake module C4205b-7, circuit 5-CG16 (BU/RD), harness side and joint connector No. 5 C427-13, circuit 5 -CG16 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to R4. No : REPAIR the circuit in question. TEST the system for normal operation.
R4 CHECK JOINT CONNECTOR No. 5 FOR AN OPEN Measure the resistance between joint connector No. 5 C427-1, component side and joint connector No. 5 C427-2, component side. Measure the resistance between joint connector No. 5 C427-12, component side and joint connector No. 5 C427-13, component side. Are the resistances less than 5 ohms? Yes : GO to R5. No : REPAIR joint connector No. 5 C427 as necessary. TEST the system for normal operation.
R5 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND JOINT CONNECTOR No. 5 C427 Disconnect: Interior AJB C283b. Measure the resistance between the interior AJB C283b-8, circuit 4-EG1 (GY/RD), harness side and joint connector No. 5 C427-1, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283b-4, circuit 5-EG1 (BU/RD), harness side and joint connector No. 5 C427-12, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to R6. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
R6 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283b AND THE INTERIOR AJB C283d Disconnect: Interior AJB C283d. Measure the resistance between the interior AJB C283d-16, component side and the interior AJB C283b-8, component side. Measure the resistance between the interior AJB C283d-12, component side and the interior AJB C283b-4, component side. Are the resistances less than 5 ohms? Yes : GO to R7. No : INSTALL a new interior AJB. TEST the system for normal operation.
R7 CHECK FOR AN OPEN BETWEEN THE INTERIOR AJB C283d AND JOINT CONNECTOR No. 4 C223 Disconnect: Interior Joint Connector No. 4 C223. Measure the resistance between the interior AJB C283d-16, circuit 4-EG1 (GY/RD), harness side and joint connector No. 4 C223-12, circuit 4-EG1 (GY/RD), harness side. Measure the resistance between the interior AJB C283d-12, circuit 5-EG1 (BU/RD), harness side and joint connector No. 4 C223-11, circuit 5-EG1 (BU/RD), harness side. Are the resistances less than 5 ohms? Yes : GO to R8. No : REPAIR the circuit in question. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
R8 CHECK JOINT CONNECTOR No. 4 FOR AN OPEN Measure the resistance between joint connector No. 4 C223-12, component side and joint connector No. 4 C223-14, component side. Measure the resistance between joint connector No. 4 C223-9, component side and joint connector No. 4 C223-11, component side. Are the resistances less than 5 ohms? Yes : REPAIR the circuit in question between the DLC C251 and joint connector No. 4 C223. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 4 C223. TEST the system for normal operation.
R9 CHECK FOR CORRECT ELECTRONIC PARKING BRAKE MODULE OPERATION Disconnect all the electronic parking brake module connectors. Check for: corrosion push-out pins Connect all the electronic parking brake module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new electronic parking brake module. REFER to «BRAKE SYSTEM»(ref-207548) . TEST the system for normal operation. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST S: The Parking Aid Module Does Not Respond To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 262

Scheme 262: PINPOINT TEST S: THE PARKING AID MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 263

Scheme 264

Scheme 265

S1 CHECK THE PARKING AID MODULE C4014b FOR DAMAGE Key in OFF position. Disconnect: Parking Aid Module C4014b. Inspect the parking aid module C4014b for damage. Is the parking aid module C4014b OK? Result / Action to Take Yes : GO to S2. No : REPAIR the parking aid module C4014b. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
S2 CHECK CIRCUIT 4-GN10 (GY) BETWEEN THE DLC C251 AND THE PARKING AID MODULE C4014b FOR AN OPEN Measure the resistance between the parking aid module C4014b-1, circuit 4-GN10 (GY), harness side and the DLC C251 -3, circuit 4-ED6 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to S7 . No : GO to S3.
S3 CHECK IN-LINE C213 FOR DAMAGE Disconnect: In-Line C213. Inspect in-lines C213M and C213F for damage. Are in-lines C213M and C213F OK? Yes : GO to S4. No : REPAIR in-lines C213M and C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
S4 CHECK CIRCUIT 4-GN10 (GY) BETWEEN THE PARKING AID MODULE C4014b AND IN-LINE C213F FOR AN OPEN Measure the resistance between in-line C213F-11, circuit 4-HC1 (GY/RD), harness side and the parking aid module C4014b-1, circuit 4-GN10 (GY), harness side. Is the resistance less than 5 ohms? Yes : GO to S5. No : REPAIR the circuit between the parking aid module C4014b and in -line C213F. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
S5 CHECK CIRCUIT 4-HC1 (GY/RD) BETWEEN IN-LINE C213M AND JOINT CONNECTOR No. 1 C261 FOR AN OPEN Disconnect: Joint Connector No. 1 C261. Measure the resistance between in-line C213M-11, circuit 4-HC1 (GY/RD), harness side and joint connector No. 1 C261 -11, circuit 4-HC1 (GY/RD), harness side. Is the resistance less than 5 ohms? Yes : GO to S6. No : REPAIR the circuit between inline C213M and joint connector No. 1 C261. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
S6 CHECK JOINT CONNECTOR No. 1 FOR AN OPEN Measure the resistance between joint connector No. 1 C261-10, component side and joint connector No. 1 C261-11, component side. Is the resistance less than 5 ohms? Yes : REPAIR the circuit between joint connector No. 1 C261 and the DLC C251. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) . No : REPAIR joint connector No. 1 C261 as necessary. CARRY OUT the «PINPOINT TEST PC: data link diagnostics network test»(ref-207567-S02970830582005113000000) .
S7 CHECK FOR CORRECT PARKING AID MODULE OPERATION Disconnect all the parking aid module connectors. Check for: corrosion push-out pins Connect all the parking aid module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new parking aid module. REFER to «INFORMATION, GAUGES & WARNING DEVICES»(ref-207563) . TEST the system for normal operation. CARRY OUT the diagnostic tool data link test. No : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.

PINPOINT TEST T: No Module/Network Communication - No Power To The Diagnostic Tool

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 266

Scheme 266: PINPOINT TEST T: NO MODULE/NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL

Scheme 267

T1 CHECK THE DIAGNOSTIC TOOL CONNECTOR Inspect the diagnostic tool pins for damage. Are the pins OK? Result / Action to Take Yes : GO to T2. No : REPAIR the diagnostic tool connector. TEST the system for normal operation.
T2 CHECK THE DLC C251 FOR DAMAGE Key in OFF position. Inspect the DLC C251 pins for damage. Are the pins OK? Yes : GO to T3. No : REPAIR the DLC C251. TEST the system for normal operation.
T3 CHECK THE VOLTAGE TO THE DIAGNOSTIC TOOL CIRCUIT 29-ED6 (OG/YE) Measure the voltage between the DLC C251-16, circuit 29-ED6 (OG/YE), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to T4. No : REPAIR the supply circuit. TEST the system for normal operation.
T4 CHECK THE DLC GROUND - CIRCUIT 31-ED6 (BK), AND CIRCUIT 91-ED6(BN) Measure the resistance between the DLC C251-4, circuit 31 -ED6 (BK), harness side and ground and between the DLC C251-5, circuit 91-ED6 (BN), harness side and ground. Are the resistances less than 5 ohms? Yes : REPAIR the diagnostic tool. TEST the system for normal operation. No : REPAIR the circuit(s) in question. TEST the system for normal operation.

Scheme 268

Scheme 268: Special Tool(s)

Pinpoint Test T

T2 Visual Inspection Chart

Visual Inspection Chart
VISUAL INSPECTION Electrical Central junction box (CJB) fuses 20 (10A) and 30 (5A) Wiring harness Connector(s) Circuitry

Condition	Possible Sources	Action
No communication with the front electronic module (FEM)	DLC. Central junction box (CJB) fuses 20 (10A) and 30 (5A) Circuit 29-DK20 (OG/GN) Circuit 29S-DK21 (OG/WH) Circuit 31-DK20 (BK) Circuit 31-DK20A (BK) Circuit 31-DK20B (BK) Circuit 31-DK20C (BK) Circuit 31-DK20D (BK) Diagnostic tool. FEM C201a, C201c FEM.	Go To PINPOINT TEST U: NO COMMUNICATION WITH THE FRONT ELECTRONIC MODULE (FEM) .

SYMPTOM

Scheme 269

Scheme 269: Front Electronic Module (FEM) C201a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
1	29S-DK22 (OG/WH) FEM power supply.	10 volts or greater at the FEM connector.
11	31-DK20A (BK/RD) FEM ground.	Less than 5 ohms between the FEM connector and ground.
13	31-DK20B (BK/RD) FEM ground.	Less than 5 ohms between the FEM connector and ground.
14	31-DK20C (BK/RD) FEM ground.	Less than 5 ohms between the FEM connector and ground.
15	31-DK20D (BK/RD) FEM ground.	Less than 5 ohms between the FEM connector and ground.

FRONT ELECTRONIC MODULE (FEM) C201A CONNECTOR PINS DESCRIPTION

Scheme 270

Scheme 270: Front Electronic Module (FEM) C201c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
6	29-DK20 (OG/GN) FEM power supply.	10 volts or greater at the FEM connector.
12	31-DK20(BK) FEM ground.	Less than 5 ohms between the FEM connector and ground.

FRONT ELECTRONIC MODULE (FEM) C201C CONNECTOR PINS DESCRIPTION

PINPOINT TEST U: No Communication With The Front Electronic Module (FEM)

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 271

Scheme 271: PINPOINT TEST U: NO COMMUNICATION WITH THE FRONT ELECTRONIC MODULE (FEM)

Scheme 272

U1 CHECK CIRCUIT 29-DK20 (OG/GN) AND 29S-DK21 (OG/WH) FOR VOLTAGE Key in OFF position. Disconnect the FEM C201a. Disconnect the FEM C201c. Key in ON position. Measure the voltage between the FEM C201a-1, circuit 29S-DK22 (OG/WH), harness side and ground and between FEM C201c-6, circuit 29-DK20 (OG/GN), harness side and ground. Are the voltages greater than 10 volts? Result / Action to Take Yes : GO to U2. No : REPAIR the circuit in question. TEST the system for normal operation.
U2 CHECK THE FEM GROUND CIRCUITS FOR AN OPEN Key in OFF position. Using the following table, measure the resistance between the FEM connector, harness side and ground: FEM CONNECTOR, HARNESS SIDE AND GROUND RESISTANCE Connector-Pin Circuit C201a-11 31-DK20A (BK/RD) C201a-13 31-DK20B (BK/RD) C201a-14 31-DK20C (BK/RD) C201a-15 31-DK20D (BK/RD) C201c-12 31-DK20 (BK/RD) Are the resistances less than 5 ohms? Yes : Go To «PINPOINT TEST B: THE FRONT ELECTRONIC MODULE (FEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL»(ref-207567-S42048239812005113000000) . No : REPAIR the circuit in question. TEST the system for normal operation.

Scheme 273

Scheme 273: Special Tool(s)

Pinpoint Test U

U2 Visual Inspection Chart

Visual Inspection Chart
VISUAL INSPECTION Electrical Battery junction box (BJB) fuse 21 (20A) Central junction box (CJB) fuse 7 (5A) Wiring harness Connector(s) Circuitry

Condition	Possible Sources	Action
No communication with the driver seat module (DSM)	DLC. Battery junction box (BJB) fuse 21 (20A) Central junction box (CJB) fuse 7 (5A) Circuit 29-AH80 (OG/WH) Circuit 30-AH80 (RD) Circuit 31-AH80 (BK) Circuit 91-AH80 (BK) DSM C341b DSM C341c DSM Diagnostic tool.	Go To PINPOINT TEST V: NO COMMUNICATION WITH THE DRIVER SEAT MODULE (DSM) .

SYMPTOM

Scheme 274

Scheme 274: Driver Seat Module (DSM) C341b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
3	31-AH80 (BK) DSM ground	Less than 5 ohms between the DSM connector and ground.
4	30-AH80 (RD) DSM power supply	10 volts or greater at the DSM connector.

DRIVER SEAT MODULE (DSM) C341B CONNECTOR PINS DESCRIPTION

Scheme 275

Scheme 275: Driver Seat Module (DSM) C341c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
2	91-AH80 (BN/WH) DSM ground.	Less than 5 ohms between the DSM connector and ground.
10	29-AH80 (OG/WH) DSM power supply.	10 volts or greater at the DSM connector.

DRIVER SEAT MODULE (DSM) C341C CONNECTOR PINS DESCRIPTION

PINPOINT TEST V: No Communication With The Driver Seat Module (DSM)

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 276

Scheme 276: PINPOINT TEST V: NO COMMUNICATION WITH THE DRIVER SEAT MODULE (DSM)

Scheme 277

V1 CHECK CIRCUIT 29-AH80 (OG/WH) AND 30-AH80 (RD) FOR VOLTAGE Key in OFF position. Disconnect the DSM C341b. Disconnect the DSM C341c. Key in ON position. Measure the voltage between the DSM C341b-4, circuit 30-AH80 (RD), harness side and ground and between the DSM C341c-10, circuit 29-AH80 (OG/WH), harness side and ground. Are the voltages greater than 10 volts? Result / Action to Take Yes : GO to V2. No : REPAIR the supply circuit in question. TEST the system for normal operation.
V2 CHECK CIRCUITS 31-AH80 (BK) AND 91-AH80 (BN/WH) FOR AN OPEN Key in OFF position. Measure the resistance between the DSM C341 b-3, circuit 31-AH80 (BK), harness side and ground and between the DSM C341c-2, circuit 91-AH80 (BN/WH), harness side and ground. Are the resistances less than 5 ohms? Yes : Go To «PINPOINT TEST I: THE DRIVER SEAT MODULE (DSM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL»(ref-207567-S31252810102005113000000) . No : REPAIR the circuit in question. TEST the system for normal operation.

Scheme 278

Scheme 278: Special Tool(s)

Pinpoint Test V

V2 Visual Inspection Chart

Visual Inspection Chart
VISUAL INSPECTION Electrical Central junction box (CJB) fuses: 7 (5A) 22 (10A) Wiring harness Connector(s) Circuitry

Condition	Possible Sources	Action
No communication with the driver door module (DDM)	DLC. Central junction box (CJB) fuses: 7 (5A) 22 (10A) Circuit 29-AJ80 (OG). Circuit 29S-AJ86 (OG/BU) Circuit 91-AJ80 (BN/BU) Circuit 31-AJ80B (BK/OG) DDM. Diagnostic tool.	Go To PINPOINT TEST W: NO COMMUNICATION WITH THE DRIVER DOOR MODULE (DDM) .

SYMPTOM

Scheme 279

Scheme 279: Driver Door Module (DDM) C501a

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
7	91-AJ80 (BN/BU) DDM ground	Less than 5 ohms between the DDM connector and ground.
8	31-AJ80B (BK/OG) DDM ground	Less than 5 ohms between the DDM connector and ground.
11	29-AJ80 (OG) DDM power supply	10 volts or greater at the DDM connector.
12	29S-AJ86 (OG/BU) DDM power supply	10 volts or greater at the DDM connector.

DRIVER DOOR MODULE (DDM) C501A CONNECTOR PINS DESCRIPTION

PINPOINT TEST W: No Communication With The Driver Door Module (DDM)

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 280

Scheme 280: PINPOINT TEST W: NO COMMUNICATION WITH THE DRIVER DOOR MODULE (DDM)

Scheme 281

W1 CHECK CIRCUITS 29-AJ80 (OG) AND 29S-AJ86 (OG/BU) FOR VOLTAGE Key in OFF position. Disconnect the DDM C501a. Key in ON position. Measure the voltage between the DDM C501a-11, circuit 29-AJ80 (OG), harness side and ground and between the DDM C501a-12, circuit 29S-AJ86 (OG/BU), harness side and ground. Are the voltages greater than 10 volts? Result / Action to Take Yes : GO to W2. No : REPAIR the supply circuit in question. TEST the system for normal operation.
W2 CHECK CIRCUITS 91-AJ80 (BN/BU) AND 31-AJ80B (BK/OG) FOR AN OPEN Key in OFF position. Measure the resistance between the DDM C501 a-7, circuit 91-AJ80 (BN/BU), harness side and ground and between the DDM C501a-8, circuit 31-AJ80B (BK/OG), harness side and ground. Is the resistance less than 10 ohms? Yes : Go To «PINPOINT TEST J: THE DRIVER DOOR MODULE (DDM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL»(ref-207567-S11693730992005113000000) . No : REPAIR the circuit in question. TEST the system for normal operation.

Scheme 282

Scheme 282: Special Tool(s)

Pinpoint Test W

W2 Visual Inspection Chart

Visual Inspection Chart
VISUAL INSPECTION Electrical Central junction box (CJB) fuse 20 (10A) Wiring harness Connector(s) Circuitry

Condition	Possible Sources	Action
No communication with the rear electronic module (REM)	DLC. Central junction box (CJB) fuse 20 (10A) Circuit 29-DK31 (OG/BK) Circuit 31-DK30D (BK/OG) Circuit 31-DK30E (BK/OG) Circuit 31-DK30F (BK/OG) Circuit 31-DK30G (BK/OG) Circuit 31-DK30H (BK/OG) Diagnostic tool REM C420b, C420c, C420d REM	Go To PINPOINT TEST X: NO COMMUNICATION WITH THE REAR ELECTRONIC MODULE (REM) .

SYMPTOM

Scheme 283

Scheme 283: Rear Electronic Module (REM) C420b

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
12	31-DK30H (BK/OG) REM ground	Less than 5 ohms between the REM connector and ground.

REAR ELECTRONIC MODULE (REM) C420B CONNECTOR PINS DESCRIPTION

Scheme 284

Scheme 284: Rear Electronic Module (REM) C420c

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
11	31-DK30D (BK/OG) REM ground.	Less than 5 ohms between the DSM connector and ground.
12	31-DK30E (BK/OG) REM ground.	Less than 5 ohms between the REM connector and ground.
25	31-DK30F (BK/OG) REM ground.	Less than 5 ohms between the REM connector and ground.
26	31-DK30G (BK/OG) REM ground.	Less than 5 ohms between the REM connector and ground.

REAR ELECTRONIC MODULE (REM) C420C CONNECTOR PINS DESCRIPTION

Scheme 285

Scheme 285: Rear Electronic Module (REM) C420d

Pin Number(s)	Circuit Designation/Description	Normal Condition/Measurement
3	29-DK31 (OG/BK) REM power supply.	10 volts or greater at the REM connector.

REAR ELECTRONIC MODULE (REM) C420D CONNECTOR PINS DESCRIPTION

PINPOINT TEST X: No Communication With The Rear Electronic Module (REM)

Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.

Test Step

Scheme 286

Scheme 286: PINPOINT TEST X: NO COMMUNICATION WITH THE REAR ELECTRONIC MODULE (REM)

Scheme 287

X1 CHECK CIRCUIT 29-DK31 (OG/BK) FOR VOLTAGE Key in OFF position. Disconnect the REM C420d. Key in ON position. Measure the voltage between the REM C420d-3, circuit 29-DK31 (OG/BK), harness side and ground. Is the voltage greater than 10 volts? Result / Action to Take Yes : GO to X2. No : REPAIR the supply circuit. TEST the system for normal operation.
X2 CHECK THE REM GROUND CIRCUITS FOR AN OPEN Disconnect: REM C420b. Disconnect: REM C420c. Key in OFF position. Using the following table, measure the resistance between the REM connector, harness side and ground: REM CONNECTOR, HARNESS SIDE AND GROUND RESISTANCE Pin Circuit C420b-12 31-DK30H (BK/OG) C420c-11 31-DK30D (BK/OG) C420c-12 31-DK30E (BK/OG) C420c-25 31-DK30F (BK/OG) C420c-26 31-DK30G (BK/OG) Are the resistances less than 5 ohms? Yes : Go To «PINPOINT TEST K: THE REAR ELECTRONIC MODULE (REM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL»(ref-207567-S31235866622005113000000) . No : REPAIR the circuit in question. TEST the system for normal operation.

Module Communications Network: Diagnosis Lincoln LS I рестайлинг

Inspection and Verification

Diagnostic Trouble Code (DTC) Chart

Scheme 1

PINPOINT TEST PC: DATA LINK DIAGNOSTICS NETWORK TEST

Symptom Chart

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

PINPOINT TEST A: The Anti-Lock Brake/Traction Control (ABS/TC) Module Or Stability Assist Module Does Not Respond To The Diagnostic Tool

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

PINPOINT TEST B: The Front Electronic Module (FEM) Does Not Respond To The Diagnostic Tool

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

PINPOINT TEST C: The Restraint Control Module (RCM) Does Not Respond To The Diagnostic Tool

Scheme 48

Scheme 49

PINPOINT TEST D: The Instrument Cluster Does Not Respond To The Diagnostic Tool

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

PINPOINT TEST E: No Powertrain Control Module (PCM) Standard Corporate Protocol (SCP) Network Communication

Scheme 56

Scheme 57

PINPOINT TEST F: The Dual Automatic Temperature Control (DATC) Module Does Not Respond To The Diagnostic Tool

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

PINPOINT TEST G: The Audio Control Module (ACM) Does Not Respond To The Diagnostic Tool

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68
