Climate Control System: Overhaul Lincoln LS I рестайлинг

A/c Compressor 7 illustrations ~272 words

Climate Control Assembly

Note. If installing a new climate control assembly (DATC module), the new module must be configured for the vehicle. For additional information, refer to MODULE COMMUNICATIONS NETWORK .

Scheme 36

Scheme 36: Climate Control Assembly
Scheme 36: Climate Control Assembly
  1. Remove the components in the order indicated in the following illustration and table.
  2. To install, reverse the removal procedure.

Scheme 37

Scheme 37: In-Vehicle Temperature Sensor
Scheme 37: In-Vehicle Temperature Sensor
  1. Remove the instrument cluster finish panel. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
  2. Remove the components in the order indicated in the following illustration and table.
  3. To install, reverse the removal procedure.

Scheme 38

Scheme 38: Mode Door Actuator - Air Inlet Door
Scheme 38: Mode Door Actuator - Air Inlet Door
  1. Remove the RH floor duct. For additional information, refer to «AIR DISTRIBUTION DUCTS»(ref-207561-S01935463842005113000000) .
  2. Remove the components in the order indicated in the following illustration and table.
  3. To install, reverse the removal procedure.

Scheme 39

Scheme 39: Mode Door Actuator - Floor Door
Scheme 39: Mode Door Actuator - Floor Door
  1. Remove the LH floor duct. For additional information, refer to «AIR DISTRIBUTION DUCTS»(ref-207561-S01935463842005113000000) .
  2. Remove the components in the order indicated in the following illustration and table.
  3. To install, reverse the removal procedure.

Scheme 40

Scheme 40: Mode Door Actuator - Cold Air Bypass Door
Scheme 40: Mode Door Actuator - Cold Air Bypass Door
  1. Remove the LH floor duct. For additional information, refer to «AIR DISTRIBUTION DUCTS»(ref-207561-S01935463842005113000000) .
  2. Remove the components in the order indicated in the following illustration and table.
  3. To install, reverse the removal procedure.

Scheme 41

Scheme 41: Mode Door Actuator - Defrost Door
Scheme 41: Mode Door Actuator - Defrost Door
  1. Remove the instrument cluster. For additional information, refer to «INFORMATION, GAUGES & WARNING DEVICES»(ref-207563) .
  2. Remove the LH lower instrument panel insulator.
  3. Remove the components in the order indicated in the following illustration and table.
  4. To install, reverse the removal procedure.

Scheme 42

Scheme 42: Mode Door Actuator - Panel Door
Scheme 42: Mode Door Actuator - Panel Door
  1. Remove the instrument panel. For additional information, refer to «INTERIOR TRIM»(ref-207570) .
  2. Remove the components in the order indicated in the following illustration and table.
  3. To install, reverse the removal procedure.
