A/C SYSTEM SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Ford FS-10 10-Cyl. |
| Compressor Belt Tension | (1) |
| System Oil Capacity | (2) 7 ozs. |
| Refrigerant (R-134a) Capacity | 34 ozs. |
| System Operating Pressures (3) |
| High Side | 130-230 psi (9.1-16.1 kg/cm 2 ) |
| Low Side | 22-47 psi (1.5-3.3 kg/cm 2 ) |
| (1) Tension is automatically adjusted. Wear indicator should be between MIN and MAX marks on automatic tensioner. (2) Use YN-12b PAG Refrigerant Oil Part No. F2AZ-19577-AB). (3) Operating pressures at ambient temperature of 80°F (27°C). |
| (1) | Tension is automatically adjusted. Wear indicator should be between MIN and MAX marks on automatic tensioner. |
| (2) | Use YN-12b PAG Refrigerant Oil Part No. F2AZ-19577-AB). |
| (3) | Operating pressures at ambient temperature of 80°F (27°C). |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Mounting Bolts | 15-22 (20-30) |
| Instrument Panel Side Bolts | 13-16 (17-23) |
| Manifold & Tube Bolt | 14-17 (18-24) |
| Refrigerant Hose Manifold | 14-16 (19-22) |
| Compressor Bolts | 15-22 (20-30) |
| INCH Lbs. (N.m) |
| A/C Cycling Switch | 18-44 (2-5) |
| Accumulator Clamp Bolt | 18-26 (2-3) |
| Blower Motor Screws | 18-26 (2-3) |
| Condenser Retaining Nuts | 27-44 (3-5) |
| Electronic Blend Door Actuator Screws | 18-26 (2-3) |
| Evaporator Housing |
| Mounting Bracket-To-Cowl | 24-60 (3-7) |
| Housing-To-Cowl Panel Nuts | 37-84 (4-9) |
| Upper/Lower Half Screws | 18-26 (2-3) |
| Floor Console Bracket Screws | 24-33 (3-4) |
| Fender Brace Screws | 61-81 (7-9) |
| Heater Core Cover Screws | 18-26 (2-3) |
| Instrument Cluster Screws | 18-26 (2-3) |
| Instrument Panel |
| Brace Screws | 18-26 (2-3) |
| Brace Studs | 53-71 (6-8) |
| Dash Brace-To-Panel Bolt | 53-71 (6-8) |
| Right Panel-To-Cowl Nuts | 89-123 (10-14) |
| Panel-To-Cowl Panel Screws | 18-26 (2-3) |
| Steering Column Cover Screws | 18-26 (2-3) |
| Steering Column Opening |
| Reinforcement Bolts | 63-98 (7-11) |
| Top Panel-To-Cowl Screws | 8-26 (2-3) |
| PCM Connector Screw | 45-61 (5-7) |
| Plenum Chamber Screws | 18-26 (2-3) |
| Pressure Relief Valve | 61-121 (7-13) |
| Radiator, Lower Support Bolts | 71-97 (8-11) |
| Vacuum Actuator Screws | 18-26 (2-3) |
Scheme 1
Scheme 1: VACUUM HOSE DIAGRAM(S)
Scheme 11: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Scheme 12: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
