SYSTEM DESCRIPTION

1. POWER MIRROR CONTROL SYSTEM DESCRIPTION This system has the following functions: automatic glare-resistant electrochromatic (EC) mirror, reverse shift-linked mirror, electrical remote control type mirror, memory function, rear window defogger-linked mirror defogger and wiper-linked mirror defogger.
2. FUNCTION OF MAIN COMPONENT MAIN COMPONENT FUNCTION Components Function Vertical mirror motor Receives signal from door ECU and adjusts remote control mirror vertically. Horizontal mirror motor Receives signal from door ECU and adjusts remote control mirror horizontally. Mirror retract motor* Receives signal from door ECU, and retracts and returns remote control mirror. Mirror defogger Receives signal from door ECU and starts mirror defogger. EC mirror cell Varies reflection rate of mirror through function of EC elements. Mirror retract switch* Retracts and returns remote control mirror. Mirror retract and return signals are sent to door ECU through driver side junction block ECU. Mirror master switch Consists of R and L switches. One must be chosen before mirror control switches can be operated. Mirror control switch After selecting R or L switch, RIGHT, LEFT, UP and DOWN control switches change angle of mirror. Mirror signals are sent to door ECU through driver side junction block ECU. Mirror position sensor Detects remote control mirror position. This data is detected by door ECU. Set switch Memory switch When set switch and memory switch are pressed simultaneously, SET, 1 or 2 switch is input to driver door ECU and remote control mirror position is recorded. Then, when memory switch is pressed, 1 or 2 switch is input to driver door ECU and remote control mirror position changes according to memory. HINT: *: w/ Retractable Mirror
3. SYSTEM OPERATION The remote control mirror has the following features: SYSTEM OPERATION REFERENCE Function Outline Manual electrical retractable mirror* Retracts remote control mirrors when mirror retract switch is pressed. Reverse shift-linked mirror Directs mirror surface downward to improve visibility when driving in reverse and all conditions below are met. Ignition switch is ON. Shift lever is moved from position other than R to R. Mirror master switch is on R or L position. Electrical remote control type mirror When mirror control switch is operated, this function moves mirror surface vertically or laterally to enable driver to attain optimal mirror angle. Setting mirror master switch to R position operates right mirror, and to L position operates left mirror. Rear window defogger-linked mirror defogger Automatically turns on mirror defogger when rear window defogger switch is turned on. Rear window defogger and mirror defogger automatically turn off after 15 min. Wiper-linked mirror defogger Improves rear visibility in rain by automatically turning on mirror defogger when wiper switch is turned on. Automatic glare-resistant EC mirror Reduces glare / reflection in inner mirror during nighttime driving for safe driving conditions. Glare / reflection from vehicle headlights behind could blind driver and cause dangerous driving conditions. Memory function Stores adjusted mirror position in multiplex network door ECU front LH and RH. Mirrors automatically return to original positions after "reverse shift-linked mirror" function has been completed. HINT: *: w/ Retractable Mirror

DESCRIPTION

This circuit detects the conditions of the mirror retract switch.

The operating condition of the mirror retract switch is input by the driver side junction block ECU and the input signals are sent to the multiplex network door ECU front LH or RH (driver or passenger door ECU).

Scheme 1

Scheme 2

1. READ VALUE OF INTELLIGENT TESTER (MIRROR RETRACT SWITCH) Check the DATA LIST for proper functioning of the mirror retract switch. Driver side junction block ECU: DATA LIST REFERENCE Item Measurement Item / Range (Display) Normal Condition Diagnostic Note MIRR FOLD SW Mirror retract signal / ON or OFF ON: Switch is ON OFF: Switch is OFF - MIRR RETRN SW Mirror return signal / ON or OFF ON: Switch is OFF OFF: Switch is ON - OK: On tester screen, each item changes between ON and OFF according to above chart. OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE NG: Go to Next step
2. INSPECT OUTER MIRROR SWITCH ASSEMBLY (MIRROR RETRACT SWITCH) (Scheme 1): Inspecting Outer Mirror Switch Assembly Measure the resistance of the switch. Standard resistance RESISTANCE REFERENCE Tester Connection Switch Condition Specified Condition 4 - 5 ON (Retract) 10 kohms or higher 4 - 5 OFF (Return) Below 1 ohms NG: REPLACE OUTER MIRROR SWITCH ASSEMBLY OK: Go to Next step
3. CHECK WIRE HARNESS (OUTER MIRROR SWITCH ASSEMBLY [MIRROR RETRACT SWITCH] - DRIVER SIDE JUNCTION BLOCK ECU AND BODY GROUND) Disconnect the M4 switch connector. Disconnect the D5 ECU connector. (Scheme 2): Identifying D5 ECU Connector Terminals And M4 Switch Connector Terminals Measure the resistance of the wire harness side connectors. Standard resistance RESISTANCE REFERENCE Tester Connection Specified Condition M4-4 - D5-8 (RET) Below 1 ohms M4-5 - Body ground Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE DRIVER SIDE JUNCTION BLOCK (DRIVER SIDE JUNCTION BLOCK ECU)

This circuit detects the conditions of the mirror master switch and mirror control switch. The operating condition of the mirror switch is input by the driver side junction block ECU, and the input signals are sent to the multiplex network door ECU front LH or RH (driver or front passenger door ECU). Mirror adjustment is controlled by the multiplex network door ECU front LH or RH.

Scheme 3

Scheme 4

1. PERFORM ACTIVE TEST BY INTELLIGENT TESTER (MIRROR RETRACT FUNCTION) Select the ACTIVE TEST, use the intelligent tester to generate a control command, and then check the mirror retract function. Multiplex network door ECU front LH, RH (driver, front passenger door ECU) DRIVER, FRONT PASSENGER DOOR ECU SPECIFICATION Item Test Details Diagnostic Note MIR FOLD/RETRN Operate mirror retract FOLD/RETRN - Result RESULT REFERENCE Result Proceed to Outer rear view mirror LH does not operate normally A Outer rear view mirror RH does not operate normally A Outer rear view mirror LH operates normally B Outer rear view mirror RH operates normally C B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU) C: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) A: Go to Next step
2. CHECK WIRE HARNESS (MULTIPLEX NETWORK DOOR ECU FRONT LH OR RH BATTERY AND BODY GROUND) Disconnect the D19 or P11 ECU connector. (Scheme 3): Identifying D19 And P11 ECU Connector Terminals Measure the voltage of the wire harness side connector. Standard voltage: Multiplex network door ECU front LH (driver door ECU) VOLTAGE SPECIFICATION Tester Connection Specified Condition D19-6 (BDR) - Body ground 10 to 14 V Multiplex network door ECU front RH (front passenger door ECU) VOLTAGE SPECIFICATION Tester Connection Specified Condition P11-6 (BDR) - Body ground 10 to 14 V Measure the resistance of the wire harness side connector. Standard resistance: Multiplex network door ECU front LH (driver door ECU) RESISTANCE REFERENCE Tester Connection Specified Condition D19-1 (GND) - Body ground Below 1 ohms Multiplex network door ECU front RH (front passenger door ECU) RESISTANCE REFERENCE Tester Connection Specified Condition P11-1 (GND) - Body ground Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next step
3. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH OR RH (RETRACTABLE MIRROR MOTOR) Disconnect the R14 or R15 mirror connector. Apply battery voltage and check the operation of the retractable mirror. NOTE: Disconnect and reconnect the battery once between each mirror position check. The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. OK MIRROR SPECIFICATION Measurement Condition Mirror Condition Specified Condition Battery positive (+) --> Terminal 3 Battery negative (-) --> Terminal 11 Retracted position Moves from retracted position to driving position Battery positive (+) --> Terminal 11 Battery negative (-) --> Terminal 3 Driving position Moves from driving position to retracted position (Scheme 4): Identifying R14 Or R15 Mirror Connector Terminals Result RESULT REFERENCE Result Proceed to Driver side is as specified A Front passenger side is as specified B Driver side is not as specified C Front passenger side is not as specified D B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) C: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH D: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH A: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU)

The driver side junction block sends power mirror switch signals through the multiplex communication line to the multiplex network door ECU front LH and RH (driver and passenger door ECU). While the theft warning ECU is sending an ACC signal through the multiplex communication line to the door ECU front LH and RH, the RIGHT, LEFT, UP and DOWN mirror surface operation occurs.

Scheme 5

Scheme 6

1. READ VALUE OF INTELLIGENT TESTER (OUTER REAR VIEW MIRROR) Check the DATA LIST for proper functioning of the outer rear view mirror. Driver side junction block (driver side junction block ECU) DATA LIST REFERENCE Item Measurement Item/ display (Range) Normal Condition Diagnostic Note MIRR SEL SW R Mirror selection switch signal for RH mirror/ ON or OFF ON: Switch is in R position OFF: Switch is in neutral or L position - MIRR SEL SW L Mirror selection switch signal for LH mirror/ ON or OFF ON: Switch is in L position OFF: Switch is in neutral or R position - MIRR POS SW R Mirror position switch signal (RIGHT)/ ON or OFF ON: RIGHT switch is ON OFF: Any switch except RIGHT is ON or all switches are OFF - MIRR POS SW L Mirror position switch signal (LEFT)/ ON or OFF ON: LEFT switch is ON OFF: Any switch except LEFT is ON or all switches are OFF - MIRR POS SW UP Mirror position switch signal (UP)/ ON or OFF ON: UP switch is ON OFF: Any switch except UP is ON or all switches are OFF - MIRR POS SW DWN Mirror position switch signal (DOWN)/ ON or OFF ON: DOWN switch is ON OFF: Any switch except DOWN is ON or all switches are OFF - OK: On tester screen, each item changes between ON and OFF according to above chart. OK: REPLACE DRIVER SIDE JUNCTION BLOCK NG: Go to Next step
2. INSPECT OUTER MIRROR SWITCH (MIRROR MASTER SWITCH AND MIRROR CONTROL SWITCH) (Scheme 5): Inspecting Outer Mirror Switch Select L or R on the mirror master switch. Measure the resistance of the switch. Standard resistance: Mirror master switch RESISTANCE REFERENCE Tester Connection Switch Condition Specified Condition 8 (MSW) - 9 (E) L 100 ohms 8 (MSW) - 9 (E) R Below 1 ohms 8 (MSW) - 9 (E) OFF 10 kohms or higher Mirror control switch MIRROR CONTROL SWITCH SPECIFICATION Tester Connection Switch Condition Specified Condition 7 (M+) - 9 (E) UP Approx. 100 ohms 7 (M+) - 9 (E) RIGHT 250 ohms 7 (M+) - 9 (E) DOWN 470 ohms 7 (M+) - 9 (E) LEFT 800 ohms 7 (M+) - 9 (E) OFF 10 kohms or higher NG: REPLACE OUTER MIRROR SWITCH OK: Go to Next step
3. CHECK WIRE HARNESS (OUTER MIRROR SWITCH [MIRROR MASTER SWITCH AND MIRROR CONTROL SWITCH] - ECU) Disconnect the R4 switch connector. Disconnect the D5 ECU connector. (Scheme 6): Identifying R4 Switch Connector Terminals And D5 ECU Connector Terminals Measure the resistance of the wire harness side connectors. Standard resistance RESISTANCE REFERENCE Tester Connection Specified Condition R4-7 (M+) - D5-11 (M+) Below 1 ohms R4-8 (MSW) - D5-10 (MSW) Below 1 ohms R4-9 (E) - D5-7 (R/E) Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE DRIVER SIDE JUNCTION BLOCK (DRIVER SIDE JUNCTION BLOCK ECU)

The driver side junction block sends power mirror switch signals through the multiplex communication line to the multiplex network door ECU front LH and RH (driver and front passenger door ECU). While the theft warning ECU is sending an ACC signal through the multiplex communication line to the door ECU front LH and RH, the RIGHT, LEFT, UP and DOWN mirror surface operation occurs.

Scheme 7

Scheme 8

1. PERFORM ACTIVE TEST BY INTELLIGENT TESTER (POWER MIRROR CONTROL FUNCTION) Select the ACTIVE TEST, use the intelligent tester to generate a control command, and then check the power mirror control function. Multiplex network door ECU front LH, RH (driver, front passenger door ECU) ACTIVE TEST REFERENCE Item Test Details Diagnostic Note MIR UP/DOWN Mirror vertical operation UP/DOWN - MIR RIGHT/LEFT Mirror horizontal operation RIGHT/LEFT - Result RESULT REFERENCE Result Proceed to Outer rear view mirror LH does not operate normally A Outer rear view mirror RH does not operate normally A Outer rear view mirror LH operates normally B Outer rear view mirror RH operates normally C B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU) C: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) A: Go to Next step
2. INSPECT OUTER REAR VIEW MIRROR LH OR RH (LEFT / RIGHT MOTOR, UP/ DOWN MOTOR) Disconnect the R14 or R15 mirror connectors. Apply battery voltage and check the operation of the mirror. OK VOLTAGE SPECIFICATION Measurement Condition Specified Condition Battery positive (+) rarr; Terminal 1 Battery negative (-) rarr; Terminal 10 Turns upward (A) Battery positive (+) rarr; Terminal 10 Battery negative (-) rarr; Terminal 1 Turns downward (B) Battery positive (+) --> Terminal 9 Battery negative (-) rarr; Terminal 10 Turns left (C) Battery positive (+) rarr; Terminal 10 Battery negative (-) rarr; Terminal 9 Turns right (D) Result RESULT REFERENCE Result Proceed to Driver side is as specified A Front passenger side is as specified A Driver side is not as specified B Front passenger side is not as specified C (Scheme 7): Identifying R14 Or R15 Mirror Connectors Terminals B: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH C: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH A: Go to Next step
3. CHECK WIRE HARNESS (OUTER REAR VIEW MIRROR LH OR RH - MULTIPLEX NETWORK DOOR ECU FRONT LH, RH) Disconnect the R14 or R15 mirror connectors. (Scheme 8): Identifying R14 Or R15 Mirror Connectors Terminals Disconnect the D19 or P11 ECU connectors. Measure the resistance of the wire harness side connectors. Standard resistance: for Driver side RESISTANCE REFERENCE Tester Connection Specified Condition R14-9 - D19-19 (DMHR) Below 1 ohms R14-10 - D19-20 (DM+R) Below 1 ohms R14-1 - D19-8 (DMVR) Below 1 ohms for Front passenger side RESISTANCE REFERENCE Tester Connection Specified Condition R15-9 - P11-19 (PMHR) Below 1 ohms R15-10 - P11-20 (PM+R) Below 1 ohms R15-1 - P11-8 (PMVR) Below 1 ohms Result RESULT REFERENCE Result Proceed to Driver side is not as specified A Front passenger side is not as specified A Driver side is as specified B Front passenger side is as specified C B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU) C: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) A: REPAIR OR REPLACE HARNESS OR CONNECTOR

The mirror heater operates when the following conditions are met: 1) the A/C amplifier sends the rear defogger switch signal through the multiplex communication line to the multiplex network door ECU front LH and RH (driver and front passenger door ECU), and 2) the deicer function is operating.

Scheme 9

Scheme 10

1. CHECK AIR CONDITIONING FUNCTION Check that the front deicer function operates normally. OK: Front deicer function operates normally. NG: GO TO «AIR CONDITIONING SYSTEM»(ref-283164-S11801934682008041900000) OK: Go to Next step
2. PERFORM ACTIVE TEST BY INTELLIGENT TESTER (MIRROR HEATER FUNCTION) Select the ACTIVE TEST, use the intelligent tester to generate a control command, and then check the mirror heater function. Multiplex network door ECU front LH, RH (driver, front passenger door ECU): ACTIVE TEST REFERENCE Item Test Details Diagnostic Note MIR HEATER Mirror defogger operation ON / OFF - Result: RESULT REFERENCE Result Proceed to Outer rear view mirror LH does not operate normally A Outer rear view mirror RH does not operate normally A Outer rear view mirror LH operates normally B Outer rear view mirror RH operates normally C B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU) C: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) A: Go to Next step
3. INSPECT OUTER REAR VIEW MIRROR SUB-ASSEMBLY LH OR RH (MIRROR HEATER) Check the operation of the mirror heater. Measure the resistance between terminals 4 and 12 of the connector. Standard resistance: 3.57 to 4.83 ohms at 25°C (77°F) Apply battery voltage and check the mirror heater operation. (Scheme 9): Identifying Mirror Heater Connector Terminal OK VOLTAGE SPECIFICATION Measurement Condition Specified Condition Battery positive (+) rarr; Terminal 4 Battery negative (-) rarr; Terminal 12 Mirror becomes warm B: REPLACE OUTER REAR VIEW MIRROR SUB-ASSEMBLY LH C: REPLACE OUTER REAR VIEW MIRROR SUB-ASSEMBLY RH A: Go to Next step
4. CHECK WIRE HARNESS (OUTER REAR VIEW MIRROR LH OR RH - MULTIPLEX NETWORK DOOR ECU FRONT LH, RH) Disconnect the R14 or R15 mirror connector. (Scheme 10): Identifying R14 Or R15 Mirror Connector Terminals Disconnect the D19 or P11 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance: for Driver side RESISTANCE REFERENCE Tester Connection Specified Condition R14-4 - D19-13 (HTR+) Below 1 ohms R14-12 - D19-22 (HTR-) Below 1 ohms for Front passenger side RESISTANCE REFERENCE Tester Connection Specified Condition R15-4 - P11-13 (HTR+) Below 1 ohms R15-12 - P11-22 (HTR-) Below 1 ohms Result: RESULT REFERENCE Result Proceed to Driver side is not as specified A Front passenger side is not as specified A Driver side is as specified B Front passenger side is as specified C B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH C: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH A: REPAIR OR REPLACE HARNESS OR CONNECTOR

When the seat memory M1 or M2 switch is pressed, the multiplex network door ECU front LH (driver door ECU) sends a memory switch status signal to the position control ECU (for driver side). Then the position control ECU sends the following to the door ECU front LH and RH: 1) a memory M1 or M2 memory recall signal, and 2) a driver and front passenger seat mirror position memory recall signal recorded in memory. When the door ECU front LH and RH receive the memory M1 or M2 memory recall signal, and then receive the driver and front passenger seat mirror position memory recall signal within 1.2 seconds, the door ECU front LH and RH activate the mirror control motors to move the mirrors to the previously recorded positions.

Scheme 11

1. CHECK SEAT MEMORY SWITCH FUNCTION (SEAT POSITION MEMORY FUNCTION) Check that the driver side seat can be moved using the driving position memory switch. OK: Driver side seat can be moved using driving position memory switch. NG: GO TO «FRONT POWER SEAT CONTROL SYSTEM»(ref-283167-S29051261962008041900000) OK: Go to Next step
2. CHECK SEAT MEMORY SWITCH FUNCTION (REGISTRATION OF SEAT MEMORY SWITCH) Check that the memory operation is properly completed. A buzzer sounds when the door mirror position and mirror facing direction are memorized. NOTE: If the SET, M1 and M2 switches are pressed simultaneously, the mirror facing direction will not be memorized. If the operation fails, the mirror facing direction will not be memorized until the SET switch is turned off. The mirror facing direction will not be memorized when the mirror is operated manually. OK: Driver side seat can be memorized using seat memory switch (for driver side). OK: NORMAL NG: Go to Next step
3. READ VALUE OF INTELLIGENT TESTER (SEAT MEMORY FUNCTION) Check the DATA LIST for proper functioning of the seat memory function. Position control ECU (for driver side) DATA LIST REFERENCE Item Measurement Item/ Range (Display) Normal Condition Diagnostic Note D-MIRR MEM M1 Driver side mirror position memorized in seat memory switch M1/ MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - D-MIRR MEM M2 Driver side mirror position memorized in seat memory switch M2/ MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - OK: On tester screen, each item changes between MEM and NOT MEM according to above chart. OK: REPLACE POSITION CONTROL ECU (for Driver Side) NG: Go to Next step
4. CHECK WIRE HARNESS (SEAT MEMORY SWITCH - MULTIPLEX NETWORK DOOR ECU FRONT LH [DRIVER DOOR ECU]) Disconnect the D20 switch connector. (Scheme 11): Identifying D20 Switch Connector Terminals Disconnect the D18 ECU connector. Measure the resistance of the wire harness side connectors. Standard resistance RESISTANCE REFERENCE Tester Connection Specified Condition D20-1 (E) - D18-23 (MSWE) Below 1 ohms D20-4 (M2) - D18-15 (M2) Below 1 ohms D20-3 (M1) - D18-16 (M1) Below 1 ohms D20-2 (MRY) - D18-24 (MM) Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH

When the seat memory M1 or M2 switch is pressed, the position control ECU (for driver side) memory's driver and front passenger seat mirror position signal is sent through the multiplex communication line to the multiplex network door ECU front LH and RH (driver and front passenger door ECU). The door ECU front LH and RH then activate the mirror control motors to move the mirrors to the previously recorded positions.

Scheme 12

Scheme 13

1. CHECK OUTER MIRROR SWITCH ASSEMBLY FUNCTION (POWER MIRROR CONTROL FUNCTION) Check that the outer rear view mirror LH and RH position can be moved using the outer mirror switch. OK: Outer rear view mirror LH and RH can be moved using outer mirror switch. NG: GO TO «PROBLEM SYMPTOMS TABLE»(ref-283198-S17339160922008041900000) OK: Go to Next step
2. CHECK SEAT MEMORY SWITCH FUNCTION (MIRROR MEMORY FUNCTION) Check that the outer rear view mirror LH and RH position can be memorized using the seat memory switch. OK: Outer rear view mirror LH and RH position can be memorized using seat memory switch. NG: GO TO POWER MIRROR DO NOT RETURN TO MEMORIZED POSITION OK: Go to Next step
3. CHECK SEAT MEMORY SWITCH FUNCTION (SEAT MEMORY FUNCTION) Check that the driver side seat can be moved using the seat memory switch. OK: Driver side seat can be moved using seat memory switch. NG: GO TO «FRONT POWER SEAT CONTROL SYSTEM»(ref-283167-S29051261962008041900000) OK: Go to Next step
4. READ VALUE OF INTELLIGENT TESTER (MIRROR POSITION SENSOR) Check the DATA LIST for proper functioning of the mirror position sensor. Multiplex network door ECU front LH, RH (driver, front passenger door ECU) DATA LIST SPECIFICATION Item Measurement Item/ Range (Display) Normal Condition Diagnostic Note MIR POS SEN V Vertical mirror position/ Min.: 0, Max.: 5 V Within range from 0 to 5 V - MIR POS SEN H Horizontal mirror position/ Min.: 0, Max.: 5 V Within range from 0 to 5 V - OK: Voltage output is as shown in above table. OK: Go to step 6 NG: Go to Next step
5. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH OR RH (MIRROR POSITION SENSOR) Disconnect the R14 or R15 mirror connector. Apply battery and dry cell battery voltage to the terminals shown in the table below. Measure the voltage while the mirror moves between the fully downward and fully upward positions. (Scheme 12): Inspecting Outer Rear View Mirror Assembly LH Or RH Standard voltage VOLTAGE SPECIFICATION Measurement Connection (Battery) Measurement Connection (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) rarr; Terminal 10 Battery negative (-) rarr; Terminal 1 Battery positive (+) rarr; Terminal 5 Battery negative (-) --> Terminal 14 Positive (+) lead rarr; Terminal 6 Negative (-) lead rarr; Terminal 14 Turns downward fully 2.8 to 5.0 V Battery positive (+) --> Terminal 1 Battery negative (-) --> Terminal 10 Battery positive (+) --> Terminal 5 Battery negative (-) --> Terminal 14 Positive (+) lead rarr; Terminal 6 Negative (-) lead rarr; Terminal 14 Turns upward fully 0 to 1.0 V Measure the voltage while the mirror moves between the fully left and fully right positions. (Scheme 13): Identifying Mirror Moves Between Fully Left And Fully Right Positions Standard voltage: for Driver side VOLTAGE SPECIFICATION Measurement Connection (Battery) Measurement Connection (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) rarr; Terminal 9 Battery negative (-) --> Terminal 10 Battery positive (+) --> Terminal 5 Battery negative (-) --> Terminal 14 Positive (+) lead rarr; Terminal 13 Negative (-) lead --> Terminal 14 Turns to left fully 2.8 to 5.0 V Battery positive (+) --> Terminal 10 Battery negative (-) rarr; Terminal 9 Battery positive (+) --> Terminal 5 Battery negative (-) --> Terminal 14 Positive (+) lead rarr; Terminal 13 Negative (-) lead rarr; Terminal 14 Turns to rightfully 0 to 1.0 V for Front passenger side VOLTAGE SPECIFICATION Measurement Connection (Battery) Measurement Connection (Dry Cell Battery) Voltmeter Condition Mirror Condition Specified Condition Battery positive (+) rarr; Terminal 9 Battery negative (-) rarr; Terminal 10 Battery positive (+) --> Terminal 5 Battery negative (-) --> Terminal 14 Positive (+) lead --> Terminal 13 Negative (-) lead --> Terminal 14 Turns to left fully 0 to 1.0 V Battery positive (+) rarr; Terminal 10 Battery negative (-) rarr; Terminal 9 Battery positive (+) rarr; Terminal 5 Battery negative (-) rarr; Terminal 14 Positive (+) lead --> Terminal 13 Negative (-) lead --> Terminal 14 Turns to right fully 2.8 to 5.0 V Result RESULT REFERENCE Result Proceed to Outer rear view mirror LH operates normally A Outer rear view mirror RH operates normally B Outer rear view mirror LH does not operate normally C Outer rear view mirror RH does not operate normally D B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) C: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH D: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH A: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU)
6. READ VALUE OF INTELLIGENT TESTER (MIRROR MEMORY POSITION, SHIFT LEVER POSITION, VEHICLE SPEED SENSOR) Check the DATA LIST for proper functioning of the mirror memory position, shift lever position and vehicle speed sensor. Position control ECU (for driver, front passenger side) DATA LIST REFERENCE Item Measurement Item/ Range (Display) Normal Condition Diagnostic Note D-MIR MEM POS 1 Driver side mirror position memorized in seat memory switch M1/ Min.: 0, Max.: 65535 Within range from 0 to 65535 - P-MIR MEM POS 1 Front passenger side mirror position memorized in seat memory switch M1/ Min.: 0, Max.: 65535 Within range from 0 to 65535 - D-MIR MEM POS 2 Driver side mirror position memorized in seat memory switch M2/ Min.: 0, Max.: 65535 Within range from 0 to 65535 - P-MIR MEM POS 2 Front passenger side mirror position memorized in seat memory switch M2/ Min.: 0, Max.: 65535 Within range from 0 to 65565 - PNPSW Shift lever position P signal/ ON or OFF ON: Shift lever on P OFF: Shift lever not on P - N SW Shift lever position N signal/ ON or OFF ON: Shift lever on N OFF: Shift lever not on N - VEHICLE SPD Vehicle speed / 0 to 255 km/h (159 mph) Actual vehicle speed - Result RESULT REFERENCE Result Proceed to Tester screen's data is within value ranges in above chart, and display changes between ON and OFF according to above chart (for driver side) A Tester screen's data is within value ranges in above chart, and display changes between ON and OFF according to above chart (for front passenger side) B Tester screen's data is not within value ranges in above chart, or display does not change between ON and OFF according to above chart (for driver side) C Tester screen's data is not within value ranges in above chart, or display does not change between ON and OFF according to above chart (for front passenger side) D B: REPLACE POSITION CONTROL ECU (for Front Passenger Side) C: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY LH D: REPLACE OUTER REAR VIEW MIRROR ASSEMBLY RH A: REPLACE POSITION CONTROL ECU (for Driver Side)

When the reverse signal is sent from the ECM through the multiplex communication line to the multiplex network door ECU front LH (driver door ECU), the ECU activates the outer rear view mirror LH and RH reverse shift-linked function.

HINT

The reverse shift-linked function will not occur when the mirror master switch is in the neutral position (OFF).
