HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use these procedures to troubleshoot the power mirror control system.
2. *: Use the intelligent tester.

1. VEHICLE BROUGHT TO WORKSHOP
2. INSPECT BATTERY VOLTAGE Standard voltage: 11 to 14 V If the voltage is below 11V, recharge or replace the battery before proceeding.
3. INSPECT COMMUNICATION FUNCTION OF MULTIPLEX COMMUNICATION SYSTEM (BEAN)* Use the intelligent tester to check if the Multiplex Communication System (MPX) is functioning normally. Result: RESULT REFERENCE Result Proceed to MPX DTC is not output A MPX DTC is output B B: GO to «MULTIPLEX COMMUNICATION SYSTEM»(ref-283178-S21998405322008041900000) A: Go to Next step
4. PROBLEM SYMPTOMS TABLE Result: RESULT REFERENCE Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B: Go to step 6 A: Go to Next step
5. OVERALL ANALYSIS AND TROUBLESHOOTING* (see «DATA LIST / ACTIVE TEST»(ref-283198-S28375920472008041900000) ) (see «TERMINALS OF ECU»(ref-283198-S09064362242008041900000) ) (see «ON-VEHICLE INSPECTION»(ref-283198-S26037309542008041900000) ) (see «INSPECTION»(ref-283198-S31172327842008041900000) )
6. REPAIR OR REPLACE
7. CONFIRMATION TEST NEXT: END

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the "Suspected area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to the system before inspecting the suspected areas below.

Power mirror control system

POWER MIRROR SYMPTOM REFERENCE

Scheme 14

Scheme 15

Scheme 16

1. CHECK MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU) (Scheme 14): Identifying ECU Connector Terminals Disconnect the D19 ECU connector. Measure the voltage and resistance of the wire harness side connector. CONNECTOR SPECIFICATION Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (D19-1) - Body ground W-B - Body ground Ground Always Below 1 ohms CPUB (D19-4) - GND (D19-1) L-O - W-B Battery (ECU power source) Always 10 to 14 V SIG (D19-5) - GND (D19-1) V-W - W-B Ignition power supply Ignition switch OFF Below 1 V SIG (D19-5) - GND (D19-1) V-W - W-B Ignition power supply Ignition switch ON 10 to 14 V BDR (D19-6) - GND (D19-1) B-R - W-B Battery (ECU power source) Always 10 to 14 V HTR- (D19-22) - GND (D19-1) W-B - W-B Mirror defogger switch signal Always Below 1 ohms HTR+ (D19-13) - GND (D19-1) R-W - W-B Mirror defogger switch signal Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the D19 ECU connector. Measure the voltage of the connector. VOLTAGE CHART Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition MR+* (D19-7) - Body ground Y - Body ground Mirror retract switch signal Mirror retract switch ON (Outer rear view mirror LH is retracting) 10 to 14 V MR-* (D19-18) - GND (D19-1) V - W-B Mirror retract switch signal Mirror retract switch OFF (Outer rear view mirror LH is returning) 10 to 14 V PM+R (D19-20) - GND (D19-1) R-B - W-B Mirror master switch signal (RIGHT and DOWN) Mirror master switch LEFT, Mirror control switch OFF 10 to 14 V PM+R (D19-20) - GND (D19-1) R-B - W-B Mirror master switch signal (RIGHT and DOWN) Mirror master switch LEFT, Mirror control switch DOWN and RIGHT Below 1 V DMHR (D19-19) - GND (D19-1) LG - W-B Mirror master switch signal (LEFT and DOWN) Mirror master switch LEFT, Mirror control switch OFF 10 to 14 V DMHR (D19-19) - GND (D19-1) LG - W-B Mirror master switch signal (LEFT and DOWN) Mirror master switch LEFT, Mirror control switch DOWN and LEFT Below 1 V DMVR (D19-8) - GND (D19-1) LG-B - W-B Mirror control switch signal (UP and RIGHT) Mirror master switch LEFT, Mirror control switch OFF 10 to 14 V DMVR (D19-8) - GND (D19-1) LG-B - W-B Mirror control switch signal (UP and RIGHT) Mirror master switch LEFT, Mirror control switch UP and RIGHT Below 1 V EC+ (D19-15) - GND (D19-1) O - W-B Mirror EC signal Electrochromatic mirror system is operating 10 to 14 V EC+ (D19-15) - GND (D19-1) O - W-B Mirror EC signal Electrochromatic mirror system is not operating Below 1 V HSSR (D19-26) - GND (D19-1) GR - W-B Horizontal direction position signal Mirror master switch LEFT Mirror control switch OFF 10 to 14 V HSSR (D19-26) - GND (D19-1) GR - W-B Horizontal direction position signal Mirror master switch LEFT Mirror control switch RIGHT and LEFT Below 1 V DE2 (D19-25) - GND (D19-1) R - W-B Power source for mirror position sensor Ignition switch ACC or OFF during sleep mode 4.8 to 5.2 V DE2 (D19-25) - GND (D19-1) R-W-B Power source for mirror position sensor Ignition switch ON Below 1 V VSSR (D19-16) - GND (D19-1) G-O - W-B Vertical direction position signal Mirror master switch LEFT Mirror control switch OFF 10 to 14 V VSSR (D19-16) - GND (D19-1) G-O - W-B Vertical direction position signal Mirror master switch LEFT Mirror control switch UP and DOWN Below 1 V HINT: *: w/ Retractable Mirror If the result is not as specified, the ECU may have a malfunction.
2. CHECK MULTIPLEX NETWORK DOOR ECU FRONT RH (PASSENGER DOOR ECU) (Scheme 15): Identifying Passenger Door ECU Connector Terminals Disconnect the P11 ECU connector. Measure the voltage and resistance of the wire harness side connector. VOLTAGE CHART Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (P11-1) - Body ground W-B - Body ground Ground Always Below 1 ohms CPUB (P11-4) - GND (P11-1) L-O - W-B Battery (ECU power source) Always 10 to 14 V SIG (P11-5) - GND (P11-1) V-W - W-B Ignition power supply Ignition switch OFF Below 1 V SIG (P11-5) - GND (P11-1) V-W - W-B Ignition power supply Ignition switch ON 10 to 14 V BDR (P11-6) - GND (P11-1) G-Y - W-B Battery (ECU power source) Always 10 to 14 V HTR- (P11-22) - GND (P11-1) W-B - W-B Mirror defogger switch signal Always Below 1 ohms HTR+ (P11-13) - GND (P11-1) R-W - W-B Mirror defogger switch signal Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the P11 ECU connector. Measure the voltage of the connector. VOLTAGE CHART Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition MR+* (P11-7) - Body ground Y - Body ground Mirror retract switch signal Mirror retract switch ON (Outer rear view mirror RH is retracting) 10 to 14 V MR-* (P11-18)-GND (P11-1) V - W-B Mirror retract switch signal Mirror retract switch OFF (Outer rear view mirror RH is returning) 10 to 14 V DM+R (P11-20) - GND (P11-1) R-B - W-B Mirror master switch signal (RIGHT and DOWN) Mirror master switch RIGHT, Mirror control switch OFF 10 to 14 V PM+R (P11-20) - GND (P11-1) R-B - W-B Mirror master switch signal (RIGHT and DOWN) Mirror master switch RIGHT, Mirror control switch DOWN and RIGHT Below 1 V PMHR (P11-19) - GND (P11-1) LG - W-B Mirror master switch signal (LEFT and DOWN) Mirror master switch RIGHT, Mirror control switch OFF 10 to 14 V PMHR (P11-19) - GND (P11-1) LG - W-B Mirror master switch signal (LEFT and DOWN) Mirror master switch RIGHT, Mirror control switch DOWN and LEFT Below 1 V PMVR (P11-8) - GND (P11-1) G-B - W-B Mirror control switch signal (UP and RIGHT) Mirror master switch RIGHT, Mirror control switch OFF 10 to 14 V PMVR (P11-8) - GND (P11-1) G-B - W-B Mirror control switch signal (UP and RIGHT) Mirror master switch RIGHT, Mirror control switch UP and RIGHT Below 1 V EC+ (P11-15) - GND (P11-1) O - W-B Mirror EC signal Electrochromatic mirror system is operating 10 to 14 V EC+ (P11-15) - GND (P11-1) O - W-B Mirror EC signal Electrochromatic mirror system is not operating Below 1 V HSSR (P11-26) - GND (P11-1) GR - W-B Horizontal direction position signal Mirror master switch RIGHT, Mirror control switch OFF 10 to 14 V HSSR (P11-26) - GND (P11-1) GR - W-B Horizontal direction position signal Mirror master switch RIGHT, Mirror control switch RIGHT and LEFT Below 1 V PE2 (P11-25) - GND (P11-1) P-L - W-B Power source for mirror position sensor Ignition switch ACC or OFF during sleep mode 4.8 to 5.2 V PE2 (P11-25) - GND (P11-1) P-L - W-B Power source for mirror position sensor Ignition switch ON Below 1 V VSSR (P11-16) - GND (P11-1) G-O - W-B Vertical direction position signal Mirror master switch RIGHT, Mirror control switch OFF 10 to 14 V VSSR (P11-16) - GND (P11-1) G-O - W-B Vertical direction position signal Mirror master switch RIGHT, Mirror control switch UP and DOWN Below 1 V HINT: *: w/ Retractable Mirror If the result is not as specified, the ECU may have a malfunction.
3. CHECK DRIVER SIDE JUNCTION BLOCK (DRIVER SIDE JUNCTION BLOCK ECU) (Scheme 16): Identifying Driver Side Junction Block ECU Connector Terminals Disconnect the D4 and D5 junction block connectors. Measure the voltage and resistance of the wire harness side connectors. VOLTAGE CHART Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition MPX-B (D4-5) - GND2 (D3-1) L-B - W-B Power supply Always Below 1 ohms R/E (D5-7) - Body ground LG - Body ground Ground Always Below 1 ohms RET* (D5-8) - GND2 (D4-1) GR - W-B Mirror retract switch signal Mirror retract switch OFF Below 1 V RET* (D5-8) - GND2 (D4-1) GR - W-B Mirror retract switch signal Mirror retract switch RETRACT 10 to 14 V MSW (D5-10) - R/E (D5-8) R-LG Mirror master switch signal (LEFT and RIGHT) Mirror master switch OFF Below 1 V MSW (D5-10) - R/E (D5-8) R-LG Mirror master switch signal (LEFT and RIGHT) Mirror master switch LEFT or RIGHT 0 to 5 V M+ (D5-11) - R/E (D5-8) R-B - LG Mirror control switch signal (UP, DOWN, LEFT and RIGHT) Mirror LEFT / RIGHT adjustment switch on neutral position Below 1 V M+ (D5-11) - R/E (D5-8) R-B - LG Mirror control switch signal (UP, DOWN, LEFT and RIGHT) Mirror LEFT / RIGHT adjustment switch on each position 0 to 5 V HINT: *: w/ Retractable Mirror If the result is not as specified, there may be a malfunction on the wire harness side.

Scheme 17

Scheme 18

1. DESCRIPTION The power mirror control system data and the Diagnostic Trouble Codes (DTCs) can be read through the Data Link Connector 3 (DLC3) of the vehicle. When the system seems to be malfunctioning, use the intelligent tester to check for malfunctions and perform repairs.
2. CHECK DLC3 The vehicle uses ISO 15765-4 communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format. (Scheme 17): Identifying DLC3 Connector Terminal TERMINAL SPECIFICATION Symbols (Terminals No.) Terminal Description Condition Specified condition SIL (7) - SG (5) Bus "+" line During transmission Pulse generation CG (4) - Body ground Chassis ground Always Below 1 ohms SG (5) - Body ground Signal ground Always Below 1 ohms BAT (16) - Body ground Battery positive Always 11 to 14 V If the result is not as specified, the DLC3 may have a malfunction. Repair or replace the harness and connector. HINT: Connect the cable of the intelligent tester (with CAN VIM) to the DLC3, turn the ignition switch ON and attempt to use the tester. If the screen displays the message UNABLE TO CONNECT TO VEHICLE, there is a problem either with the vehicle or with the tester. (Scheme 18): Connecting Cable Of Intelligent Tester To DLC3 If communication is normal when the tester is connected to another vehicle, inspect the DLC3 of the original vehicle. If communication is still not possible when the tester is connected to another vehicle, the problem is probably in the tester itself. Consult the Service Department listed in the tester's instruction manual.

DATA LIST / ACTIVE TEST

1. READ DATA LIST HINT: Using the intelligent tester's DATA LIST allows switch, sensor, actuator and other item values to be read without removing any parts. Reading the DATA LIST early in troubleshooting is one way to save time. Connect the intelligent tester to the DLC3. Turn the ignition switch ON. Read the DATA LIST. Multiplex network door ECU front LH (driver door ECU): DATA LIST REFERENCE Item Measurement Item / Range (Display) Normal Condition Diagnostic Note MIR POS SEN V Vertical mirror position I Min.: 0, Max.: 5 V Within range from 0 to 5 V - MIR POS SEN H Horizontal mirror position / Min.: 0, Max.: 5 V Within range from 0 to 5 V - Multiplex network door ECU front RH (front passenger door ECU): DATA LIST REFERENCE Item Measurement Item / Range (Display) Normal Condition Diagnostic Note MIR POS SEN V Vertical mirror position / Min.: 0, Max.: 5 V Within range from 0 to 5 V - MIR POS SEN H Horizontal mirror position / Min.: 0, Max.: 5 V Within range from 0 to 5 V - Driver side junction block ECU: DATA LIST REFERENCE Item Measurement Item / Range (Display) Normal Condition Diagnostic Note MIRR SEL SW R Mirror selection switch signal for RH mirror / ON or OFF ON: Switch is in R position OFF: Switch is in neutral or L position - MIRR SEL SW L Mirror selection switch signal for LH mirror / ON or OFF ON: Switch is in L position OFF: Switch is in neutral or R position - MIRR POS SW R Mirror position switch signal (RIGHT) / ON or OFF ON: RIGHT switch is ON OFF: Any switch except RIGHT is ON or all switches are OFF - MIRR POS SW L Mirror position switch signal (LEFT)/ ON or OFF ON: LEFT switch is ON OFF: Any switch except LEFT is ON or all switches are OFF - MIRR POS SW UP Mirror position switch signal (UP) / ON or OFF ON: UP switch is ON OFF: Any switch except UP is ON or all switches are OFF - MIRR POS SW DWN Mirror position switch signal (DOWN) / ON or OFF ON: DOWN switch is ON OFF: Any switch except DOWN is ON or all switches are OFF - MIRR FOLD SW* Mirror retract signal / ON or OFF ON: Switch is ON OFF: Switch is OFF - MIRR RETRN SW* Mirror return signal / ON or OFF ON: Switch is OFF OFF: Switch is ON - HINT: *: w/ Retractable Mirror Position control ECU (for driver side): DATA LIST REFERENCE Item Measurement Item / Range (Display) Normal Condition Diagnostic Note POWER VOLTAGE Power supply for position control ECU & switch / Min.: 0, Max.: 19.89 V Within range from 10 to 14 V - VEHICLE SPD Vehicle speed / 0 to 255 km/h (159 mph) Actual vehicle speed - IG SW Ignition switch status / ON or OFF ON: Ignition switch is ON OFF: Ignition switch is OFF - KEY UNLOCK SW Key unlock warning switch signal / ON or OFF ON: Key is in ignition key cylinder OFF: Key is not in ignition key cylinder - D-DOOR WARN SW Door courtesy switch signal / ON or OFF ON: Driver side door is open OFF: Driver side door is closed - PNP SW Shift lever position P signal / ON or OFF ON: Shift lever on P OFF: Shift lever not on P - N SW Shift lever position N signal / ON or OFF ON: Shift lever on N OFF: Shift lever not on N - M2SW Seat memory switch M2 signal / ON or OFF ON: Seat memory switch M2 is ON OFF: Seat memory switch M2 is OFF - M1 SW Seat memory switch M1 signal / ON or OFF ON: Seat memory switch M1 is ON OFF: Seat memory switch M1 is OFF - SET SW Seat memory set switch signal / ON or OFF ON: Memory set switch is ON OFF: Memory set switch is OFF - MEM M1 SW Driving position memorized in seat memory switch M1 / MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - MEM M2 SW Driving position memorized in seat memory switch M2 / MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - D-MIRR MEM M1 Driver side mirror position memorized in seat memory switch M1 / MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - D-MIRR MEM M2 Driver side mirror position memorized in seat memory switch M2 / MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - P-MIRR MEM M1 Front passenger side mirror position memorized in seat memory switch M1 / MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - P-MIRR MEM M2 Front passenger side mirror position memorized in seat memory switch M2 / MEM or NOT MEM MEM: Memorized NOT MEM: Not memorized - D-MIR MEM POS 1 Driver side mirror position memorized in seat memory switch M1 / Min.: 0, Max.: 65535 Within range from 0 to 65535 - P-MIR MEM POS 1 Front passenger side mirror position memorized in seat memory switch M1 / Min.: 0, Max.: 65535 Within range from 0 to 65535 - D-MIR MEM POS 2 Driver side mirror position memorized in seat memory switch M2 / Min.: 0, Max.: 65535 Within range from 0 to 65535 - P-MIR MEM POS 2 Front passenger side mirror position memorized in seat memory switch M2 / Min.: 0, Max.: 65535 Within range from 0 to 65535
2. PERFORM ACTIVE TEST HINT: Performing the intelligent tester's ACTIVE TEST allows relay, VSV, actuator and other items to be operated without removing any parts. Performing the ACTIVE TEST early in the troubleshooting is one way to save time. The DATA LIST can be displayed during the ACTIVE TEST. Connect the intelligent tester to the DLC3. Turn the ignition switch ON. Perform the ACTIVE TEST by following the directions on the tester screen. Multiplex network door ECU front LH (driver door ECU): DATA LIST REFERENCE Item Test Details Diagnostic Note MIR HEATER Mirror defogger operation OFF/ON - MIR FOLD / RETRN* Mirror retract operation FOLD / RETRN - MIR RIGHT / LEFT Mirror horizontal operation RIGHT / LEFT - MIR UP / DOWN Mirror vertical operation UP / DOWN - HINT: *: w/ Retractable Mirror Multiplex network door ECU front RH (front passenger door ECU): DATA LIST REFERENCE Item Test Details Diagnostic Note MIR HEATER Mirror defogger operation OFF/ON - MIR FOLD / RETRN* Mirror retract operation FOLD / RETRN - MIR RIGHT / LEFT Mirror horizontal operation RIGHT / LEFT - MIR UP / DOWN Mirror vertical operation UP / DOWN - HINT: *: w/ Retractable Mirror

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. CHECK MEMORY AND REACTIVATION FUNCTION Procedure "A": Turn the ignition switch ON and move the shift lever to the P position. Procedure "B": Check the seat memory (for driver side) M1 switch. Step 1: Using the outer mirror switch, move the mirror as much as possible to the left. Step 2: Press and hold down switches M1 and SET. Check that the buzzer sounds for 0.5 seconds, signaling that the outer mirror position has been recorded. Step 3: Change the position of the outer mirror and then press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the position in Procedure "B" - step 1. Procedure "C": Check the M2 switch. Step 1: Using the outer mirror switch, move the mirror as much as possible to the right. Step 2: Press and hold down switches M2 and SET. Check that the buzzer sounds for 0.5 seconds, signaling that the outer mirror position has been recorded. Step 3: Change the position of the outer mirror and then press the M2 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the position in Procedure "C" - step 1. (Scheme 19): Checking Memory And Reactivation Function Procedure "D": When the outer mirror is in the driving position: Check that switches M1 and M2 cause the outer mirror to move to the recorded outer mirror positions under these conditions: turn the ignition switch OFF, remove the key from the key cylinder, open the driver side door and press M1 or M2 within 30 seconds. Procedure "E": Check that the following procedures will erase the recorded outer mirror positions of switches M1 and M2: press and hold the power seat slide switch; disconnect the cable from the negative (-) battery terminal; and wait for at least 1 minute. Procedure "F": Check that the outer mirror position is not memorized when the M1, M2 and SET switches are pressed and held simultaneously.
2. CHECK ELECTRICALLY-RETRACTABLE DOOR MIRROR (W/ RETRACTABLE MIRROR) Turn the ignition switch to ACC. At each position of the outer mirror body, check the operation when operating the retract switch of the outer mirror. Change the retract switch from the (A) to the (B) position. Check that the right and left mirrors move from the driving position to the retracted position. (Scheme 20): Identifying Outer Mirror Body Switch Position Move one of the mirrors to the forward position by hand. Change the retract switch from the (A) to the (B) position. Check that the mirror moves from the forward position to the retracted position. Check that the other mirror moves from the driving position to the retracted position. (Scheme 21): Identifying Outer Mirror Body Switch Position Move one of the mirrors to the retracted position by hand. Change the retract switch from the (A) to the (B) position. Check that the other mirror moves from the driving position to the retracted position. (Scheme 22): Identifying Outer Mirror Body Switch Position Change the retract switch from the (B) to the (A) position. Check that the right and left mirrors move from the retracted position to the driving position. (Scheme 23): Identifying Outer Mirror Body Switch Position Move one of the mirrors to the driving position by hand. Change the retract switch from the (B) to the (A) position. Check that the other mirror moves from the retracted position to the driving position. (Scheme 24): Identifying Outer Mirror Body Switch Position Check the operation of the outer mirror body in relation to retract switch operations and ignition switch position change. When the mirror body is operating, turn the ignition switch OFF. Check that the mirror operation does not stop and continues until the operation has finished. Repeat the step above. This time, before the mirror operation completes, turn the ignition switch to ACC and press the retract switch. Check that the mirror operates in the opposite direction. Check the operation of the outer mirror body when it is restrained by an obstacle. Step 1: When the mirror body is moving to the retracted or driving position, restrain the mirror body by hand. Check that the mirror body movement stops. Step 2: With the mirror body stopped partway in step 1, push the retract switch. Check that the mirror body moves in the opposite direction it was moving in step 1.
3. CHECK REVERSE-SHIFT-LINKED OPERATION OF MIRRORS Turn the ignition switch ON. Set the mirror master switch to L or R. Check that the mirror faces downward when the shift lever is moved to R. When the shift lever is not on P, or the mirror master switch is in the neutral position (OFF), check that the outer rear view mirror returns to the driving position. (Scheme 25): Identifying Mirror Master Switch

INSPECTION PROCEDURE

1. CHECK OUTER MIRROR SWITCH ASSEMBLY FUNCTION (POWER MIRROR CONTROL FUNCTION) Check that the outer rear view mirror LH and RH can be moved using the outer mirror switch. OK: Outer rear view mirror LH and RH can be moved using outer mirror switch. NG: GO TO «PROBLEM SYMPTOMS TABLE»(ref-283198-S17339160922008041900000) OK: Go to Next step
2. CHECK OPERATION OF SHIFT INDICATOR Check that the shift indicator of the combination meter operates normally. OK: Shift indicator of combination meter operates normally. NG: GO TO «COMBINATION METER»(ref-283180-S32187046362008041900000) OK: Go to Next step
3. CHECK SEAT MEMORY SWITCH FUNCTION (MIRROR MEMORY FUNCTION) Check that the outer rear view mirror LH and RH can be memorized using the seat memory switch. Result: RESULT REFERENCE Result Proceed to Outer rear view mirror LH does not operate normally A Outer rear view mirror RH does not operate normally A Outer rear view mirror LH operates normally B Outer rear view mirror RH operates normally C B: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT LH (DRIVER DOOR ECU) C: REPLACE MULTIPLEX NETWORK DOOR ECU FRONT RH (FRONT PASSENGER DOOR ECU) A: GO TO «PROBLEM SYMPTOMS TABLE»(ref-283198-S17339160922008041900000)

Scheme 26

Scheme 27

1. REMOVE MAP LIGHT ASSEMBLY
2. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER Using a screwdriver, remove the holder cover. HINT: Tape the screwdriver tip before use. (Scheme 26): Identifying Inner Rear View Mirror Stay Holder Cover
3. REMOVE INNER REAR VIEW MIRROR ASSEMBLY Disconnect the mirror connector. Remove the mirror by turning the stay part of the mirror counterclockwise. (Scheme 27): Removing Inner Rear View Mirror Assembly

Scheme 28

1. INSPECT INNER REAR VIEW MIRROR ASSEMBLY Inspect the operation of the electronic inner mirror. Connect the battery's positive (+) lead to terminal 6 (IG) and the negative (-) lead to terminal 3 (GND). Attach black colored tape to the forward sensor to block it. Light up the mirror with an electric light, and check that the mirror surface changes from bright to dark. HINT: When the environment is very bright, the antiglare operation may occur immediately after the tape is applied. If the result is not as specified, replace the mirror assembly. (Scheme 28): Inspecting Operation Of Electronic Inner Mirror

Scheme 29

Scheme 30

1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY Match the claw of the stay part of the mirror with the cut part of the base. Turn the stay part of the mirror clockwise so that the stay comes to the original position, and then install the mirror. Connect the mirror connector. (Scheme 29): Installing Inner Rear View Mirror Assembly
2. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER Install the cover. (Scheme 30): Identifying Inner Rear View Mirror Stay Holder Cover
